Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: C15-22154
Brand: Eaton
MPN: LD3300
UPC: 78667902648
Shipping Weight: 0.00 lbs.
Shipping Height: 0.00 In.
Shipping Length: 0.00 In.
Shipping Width: 0.00 In.
Product Notes:
Long Description: Eaton LD3300 Molded Case Breakers (MCCBs)
Specifications
Number of Poles: |
3 |
Interrupting Rating: |
65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at 600 VAC, 22 kA at 250 VDC (UL), 85 kA at 240 VAC, 45 kA at 415 VAC, 20 kA at 690 VAC/250 VDC (IEC) |
Voltage Rating: |
600 VAC 50/60 Hertz, 250 VDC |
Type: |
Thermal Magnetic, Standard Interrupting Capacity, Molded Case |
Terminal Type: |
Aluminum Line and Load |
Current Rating: |
300 A |
Approval: |
UL 489, CSA C22.2, CE |
Maximum AC Voltage Rating: |
600 V |
Frame Type: |
LD |
Catalog: |
|
Size: |
8.25 Inch Width x 4.06 Inch Depth x 10.75 Inch Height |
Maximum DC Voltage Rating: |
250 V |
Installation/Operator: |
