Square D
Square D QOU110 Miniature Circuit Breakers (MCBs)
- MPN:
- QOU110
- SKU:
- C15-6671
Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: C15-6671
Brand: Square D
MPN: QOU110
UPC:
Shipping Weight: 0.00 lbs.
Shipping Height: 0.00 In.
Shipping Length: 0.00 In.
Shipping Width: 0.00 In.
Product Notes:
Long Description: Square D QOU110 Miniature Circuit Breakers (MCBs)
Specifications
Current Rating: |
10 A |
Series: |
QOU |
Size: |
0.75 Inch Width x 2.95 Inch Depth x 4.05 Inch Height |
Number of Poles: |
1 |
Wire Size: |
14 to 2 AWG (Copper/Aluminum) |
Mounting: |
DIN Rail/Unit/Surface/Flush |
Catalog: |
|
CAD Drawings: |
|
Terminal Type: |
Slotted Box Lug Line/Load |
Data Sheet: |
|
Voltage Rating: |
120/240 VAC 50/60 Hertz, 48 VDC |
Used On: |
OEM |
Type: |
Miniature, Standard |
Installation/Operator: |
|
Interrupting Rating: |
10 kA |
TS PIK: |
21356075 |
Approval: |
UL, CSA |
