Circuit Breakers
Our selection of circuit breakers spans a wide range of applications, from heavy-duty air circuit breakers (ACBs) to compact miniature circuit breakers (MCBs). We offer leading brands like Eaton, Siemens, and Square D, known for their reliability and performance. Whatever your power management needs, you can find the perfect solution here at ARCA Supply.
-
Din Rail Mounted Circuit Breakers
-
Main Breakers
-
Miniature Circuit Breakers (MCBs)
-
Molded Case Breakers (MCCBs)
-
Motor Circuit Protector (MCPs)
-
Lug Terminal Kits
-
Auxiliary, Shunt, Trip Units and UVRs
-
Circuit Breaker Accessories
- Product
- Qty in Cart
- Price
-
Siemens ED43S100A Molded Case Breakers (MCCBs)
MSRP $2,310.00Surplus $507.00SKU: E30-11696 Brand: Siemens MPN: ED43S100A UPC: 78364321103 Shipping Weight: 3.70 lbs. Shipping Height: 6.00 In. Shipping Length: 7.00 In. Shipping Width: 4.00 In...- SKU:
- E30-11696
- TS PIK:
- 126673849
- Series:
- ED4
- Interrupting Rating:
- 18 kA at 480 VAC (UL)
- Catalog:
- SiemensAG_01698_17_78_17_114_CAT.pdf
- Short Description:
- 480 VAC 50/60 Hz, 100 A, 1000 A Self-Protective Instantaneous Override, 3-Pole, 10 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker Switch
- Installation/Operator:
- SiemensAG_00313_INST.pdf
- Terminal Type:
- Load Lug
- Type:
- Molded Case Switch
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Size:
- 3 Inch W x 4.56 Inch D x 6.35 Inch H
- Voltage Rating:
- 480 VAC at 50/60 Hz, 500 VDC (UL)
- Country of Origin:
- Mexico
- Wire Size:
- 10 to 1/0 AWG (Copper/Aluminum)
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Mounting:
- Plug-On
- Approval:
- UL 489, CSA C22.2
MSRP $2,310.00Surplus $507.00 -
Siemens ED63B100 Molded Case Breakers (MCCBs) 3P 100A 600V
MSRP $2,777.00Surplus $798.00SKU: C15-7431 Brand: Siemens MPN: ED63B100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7431
- TS PIK:
- 115676275
- Country of Origin:
- Mexico
- Frame Type:
- ED
- Short Description:
- 600 VAC 50/60 Hz, 500 VDC, 100 A, 18/25 kA, 3-Pole, 10 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker
- Voltage Rating:
- 600 VAC, 500 VDC
- Type:
- Thermal Magnetic
- Series:
- ED6
- Number of Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC (UL 489), 25 kA at 480 VAC (UL 489), 18 kA at 600 VAC/500 VDC (UL 489), 65/17 kA at 220/240 VAC (IEC), 35/9 kA at 380/415 VAC (IEC), 18/5 kA at 500 VAC (IEC)
- Catalog:
- SiemensAG_01698_17_78-17_80_CAT.pdf
- Terminal Type:
- Load Lug
- Size:
- 3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height
- Current Rating:
- 100 A
- Installation/Operator:
- SiemensAG_00313_INST.pdf
- Approval:
- UL 489, IEC
MSRP $2,777.00Surplus $798.00 -
Contact Us For Quote
Siemens ED63S100A Miniature Circuit Breakers (MCBs)
MSRP $2,364.00Surplus $638.28SKU: C15-18991 Brand: Siemens MPN: ED63S100A UPC: 78364321105 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18991
- Country of Origin:
- MEX
- Series:
- ED6
- Number of Poles:
- 3
- Type:
- Molded Case Switch
- Short Description:
- 600 VAC 50/60 Hz, 100 A, 1000 A Self-Protective Instantaneous Override, 3-Pole, 10 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker Switch
- Mounting:
- Plug-On
- Current Rating:
- 100 A
- Interrupting Rating:
- 18 kA at 600 VAC/500 VDC (UL)
- Voltage Rating:
- 600 VAC at 50/60 Hz, 500 VDC
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Wire Size:
- 10 to 1/0 AWG (Copper/Aluminum)
- Catalog:
- SiemensAG_01698_17_78_17_114_CAT.pdf
- Terminal Type:
- Load Lug
- Size:
- 3 Inch W x 4 Inch D x 6.34 Inch H
- Approval:
- UL, CSA, CE, IEC
- Installation/Operator:
- SiemensAG_00313_INST.pdf
MSRP $2,364.00Surplus $638.28 -
Contact Us For Quote
Siemens EQ8681 Molded Case Breakers (MCCBs)
MSRP $132.00Surplus $35.64SKU: C15-16013 Brand: Siemens MPN: EQ8681 UPC: 78364338788 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16013
- Series:
- EQ
- Short Description:
- 100 A, 22 kA, Plug-On Mount, EQ Frame, Thermal Magnetic, Main Circuit Breaker Kit for Load Center
- Voltage Rating:
- 120/240 VAC
- Wire Size:
- 4 AWG to 300 KCMIL (Copper/Aluminum)
- Mounting:
- Bolt-On
- Data Sheet:
- SiemensAG_05853_1_DATA.pdf
- Used On:
- Loadcenter
- Current Rating:
- 100 A
- Interrupting Rating:
- 22 kA
- Installation/Operator:
- SiemensAG_00316_INST.pdf
- Country of Origin:
- MEX
- Catalog:
- SiemensAG_01808_1_40-1_42_CAT.pdf
- Approval:
- UL
MSRP $132.00Surplus $35.64 -
Siemens FD63T100 Molded Case Breakers (MCCBs)
MSRP $3,422.00Surplus $771.40SKU: C15-8764 Brand: Siemens MPN: FD63T100 UPC: 78364321192 Shipping Weight: 1.25 lbs. Shipping Height: 4.00 In. Shipping Length: 5.00 In. Shipping Width: 5.00 In...- SKU:
- C15-8764
- TS PIK:
- 21334182
- Number of Poles:
- 3
- Installation/Operator:
- SiemensAG_00224_INST.pdf
- Catalog:
- SiemensAG_01698_17_78_17_82_17_83_CAT.pdf
- Type:
- Interchangeable Trip, Thermal Magnetic
- Short Description:
- 600 VAC, 500 VDC, 100 A, 25/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, FD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit
- Series:
- FD6-A
- Frame Type:
- FD
- Current Rating:
- 100 A
- Country of Origin:
- Mexico
- Approval:
- UL 489
- Adjustment:
- Thermal Magnetic Trip
MSRP $3,422.00Surplus $771.40 -
Contact Us For Quote
Siemens FXD62B100 Molded Case Breakers (MCCBs)
MSRP $7,081.00Surplus $1,271.20SKU: C15-10401 Brand: Siemens MPN: FXD62B100 UPC: 78364321111 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10401
- TS PIK:
- 21367512
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Series:
- FXD6-A
- Number of Poles:
- 2
- Country of Origin:
- MEX
- Current Rating:
- 100 A
- Terminal Type:
- Not Included
- Frame Type:
- FD
- Size:
- 4.5 Inch W x 5.25 Inch D x 9.5 Inch H
- Catalog:
- SiemensAG_01698_17_78_17_82_17_111_CAT.pdf
- Interrupting Rating:
- 22 kA at 600 VAC, 30 kA at 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35 kA at 480 VAC, 2-Pole, FD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 600 V
- Type:
- Molded Case, Thermal Magnetic
- Approval:
- UL, CSA, IEC
- Installation/Operator:
- SiemensAG_00224_INST.pdf
MSRP $7,081.00Surplus $1,271.20 -
Contact Us For Quote
Siemens HB3B100 Molded Case Breakers (MCCBs)
MSRP $2,145.00Surplus $579.15SKU: C15-16388 Brand: Siemens MPN: HB3B100 UPC: 78364311133 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16388
- Voltage Rating:
- 240 VAC
- Data Sheet:
- SiemensAG_09574_1_2_DATA.pdf
- Catalog:
- SiemensAG_09175_17_8_17_9_CAT.pdf
- Terminal Type:
- Load Lug
- Size:
- 3 Inch Width x 3 Inch Depth x 4 Inch Height
- Maximum AC Voltage Rating:
- 240 V
- Current Rating:
- 100 A
- Country of Origin:
- MEX
- Interrupting Rating:
- 65 kA at 240 VAC
- Number of Poles:
- 3
- Type:
- Molded Case, Low Vage, Common Trip, Circuit Protector
- Approval:
- UL 489
- Short Description:
- BRKR HBQ 3P 240V 100A 65K
MSRP $2,145.00Surplus $579.15 -
Contact Us For Quote
Siemens HEB3B100B Miniature Circuit Breakers (MCBs) 3P 100A 480V
MSRP $13,253.00Surplus $2,394.00SKU: C15-7390 Brand: Siemens MPN: HEB3B100B UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7390
- TS PIK:
- 115675920
- Country of Origin:
- DOM
- Short Description:
- 600 VAC Star/347 VAC, 100 A, 65 kA, 3-Pole, Molded Case, Thermal Magnetic, Panelboard Circuit Breaker
- Interrupting Rating:
- 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 Star/347 VAC, 42 kA at 125/250 VDC (UL/CSA), 100 kA at 240 VAC, 70 kA at 415 VAC, 42 kA at 125/250 VDC (IEC)
- Number of Poles:
- 3
- Series:
- HEB
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Current Rating:
- 100 A
- Type:
- Molded Case, Thermal and Fixed Magnetic
- Application:
- Lighting, Distribution
- Voltage Rating:
- 240/480 VAC, 600 Star/347 VAC at 50/60 Hz, 125/250 VDC (UL/CSA), 240/415 VAC at 50/60 Hz, 125/250 VDC (IEC)
- Approval:
- UL 489, CSA, IEC 60947-2
MSRP $13,253.00Surplus $2,394.00 -
Contact Us For Quote
Siemens HED42B100 Molded Case Breakers (MCCBs)
MSRP $4,439.00Surplus $1,198.53SKU: C15-16464 Brand: Siemens MPN: HED42B100 UPC: 78364321006 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16464
- Current Rating:
- 100 A
- Type:
- Thermal Magnetic
- Number of Poles:
- 2
- Voltage Rating:
- 480 VAC, 250 VDC
- Interrupting Rating:
- 100 kA at 240 VAC (UL 489), 42 kA at 480 VAC (UL 489), 30 kA at 250 VDC (UL 489)
- Series:
- HED4
- Frame Type:
- ED
- Short Description:
- 480 VAC, 250 VDC, 100 A, 42 kA, 2-Pole, 10 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker
- Country of Origin:
- MEX
- Installation/Operator:
- SiemensAG_00313_INST.pdf
- Approval:
- UL 489
- Terminal Type:
- Load Lug
- Size:
- 2 Inch Width x 4.56 Inch Depth x 6.35 Inch Height
- Catalog:
- SiemensAG_01698_17_78-17_80_CAT.pdf
MSRP $4,439.00Surplus $1,198.53 -
Contact Us For Quote
Siemens HED43B100 Molded Case Breakers (MCCBs)
MSRP $998.00Surplus $663.67SKU: C15-10406 Brand: Siemens MPN: HED43B100 UPC: 78364321021 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10406
- TS PIK:
- 21367460
- Country of Origin:
- MEX
- Short Description:
- 480 VAC, 100 A, 100 kA Interrupt, 3-Pole, HE4D-Frame, Thermal Magnetic, Molded Case Circuit Breaker
- Type:
- Thermal Magnetic
- Voltage Rating:
- 480 VAC
- Current Rating:
- 100 A
- Series:
- HED4
- Size:
- 3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height
- Number of Poles:
- 3
- Terminal Type:
- Load Lug
- Approval:
- UL 489
- Catalog:
- SiemensAG_00876_5_30_5_31_CAT.pdf
- Frame Type:
- ED
- Interrupting Rating:
- 100 kA at 240 VAC (UL 489), 42 kA at 480 VAC (UL 489)
MSRP $998.00Surplus $663.67 -
Contact Us For Quote
Siemens HFD63B100 Molded Case Breakers (MCCBs)
MSRP $23,241.75Surplus $6,275.27SKU: C15-16482 Brand: Siemens MPN: HFD63B100 UPC: 78364321179 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16482
- Short Description:
- 600 VAC, 500 VDC, 100 A, 65 kA at 480 VAC, 3-Pole, FD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker
- Series:
- HFD6
- Voltage Rating:
- 600 VAC 50/60 Hertz, 500 VDC
- Interrupting Rating:
- 25 kA at 600 VAC, 25 kA at 500 VDC (UL)
- Type:
- Molded Case, Thermal Magnetic, Low Vage, High Breaking Capacity
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.5 Inch Width x 5.25 Inch Depth x 9.5 Inch Height
- Current Rating:
- 100 A
- Installation/Operator:
- SiemensAG_00224_INST.pdf
- Maximum DC Voltage Rating:
- 500 V
- Frame Type:
- FD
- Catalog:
- SiemensAG_01698_17_78_17_82_17_83_17_111_CAT.pdf
- Approval:
- UL 489
- Number of Poles:
- 3
- Terminal Type:
- Load Side Lug
- Country of Origin:
- MEX
MSRP $23,241.75Surplus $6,275.27 -
Siemens HGB2B100B Molded Case Breakers (MCCBs)
MSRP $2,400.00Surplus $664.09SKU: C15-10425 Brand: Siemens MPN: HGB2B100B UPC: 88762121973 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10425
- TS PIK:
- 125309210
- Number of Poles:
- 2
- Type:
- Low Vage
- Catalog:
- SiemensAG_00564_7_3-7_5_7_33_CAT.pdf
- Current Rating:
- 100 A
- Country of Origin:
- Mexico
- Short Description:
- 240/480 Star/277 VAC, 125/250 VDC, 100 A, 100 kA, 2-Pole, Molded Case, Thermal Magnetic Trip Unit, Panelboard Circuit Breaker
- Used On:
- Panelboard
- Approval:
- UL
MSRP $2,400.00Surplus $664.09 -
Contact Us For Quote
Siemens HGB3B100B Molded Case Breakers (MCCBs)
MSRP $3,000.00Surplus $836.98SKU: C15-10435 Brand: Siemens MPN: HGB3B100B UPC: 88762121988 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10435
- TS PIK:
- 125309225
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC
- Catalog:
- SiemensAG_01796_7_7_7_33_CAT.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz
- Type:
- Molded Case, Low Vage, Thermal and Fixed Magnetic, High Breaking Capacity
- Country of Origin:
- Mexico
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Short Description:
- BRKR HGB 100A 3P 480Y 35K LD LUG
- Approval:
- UL 489
- Application:
- Lighting, Distribution
MSRP $3,000.00Surplus $836.98 -
Siemens HQR22B100 Molded Case Breakers (MCCBs) EA
MSRP $2,000.00Surplus $659.45SKU: C15-10448 Brand: Siemens MPN: HQR22B100 UPC: 80476613632 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10448
- TS PIK:
- 127183117
- Country of Origin:
- Mexico
- Short Description:
- 240 VAC 50/60 Hz, 100 A, 65 kA, 2-Pole, QR Frame, Molded Case, Thermal Magnetic, Circuit Breaker
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Frame Type:
- QR
- Type:
- Molded Case, Thermal Magnetic
- Interrupting Rating:
- 65 kA at 240 V
- Size:
- 3 Inch Width x 2.53 Inch Depth x 7 Inch Height
- Voltage Rating:
- 240 VAC 50/60 Hertz (UL)
- Maximum AC Voltage Rating:
- 240 V
- Terminal Type:
- No
- Catalog:
- SiemensAG_00882_17_1_17_9_17_118_17_119_17_131_CAT.pdf
- Approval:
- UL 489
MSRP $2,000.00Surplus $659.45 -
Contact Us For Quote
Siemens LGB2B100B Molded Case Breakers (MCCBs)
MSRP $408.00Surplus $110.16SKU: C15-19011 Brand: Siemens MPN: LGB2B100B UPC: 88762122018 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-19011
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC/125/250 VDC
- Catalog:
- SiemensAG_01796_7_7_7_33_CAT.pdf
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 125/250 VDC
- Country of Origin:
- MEX
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Approval:
- UL 489
- Type:
- Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity
- Short Description:
- BRKR LGB 100A 2P 480Y 65K LD LUG
- Application:
- Lighting, Distribution
MSRP $408.00Surplus $110.16 -
Siemens LGB3B100B Molded Case Breakers (MCCBs)
MSRP $3,400.00Surplus $982.41SKU: C15-10486 Brand: Siemens MPN: LGB3B100B UPC: 88762122033 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10486
- TS PIK:
- 125266297
- Interrupting Rating:
- 65 kA
- Terminal Type:
- Load Lug
- Type:
- Thermal Magnetic
- Size:
- 3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height
- Catalog:
- SiemensAG_00564_7_33_CAT.pdf
- Number of Poles:
- 3
- Series:
- LGB
- Short Description:
- 600 VAC Star/347 VAC, 100 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard
- Current Rating:
- 100 A
- Voltage Rating:
- 480 V
- Country of Origin:
- Mexico
- Approval:
- UL
- Wire Size:
- 8 to 1/0 AWG (Copper/Aluminum)
- Used On:
- Panelboard
MSRP $3,400.00Surplus $982.41 -
Contact Us For Quote
Siemens LGB3K100B Molded Case Breakers (MCCBs)
MSRP $3,396.84Surplus $917.14SKU: C15-16831 Brand: Siemens MPN: LGB3K100B UPC: 80476634044 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16831
- Number of Poles:
- 3
- Catalog:
- SiemensAG_01796_7_7_7_34_CAT.pdf
- Approval:
- UL 489
- Short Description:
- BRKR LGB 100A 3P 480V 65K LD LUG
- Interrupting Rating:
- 25 kA at 600 Star/347 VAC
- Country of Origin:
- MEX
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz
- Application:
- Lighting, Distribution
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Current Rating:
- 100 A
- Type:
- Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity
MSRP $3,396.84Surplus $917.14 -
Contact Us For Quote
Siemens NEB3B100B Miniature Circuit Breakers (MCBs) 3P 100A
MSRP $11,107.00Surplus $2,394.00Siemens NEB3B100B Miniature Circuit Breakers (MCBs) 3P 100A​ ARCA SKU: C15-7676 Brand: Siemens MPN: NEB3B100B UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- C15-7676
- TS PIK:
- 21334135
- Series:
- NEB
- Type:
- Thermal Magnetic, Molded Case
- Number of Poles:
- 3
- Country of Origin:
- DOM
- Current Rating:
- 100 A
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Approval:
- UL 489, CSA, IEC 60947-2
- Short Description:
- 240/347/480/600 VAC 50/60 Hz, 125/250 VDC, 100 A, 85 kA, 3-Pole, Thermal Magnetic Trip Unit, Panelboard Circuit Breaker
- Interrupting Rating:
- 85 kA at 240 VAC (UL 489), 35 kA at 480 VAC/125/250 VDC (UL 489), 22 kA at 600 Star/347 VAC (UL 489), 85 kA at 240 VAC (IEC), 40 kA at 415 VAC (IEC), 35 kA at 250 VDC (IEC)
- Voltage Rating:
- 480 V
MSRP $11,107.00Surplus $2,394.00 -
Contact Us For Quote
Siemens NGB1B100B Molded Case Breakers (MCCBs)
MSRP $985.00Surplus $265.95SKU: C15-16980 Brand: Siemens MPN: NGB1B100B UPC: 78364341407 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16980
- Current Rating:
- 100 A
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Catalog:
- SiemensAG_01796_7_5_7_7_7_33_7_159_CAT.pdf
- Installation/Operator:
- SiemensAG_00631_INST.pdf
- Application:
- Lighting, Distribution
- Approval:
- UL 489
- Voltage Rating:
- 347 VAC 50/60 Hertz
- Country of Origin:
- MEX
- Short Description:
- BREAKER NGB 1P 100A 347V 14kA LD LUG
- Interrupting Rating:
- 14 kA at 347 VAC
- Number of Poles:
- 1
- Type:
- Molded Case, Low Vage, Thermal and Fixed Magnetic
MSRP $985.00Surplus $265.95 -
Contact Us For Quote
Siemens NGB3K100B Molded Case Breakers (MCCBs)
MSRP $725.00Surplus $195.75SKU: C15-16994 Brand: Siemens MPN: NGB3K100B UPC: 80476633954 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16994
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Short Description:
- BRKR NGB 100A 3P 480V 25K LD LUG
- Catalog:
- SiemensAG_01796_7_7_7_34_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz
- Installation/Operator:
- SiemensAG_00631_INST.pdf
- Country of Origin:
- MEX
- Current Rating:
- 100 A
- Approval:
- UL 489
- Type:
- Molded Case, Low Vage, Thermal and Fixed Magnetic, Standard Breaking Capacity
- Application:
- Lighting, Distribution
- Number of Poles:
- 3
MSRP $725.00Surplus $195.75 -
Siemens Q2100 Miniature Circuit Breakers (MCBs)
MSRP $297.50Surplus $37.83SKU: C15-11912 Brand: Siemens MPN: Q2100 UPC: 78364314868 Shipping Weight: 0.65 lbs. Shipping Height: 3.00 In. Shipping Length: 3.00 In. Shipping Width: 2.00 In...- SKU:
- C15-11912
- TS PIK:
- 21366655
- Number of Poles:
- 2
- Type:
- Low Vage, Common Trip, Thermal Magnetic, Miniature
- Current Rating:
- 100 A
- Country of Origin:
- Mexico
- Voltage Rating:
- 120/240 VAC
- Short Description:
- 120/240 VAC, 100 A, 10 kA Interrupt, 2-Pole, Plug-On Mount, QP/MP-Frame, Low Vage, Common Trip, Thermal Magnetic, Miniature, Circuit Breaker
- Mounting:
- Plug-On
- Used On:
- Load Center
- Size:
- 2 Inch Width x 3 Inch Depth x 3 Inch Height
- Approval:
- UL 489, CSA
- Installation/Operator:
- SiemensAG_00053_INST.pdf
- Interrupting Rating:
- 10 kA
- Data Sheet:
- SiemensAG_00870_1_2_DATA.pdf
- Catalog:
- SiemensAG_01829_2_5_CAT.pdf
MSRP $297.50Surplus $37.83 -
Siemens Q2100 Miniature Circuit Breakers (MCBs) 2P 100A 120/240V
MSRP $908.77Surplus $108.90SKU: C15-8486 Brand: Siemens MPN: Q2100 UPC: 78312661976 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-8486
- TS PIK:
- 21333978
- Approval:
- UL 489, CSA
- Installation/Operator:
- SiemensAG_00053_INST.pdf
- Interrupting Rating:
- 10 kA
- Country of Origin:
- Mexico
- Catalog:
- SiemensAG_01829_2_5_CAT.pdf
- Number of Poles:
- 2
- Short Description:
- 120/240 VAC, 100 A, 10 kA Interrupt, 2-Pole, Plug-On Mount, QP/MP-Frame, Low Vage, Common Trip, Thermal Magnetic, Miniature, Circuit Breaker
- Mounting:
- Plug-On
- Type:
- Low Vage, Common Trip, Thermal Magnetic, Miniature
- Size:
- 2 Inch Width x 3 Inch Depth x 3 Inch Height
- Used On:
- Load Center
- Data Sheet:
- SiemensAG_00870_1_2_DATA.pdf
- Current Rating:
- 100 A
- Voltage Rating:
- 120/240 VAC
MSRP $908.77Surplus $108.90 -
Contact Us For Quote
Siemens Q2100HH Molded Case Breakers (MCCBs)
MSRP $228.90Surplus $61.80SKU: C15-19046 Brand: Siemens MPN: Q2100HH UPC: 78364314901 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-19046
- Current Rating:
- 100 A
- Country of Origin:
- MEX
- Number of Poles:
- 2
- Voltage Rating:
- 120/240 VAC at 50/60 Hz
- Short Description:
- 120/240 VAC, 100 A, 65 kA, 2-Pole, 8 to 2/0 AWG Copper/Aluminum, Load Lug Terminal, Plug-On Mount, HQP Frame, Common Trip, Thermal Magnetic Trip Unit, Miniature Circuit Breaker for Load Center
- Wire Size:
- 8 to 2/0 AWG (Copper/Aluminum)
- Installation/Operator:
- SiemensAG_00215_INST.pdf
- Catalog:
- SiemensAG_00562_1_41_1_46_1_47_CAT.pdf
- Data Sheet:
- SiemensAG_06985_1_DATA.pdf
- Type:
- Thermal and Fixed Magnetic, Common Trip
- Size:
- 2 Inch W x 3 Inch D x 3-1/8 Inch H
- Interrupting Rating:
- 65 kA
- Used On:
- Loadcenter
- Terminal Type:
- Load Lug
- Mounting:
- Plug-On
- Approval:
- UL 489, CSA C22.2
MSRP $228.90Surplus $61.80 -
Siemens Q3100 Miniature Circuit Breakers (MCBs)
MSRP $141.03Surplus $87.48SKU: C15-6275 Brand: Siemens MPN: Q3100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-6275
- TS PIK:
- 115704614
- Mounting:
- Plug-On
- Data Sheet:
- SiemensAG_01547_1_DATA.pdf
- Used On:
- Load Centre Main, Feeder
- Size:
- 3 Inch Width x 3 Inch Depth x 2 Inch Height
- Catalog:
- SiemensAG_01502_1_12_CAT.pdf
- Interrupting Rating:
- 10 kA
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Voltage Rating:
- 240 V
- Type:
- Thermal Magnetic, Common Trip
- Short Description:
- 240 V, 100 A, 10 kA, 3-Pole, Plug-On, QP/MP Frame, Common Trip, Thermal Magnetic, Miniature, Circuit Breaker
- Country of Origin:
- Mexico
- Approval:
- UL 489
MSRP $141.03Surplus $87.48 -
Contact Us For Quote
Siemens Q310000S01 Miniature Circuit Breakers (MCBs)
MSRP $804.00Surplus $319.20SKU: C15-10559 Brand: Siemens MPN: Q310000S01 UPC: 78364323768 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10559
- TS PIK:
- 120831462
- Short Description:
- 240 VAC, 100 A, 10 kA, 3-Pole, 8 to 2/0 AWG Copper/Aluminum, Load Lug Terminal, Plug-On Mount, QP Frame, 120 VAC Shunt Trip, Thermal Magnetic Trip Unit, Miniature Circuit Breaker for Load Center
- Type:
- Thermal and Fixed Magnetic, Common Trip
- Voltage Rating:
- 240 VAC at 50/60 Hz
- Number of Poles:
- 3
- Mounting:
- Plug-On
- Installation/Operator:
- SiemensAG_00215_INST.pdf
- Current Rating:
- 100 A
- Catalog:
- SiemensAG_00562_1_41_1_46_1_47_CAT.pdf
- Data Sheet:
- SiemensAG_07052_1_DATA.pdf
- Size:
- 3 Inch W x 3 Inch D x 3-1/8 Inch H
- Interrupting Rating:
- 10 kA
- Wire Size:
- 8 to 2/0 AWG (Copper/Aluminum)
- Used On:
- Loadcenter
- Terminal Type:
- Load Lug
- Country of Origin:
- Mexico
- Approval:
- UL 489, CSA C22.2
MSRP $804.00Surplus $319.20 -
Siemens Q3100H Miniature Circuit Breakers (MCBs) EA
MSRP $700.00Surplus $132.60SKU: C15-10560 Brand: Siemens MPN: Q3100H UPC: 78364317082 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10560
- TS PIK:
- 21366919
- Short Description:
- 240 VAC, 100 A, 22 kA, 3-Pole, 8 to 2/0 AWG Copper/Aluminum, Load Lug Terminal, Plug-On Mount, QPH Frame, Common Trip, Thermal Magnetic Trip Unit, Miniature Circuit Breaker for Load Center
- Voltage Rating:
- 240 V
- Mounting:
- Plug-On
- Type:
- Thermal Magnetic
- Size:
- 3 Inch Width x 3 Inch Depth x 2 Inch Height
- Interrupting Rating:
- 22 kA
- Data Sheet:
- SiemensAG_07053_1_DATA.pdf
- Current Rating:
- 100 A
- Installation/Operator:
- SiemensAG_00215_INST.pdf
- Number of Poles:
- 3
- Used On:
- Load Centre Main, Feeder
- Catalog:
- SiemensAG_00562_1_41_1_46_1_47_CAT.pdf
- Country of Origin:
- Mexico
- Approval:
- UL 489
MSRP $700.00Surplus $132.60 -
Contact Us For Quote
Siemens Q3100HH Molded Case Breakers (MCCBs)
MSRP $682.00Surplus $184.14SKU: C15-19053 Brand: Siemens MPN: Q3100HH UPC: 78364314910 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-19053
- Short Description:
- 240 VAC, 100 A, 65 kA, 3-Pole, 8 to 2/0 AWG Copper/Aluminum, Load Lug Terminal, Plug-On Mount, HQP Frame, Common Trip, Thermal Magnetic Trip Unit, Miniature Circuit Breaker for Load Center
- Size:
- 3 Inch W x 3 Inch D x 3-1/8 Inch H
- Current Rating:
- 100 A
- Voltage Rating:
- 240 VAC at 50/60 Hz
- Country of Origin:
- MEX
- Type:
- Thermal and Fixed Magnetic, Common Trip
- Terminal Type:
- Load Lug
- Catalog:
- SiemensAG_00562_1_41_1_46_1_47_CAT.pdf
- Number of Poles:
- 3
- Data Sheet:
- SiemensAG_07054_1_DATA.pdf
- Wire Size:
- 8 to 2/0 AWG (Copper/Aluminum)
- Approval:
- UL 489, CSA C22.2
- Mounting:
- Plug-On
- Interrupting Rating:
- 65 kA
- Used On:
- Loadcenter
- Installation/Operator:
- SiemensAG_00215_INST.pdf
MSRP $682.00Surplus $184.14 -
Siemens QJ22B100 Molded Case Breakers (MCCBs)
MSRP $801.00Surplus $720.20SKU: C15-6282 Brand: Siemens MPN: QJ22B100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-6282
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Short Description:
- 240 VAC, 100 A, 10 kA, 2-Pole, Load Lug Terminal, QJ Frame, Molded Case Circuit Breaker
- Country of Origin:
- MEX
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL)
- Interrupting Rating:
- 10 kA at 240 VAC (UL)
- Size:
- 3 Inch W x 2.53 Inch D x 7 Inch H
- Wire Size:
- 6 AWG to 300 KCMIL (Copper), 4 AWG to 300 KCMIL (Aluminum)
- Type:
- Molded Case, Thermal and Fixed Magnetic
- Catalog:
- SiemensAG_01842_7_CAT.pdf
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Approval:
- UL 489, CSA C22.2
- Terminal Type:
- Load Lug
- Series:
- QJ2
- TS PIK:
- 119384748
MSRP $801.00Surplus $720.20 -
Contact Us For Quote
Siemens QJ23B100 Molded Case Breakers (MCCBs)
MSRP $2,090.00Surplus $538.36SKU: C15-7634 Brand: Siemens MPN: QJ23B100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7634
- TS PIK:
- 120152761
- Country of Origin:
- MEX
- Wire Size:
- 6 AWG to 300 KCMIL (Copper), 4 AWG to 300 KCMIL (Aluminum)
- Size:
- 4.5 Inch W x 2.53 Inch D x 7 Inch H
- Terminal Type:
- Load Lug
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL)
- Number of Poles:
- 3
- Series:
- QJ2
- Short Description:
- 240 VAC, 100 A, 10 kA, 3-Pole, Load Lug Terminal, QJ Frame, Molded Case Circuit Breaker
- Current Rating:
- 100 A
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Interrupting Rating:
- 10 kA at 240 VAC (UL)
- Catalog:
- SiemensAG_01842_7_CAT.pdf
- Type:
- Molded Case, Thermal and Fixed Magnetic
- Approval:
- UL 489, CSA C22.2
MSRP $2,090.00Surplus $538.36 -
Contact Us For Quote
Siemens QJ23B100H Molded Case Breakers (MCCBs)
MSRP $3,713.00Surplus $995.39SKU: C15-7635 Brand: Siemens MPN: QJ23B100H UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7635
- TS PIK:
- 123475010
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Interrupting Rating:
- 42 kA at 240 VAC (UL)
- Approval:
- UL 489, CSA C22.2
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL)
- Wire Size:
- 6 AWG to 300 KCMIL (Copper), 4 AWG to 300 KCMIL (Aluminum)
- Catalog:
- SiemensAG_01842_7_CAT.pdf
- Short Description:
- 240 VAC, 100 A, 42 kA, 3-Pole, Load Lug Terminal, QJ Frame, Molded Case Circuit Breaker
- Country of Origin:
- MEX
- Series:
- QJ2H
- Type:
- Molded Case, Thermal and Fixed Magnetic
- Size:
- 4.5 Inch W x 2.53 Inch D x 7 Inch H
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Terminal Type:
- Load Lug
MSRP $3,713.00Surplus $995.39 -
Contact Us For Quote
Siemens QJH22B100 Molded Case Breakers (MCCBs)
MSRP $649.80Surplus $175.45SKU: C15-17712 Brand: Siemens MPN: QJH22B100 UPC: 78364320113 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-17712
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Wire Size:
- 6 AWG to 300 KCMIL (Copper), 4 AWG to 300 KCMIL (Aluminum)
- Approval:
- UL 489, CSA C22.2
- Current Rating:
- 100 A
- Interrupting Rating:
- 22 kA at 240 VAC (UL)
- Terminal Type:
- Load Lug
- Type:
- Molded Case, Thermal and Fixed Magnetic
- Catalog:
- SiemensAG_01842_7_CAT.pdf
- Number of Poles:
- 2
- Short Description:
- 240 VAC, 100 A, 22 kA, 2-Pole, Load Lug Terminal, QJ Frame, Molded Case Circuit Breaker
- Country of Origin:
- MEX
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL)
- Series:
- QJH2
- Size:
- 3 Inch W x 2.53 Inch D x 7 Inch H
MSRP $649.80Surplus $175.45 -
Contact Us For Quote
Siemens QJH23B100 Molded Case Breakers (MCCBs)
MSRP $3,242.00Surplus $872.05SKU: C15-7690 Brand: Siemens MPN: QJH23B100 UPC: 78364320119 Shipping Weight: 4.55 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-7690
- TS PIK:
- 21333885
- Series:
- QJH2
- Type:
- Fixed Thermal Magnetic
- Country of Origin:
- MEX
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL)
- Short Description:
- 240 VAC, 100 A, 22 kA, 3-Pole, Load Lug Terminal, QJ Frame, Molded Case Circuit Breaker
- Current Rating:
- 100 A
- Interrupting Rating:
- 22 kA at 240 VAC (UL)
- Number of Poles:
- 3
- Terminal Type:
- Load Lug
- Catalog:
- SiemensAG_01842_7_CAT.pdf
- Used On:
- P1/P2/P3/P4/P5 Panelboard
- Wire Size:
- 6 AWG to 300 KCMIL (Copper), 4 AWG to 300 KCMIL (Aluminum)
- Size:
- 4.5 Inch W x 2.53 Inch D x 7 Inch H
- Approval:
- UL 489, CSA C22.2
MSRP $3,242.00Surplus $872.05 -
Siemens SCND69100A Molded Case Breakers (MCCBs) SCND6 3P 1000A 600V 50/60Hz 3Ph
MSRP $37,350.00Surplus $2,270.03SKU: C15-3445 Brand: Siemens MPN: SCND69100A UPC: Shipping Weight: 64.10 lbs. Shipping Height: 9.00 In. Shipping Length: 23.00 In. Shipping Width: 10.00 In. Product...- SKU:
- C15-3445
- Series:
- SCND6-A
- Type:
- Electronic
- Type:
- Solid State
- Approval:
- UL 489
- Approval:
- IEC 947-2
- Size:
- 9 Inch Width x 8.25 Inch Depth x 16 Inch Height
- Volts:
- 600 VAC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 200 kA at 240 VAC (UL 489)
- Interrupting Rating:
- 100 kA at 480 Volt AC (UL 489)
- Interrupting Rating:
- 65 kA at 600 Volt AC (UL 489)
- Terminal Type:
- Line/Load Lug
- Frame Type:
- ND
- Maximum AC Voltage Rating:
- 600 V
- Short Description:
- 600 VAC, 1000 A, 100 kA, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, MD Frame, LI Sensitrip, Electronic Trip
- Current Rating:
- 100 A
- Voltage Rating:
- 600 VAC
- Number of Poles:
- 3
- Country of Origin:
- MEX
MSRP $37,350.00Surplus $2,270.03 -
Contact Us For Quote
Square D BDA24100Y1 Molded Case Breakers (MCCBs)
MSRP $966.00Surplus $260.82SKU: C15-15456 Brand: Square D MPN: BDA24100Y1 UPC: 60648115195 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15456
- Current Rating:
- 100 A
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, AB Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- BD
- Maximum AC Voltage Rating:
- 277 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC, 10 kA at 250 VDC
- Type:
- Thermal Magnetic
- Approval:
- UL, CSA, CE
- Maximum DC Voltage Rating:
- 250 V
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Terminal Type:
- I-Line Connection Line Lug Load
- Data Sheet:
- SchneiderElectric-SquareD_34791_1-4_DATA.pdf
- Frame Type:
- B
- Number of Poles:
- 2
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73415_1_CAD.pdf
MSRP $966.00Surplus $260.82 -
Contact Us For Quote
Square D BDA24100Y2 Molded Case Breakers (MCCBs)
MSRP $621.00Surplus $167.67SKU: C15-18663 Brand: Square D MPN: BDA24100Y2 UPC: 60648115196 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18663
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, AC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC, 10 kA at 250 VDC
- Number of Poles:
- 2
- Frame Type:
- B
- Type:
- Thermal Magnetic
- Maximum DC Voltage Rating:
- 250 V
- Approval:
- UL, CSA, CE
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Terminal Type:
- I-Line Connection Line Lug Load
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- Series:
- BD
- Current Rating:
- 100 A
- Data Sheet:
- SchneiderElectric-SquareD_34792_1-4_DATA.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73416_1_CAD.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Maximum AC Voltage Rating:
- 277 V
MSRP $621.00Surplus $167.67 -
Contact Us For Quote
Square D BDA24100Y4 Molded Case Breakers (MCCBs)
MSRP $621.00Surplus $167.67SKU: C15-15457 Brand: Square D MPN: BDA24100Y4 UPC: 60648115197 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15457
- Series:
- BD
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, BC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Number of Poles:
- 2
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC, 10 kA at 250 VDC
- Maximum AC Voltage Rating:
- 277 V
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Data Sheet:
- SchneiderElectric-SquareD_34793_1-4_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73417_1_CAD.pdf
- Approval:
- UL, CSA, CE
- Type:
- Thermal Magnetic
- Frame Type:
- B
- Terminal Type:
- I-Line Connection Line Lug Load
- Current Rating:
- 100 A
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
MSRP $621.00Surplus $167.67 -
Square D BDA261001 Molded Case Breakers (MCCBs)
MSRP $850.00Surplus $630.59SKU: C15-10632 Brand: Square D MPN: BDA261001 UPC: 78590104905 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10632
- TS PIK:
- 127013770
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, B-Frame, AB Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic
- Frame Type:
- B
- Series:
- BD
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- CAD Drawings:
- SchneiderElectric_29055_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- Maximum AC Voltage Rating:
- 347 V
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- I-Line Connection Line Lug Load
- Prop 65 Warning:
- Yes
- Data Sheet:
- SchneiderElectric-SquareD_34822_1-4_DATA.pdf
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
MSRP $850.00Surplus $630.59 -
Square D BDA261002 Molded Case Breakers (MCCBs)
MSRP $980.00Surplus $630.59SKU: C15-10633 Brand: Square D MPN: BDA261002 UPC: 60648115232 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10633
- TS PIK:
- 127013673
- Frame Type:
- B
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 2
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73450_1_CAD.pdf
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 347 V
- Data Sheet:
- SchneiderElectric-SquareD_34823_1-4_DATA.pdf
- Terminal Type:
- I-Line Connection Line Lug Load
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
- Type:
- Thermal Magnetic
- Current Rating:
- 100 A
- Prop 65 Warning:
- Yes
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, B-Frame, AC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- BD
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $980.00Surplus $630.59 -
Contact Us For Quote
Square D BDA261004 Molded Case Breakers (MCCBs)
MSRP $979.83Surplus $264.56SKU: C15-15467 Brand: Square D MPN: BDA261004 UPC: 78590194202 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15467
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- SchneiderElectric-SquareD_01071_INST.pdf
- Current Rating:
- 100 A
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Maximum AC Voltage Rating:
- 347 V
- Terminal Type:
- I-Line Connection Line Lug Load
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
- Frame Type:
- B
- Type:
- Thermal Magnetic
- Approval:
- UL, CSA, CE
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Number of Poles:
- 2
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, B-Frame, BC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- BD
- CAD Drawings:
- SchneiderElectric_29056_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_37171_1-4_DATA.pdf
MSRP $979.83Surplus $264.56 -
Contact Us For Quote
Square D BDA34100Y Molded Case Breakers (MCCBs)
MSRP $863.00Surplus $233.01SKU: C15-15477 Brand: Square D MPN: BDA34100Y UPC: 60648115247 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15477
- Series:
- BD
- Number of Poles:
- 3
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Terminal Type:
- I-Line Connection Line Lug Load
- Type:
- Thermal Magnetic
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Data Sheet:
- SchneiderElectric-SquareD_34836_1-4_DATA.pdf
- Current Rating:
- 100 A
- Frame Type:
- B
- Prop 65 Warning:
- Yes
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Maximum AC Voltage Rating:
- 277 V
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC, 10 kA at 250 VDC
- CAD Drawings:
- SchneiderElectric-SquareD_73464_1_CAD.pdf
- Approval:
- UL, CSA, CE
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
MSRP $863.00Surplus $233.01 -
Square D BDA36100 Molded Case Breakers (MCCBs)
MSRP $1,000.00Surplus $714.42SKU: C15-10642 Brand: Square D MPN: BDA36100 UPC: 60648115272 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10642
- TS PIK:
- 127013689
- Type:
- Thermal Magnetic
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Prop 65 Warning:
- Yes
- Frame Type:
- B
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Series:
- BD
- Number of Poles:
- 3
- Data Sheet:
- SchneiderElectric-SquareD_34848_1-3_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Current Rating:
- 100 A
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Terminal Type:
- I-Line Connection Line Lug Load
- Maximum AC Voltage Rating:
- 347 V
- CAD Drawings:
- SchneiderElectric-SquareD_73475_1_CAD.pdf
- Maximum DC Voltage Rating:
- 250 V
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
MSRP $1,000.00Surplus $714.42 -
Contact Us For Quote
Square D BDL26100 Miniature Circuit Breakers (MCBs)
MSRP $644.00Surplus $770.00SKU: C15-10645 Brand: Square D MPN: BDL26100 UPC: 60648115292 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10645
- TS PIK:
- 126841963
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, B-Frame, Clip-On Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Molded Case Circuit Breaker
- Number of Poles:
- 2
- Size:
- 2.13 Inch Width x 3.15 Inch Depth x 5.39 Inch Height
- Series:
- BD
- Prop 65 Warning:
- Yes
- Current Rating:
- 100 A
- Interrupting Rating:
- 14 kA at 600 Star/347 V AC, 10 kA at 250 V DC
- Voltage Rating:
- 600 Star/347 V AC 50/60 Hertz, 250 V DC
- Data Sheet:
- SchneiderElectric-SquareD_34941_1-4_DATA.pdf
- Type:
- Thermal Magnetic
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73496_1_CAD.pdf
- Terminal Type:
- Line/Load Lug
- Approval:
- UL, CSA, CE
- Installation/Operator:
- SchneiderElectric-SquareD_00009_INST.pdf
- Frame Type:
- B
- Maximum AC Voltage Rating:
- 347 V
MSRP $644.00Surplus $770.00 -
Contact Us For Quote
Square D BDL36100 Molded Case Breakers (MCCBs)
MSRP $1,708.00Surplus $461.16SKU: C15-18684 Brand: Square D MPN: BDL36100 UPC: 60648115322 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18684
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 3
- Series:
- BD100
- Current Rating:
- 100 A
- Size:
- 3.19 Inch Width x 3.15 Inch Depth x 5.39 Inch Height
- Interrupting Rating:
- 25 kA at 208 Star/120/240 VAC, 18 kA at 480/277 VAC, 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
- Terminal Type:
- Line/Load Lug
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA Interrupt Rating, 14 to 3/0 AWG Aluminum/Copper, 3-Pole, Gray, B-Frame, Line/Load Lug Terminal, Thermal Magnetic, Molded Case, Circuit Breaker
- CAD Drawings:
- SchneiderElectric-SquareD_78347_1_CAD.pdf
- Type:
- Molded Case, Thermal Magnetic
- Installation/Operator:
- SchneiderElectric-SquareD_00233_INST.pdf
- Frame Type:
- B
- Approval:
- UL 489, NOM, EAC, CSA C22.2, CE, CCC
- Prop 65 Warning:
- Yes
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 347 V
- Catalog:
- SchneiderElectric-SquareD_01063_9-14_17_101_CAT.pdf
MSRP $1,708.00Surplus $461.16 -
Contact Us For Quote
Square D BDL36100SA Molded Case Breakers (MCCBs)
MSRP $1,839.60Surplus $496.69SKU: C15-15491 Brand: Square D MPN: BDL36100SA UPC: 60648115323 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15491
- Frame Type:
- B
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, B-Frame, Clip-On Mount, Line/Load Lug Terminal, Thermal Magnetic, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Maximum AC Voltage Rating:
- 347 V
- Terminal Type:
- Line/Load Lug
- Approval:
- UL, CSA, CE
- Series:
- BD
- Size:
- 81 Millimeter Width x 80 Millimeter Depth x 137 Millimeter Height
- Current Rating:
- 100 A
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Number of Poles:
- 3
- Type:
- Thermal Magnetic
- Data Sheet:
- SchneiderElectric_30538_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric_29074_1-7_CAD.pdf
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC, 10 kA at 250 VDC
MSRP $1,839.60Surplus $496.69 -
Contact Us For Quote
Square D BGA24100Y1 Molded Case Breakers (MCCBs)
MSRP $1,302.00Surplus $351.54SKU: C15-15526 Brand: Square D MPN: BGA24100Y1 UPC: 78590146173 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15526
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Size:
- 54 Millimeter Width x 89 Millimeter Depth x 137 Millimeter Height
- Interrupting Rating:
- 35 kA at 480 Star/277 VAC, 20 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00006_INST.pdf
- Type:
- Thermal Magnetic
- Number of Poles:
- 2
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 35 kA, 2-Pole, B-Frame, AB Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 277 V
- Approval:
- UL, CSA, CE
- Current Rating:
- 100 A
- Frame Type:
- B
- Series:
- BG
- Data Sheet:
- SchneiderElectric-SquareD_74761_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric_29097_1_CAD.pdf
- Terminal Type:
- I-Line Connection Line Lug Load
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
MSRP $1,302.00Surplus $351.54 -
Contact Us For Quote
Square D BGA24100Y2 Molded Case Breakers (MCCBs)
MSRP $838.00Surplus $226.26SKU: C15-15527 Brand: Square D MPN: BGA24100Y2 UPC: 60648628156 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15527
- Interrupting Rating:
- 35 kA at 480 Star/277 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00006_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73570_1_CAD.pdf
- Size:
- 54 Millimeter Width x 89 Millimeter Depth x 137 Millimeter Height
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 277 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Number of Poles:
- 2
- Data Sheet:
- SchneiderElectric-SquareD_74762_1-3_DATA.pdf
- Maximum DC Voltage Rating:
- 250 V
- Type:
- Thermal Magnetic
- Series:
- BG
- Terminal Type:
- I-Line Connection Line Lug Load
- Frame Type:
- B
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 35 kA, 2-Pole, B-Frame, AC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
MSRP $838.00Surplus $226.26 -
Contact Us For Quote
Square D BGA261001 Molded Case Breakers (MCCBs)
MSRP $1,518.00Surplus $409.86SKU: C15-15549 Brand: Square D MPN: BGA261001 UPC: 60648115361 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15549
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Type:
- Thermal Magnetic
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, AB Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Frame Type:
- B
- Approval:
- UL, CSA, CE
- Terminal Type:
- I-Line Connection Line Lug Load
- Interrupting Rating:
- 18 kA at 600 Star/347 V, 20 kA at 250 VDC
- Maximum AC Voltage Rating:
- 347 V
- Data Sheet:
- SchneiderElectric-SquareD_35045_1-4_DATA.pdf
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- SchneiderElectric-SquareD_73598_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_00006_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Series:
- BG
MSRP $1,518.00Surplus $409.86 -
Contact Us For Quote
Square D BGA261002 Molded Case Breakers (MCCBs)
MSRP $1,041.00Surplus $388.59SKU: U00-7874 Brand: Square D MPN: BGA261002 UPC: 60648115362 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- U00-7874
- Interrupting Rating:
- 18 kA at 600 Star/347 V, 20 kA at 250 VDC
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, AC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Frame Type:
- B
- Series:
- BG
- Type:
- Thermal Magnetic
- Current Rating:
- 100 A
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 2
- Terminal Type:
- I-Line Connection Line Lug Load
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_00006_INST.pdf
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- CAD Drawings:
- SchneiderElectric-SquareD_73599_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_35046_1-4_DATA.pdf
- Maximum AC Voltage Rating:
- 347 V
MSRP $1,041.00Surplus $388.59 -
Contact Us For Quote
Square D BGA261004 Molded Case Breakers (MCCBs)
MSRP $983.00Surplus $265.41SKU: C15-15550 Brand: Square D MPN: BGA261004 UPC: 60648115364 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15550
- Size:
- 2.13 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Maximum AC Voltage Rating:
- 347 V
- Frame Type:
- B
- CAD Drawings:
- SchneiderElectric-SquareD_73600_1_CAD.pdf
- Terminal Type:
- I-Line Connection Line Lug Load
- Interrupting Rating:
- 18 kA at 600 Star/347 V, 20 kA at 250 VDC
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, B-Frame, BC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_35047_1-4_DATA.pdf
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Approval:
- UL, CSA, CE
- Number of Poles:
- 2
- Current Rating:
- 100 A
- Series:
- BG
- Type:
- Thermal Magnetic
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00006_INST.pdf
MSRP $983.00Surplus $265.41 -
Contact Us For Quote
Square D BGA34100Y Molded Case Breakers (MCCBs)
MSRP $1,574.00Surplus $382.48SKU: C15-18691 Brand: Square D MPN: BGA34100Y UPC: 78590106952 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18691
- Short Description:
- 480 Star/277 VAC 50/60 Hz, 250 VDC, 100 A, 35 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Number of Poles:
- 3
- Series:
- BG
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Data Sheet:
- SchneiderElectric-SquareD_74779_1-3_DATA.pdf
- Type:
- Thermal Magnetic
- Size:
- 81 Millimeter Width x 89 Millimeter Depth x 137 Millimeter Height
- Interrupting Rating:
- 35 kA at 480 Star/277 VAC, 20 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- CAD Drawings:
- SchneiderElectric_29120_1_CAD.pdf
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 277 V
- Frame Type:
- B
- Voltage Rating:
- 480 Star/277 VAC 50/60 Hertz, 250 VDC
- Terminal Type:
- I-Line Connection Line Lug Load
MSRP $1,574.00Surplus $382.48 -
Square D BGA36100 Molded Case Breakers (MCCBs)
MSRP $1,595.00Surplus $838.50SKU: U00-6304 Brand: Square D MPN: BGA36100 UPC: 60648115393 Shipping Weight: 1.89 lbs. Shipping Height: 5.39 In. Shipping Length: 5.39 In. Shipping Width: 3.19 In...- SKU:
- U00-6304
- Series:
- BG
- Prop 65 Warning:
- Yes
- Number of Poles:
- 3
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Data Sheet:
- SchneiderElectric-SquareD_35060_1-4_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73613_1_CAD.pdf
- Frame Type:
- B
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Interrupting Rating:
- 18 kA at 600 Star/347 V, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 347 V
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Type:
- Thermal Magnetic
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Terminal Type:
- I-Line Connection Line Lug Load
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
MSRP $1,595.00Surplus $838.50 -
Square D BJA36100 Din Rail Mounted Circuit Breakers
MSRP $2,000.00Surplus $1,023.54SKU: C15-10674 Brand: Square D MPN: BJA36100 UPC: 60648118592 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10674
- TS PIK:
- 127013747
- Series:
- BJ
- Type:
- Thermal Magnetic
- Terminal Type:
- I-Line Connection Line Lug Load
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_35205_1-4_DATA.pdf
- Prop 65 Warning:
- Yes
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Interrupting Rating:
- 25 kA at 600 Star/347 V, 50 kA at 250 VDC
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Approval:
- UL, CSA, CE
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 25 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- CAD Drawings:
- SchneiderElectric-SquareD_73681_1_CAD.pdf
- Frame Type:
- B
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 347 V
- Country of Origin:
- United States
MSRP $2,000.00Surplus $1,023.54 -
Contact Us For Quote
Square D BJL36100 Molded Case Breakers (MCCBs)
MSRP $1,415.00Surplus $382.05SKU: C15-18700 Brand: Square D MPN: BJL36100 UPC: 60648118607 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18700
- Current Rating:
- 100 A
- Interrupting Rating:
- 25 kA at 600 Star/347 V, 50 kA at 250 VDC
- Series:
- BJ
- Number of Poles:
- 3
- Frame Type:
- B
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 100 A, 25 kA, 3-Pole, B-Frame, Clip-On Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Molded Case Circuit Breaker
- Terminal Type:
- Line/Load Lug
- Size:
- 3.19 Inch Width x 3.15 Inch Depth x 5.39 Inch Height
- Installation/Operator:
- SchneiderElectric-SquareD_00233_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_73706_1_CAD.pdf
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 347 V
- Data Sheet:
- SchneiderElectric-SquareD_35305_1-4_DATA.pdf
- Approval:
- UL, CSA, CE
MSRP $1,415.00Surplus $382.05 -
Square D EDB24100 Miniature Circuit Breakers (MCBs)
MSRP $756.00Surplus $357.27SKU: C15-10682 Brand: Square D MPN: EDB24100 UPC: 78590107292 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10682
- TS PIK:
- 115345449
- Installation/Operator:
- SchneiderElectric-SquareD_01117_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_45589_1_2_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf
- Current Rating:
- 100 A
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC
- Series:
- EDB
- Number of Poles:
- 2
- Type:
- Thermal Magnetic, Branch, Miniature
- Short Description:
- 480 Star/277 VAC, 100 A, 18 kA, 2-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Voltage Rating:
- 480 Star/277 VAC
- Used On:
- NF Merchandised Panelboard
- Installation:
- Bolt-On
- Approval:
- UL (Canada and US)
- Application:
- Lighting
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Country of Origin:
- Mexico
MSRP $756.00Surplus $357.27 -
Contact Us For Quote
Square D EDB26100 Miniature Circuit Breakers (MCBs)
MSRP $1,346.00Surplus $363.42SKU: C15-15879 Brand: Square D MPN: EDB26100 UPC: 78590141233 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15879
- Catalog:
- SchneiderElectric-SquareD_32357_9_32_9_33_CAT.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_01951_INST.pdf
- Application:
- Lighting
- Installation:
- Bolt-On
- Current Rating:
- 100 A
- Used On:
- NF Merchandised Panelboard
- Number of Poles:
- 2
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Voltage Rating:
- 600 Star/347 VAC
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC
- Data Sheet:
- SchneiderElectric_14161_1_2_DATA.pdf
- Type:
- Thermal Magnetic, Branch, Miniature
- Approval:
- UL (Canada and US)
- Series:
- EDB
- Short Description:
- 600 Star/347 VAC, 100 A, 14 kA, 2-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
MSRP $1,346.00Surplus $363.42 -
Square D EDB34100SA Miniature Circuit Breakers (MCBs)
MSRP $1,816.00Surplus $1,207.64SKU: C15-10692 Brand: Square D MPN: EDB34100SA UPC: 78590133516 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10692
- TS PIK:
- 115773498
- Series:
- EDB
- Interrupting Rating:
- 18 kA at 480 Star/277 VAC
- Type:
- Thermal Magnetic, Branch, Miniature
- Installation/Operator:
- SchneiderElectric-SquareD_01117_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_45635_1_2_DATA.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Used On:
- NF Merchandised Panelboard
- Application:
- Lighting
- Installation:
- Bolt-On
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Catalog:
- SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf
- Voltage Rating:
- 480 Star/277 VAC
- Short Description:
- 480 Star/277 VAC, 100 A, 18 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker with Shunt Trip Package
- Approval:
- UL (Canada and US)
- Country of Origin:
- Mexico
MSRP $1,816.00Surplus $1,207.64 -
Contact Us For Quote
Square D EDB36100 Molded Case Breakers (MCCBs)
MSRP $1,516.00Surplus $409.32SKU: C15-15887 Brand: Square D MPN: EDB36100 UPC: 78590129638 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15887
- Series:
- EDB
- Interrupting Rating:
- 14 kA at 600 Star/347 VAC
- Current Rating:
- 100 A
- Voltage Rating:
- 600 Star/347 VAC
- Number of Poles:
- 3
- Short Description:
- 600 Star/347 VAC, 100 A, 14 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Approval:
- UL (Canada and US)
- Type:
- Thermal Magnetic, Branch, Miniature
- Used On:
- NF Merchandised Panelboard
- Application:
- Lighting
- Data Sheet:
- SchneiderElectric_14175_1_2_DATA.pdf
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Installation/Operator:
- SchneiderElectric-SquareD_01951_INST.pdf
- Installation:
- Bolt-On
- Catalog:
- SchneiderElectric-SquareD_32357_9_32_9_33_CAT.pdf
MSRP $1,516.00Surplus $409.32 -
Contact Us For Quote
Square D EGB26100 Molded Case Breakers (MCCBs)
MSRP $2,130.00Surplus $575.10SKU: C15-15914 Brand: Square D MPN: EGB26100 UPC: 78590141235 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15914
- Voltage Rating:
- 600 Star/347 VAC
- Current Rating:
- 100 A
- Series:
- EGB
- Number of Poles:
- 2
- Approval:
- UL (Canada and US)
- Installation/Operator:
- SchneiderElectric-SquareD_01951_INST.pdf
- Application:
- Lighting
- Short Description:
- 600 Star/347 VAC, 100 A, 18 kA, 2-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Type:
- Thermal Magnetic, Branch, Miniature
- Data Sheet:
- SchneiderElectric_14195_1_2_DATA.pdf
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Used On:
- NF Merchandised Panelboard
- Catalog:
- SchneiderElectric-SquareD_32357_9_32_9_33_CAT.pdf
- Installation:
- Bolt-On
- Interrupting Rating:
- 18 kA at 600 Star/347 VAC
MSRP $2,130.00Surplus $575.10 -
Square D EGB34100 Miniature Circuit Breakers (MCBs)
MSRP $1,292.00Surplus $518.83SKU: C15-7760 Brand: Square D MPN: EGB34100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7760
- TS PIK:
- 21333922
- Type:
- Thermal Magnetic, Branch, Miniature
- Series:
- EGB
- Used On:
- NF Merchandised Panelboard
- Number of Poles:
- 3
- Voltage Rating:
- 480 Star/277 VAC
- Installation/Operator:
- SchneiderElectric-SquareD_01117_INST.pdf
- Short Description:
- 480 Star/277 VAC, 100 A, 35 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Interrupting Rating:
- 35 kA at 480 Star/277 VAC
- Current Rating:
- 100 A
- Catalog:
- SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_45691_1_2_DATA.pdf
- Installation:
- Bolt-On
- Application:
- Lighting
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Approval:
- UL (Canada and US)
- Country of Origin:
- Mexico
MSRP $1,292.00Surplus $518.83 -
Contact Us For Quote
Square D EGB34100SA Miniature Circuit Breakers (MCBs)
MSRP $2,476.00Surplus $1,646.54SKU: C15-10700 Brand: Square D MPN: EGB34100SA UPC: 78590115948 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10700
- TS PIK:
- 116559407
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Short Description:
- 480 Star/277 VAC, 100 A, 35 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker with Shunt Trip Package
- Type:
- Thermal Magnetic, Branch, Miniature
- Voltage Rating:
- 480 Star/277 VAC
- Approval:
- UL (Canada and US)
- Data Sheet:
- SchneiderElectric-SquareD_45692_1_2_DATA.pdf
- Interrupting Rating:
- 35 kA at 480 Star/277 VAC
- Series:
- EGB
- Used On:
- NF Merchandised Panelboard
- Installation:
- Bolt-On
- Catalog:
- SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf
- Application:
- Lighting
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
- Installation/Operator:
- SchneiderElectric-SquareD_01117_INST.pdf
MSRP $2,476.00Surplus $1,646.54 -
Contact Us For Quote
Square D EGB36100 Molded Case Breakers (MCCBs)
MSRP $1,701.00Surplus $459.27SKU: C15-15928 Brand: Square D MPN: EGB36100 UPC: 78590123484 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-15928
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_9_32_9_33_CAT.pdf
- Installation:
- Bolt-On
- Interrupting Rating:
- 18 kA at 600 Star/347 VAC
- Approval:
- UL (Canada and US)
- Short Description:
- 600 Star/347 VAC, 100 A, 18 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Current Rating:
- 100 A
- Application:
- Lighting
- Series:
- EGB
- Type:
- Thermal Magnetic, Branch, Miniature
- Installation/Operator:
- SchneiderElectric-SquareD_01951_INST.pdf
- Used On:
- NF Merchandised Panelboard
- Data Sheet:
- SchneiderElectric_14208_1_2_DATA.pdf
- Voltage Rating:
- 600 Star/347 VAC
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
MSRP $1,701.00Surplus $459.27 -
Contact Us For Quote
Square D EHB34100 Molded Case Breakers (MCCBs)
Surplus $4,480.00SKU: C15-8622 Brand: Square D MPN: EHB34100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-8622
- Number of Poles:
- 3
- Type:
- Molded Case, Thermal Magnetic
- Frame Type:
- E
- Interrupting Rating:
- 65 kA at 240 VAC, 14 kA at 480 VAC Star/277 VAC (UL/CSA)
- Terminal Type:
- Bolt-On
- Voltage Rating:
- 240 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA)
- Short Description:
- 240/480 Star/277 VAC, 100 A, 65/14 kA, 3-Pole, E-Frame, Bolt-On Mount, Miniature Circuit Breaker
- Series:
- EHB
- Current Rating:
- 100 A
- Size:
- 3 Inch W x 2.97 Inch D x 3.5 Inch H
- Maximum AC Voltage Rating:
- 277 V
Surplus $4,480.00 -
Contact Us For Quote
Square D EJB34100SA Molded Case Breakers (MCCBs)
MSRP $2,885.00Surplus $778.95SKU: C15-16007 Brand: Square D MPN: EJB34100SA UPC: 78590164920 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16007
- Installation/Operator:
- SchneiderElectric-SquareD_01117_INST.pdf
- Used On:
- NF Merchandised Panelboard
- Current Rating:
- 100 A
- Series:
- EJB
- Number of Poles:
- 3
- Voltage Rating:
- 480 Star/277 VAC
- Data Sheet:
- SchneiderElectric-SquareD_45746_1_2_DATA.pdf
- Type:
- Thermal Magnetic, Branch, Miniature
- Approval:
- UL (Canada and US)
- Catalog:
- SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf
- Interrupting Rating:
- 65 kA at 480 Star/277 VAC
- Short Description:
- 480 Star/277 VAC, 100 A, 65 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker with Shunt Trip Package
- Installation:
- Bolt-On
- Application:
- Lighting
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
MSRP $2,885.00Surplus $778.95 -
Contact Us For Quote
Square D EJB36100 Molded Case Breakers (MCCBs)
MSRP $3,075.00Surplus $830.25SKU: C15-16012 Brand: Square D MPN: EJB36100 UPC: 78590141137 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16012
- Interrupting Rating:
- 25 kA at 600 Star/347 VAC
- Short Description:
- 600 Star/347 VAC, 100 A, 25 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker
- Voltage Rating:
- 600 Star/347 VAC
- Application:
- Lighting
- Type:
- Thermal Magnetic, Branch, Miniature
- Used On:
- NF Merchandised Panelboard
- Number of Poles:
- 3
- Series:
- EJB
- Installation/Operator:
- SchneiderElectric-SquareD_01951_INST.pdf
- Current Rating:
- 100 A
- Installation:
- Bolt-On
- Approval:
- UL (Canada and US)
- Catalog:
- SchneiderElectric-SquareD_32357_9_32_9_33_CAT.pdf
- Data Sheet:
- SchneiderElectric_14238_1_2_DATA.pdf
- Trip Setting:
- 1000 A (Hold), 2300 A (Trip)
MSRP $3,075.00Surplus $830.25 -
Contact Us For Quote
Square D FA22100AB Molded Case Breakers (MCCBs)
MSRP $472.15Surplus $585.20SKU: C15-6693 Brand: Square D MPN: FA22100AB UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-6693
- Short Description:
- 240 VAC, 250 VDC, 100 A, 5/10 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Interrupting Rating:
- 10 kA at 240 VAC, 25 kA at 480 VAC, 25 kA at 600 VAC
- Data Sheet:
- SchneiderElectric-SquareD_04259_1_2_DATA.pdf
- Current Rating:
- 100 A
- Application:
- Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Series:
- 650, FA
- Installation:
- Plug-On
- Voltage Rating:
- 240 VAC
- Type:
- Molded Case, Thermal Magnetic, Main
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Used On:
- I-Line Panelboard and Switchboard
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Number of Poles:
- 2
MSRP $472.15Surplus $585.20 -
Contact Us For Quote
Square D FA22100AC Everything Else
MSRP $425.00Surplus $345.04SKU: C15-8665 Brand: Square D MPN: FA22100AC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-8665
- Series:
- 650, FA
- Number of Poles:
- 2
- Short Description:
- 240 VAC, 250 VDC, 100 A, 5/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Current Rating:
- 100 A
- Voltage Rating:
- 240 VAC
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Application:
- Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic, Main
- Used On:
- I-Line Panelboard and Switchboard
- Prop 65 Warning:
- Yes
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Interrupting Rating:
- 10 kA at 240 VAC, 25 kA at 480 VAC, 25 kA at 600 VAC
- Data Sheet:
- SchneiderElectric-SquareD_04260_1_2_DATA.pdf
MSRP $425.00Surplus $345.04 -
Contact Us For Quote
Square D FA22100BC Molded Case Breakers (MCCBs)
MSRP $1,000.00Surplus $616.00SKU: C15-8598 Brand: Square D MPN: FA22100BC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-8598
- Interrupting Rating:
- 25 kA at 240 VAC (UL/CSA/NOM)
- Data Sheet:
- SchneiderElectric-SquareD_04261_1_2_DATA.pdf
- Used On:
- Class 650/651 I-Line Panelboard/Switchboard
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Application:
- Power Distribution
- Series:
- FA
- Type:
- Molded Case, Thermal Magnetic
- Approval:
- UL, CSA
- Number of Poles:
- 2
- Short Description:
- 240 VAC, 250 VDC, 100 A, 5/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Current Rating:
- 100 A
- Trip Setting:
- 900 to 1700 A
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL/CSA/NOM/IEC)
MSRP $1,000.00Surplus $616.00 -
Contact Us For Quote
Square D FA24100AC Molded Case Breakers (MCCBs)
MSRP $924.00Surplus $249.48SKU: L19-6476 Brand: Square D MPN: FA24100AC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- L19-6476
- Current Rating:
- 100 A
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Approval:
- UL, CSA
- Number of Poles:
- 2
- Short Description:
- 480 VAC, 250 VDC, 100 A, 10/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- FA
- Data Sheet:
- SchneiderElectric-SquareD_04291_1_2_DATA.pdf
- Used On:
- Class 650/651 I-Line Panelboard/Switchboard
- Trip Setting:
- 900 to 1700 A
- Type:
- Thermal Magnetic, Molded Case
- Application:
- Power Distribution
- Interrupting Rating:
- 18 kA at 480 VAC, 10 kA at 250 VDC
- Voltage Rating:
- 480 VAC, 250 VDC
MSRP $924.00Surplus $249.48 -
Contact Us For Quote
Square D FA24100BC Molded Case Breakers (MCCBs)
MSRP $688.00Surplus $185.76SKU: L19-6477 Brand: Square D MPN: FA24100BC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- L19-6477
- Series:
- FA
- Prop 65 Warning:
- Yes
- Number of Poles:
- 2
- Type:
- Molded Case, Thermal Magnetic
- Current Rating:
- 100 A
- Interrupting Rating:
- 25 kA at 240 VAC, 18 kA at 480 VAC Star/277 VAC or 480 VAC (UL/CSA/NOM), 10 kA at 415 VAC (IEC), 10 kA at 250 VDC
- Voltage Rating:
- 240/480 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA/NOM), 240/415 VAC at 50/60 Hz (IEC), 250 VDC
- Short Description:
- 480 VAC, 250 VDC, 100 A, 10/18/25 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Used On:
- Class 650/651 I-Line Panelboard/Switchboard
- Data Sheet:
- SchneiderElectric-SquareD_04292_1_2_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Application:
- Power Distribution
- Approval:
- UL, CSA
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Trip Setting:
- 900 to 1700 A
MSRP $688.00Surplus $185.76 -
Contact Us For Quote
Square D FA32100 Molded Case Breakers (MCCBs)
MSRP $1,121.00Surplus $302.67SKU: L19-6496 Brand: Square D MPN: FA32100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- L19-6496
- Number of Poles:
- 3
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Interrupting Rating:
- 10 kA at 240 VAC, 25 kA at 480 VAC, 25 kA at 600 VAC
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Short Description:
- 240 VAC, 250 VDC, 100 A, 5/10 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Type:
- Molded Case, Thermal Magnetic, Main
- Application:
- Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial
- Used On:
- I-Line Panelboard and Switchboard
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Current Rating:
- 100 A
- Installation:
- Plug-On
- Data Sheet:
- SchneiderElectric-SquareD_04334_1_2_DATA.pdf
- Series:
- 650, FA
- Voltage Rating:
- 240 VAC
MSRP $1,121.00Surplus $302.67 -
Contact Us For Quote
Square D FA34100 Molded Case Breakers (MCCBs)
MSRP $505.87Surplus $257.44SKU: C15-6573 Brand: Square D MPN: FA34100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-6573
- Number of Poles:
- 3
- Interrupting Rating:
- 18 kA at 480 VAC, 10 kA at 250 VDC
- Approval:
- UL, CSA
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Voltage Rating:
- 480 VAC, 250 VDC
- Application:
- Power Distribution
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Type:
- Thermal Magnetic, Molded Case
- Short Description:
- 480 VAC, 250 VDC, 100 A, 10/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Current Rating:
- 100 A
- Used On:
- Class 650/651 I-Line Panelboard/Switchboard
- Trip Setting:
- 900 to 1700 A
- Series:
- FA
- Data Sheet:
- SchneiderElectric-SquareD_04352_1_2_DATA.pdf
MSRP $505.87Surplus $257.44 -
Contact Us For Quote
Square D FA341001021 Molded Case Breakers (MCCBs)
MSRP $725.00Surplus $655.44SKU: C15-8667 Brand: Square D MPN: FA341001021 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-8667
- Short Description:
- 480 VAC, 250 VDC, 100 A, 10/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker
- Series:
- FA
- Interrupting Rating:
- 18 kA at 480/600 VAC
- Data Sheet:
- SchneiderElectric-SquareD_04353_1_2_DATA.pdf
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Type:
- Molded Case, Thermal Magnetic, Main
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Installation:
- Plug-On
- Application:
- Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial
- Used On:
- I-Line Panelboard and Switchboard
- Voltage Rating:
- 480 VAC, 250 VDC
- Trip Setting:
- 900 A Hold, 1700 A Trip
MSRP $725.00Surplus $655.44 -
Contact Us For Quote
Square D FA36100 Molded Case Breakers (MCCBs)
MSRP $1,011.74Surplus $383.82SKU: C15-7751 Brand: Square D MPN: FA36100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-7751
- Data Sheet:
- SchneiderElectric-SquareD_04371_1_2_DATA.pdf
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Interrupting Rating:
- 14 kA at 600 VAC
- Application:
- Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial
- Series:
- FA
- Short Description:
- 600 VAC, 250 VDC, 100 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Voltage Rating:
- 600 VAC, 250 VDC
- Current Rating:
- 100 A
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Type:
- Molded Case, Thermal Magnetic, Main
- Installation:
- Plug-On
- Catalog:
- SchneiderElectric-SquareD_00096_25_28_CAT.pdf
- Number of Poles:
- 3
- Used On:
- I-Line Panelboard and Switchboard
MSRP $1,011.74Surplus $383.82 -
Contact Us For Quote
Square D FA361001021 Molded Case Breakers (MCCBs)
MSRP $2,608.00Surplus $427.42SKU: C15-7041 Brand: Square D MPN: FA361001021 UPC: Shipping Weight: 6.00 lbs. Shipping Height: 5.00 In. Shipping Length: 10.00 In. Shipping Width: 7.00 In. Product...- SKU:
- C15-7041
- Voltage Rating:
- 600 VAC, 250 VDC
- Short Description:
- 600 VAC, 250 VDC, 100 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_04372_1_2_DATA.pdf
- Interrupting Rating:
- 10 kA
- Type:
- Molded Case, Thermal Magnetic
- Number of Poles:
- 3
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Current Rating:
- 100 A
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA
- Trip Setting:
- 900 to 1700 A
- Used On:
- Class 650, 734, 820 Panelboard/Switchboard
- Application:
- Power Distribution
MSRP $2,608.00Surplus $427.42 -
Contact Us For Quote
Square D FAL22100 Molded Case Breakers (MCCBs)
MSRP $1,368.00Surplus $289.30SKU: E30-12536 Brand: Square D MPN: FAL22100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- E30-12536
- Short Description:
- 240 VAC, 250 VDC, 100 A, 10/5 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Terminal Type:
- Lug
- Prop 65 Warning:
- Yes
- Interrupting Rating:
- 10 kA at 240 VAC, 25 kA at 480 VAC, 25 kA at 600 VAC
- Type:
- Thermal Magnetic
- Data Sheet:
- SchneiderElectric-SquareD_04411_1_2_DATA.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Frame Type:
- F
- Size:
- 3 Inch Width x 4.13 Inch Depth x 6 Inch Height
- Approval:
- UL, CSA, IEC, Federal Specification W-C-375B/GEN
- Series:
- FA
- Voltage Rating:
- 240 VAC
- Catalog:
- SchneiderElectric-SquareD_00096_25_26_CAT.pdf
- Number of Poles:
- 2
- Current Rating:
- 100 A
MSRP $1,368.00Surplus $289.30 -
Contact Us For Quote
Square D FAL24100 Molded Case Breakers (MCCBs)
MSRP $703.00Surplus $144.47SKU: U00-8056 Brand: Square D MPN: FAL24100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- U00-8056
- Number of Poles:
- 2
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA, IEC, Federal Specification W-C-375B/GEN
- Series:
- FA
- Data Sheet:
- SchneiderElectric-SquareD_04426_1_2_DATA.pdf
- Current Rating:
- 100 A
- Frame Type:
- F
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Terminal Type:
- Lug
- Catalog:
- SchneiderElectric-SquareD_00096_25_26_CAT.pdf
- Voltage Rating:
- 480 VAC, 250 VDC
- Type:
- Thermal Magnetic
- Short Description:
- 480 VAC, 250 VDC, 100 A, 18/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Interrupting Rating:
- 18 kA at 480/600 VAC
- Size:
- 3 Inch Width x 4.13 Inch Depth x 6 Inch Height
MSRP $703.00Surplus $144.47 -
Contact Us For Quote
Square D FAL26100 Molded Case Breakers (MCCBs)
MSRP $648.38Surplus $175.06SKU: C15-16093 Brand: Square D MPN: FAL26100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16093
- Current Rating:
- 100 A
- Series:
- FA
- Size:
- 3 Inch W x 4.13 Inch D x 6 Inch H
- Short Description:
- 600 VAC, 250 VDC, 100 A, 14/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Maximum AC Voltage Rating:
- 600 V
- Terminal Type:
- Line Lug, Load Lug
- Prop 65 Warning:
- Yes
- Interrupting Rating:
- 25 kA at 240 VAC, 18 kA at 480 VAC Star/277 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC Star/347 VAC, 14 kA at 600 VAC (UL/CSA/NOM), 10/2.5 kA at 415 VAC (IEC), 10 kA at 250 VDC
- Voltage Rating:
- 240/480/600 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz, 600 VAC Star/347 VAC at 50/60 Hz (UL/CSA/NOM), 415 VAC at 50/60 Hz (IEC), 250 VDC
- Approval:
- UL, CSA
- Number of Poles:
- 2
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_00096_25_26_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_04434_1_2_DATA.pdf
- Frame Type:
- F
MSRP $648.38Surplus $175.06 -
Contact Us For Quote
Square D FAL321001021 Molded Case Breakers (MCCBs)
MSRP $1,000.00Surplus $482.16SKU: C15-8564 Brand: Square D MPN: FAL321001021 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-8564
- Series:
- FA
- Prop 65 Warning:
- Yes
- Type:
- Molded Case, Thermal Magnetic
- Approval:
- UL, CSA
- Voltage Rating:
- 240 VAC at 50/60 Hz (UL/CSA/NOM)
- Frame Type:
- F
- Interrupting Rating:
- 10 kA at 240 VAC (UL/CSA/NOM), 10/2.5 kA at 415 VAC (IEC)
- Data Sheet:
- SchneiderElectric-SquareD_04451_1_2_DATA.pdf
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 240 V
- Terminal Type:
- Line Lug, Load Lug
- Size:
- 4.5 Inch W x 4.13 Inch D x 6 Inch H
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Short Description:
- 240 VAC, 250 VDC, 100 A, 10/5 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker
MSRP $1,000.00Surplus $482.16 -
Contact Us For Quote
Square D FAL341001021 Molded Case Breakers (MCCBs) 3P 100A 50/60Hz 3Ph EA
MSRP $2,200.00Surplus $249.98SKU: C15-7026 Brand: Square D MPN: FAL341001021 UPC: Shipping Weight: 5.05 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In. Product...- SKU:
- C15-7026
- Short Description:
- 480 VAC, 250 VDC, 100 A, 18/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker
- Type:
- Molded Case, Thermal Magnetic
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Interrupting Rating:
- 25 kA at 240 VAC, 18 kA at 480 VAC Star/277 VAC, 18 kA at 480 VAC (UL/CSA/NOM), 10/2.5 kA at 415 VAC (IEC), 10 kA at 250 VDC
- Number of Poles:
- 3
- Terminal Type:
- Line Lug, Load Lug
- Series:
- FA
- Voltage Rating:
- 240/480 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz (UL/CSA/NOM), 415 VAC at 50/60 Hz (IEC), 250 VDC
- Size:
- 4.5 Inch W x 4.13 Inch D x 6 Inch H
- Frame Type:
- F
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 480 V
- Data Sheet:
- SchneiderElectric-SquareD_04480_1_2_DATA.pdf
- Prop 65 Warning:
- Yes
MSRP $2,200.00Surplus $249.98 -
Contact Us For Quote
Square D FAL36100 Molded Case Breakers (MCCBs)
MSRP $2,500.00Surplus $317.43SKU: C15-6996 Brand: Square D MPN: FAL36100 UPC: 78590142378 Shipping Weight: 4.60 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In...- SKU:
- C15-6996
- TS PIK:
- 120072265
- Short Description:
- 600 VAC, 250 VDC, 100 A, 3-Pole, F-Frame, Line/Load Lug Terminal Unit Mount, Thermal Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker
- Voltage Rating:
- 600 VAC, 250 VDC
- Frame Type:
- F
- Number of Poles:
- 3
- Series:
- FAL
- Current Rating:
- 100 A
- Interrupting Rating:
- 25 kA at 120/240 VAC, 18 kA at 277/480 VAC, 14 kA at 347/600 VAC, 10 kA at 125/250 VDC Symmetrical
- Data Sheet:
- SchneiderElectric-SquareD_12909_1_2_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_03392_11_8_CAT.pdf
- Size:
- 4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Terminal Type:
- Line and Load Lug
- Type:
- Thermal Magnetic, Molded Case
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA, IEC
- Maximum AC Voltage Rating (V):
- 600
- Maximum DC Voltage Rating (V):
- 250
MSRP $2,500.00Surplus $317.43 -
Contact Us For Quote
Square D FAL361001021 Molded Case Breakers (MCCBs)
MSRP $1,707.00Surplus $460.89SKU: C15-16126 Brand: Square D MPN: FAL361001021 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16126
- Size:
- 4.5 Inch W x 4.13 Inch D x 6 Inch H
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Current Rating:
- 100 A
- Maximum AC Voltage Rating:
- 600 V
- Data Sheet:
- SchneiderElectric-SquareD_04499_1_2_DATA.pdf
- Approval:
- UL, CSA
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Line Lug, Load Lug
- Type:
- Molded Case, Thermal Magnetic
- Series:
- FA
- Voltage Rating:
- 240/480/600 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz, 600 VAC Star/347 VAC at 50/60 Hz (UL/CSA/NOM), 415 VAC at 50/60 Hz (IEC), 250 VDC
- Prop 65 Warning:
- Yes
- Frame Type:
- F
- Interrupting Rating:
- 25 kA at 240 VAC, 18 kA at 480 VAC Star/277 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC Star/347 VAC, 14 kA at 600 VAC at 50/60 Hz (UL/CSA/NOM), 10/2.5 kA at 415 VAC at 50/60 Hz (IEC), 10 kA at 250 VDC
- Number of Poles:
- 3
- Short Description:
- 600 AC, 250 VDC, 100 A, 14/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker
MSRP $1,707.00Surplus $460.89 -
Square D FCL34100 Molded Case Breakers (MCCBs)
MSRP $3,650.00Surplus $1,560.00SKU: C15-7035 Brand: Square D MPN: FCL34100 UPC: Shipping Weight: 3.30 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-7035
- Terminal Type:
- Line Lug, Load Lug
- Short Description:
- 480 VAC, 250 VDC, 100 A, 65 kA, 3-Pole, F-Frame, Individually Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Interrupting Rating:
- 100 kA at 240 VAC, 65 kA at 480 VAC Star/277 VAC or 480 VAC (UL/CSA/NOM), 10 kA at 240/415 VAC (IEC)
- Voltage Rating:
- 240 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz, 480 VAC at 50/60 Hz (UL/CSA/NOM), 240/415 VAC at 50/60 Hz (IEC)
- Catalog:
- SchneiderElectric-SquareD_00935_11_11_11_23_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 480 V
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Size:
- 4.5 Inch W x 4.13 Inch D x 6 Inch H
- Approval:
- UL, CSA, CE
- Country of Origin:
- United States
MSRP $3,650.00Surplus $1,560.00 -
Contact Us For Quote
Square D FH26100AB Molded Case Breakers (MCCBs)
MSRP $1,368.00Surplus $369.36SKU: L19-6514 Brand: Square D MPN: FH26100AB UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- L19-6514
- Approval:
- UL, CSA
- Catalog:
- SchneiderElectric_00256_11_9_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_04547_1_2_DATA.pdf
- Type:
- Molded Case
- Used On:
- Class 650/734/820 I-Line Panelboard/Switchboard
- Application:
- Power Distribution
- Trip Setting:
- 900 to 1700 A
- Interrupting Rating:
- 10/65 kA at 240 VAC, 25 kA at 480 VAC Star/277 VAC or 480 VAC, 18 kA at 600 VAC Star/347 VAC or 600 VAC (UL/CSA/NOM); 10 kA at 415 VAC (IEC); 50 kA at 250 VDC
- Current Rating:
- 100 A
- Voltage Rating:
- 240/480/600 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz, 600 VAC Star/347 VAC at 50/60 Hz (UL/CSA/NOM), 415 VAC at 50/60 Hz (IEC), 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Series:
- FH
- Number of Poles:
- 2
- Short Description:
- 240/480/600 VAC, 250 VDC, 100 A, 65/25/18/10 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
MSRP $1,368.00Surplus $369.36 -
Contact Us For Quote
Square D FH26100AC Molded Case Breakers (MCCBs)
MSRP $1,368.00Surplus $369.36SKU: L19-6515 Brand: Square D MPN: FH26100AC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- L19-6515
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Series:
- 650, FH
- Number of Poles:
- 2
- Short Description:
- 600 VAC/250 VDC, 100 A, 18 kA, 2-Pole, 100A-Frame, Thermal Magnetic, Panelboard Molded Case Circuit Breaker
- Type:
- Molded Case, Thermal Magnetic, Main
- Catalog:
- SchneiderElectric-SquareD_00096_29_CAT.pdf
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Data Sheet:
- SchneiderElectric-SquareD_12915_1_2_DATA.pdf
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Application:
- Construction
- Used On:
- I-Line Panelboard and Switchboard
- Interrupting Rating:
- 18 kA at 600 VAC
- Current Rating:
- 100 A
- Installation:
- Plug-On
- Voltage Rating:
- 600 VAC, 250 VDC
MSRP $1,368.00Surplus $369.36 -
Contact Us For Quote
Square D FH26100BC Molded Case Breakers (MCCBs)
MSRP $1,080.04Surplus $291.61SKU: C15-16277 Brand: Square D MPN: FH26100BC UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16277
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Short Description:
- 240/480/600 VAC, 250 VDC, 100 A, 65/25/18/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Type:
- Molded Case
- Current Rating:
- 100 A
- Catalog:
- SchneiderElectric_00256_11_9_CAT.pdf
- Number of Poles:
- 2
- Application:
- Power Distribution
- Data Sheet:
- SchneiderElectric-SquareD_04548_1_2_DATA.pdf
- Voltage Rating:
- 240/480/600 VAC at 50/60 Hz, 480 VAC Star/277 VAC at 50/60 Hz, 600 VAC Star/347 VAC at 50/60 Hz (UL/CSA/NOM), 240/415 VAC at 50/60 Hz (IEC), 250 VDC
- Used On:
- Class 650/734/820 I-Line Panelboard/Switchboard
- Approval:
- UL, CSA
- Trip Setting:
- 900 to 1700 A
- Interrupting Rating:
- 65 kA at 240 VAC, 25 kA at 480 VAC Star/277 VAC or 480 VAC, 18 kA at 600 STAR VAC/347 VAC or 600 VAC (UL/CSA/NOM), 10 kA at 415 VAC (IEC), 50 kA at 250 VDC
MSRP $1,080.04Surplus $291.61 -
Contact Us For Quote
Square D FH36100 Molded Case Breakers (MCCBs) EA
MSRP $1,050.00Surplus $1,560.00SKU: C15-7174 Brand: Square D MPN: FH36100 UPC: Shipping Weight: 5.40 lbs. Shipping Height: 6.00 In. Shipping Length: 9.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-7174
- Short Description:
- 240/480/600 VAC, 250 VDC, 100 A, 65/25/18/10 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Interrupting Rating:
- 18 kA at 600 VAC
- Data Sheet:
- SchneiderElectric-SquareD_04564_1_2_DATA.pdf
- Type:
- Molded Case, Thermal Magnetic, Main
- Catalog:
- SchneiderElectric_00256_11_9_CAT.pdf
- Series:
- 650, FH
- Voltage Rating:
- 600 VAC, 250 VDC
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Approval:
- UL 489, CSA, IEC, Federal Specification W-C-375B/GEN
- Installation:
- Plug-On
- Used On:
- I-Line Panelboard and Switchboard
- Application:
- Construction
MSRP $1,050.00Surplus $1,560.00 -
Contact Us For Quote
Square D FHL36000M Molded Case Breakers (MCCBs)
MSRP $1,191.00Surplus $219.94SKU: S21-2325 Brand: Square D MPN: FHL36000M UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- S21-2325
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC, 250 VDC
- Frame Type:
- FA/LA
- Short Description:
- 600 VAC, 100 A, 25 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Automatic Molded Case Switch
- Terminal Type:
- Line and Load Lug
- Interrupting Rating:
- 65 kA at 240 VAC, 18 kA at 600 VAC, 25 kA at 480 VAC, 10 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Type:
- Molded Case, Thermal Magnetic
- Current Rating:
- 100 A
- Size:
- 4.5 Inch Width x 4.13 Inch Depth x 6.4 Inch Height
- Data Sheet:
- SchneiderElectric-SquareD_04571_1_2_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_00935_11_20_CAT.pdf
- Number of Poles:
- 3
- Approval:
- UL, CSA
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
MSRP $1,191.00Surplus $219.94 -
Contact Us For Quote
Square D FHP36100 Molded Case Breakers (MCCBs)
MSRP $1,111.00Surplus $299.97SKU: C15-16299 Brand: Square D MPN: FHP36100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16299
- Short Description:
- 600 VAC, 250 VDC, 100 A, 18/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Prop 65 Warning:
- Yes
- Terminal Type:
- OFF End Lug
- Series:
- FH
- Installation/Operator:
- SchneiderElectric-SquareD_00076_INST.pdf
- Frame Type:
- F
- Voltage Rating:
- 600 VAC, 250 VDC
- Interrupting Rating:
- 18 kA at 600 VAC
- Approval:
- UL, CSA, IEC, Federal Specification W-C-375B/GEN
- Data Sheet:
- SchneiderElectric-SquareD_04585_1_2_DATA.pdf
- Current Rating:
- 100 A
- Type:
- Thermal Magnetic
- Size:
- 4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_00096_5-9_17_23_CAT.pdf
MSRP $1,111.00Surplus $299.97 -
Contact Us For Quote
Square D FI36100 Molded Case Breakers (MCCBs)
MSRP $5,000.00Surplus $1,350.00SKU: C15-16308 Brand: Square D MPN: FI36100 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16308
- Catalog:
- SchneiderElectric_00256_11_9_CAT.pdf
- Prop 65 Warning:
- Yes
- Current Rating:
- 100 A
- Type:
- Molded Case, Thermal Magnetic, Main
- Approval:
- UL 489, CSA, IEC
- Short Description:
- 600 VAC, 250 VDC, 100 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker
- Number of Poles:
- 3
- Interrupting Rating:
- 200 kA at 240/480 VAC, 100 kA at 600 VAC
- Installation:
- Plug-On
- Voltage Rating:
- 600 VAC, 250 VDC
- Series:
- 650, FI
- Trip Setting:
- 900 A Hold, 1700 A Trip
- Installation/Operator:
- SchneiderElectric-SquareD_00425_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_04592_1_DATA.pdf
- Used On:
- I-Line Panelboard and Switchboard
MSRP $5,000.00Surplus $1,350.00 -
Contact Us For Quote
Square D HDA261001 Molded Case Breakers (MCCBs)
MSRP $1,365.00Surplus $368.55SKU: C15-18745 Brand: Square D MPN: HDA261001 UPC: 78590141905 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18745
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Number of Poles:
- 2
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46376_1-3_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 100 A
- CAD Drawings:
- SchneiderElectric_29555_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Trip Setting:
- 800 A (Hold), 1700 A (Trip)
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, H-Frame, AB Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Application:
- Distribution
- Approval:
- UL, CSA, CE
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Series:
- HD
- Type:
- Thermal Magnetic, Current Limiting
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
MSRP $1,365.00Surplus $368.55 -
Contact Us For Quote
Square D HDA261002 Molded Case Breakers (MCCBs)
MSRP $943.00Surplus $254.61SKU: C15-18746 Brand: Square D MPN: HDA261002 UPC: 78590175038 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18746
- CAD Drawings:
- SchneiderElectric_29556_1_CAD.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Application:
- Distribution
- Prop 65 Warning:
- Yes
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Type:
- Thermal Magnetic, Current Limiting
- Trip Setting:
- 800 A (Hold), 1700 A (Trip)
- Number of Poles:
- 2
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, H-Frame, AC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Approval:
- UL, CSA, CE
- Data Sheet:
- SchneiderElectric-SquareD_46377_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
MSRP $943.00Surplus $254.61 -
Contact Us For Quote
Square D HDA261004 Molded Case Breakers (MCCBs)
MSRP $990.30Surplus $267.38SKU: C15-18747 Brand: Square D MPN: HDA261004 UPC: 78590175435 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18747
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, H-Frame, BC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Number of Poles:
- 2
- Prop 65 Warning:
- Yes
- Series:
- HD
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Type:
- Thermal Magnetic, Current Limiting
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Data Sheet:
- SchneiderElectric-SquareD_46378_1-3_DATA.pdf
- Application:
- Distribution
- CAD Drawings:
- SchneiderElectric_29557_1_CAD.pdf
- Trip Setting:
- 800 A (Hold), 1700 A (Trip)
MSRP $990.30Surplus $267.38 -
Contact Us For Quote
Square D HDA36100 Molded Case Breakers (MCCBs) EA
MSRP $1,361.00Surplus $836.70SKU: C15-5195 Brand: Square D MPN: HDA36100 UPC: 785901419983 Shipping Weight: 5.55 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-5195
- Series:
- HD
- Type:
- Thermal Magnetic
- Type:
- Current Limiting
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC
- Interrupting Rating:
- 20 kA at 250 Volt DC
- Application:
- Distribution
- Trip Setting:
- 800 A (Hold)
- Trip Setting:
- 1700 Amp (Trip)
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46405_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawing:
- SchneiderElectric_29583_1_CAD.pdf
- Manufacturer Warranty:
- SchneiderElectric-SquareD_00002_WARR.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
MSRP $1,361.00Surplus $836.70 -
Contact Us For Quote
Square D HDA36100U31X Molded Case Breakers (MCCBs)
MSRP $1,444.00Surplus $389.88SKU: C15-16417 Brand: Square D MPN: HDA36100U31X UPC: 78590115442 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16417
- Prop 65 Warning:
- Yes
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Panelboard Molded Case Circuit Breaker
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Series:
- HD
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Application:
- Distribution
- Data Sheet:
- SchneiderElectric-SquareD_46407_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard
- Number of Poles:
- 3
MSRP $1,444.00Surplus $389.88 -
Contact Us For Quote
Square D HDA36100U33X Molded Case Breakers (MCCBs)
MSRP $1,501.20Surplus $405.32SKU: C15-16418 Brand: Square D MPN: HDA36100U33X UPC: 78590140358 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16418
- Series:
- HD
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Ammeter, Micrologic 3.2 S, LSI, Current Limiting, Panelboard Molded Case Circuit Breaker
- Number of Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Current Rating:
- 100 A
- Data Sheet:
- SchneiderElectric-SquareD_46408_1-3_DATA.pdf
- Application:
- Distribution
- Type:
- Electronic, Standard, Micrologic 3.2 S, LSI, Current Limiting
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Used On:
- Class 611/612 I-Line Panelboard
MSRP $1,501.20Surplus $405.32 -
Contact Us For Quote
Square D HDA36100U44X Molded Case Breakers (MCCBs)
MSRP $2,339.00Surplus $631.53SKU: C15-16419 Brand: Square D MPN: HDA36100U44X UPC: 78590113345 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16419
- Used On:
- Class 611/612 I-Line Panelboard
- Application:
- Distribution
- Data Sheet:
- SchneiderElectric-SquareD_46409_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric_29584_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Electronic, Ammeter, Micrologic 6.2 A, LSIG, Current Limiting
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Ammeter, Micrologic 6.2 A, LSIG, Current Limiting, Panelboard Molded Case Circuit Breaker
MSRP $2,339.00Surplus $631.53 -
Contact Us For Quote
Square D HDL26100 Molded Case Breakers (MCCBs)
MSRP $923.00Surplus $249.21SKU: C15-18760 Brand: Square D MPN: HDL26100 UPC: 78590157794 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18760
- Approval:
- UL, CSA, CE
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Terminal Type:
- Line/Load Lug
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 2-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- SchneiderElectric-SquareD_74671_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Data Sheet:
- SchneiderElectric-SquareD_46436_1-3_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
MSRP $923.00Surplus $249.21 -
Contact Us For Quote
Square D HDL36100SA Molded Case Breakers (MCCBs)
MSRP $3,082.00Surplus $832.14SKU: C15-16433 Brand: Square D MPN: HDL36100SA UPC: 78590152557 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16433
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Prop 65 Warning:
- Yes
- Data Sheet:
- SchneiderElectric-SquareD_46491_1-3_DATA.pdf
- Maximum AC Voltage Rating:
- 600 V
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Maximum DC Voltage Rating:
- 250 V
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Series:
- HD
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Frame Type:
- H
- Approval:
- UL, CSA, CE
MSRP $3,082.00Surplus $832.14 -
Square D HDL36100U31X Molded Case Breakers (MCCBs)
MSRP $1,236.88Surplus $333.95SKU: C15-16434 Brand: Square D MPN: HDL36100U31X UPC: 78590154832 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16434
- Current Rating:
- 100 A
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Approval:
- UL, CSA, CE
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46492_1-3_DATA.pdf
- Series:
- HD
- Number of Poles:
- 3
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Molded Case Circuit Breaker
- Country of Origin:
- Mexico
MSRP $1,236.88Surplus $333.95 -
Contact Us For Quote
Square D HGA261001 Molded Case Breakers (MCCBs)
MSRP $1,737.00Surplus $468.99SKU: C15-16511 Brand: Square D MPN: HGA261001 UPC: 78590165152 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16511
- Series:
- HG
- Type:
- Thermal Magnetic, Current Limiting
- Number of Poles:
- 2
- Application:
- Distribution
- CAD Drawings:
- SchneiderElectric-SquareD_73183_1_CAD.pdf
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 18 kA, 2-Pole, H-Frame, AB Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_46566_1-3_DATA.pdf
- Interrupting Rating:
- 18 kA at 600 VAC, 20 kA at 250 VDC
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Trip Setting:
- 800 A (Hold), 1700 A (Trip)
- Current Rating:
- 100 A
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
MSRP $1,737.00Surplus $468.99
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
