Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: C15-21996
Brand: Eaton
MPN: JDC3090
UPC: 78667902667
Shipping Weight: 0.00 lbs.
Shipping Height: 0.00 In.
Shipping Length: 0.00 In.
Shipping Width: 0.00 In.
Product Notes:
Long Description: Eaton JDC3090 Molded Case Breakers (MCCBs)
Specifications
Number of Poles: |
3 |
Type: |
Thermal Magnetic, Ultra High Interrupting Capacity, Molded Case |
Current Rating: |
90 A |
Voltage Rating: |
600 VAC 50/60 Hertz, 250 VDC |
Terminal Type: |
Aluminum Line and Load |
Maximum AC Voltage Rating: |
600 V |
Interrupting Rating: |
200 kA at 240 VAC, 100 kA at 480 VAC, 35 kA at 600 VAC, 22 kA at 250 VDC (UL), 200 kA at 240 VAC, 100 kA at 380/415 VAC, 22 kA at 250 VDC (IEC) |
Catalog: |
|
CAD Drawings: |
|
Size: |
4.13 Inch Width x 4.06 Inch Depth x 10 Inch Height |
Approval: |
UL 489, CSA C22.2 |
Maximum DC Voltage Rating: |
250 V |
Frame Type: |
JD |
