Westinghouse BAB1015 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-9421

TS PIK:

21508666

Series:

BAB

Terminal Type:

Extended Tang Line, Box Lug Load

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature, Circuit Breaker

Type:

Thermal Magnetic

Interrupting Rating:

10 kA at 120/240 VAC, 5 kA at 24 to 48 VDC, 3.8 kA at 62.5 VDC

Current Rating:

15 A

Number of Poles:

1

Mounting:

Bolt-On

Wire Size:

14 to 4 AWG Copper/Aluminum (Load)

Catalog:

Eaton_03771_V4T1_11_V4T1_12_V4T1_46_CAT.pdf

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA

Main Category:

Miniature Circuit Breakers (MCBs)

GENERAL ELECTRIC THQL1115 Miniature Circuit Breakers (MCBs) 1P 15A 120V EA

SKU:

C15-2947

Approval:

UL

Amps:

15 A

Frame:

Q-Line

Interrupting Rating:

10 kA at 120/240 VAC

Maximum AC Voltage:

240 V

Poles:

1

Terminal Type:

Plug-On

Type:

Thermal Magnetic

Type:

Compact

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum, 1" Plug-In Mount, Box Terminal, Q-Line Frame, Molded Case, Non-Interchangeable Trip, Compact, Fixed Thermal Magnetic, Circuit Breaker

TS PIK:

555073

Voltage Rating:

120/240 VAC

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00006_INST.pdf

Number of Poles:

1

Current Rating:

15 A

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_8_6_30_CAT.pdf

Mounting:

Plug-On

Series:

THQL

Maximum AC Voltage Rating:

240 V

Frame Type:

Q-Line

Country of Origin:

United States

GENERAL ELECTRIC THQP115 Miniature Circuit Breakers (MCBs) 1P 15A 120V EA

SKU:

C15-3087

Approval:

UL

Amps:

15 A

Frame:

Q-Line

Interrupting Rating:

10 kA at 120/240 VAC

Maximum AC Voltage:

240 V

Poles:

1

Size:

1/2 Inch Width

Terminal Type:

Plug-On

Type:

Thermal Magnetic

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum, 1/2" Plug-In Mount, Box Terminal, Q-Line Frame, Molded Case, Fixed Thermal Magnetic, Circuit Breaker

TS PIK:

112127458

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00472_1_CAD.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00004_INST.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

1

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_8_6_30_CAT.pdf

Mounting:

Plug-On

Maximum AC Voltage Rating:

240 V

Frame Type:

Q-Line

Country of Origin:

United States

Siemens Q215 Miniature Circuit Breakers (MCBs) 2P 15A

SKU:

C15-6099

TS PIK:

115277070

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 2-Pole, Plug-On Mount, QP-Frame, Common Trip, Circuit Breaker

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Interrupting Rating:

10 kA

Number of Poles:

2

Size:

3 Inch Width x 3 Inch Depth x 2 Inch Height

Catalog:

SiemensAG_23945_7_20_CAT.pdf

Mounting:

Plug-On

Installation/Operator:

SiemensAG_00053_INST.pdf

Type:

Common Trip

Used On:

Load Center

Country of Origin:

MEX

Approval:

UL 489

Poles:

2

Square D QOU115 Miniature Circuit Breakers (MCBs)

SKU:

C15-4929

Series:

QOU

Type:

Miniature

Type:

Standard

Approval:

UL

Approval:

CSA

Size:

0.75 Inch Width x 2.95 Inch Depth x 4.05 Inch Height

Volts:

120/240 VAC 50/60 Hertz

Volts:

48 VDC

Amps:

32 A

Used On:

OEM

Poles:

1

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Slotted Box Lug Line/Load

Wire Size:

14 to 2 AWG (Copper/Aluminum)

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 10 kA Interrupt, 1-Pole, 14 to 2 AWG Copper/Aluminum, Unit Mount, Slotted Box Lug Line/Load Terminal, Standard

Catalog:

SchneiderElectric-SquareD_32357_7_19_7_21_CAT.pdf

Data Sheet:

SchneiderElectric_21454_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02170_INST.pdf

CAD Drawing:

SchneiderElectric_30265_1_CAD.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

113285771

Voltage Rating:

120/240 VAC

CAD Drawings:

SchneiderElectric_30265_1_CAD.pdf

Number of Poles:

1

Current Rating:

15 A

Country of Origin:

Mexico

GENERAL ELECTRIC THHQB1115 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-3920

Type:

Thermal Magnetic

Type:

Compact

Approval:

UL

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Interrupting Rating:

22 kA at 120/240 VAC

Terminal Type:

Bolt-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120/240 VAC, 15 A, 22 kA Interrupt, 1-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum Load Lug Terminal, 1" Bolt-On Mount, Q-Line Frame, Non-Interchangeable Trip, Compact, Fixed Thermal Magnetic

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_38_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00005_INST.pdf

CAD Drawing:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01786_1_CAD.pdf

TS PIK:

112128179

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01786_1_CAD.pdf

Voltage Rating:

120/240 VAC

Number of Poles:

1

Current Rating:

15 A

Mounting:

Bolt-On

Series:

THHQ

Country of Origin:

United States

Eaton CL115 Miniature Circuit Breakers (MCBs) 1P 15A 240V EA

SKU:

C15-1522

Type:

With Angle Adapter

Approval:

UL 489

Volts:

120/240 V

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 V, 15 A, 10 kA, 1-Pole, 14 to 4 AWG Copper/Aluminum, Thermal Magnetic, Type CL

Catalog:

Eaton_00001_V1T1_104_CAT.pdf

TS PIK:

116434775

Voltage Rating:

120/240 VAC

Number of Poles:

1

Current Rating:

15 A

Series:

CL

Country of Origin:

Dominican Republic

Used On:

Load centers

Square D QOB115 Miniature Circuit Breakers (MCBs) 15A 120V

SKU:

C15-4756

Series:

QOB

Type:

Miniature

Type:

Standard

Approval:

UL

Approval:

CSA

Volts:

120/240 VAC 50/60 Hertz

Volts:

48 VDC

Amps:

32 A

Used On:

NQ Panelboard

Poles:

1

Interrupting Rating:

10 kA

Interrupting Rating:

5 kA at 48 Volt DC

Installation:

Bolt-On

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 10 kA, 1-Pole, Q-Frame, Bolt-On Mount, Pressure Plate Terminal, Miniature, Standard

Catalog:

SchneiderElectric-SquareD_32357_9_16_CAT.pdf

Data Sheet:

SchneiderElectric_21231_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02166_INST.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

115339800

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

Ireland

THQL1115AF2 Miniature Circuit Breakers (MCBs) 1P 15A 120V

SKU:

C15-2639

Type:

Thermal Magnetic

Type:

Compact

Approval:

UL

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Plug-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, 14 to 10 AWG Copper/Aluminum, 1" Plug-In Mount, Box Terminal, Q-Line Frame, Molded Case, Non-Interchangeable Trip, Compact, Fixed Thermal Magnetic, Arc Fault

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_8_6_31_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00006_INST.pdf

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Mounting:

Plug-On

Series:

THQL

Country of Origin:

United States

GENERAL ELECTRIC THQL1115GFT Miniature Circuit Breakers (MCBs) 1P 15A EA

SKU:

C15-5926

Type:

Compact

Terminal Type:

Plug-On

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Interrupting Rating:

10 kA at 120 VAC

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum, 1" Plug-In Mount, Box Terminal, Q-Line Frame, Molded Case, Common Trip, Compact, Fixed Thermal Magnetic, Ground Fault, Self-Test, Circuit Breaker

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_8_6_32_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00006_INST.pdf

Specification/Technical:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00341_1_2_SPEC.pdf

TS PIK:

126205042

Mounting:

Plug-On

Approval:

UL

Maximum AC Voltage Rating:

240 V

Frame Type:

Q-Line

Country of Origin:

United States

Poles:

1

Eaton CHFCAF115 Miniature Circuit Breakers (MCBs) CHF 1P 15A 240V 50/60Hz 1Ph EA

SKU:

C15-1638

Series:

CHF

Type:

Class K5

Approval:

UL

Size:

3.5 Inch Length x 1 Inch Width x 3 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

CH Series Loadcenter

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Clip (Line)

Poles:

1

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Clip Line Terminal, Plug-On Mount, Thermal Magnetic, Common Trip

Catalog:

Eaton_00071_V1T1_36_V1T1_38_CAT.pdf

Data Sheet:

Mersen_00082_PF30_PF31_DATA.pdf

CAD Drawing:

Mersen_00269_1_CAD.pdf

TS PIK:

125134628

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

1

Country of Origin:

United States

Eaton BAB2015 Miniature Circuit Breakers (MCBs) 2P 15A 120V EA

SKU:

C15-1035

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

10 kA at 120/240 VAC

Interrupting Rating:

5 kA at 24 to 48/62.5/80 Volt DC

Terminal Type:

Extended Tang Line

Terminal Type:

Box Lug Load

Wire Size:

14 to 4 AWG Copper/Aluminum (Load)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_11_V4T1_12_V4T1_46_CAT.pdf

TS PIK:

21508677

Voltage Rating:

120/240 VAC

Number of Poles:

2

Current Rating:

15 A

Country of Origin:

Dominican Republic

Square D QOB115VH Miniature Circuit Breakers (MCBs)

SKU:

C15-6385

TS PIK:

125439266

Used On:

NQ Panelboard

Installation/Operator:

SchneiderElectric-SquareD_02166_INST.pdf

Current Rating:

15 A

Catalog:

SchneiderElectric-SquareD_32357_9_16_CAT.pdf

Series:

QOB-VH

Type:

Miniature, Standard

Voltage Rating:

120/240 VAC

Number of Poles:

1

Data Sheet:

SchneiderElectric_21239_1_2_DATA.pdf

Interrupting Rating:

22 kA at 120/240 VAC

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 22 kA, 1-Pole, Q-Frame, Bolt-On Mount, Pressure Plate Terminal, Miniature, Standard, Panelboard Circuit Breaker

Country of Origin:

Mexico

Approval:

UL, CSA

Installation:

Bolt-On

Poles:

1

Eaton BAB1015S Miniature Circuit Breakers (MCBs) EA

SKU:

C15-9286

Size:

2.2 Inch Width x 3.8 Inch Depth x 4.8 Inch Height

Mounting:

Bolt-On

Type:

Thermal Magnetic, Non-Interchangeable Trip, Miniature

Voltage Rating:

120/240 VAC

Short Description:

120/240 VAC, 24/48 VDC, 15 A, 10 kA Interrupt, 1-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Type BAB, Non-Interchangeable Industrial Circuit Breaker (7 per Pack)

Number of Poles:

1

Terminal Type:

Steel Box Lug Standard Load

Interrupting Rating:

10 kA

Current Rating:

15 A

Wire Size:

14 to 4 AWG Copper/Aluminum (Standard Load)

Approval:

UL 489, CSA

Country of Origin:

Dominican Republic

Poles:

1

Eaton BR115CAF Miniature Circuit Breakers (MCBs) 1P 15A 240V EA

SKU:

C15-1187

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

1 Inch W

Terminal Used On:

Loadcenter

Volts:

120/240 VAC

Gauge:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 1-Pole, Plug-On Mount, Arc Fault Circuit Breaker

Series:

BR

TS PIK:

123423218

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Catalog:

EATCORE00420_V1T1_77.pdf

Used On:

Loadcenter

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Number of Poles:

1

Eaton QCR2015 Miniature Circuit Breakers (MCBs) QCR 2P 15A 240V 50/60Hz 1Ph

SKU:

C15-1644

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL

Approval:

CSA

Size:

5.1 Inch Length x 3.2 Inch Width x 1.2 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Ring/Spade Lug

Short Description:

120/240 VAC, 15 A, 2-Pole, 10 kA, Ring/Spade Lug Fixed Terminal, DIN Rail Rear Mount, Cable-In/Cable-Out, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_23_V4T1_24_CAT.pdf

Data Sheet:

Eaton_53970_1-5_DATA.pdf

Number of Poles:

2 P

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

Dominican Republic

Square D QOB315 Miniature Circuit Breakers (MCBs)

SKU:

C15-4927

TS PIK:

122082360

Installation/Operator:

SchneiderElectric-SquareD_02166_INST.pdf

Type:

Miniature, Standard

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 10 kA, 3-Pole, Q-Frame, Bolt-On Mount, Pressure Plate Terminal, Miniature, Standard, Panelboard Circuit Breaker

Catalog:

SchneiderElectric-SquareD_32357_9_16_CAT.pdf

Current Rating:

15 A

Interrupting Rating:

10 kA at 120/240 VAC, 5 kA at 48 VDC

Used On:

NQ Panelboard

Number of Poles:

3

Voltage Rating:

120/240 VAC

Series:

QOB

Data Sheet:

SchneiderElectric_21366_1_2_DATA.pdf

Country of Origin:

United States

Approval:

UL, CSA

Installation:

Bolt-On

Poles:

3

Eaton BRLH115CAF Miniature Circuit Breakers (MCBs) BR 1P 15A 120V 50/60Hz 1Ph

SKU:

C15-2509

Series:

BR

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON BR AFCI CIRCUIT BREAKER

Type:

Arc Fault

Number of Poles:

1

Mounting:

Plug-On

Current Rating:

15 A

Country of Origin:

United States

Interrupting Rating:

15 kA

Voltage Rating:

120/240 VAC

Used On:

Type BR Loadcenters

Approval:

UL 1699

Eaton QC1015 Din Rail Mounted Circuit Breakers 1P 15A 0Ph EA

SKU:

C15-3417

Series:

QC

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

DIN Rail

Mounting:

Cable Out

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48 VDC

Interrupting Rating:

3800 A at 62.5 VDC

Terminal Type:

Screw

Wire Size:

14 to 10 AWG Aluminum/Copper (Load)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf

TS PIK:

21508933

Number of Poles:

1

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Square D QO315 Miniature Circuit Breakers (MCBs) 3P 15A 240V

SKU:

C15-3748

Series:

QO

Type:

Common Trip

Type:

Miniature

Type:

Standard

Approval:

UL

Approval:

CSA

Size:

2.24 Inch Width x 2.91 Inch Depth x 2.99 Inch Height

Volts:

120/240 VAC 50/60 Hertz

Volts:

48 VDC

Amps:

32 A

Used On:

QO Load Center

Used On:

NQ/NQOD Panelboard/OEM Interior/Speed-D Switchboard Distribution Panel

Poles:

3

Mounting:

Plug-On

Interrupting Rating:

5/10 kA

Terminal Type:

Pressure Plate

Wire Size:

14 to 8 AWG (Copper/Aluminum)

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 5/10 kA Interrupt, 3-Pole, 14 to 8 AWG Copper/Aluminum, Plug-In Mount, Pressure Plate Terminal, Standard

Catalog:

SchneiderElectric-SquareD_32357_1_2_1_3_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_53563_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_01265_INST.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

597393

Number of Poles:

3

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

Mexico

Square D QOB215 Miniature Circuit Breakers (MCBs) 2P 15A 120V

SKU:

C15-6652

TS PIK:

21032636

Type:

Miniature, Standard

Used On:

NQ Panelboard

Voltage Rating:

120/240 VAC

Installation/Operator:

SchneiderElectric-SquareD_02166_INST.pdf

Number of Poles:

2

Current Rating:

15 A

Catalog:

SchneiderElectric-SquareD_32357_9_16_CAT.pdf

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 10 kA, 2-Pole, Q-Frame, Bolt-On Mount, Pressure Plate Terminal, Miniature, Standard, Panelboard Circuit Breaker

Data Sheet:

SchneiderElectric_21295_1_2_DATA.pdf

Interrupting Rating:

10 kA at 120/240 VAC, 5 kA at 48 VDC

Series:

QOB

Country of Origin:

Mexico

Installation:

Bolt-On

Approval:

UL, CSA

Poles:

2

Eaton QBGFT2015 Miniature Circuit Breakers (MCBs) QBGF 2P 15A 240V 50/60Hz 1Ph EA

SKU:

C15-4084

Approval:

UL 489

Size:

2.75 Inch Width x 4.5 Inch Depth x 2 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Interrupting Rating:

10 kA

Terminal Type:

Cable-In/Cable-Out

Wire Size:

14 to 10 AWG (Copper)

Wire Size:

12 to 10 AWG (Aluminum)

Trip Sensitivity:

5 MilliA

Short Description:

120/240 VAC, 15 A, 2-Pole, 10 kA, Common Trip, Thermal Magnetic

Catalog:

Eaton_14663_V4T1_17_CAT.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

2

TS PIK:

126205830

Country of Origin:

United States

Eaton QBHCAF1015 Miniature Circuit Breakers (MCBs)

SKU:

C15-9846

TS PIK:

123106440

Number of Poles:

1

Current Rating:

15 A

Used On:

Sumter Panel

Interrupting Rating:

22 kA

Short Description:

BOLT-ON COMBINATION ARC FAULT 1P 15A 22kA

Size:

3 Inch Width x 4.75 Inch Depth x 1.25 Inch Height

Voltage Rating:

120/240 VAC

Type:

Combination

Approval:

UL 489

Mounting:

Bolt-On

Country of Origin:

Dominican Republic

Poles:

1

Eaton QCR2015T Miniature Circuit Breakers (MCBs) QCR 2P 15A 240V 50/60Hz 1Ph

SKU:

C15-1999

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL

Approval:

CSA

Size:

3 Inch Length x 2 Inch Width x 1 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Ring/Spade Lug

Short Description:

120/240 VAC, 15 A, 2-Pole, 10 kA, Ring/Spade Lug Terminal, DIN Rail Rear Mount, Cable-In/Cable-Out, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_23_V4T1_24_CAT.pdf

Data Sheet:

Eaton_53969_1_2_DATA.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

2 P

Country of Origin:

Dominican Republic

Series:

QCR

GENERAL ELECTRIC THQB1115GF Molded Case Breakers (MCCBs)

SKU:

C15-5910

Size:

1 Inch Width x 2-3/8 Inch Depth x 3-9/32 Inch Height

Terminal Type:

Load Lug

Type:

Molded Case, Fixed Thermal Magnetic, Non-Interchangeable Trip

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_04199_1_CAD.pdf

Current Rating:

15 A

Series:

THQB

Number of Poles:

1

Voltage Rating:

120/240 VAC

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01912_6_36_CAT.pdf

Short Description:

120/240 VAC, 15 A, 1-Pole, 10 kA, 14 to 8 AWG Copper, 12 to 8 AWG Aluminum, Bolt-On Mount, Molded Case, Thermal Magnetic, Self-Test, Ground Fault Circuit Breaker

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00124_INST.pdf

Interrupting Rating:

10 kA

Wire Size:

14 to 8 AWG (Copper), 12 to 8 AWG (Aluminum)

Approval:

UL, UL (Canada and US), CSA

Mounting:

Bolt-On

Used On:

Load Center, Lighting Panelboard

Eaton CL115GF Miniature Circuit Breakers (MCBs) 1P 15A 240V

SKU:

C15-2791

Series:

CL

Type:

Thermal Magnetic

Type:

Compact

Approval:

UL

Volts:

120/240 V

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Trip Sensitivity:

5 MilliA

Short Description:

120/240 V, 15 A, 10 kA, 5 mA Trip Level, 1-Pole, 1" Space, Plug-On Mount

Catalog:

Eaton_36620_V1T1_104_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00118_INST.pdf

CAD Drawing:

ABBElectrificationProducts-ABBGEIndustrialSolutions_04184_1_CAD.pdf

TS PIK:

117057836

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton QBHW2015 Miniature Circuit Breakers (MCBs) QBHW 2P 15A 240V 50/60Hz 1Ph EA

SKU:

C15-2423

Series:

QBHW

Type:

Thermal Magnetic

Approval:

UL

Approval:

CSA

Size:

3.9 Inch Length x 2.1 Inch Width x 4.8 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

22 kA

Terminal Type:

Extended Tang Line Terminal

Terminal Type:

Box Lug Load Terminal

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 22 kA, 2-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_12_CAT.pdf

Number of Poles:

2

Current Rating:

15 A

Voltage Rating:

120/240 VAC

TS PIK:

21510591

Country of Origin:

Dominican Republic

Eaton CHNT1515 Miniature Circuit Breakers (MCBs)

SKU:

C15-6739

Size:

3/4 Inch W

Series:

CH

Voltage Rating:

120/240 VAC

Mounting:

Plug-On

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Non-CTL, Renewal, Circuit Breaker

Catalog:

Eaton_14709_V12T5_24_CAT.pdf

Type:

Thermal Magnetic

Installation/Operator:

Eaton_00008_INST.pdf

Current Rating:

15 A

Wire Size:

14 to 8 AWG (Aluminum/Copper)

Interrupting Rating:

10 kA

Used On:

Loadcenter

Number of Poles:

1

Country of Origin:

Dominican Republic

Application:

HARC

Poles:

1

Eaton HQP2015 Miniature Circuit Breakers (MCBs) HQP 2P 15A 120V 50/60Hz 1Ph

SKU:

C15-2718

Series:

HQP

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10kA at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48/62.5/80 VDC

Terminal Type:

Plug-On

Wire Size:

14 to 4 AWG Aluminum/Copper (Load)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Female Clip Terminal, Plug-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_5_V4T1_6_CAT.pdf

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

Dominican Republic

GENERAL ELECTRIC THHQB32015 Miniature Circuit Breakers (MCBs)

SKU:

C15-5896

Number of Poles:

3

Current Rating:

15 A

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01786_1_CAD.pdf

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_38_CAT.pdf

Voltage Rating:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 22 kA Interrupt, 3-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum Load Lug Terminal, 1" Bolt-On Mount, Q-Line Frame, Non-Interchangeable/Internal Common Trip, Compact, Fixed Thermal Magnetic, Miniature Molded Case Circuit Breaker

Type:

Thermal Magnetic, Compact

Interrupting Rating:

22 kA at 120/240 VAC

Terminal Type:

Bolt-On

Maximum AC Voltage Rating:

240 V

Frame Type:

Q-Line

Approval:

UL

Country of Origin:

United States

Poles:

3

GENERAL ELECTRIC THHQL1115 Miniature Circuit Breakers (MCBs)

SKU:

C15-2122

Type:

With Angle Opening

Approval:

UL

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Interrupting Rating:

22 kA at 120/240 VAC

Terminal Type:

Plug-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120 VAC, 15 A, 22 kA Interrupt, 1-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum Load Lug Terminal, 1" Plug-In Mount, Q-Line Frame, Non-Interchangeable Trip, Compact, Fixed Thermal Magnetic

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_33_CAT.pdf

Installation/Operator:

EmersonElectric-Appleton_00031_INST.pdf

Manufacturer Warranty:

EmersonElectric-Appleton_00002_WARR.pdf

TS PIK:

112128095

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01789_1_CAD.pdf

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Mounting:

Plug-On

Series:

THHQ

Country of Origin:

United States

GENERAL ELECTRIC THQC1115WL Din Rail Mounted Circuit Breakers

SKU:

E30-8028

Terminal Type:

Lug

Interrupting Rating:

10 kA at 120/240 VAC

Current Rating:

15 A

Number of Poles:

1 P

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01788_1_CAD.pdf

Voltage Rating:

120/240 VAC

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_40_CAT.pdf

Type:

Thermal Magnetic, Compact

Country of Origin:

United States

Approval:

UL

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Square D HOMT1515 Molded Case Breakers (MCCBs) EA

SKU:

C15-6523

TS PIK:

109594845

Installation/Operator:

SchneiderElectric-SquareD_00099_INST.pdf

Interrupting Rating:

10 kA

Size:

1 Inch Width x 2.98 Inch Depth x 3.13 Inch Height

Catalog:

SchneiderElectric-SquareD_03264_1_20_CAT.pdf

Current Rating:

15 A

Type:

Tandem

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Box Lug Terminal, Plug-On Mount, Tandem, Miniature Circuit Breaker

Terminal Type:

Box Lug

Number of Poles:

1

Voltage Rating:

120/240 VAC

Country of Origin:

United States

Used On:

Load Center

Mounting:

Plug-On

Approval:

UL

Wire Size:

14 to 8 AWG (Aluminum/Copper)

THQB2115 Miniature Circuit Breakers (MCBs) THQB 2P 15A 240V

SKU:

C15-3468

Type:

Thermal Magnetic

Type:

Compact

Approval:

UL

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Bolt-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum, 1" Bolt-On Mount, Q-Line Frame, Molded Case, Non-Interchangeable/Common Trip, Compact, Fixed Thermal Magnetic

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00015_6_8_6_35_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00005_INST.pdf

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

United States

Bryant BR415 Miniature Circuit Breakers (MCBs)

SKU:

C15-3461

Approval:

UL 489

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

4

Size:

2 Inch Width x 3 Inch Depth x 3 Inch Height

Terminal Type:

Thermal Magnetic

Type:

Independent Trip

Used On:

BR Load Center

Volts:

120/240 VAC

Gauge:

14 to 4 AWG Copper/Aluminum at 65 Deg C

Short Description:

120/240 VAC, (2) 15 A, 10 kA Interrupt, 4-Pole, 14 to 4 AWG Copper/Aluminum Terminal, Non-CTL Plug-On Mount, Quadplex Independent Trip, Thermal Magnetic, Type BR, Circuit Breaker (28 per Pack)

Specification/Technical:

EatonCorp_00332_1_2_SPEC.pdf

TS PIK:

21493998

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Catalog:

EatonCorp_00272_V1T1_88_CAT.pdf

Wire Size:

14 to 4 AWG Copper/Aluminum at 65 Deg C

Number of Poles:

4

Series:

BR

Country of Origin:

Dominican Republic

Challenger HAGF215 Miniature Circuit Breakers (MCBs)

SKU:

C15-8850

Number of Poles:

2

Country of Origin:

United States

Poles:

2

Voltage Rating:

120/240 VAC

Short Description:

NEW Challenger Plug On GFI Circuit Breaker HAGF215 2 Pole 15A 120/240VAC

Current Rating:

15 A

Approval:

UL Listed and CSA Certified

Crouse-Hinds BR115AF Miniature Circuit Breakers (MCBs)

SKU:

C15-5430

TS PIK:

115463477

Type:

Branch Feeder

Voltage Rating:

120/240 VAC

Interrupting Rating:

10 kA

Used On:

BR Type Load Center

Series:

BR

Mounting:

Plug-On

Catalog:

Eaton_36650_V1T1_76_V1T1_78_CAT.pdf

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Branch Feeder, Arc Fault Circuit Breaker

Current Rating:

15 A

Size:

1 Inch Width

Number of Poles:

1

Poles:

1

Construction Feature:

Arc Fault Circuit Interrupter

Approval:

UL 1699

Crouse-Hinds CHF215 Miniature Circuit Breakers (MCBs)

SKU:

C15-5698

TS PIK:

123562708

Current Rating:

15 A

Installation/Operator:

Eaton_00008_INST.pdf

Approval:

UL 489

Wire Size:

(1) 14 to 8 AWG, (2) 14 to 10 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Plug-On Mount, Common Trip, Thermal Magnetic, Mechanical Trip Flag, Circuit Breaker

Voltage Rating:

120/240 VAC

Series:

CHF

Interrupting Rating:

10 kA

Used On:

CH Series Loadcenter

Type:

Thermal Magnetic, Common Trip

Catalog:

Eaton_36601_V1T1_35_V1T1_36_CAT.pdf

Size:

1.5 Inch Length x 1.5 Inch Width x 2.6 Inch Height

Number of Poles:

2

Mounting:

Plug-On

Crouse-Hinds CHT1515 Miniature Circuit Breakers (MCBs)

SKU:

C15-5706

TS PIK:

111022682

Data Sheet:

Eaton_36590_1_2_DATA.pdf

Voltage Rating:

120/240 VAC

Size:

0.7 Inch Length x 3.2 Inch Width x 2.6 Inch Height

Catalog:

Eaton_36601_V1T1_35_V1T1_39_CAT.pdf

Interrupting Rating:

10 kA

Mounting:

Plug-On

Installation/Operator:

Eaton_00008_INST.pdf

Series:

CHT

Used On:

Type CH Loadcenter

Type:

Thermal Magnetic, Twin, Switch Duty

Number of Poles:

1

Short Description:

120/240 VAC, 15 A, 10 kA, Twin Neutral, Plug-On Mount, Universal Breaker, Circuit Breaker

Current Rating:

15 A

Wire Size:

14 to 8 AWG Copper/Aluminum

Crouse-Hinds GFCB215 Miniature Circuit Breakers (MCBs) 2P 15A

SKU:

C15-5737

TS PIK:

21493924

Current Rating:

15 A

Type:

Common Trip

Catalog:

EATCORE00132_V1T1_76_V1T1_79.pdf

Number of Poles:

2

Mounting:

Plug-On

Voltage Rating:

120/240 VAC

Used On:

Loadcenter

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 2-Pole, Plug-On Mount, Common Trip, Ground Fault Circuit Breaker

Interrupting Rating:

10 kA

Series:

GFCB

Crouse-Hinds MP215 Miniature Circuit Breakers (MCBs)

SKU:

E30-7370

TS PIK:

21029784

Size:

2 Inch W x 3 Inch D x 3 1/8 Inch H

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

2

Series:

MP-T

Mounting:

Plug-On

Wire Size:

16 to 14 AWG (Copper/Aluminum)

Terminal Type:

Load Lug

Short Description:

120/240 V, 15 A, 10 kA, 2-Pole, Load Lug Terminal, MP-T Frame, Thermal Magnetic, Low Vage, Miniature, Circuit Breaker

Type:

Common Trip

Data Sheet:

SiemensAG_01522_1_DATA.pdf

Used On:

Loadcenter

Interrupting Rating:

10 kA

Country of Origin:

Mexico

Poles:

2

Approval:

UL Listed

Crouse-Hinds QBGF2015 Miniature Circuit Breakers (MCBs)

SKU:

C15-5526

Series:

QBGF

Type:

Thermal Magnetic

Voltage Rating:

120/240 VAC

Number of Poles:

2

Short Description:

120/240 VAC, 15 A, 10 kA, 5 mA Trip Level, 2-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Ground Fault Circuit Breaker

Wire Size:

14 to 8 AWG Aluminum/Copper (Load)

Terminal Type:

Extended Tang Line Terminal, Steel Box Lug Load Terminal

Current Rating:

15 A

Interrupting Rating:

10 kA

Mounting:

Bolt-On

Catalog:

Eaton_21247_4_8_CAT.pdf

Crouse-Hinds QBHW2015 Miniature Circuit Breakers (MCBs)

SKU:

C15-5766

TS PIK:

21510591

Number of Poles:

2

Mounting:

Bolt-On

Current Rating:

15 A

Short Description:

120/240 VAC, 15 A, 22 kA, 2-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature, Circuit Breaker

Catalog:

Eaton_03771_V4T1_12_CAT.pdf

Series:

QBHW

Terminal Type:

Extended Tang Line Terminal, Box Lug Load Terminal

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Type:

Thermal Magnetic

Interrupting Rating:

22 kA

Voltage Rating:

120/240 VAC

Size:

3.9 Inch Length x 2.1 Inch Width x 4.8 Inch Height

Crouse-Hinds QC1015 Miniature Circuit Breakers (MCBs) QC 1P 15A 50/60Hz 1Ph EA

SKU:

C15-5537

TS PIK:

21508933

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature, Circuit Breaker

Terminal Type:

Ring

Current Rating:

15 A

Type:

Thermal Magnetic

Series:

QC

Number of Poles:

1

Voltage Rating:

120/240 VAC

Wire Size:

14 to 10 AWG Aluminum/Copper (Load)

Mounting:

Cable-In, Cable Out

Catalog:

Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf

Interrupting Rating:

10000 A at 120/240 VAC, 5000 A at 24 to 48 VDC, 3800 A at 62.5 VDC

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA

Cutler-Hammer BRN115GF Miniature Circuit Breakers (MCBs)

SKU:

C15-1344

Series:

BRN

Approval:

UL

Size:

4 Inch Length x 3.5 Inch Width x 1 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Load Center

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Trip Sensitivity:

5 MilliA

Short Description:

120 VAC, 15 A, 10 kA Interrupting, 1-Pole, 14 to 4 AWG Copper/Aluminum, Pigtail, Ground Fault

Catalog:

Eaton_00001_V1T1_50_V1T1_86_CAT.pdf

Type:

Pigtail

Number of Poles:

1

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

TS PIK:

127411332

Cutler-Hammer CH115CAFA Miniature Circuit Breakers (MCBs)

SKU:

C15-1367

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

3/4 Inch W

Terminal Type:

Thermal Magnetic

Used On:

Loadcenter

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 1-Pole, Plug-On Mount, Thermal Magnetic, Arc Fault Circuit Breaker

Series:

CH

Voltage Rating:

120/240 VAC

Catalog:

CUTHMRE02076_V1T1_29_V1T1_30_V1T1_32.pdf

Type:

Thermal Magnetic

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

United States

Approval:

UL Listed and CSA approved

Cutler-Hammer CH215 Miniature Circuit Breakers (MCBs)

SKU:

C15-1398

Series:

CH

Type:

Thermal Magnetic

Type:

Common Trip

Volts:

120/240 VAC

Amps:

32 A

Used On:

Type CH Loadcenter

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

(1) 14 to 8 AWG

Wire Size:

(2) 14 to 10 AWG

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Plug-On Mount, Common Trip, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_36_V1T1_37_CAT.pdf

Installation/Operator:

Eaton_00008_INST.pdf

Manufacturer Warranty:

Eaton_00009_WARR.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

2

Country of Origin:

Dominican Republic

Approval:

UL, CSA. CE

TS PIK:

531262

Eaton 66C1488G12 Miniature Circuit Breakers (MCBs)

SKU:

C15-2883

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON BR ARC FAULT / GROUND FAULT CIRCUIT BREAKER

TS PIK:

126287060

Number of Poles:

1

Country of Origin:

Dominican Republic

Interrupting Rating:

10 kA

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Approval:

UL Listed and CSA Certified

Eaton BAB1015 Miniature Circuit Breakers (MCBs) 1P 15A 120V EA

SKU:

C15-1014

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

Bolt-On

Interrupting Rating:

10 kA at 120/240 VAC

Interrupting Rating:

5 kA at 24 to 48 Volt DC

Interrupting Rating:

3.8 kA at 62.5 Volt DC

Terminal Type:

Extended Tang Line

Terminal Type:

Box Lug Load

Wire Size:

14 to 4 AWG Copper/Aluminum (Load)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_11_V4T1_12_V4T1_46_CAT.pdf

TS PIK:

21508666

Voltage Rating:

120/240 VAC

Number of Poles:

1

Current Rating:

15 A

Country of Origin:

Dominican Republic

Eaton BAB1015V Miniature Circuit Breakers (MCBs) BA 1P 15A 240V 50/60Hz 1Ph EA

SKU:

C15-1016

Type:

Thermal Magnetic

Type:

Non-Interchangeable Trip

Approval:

UL

Approval:

CSA

Size:

3.5 Inch Length x 1 Inch Width x 3.5 Inch Height

Volts:

120/240 V

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Bolt-On Mount, BAB Frame, Non-Interchangeable Trip Thermal Magnetic

Catalog:

Eaton_03771_V4T1_3_V4T1_11_V4T1_12_CAT.pdf

TS PIK:

107007334

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton BAB2015C Miniature Circuit Breakers (MCBs)

SKU:

C15-3274

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

Bolt-On

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48 VDC

Interrupting Rating:

3800 A at 62.5 VDC

Terminal Type:

Extended Tang Line Terminal

Terminal Type:

Box Lug Load Terminal

Wire Size:

14 to 4 AWG Aluminum/Copper (Load)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_39_V4T1_40_CAT.pdf

Voltage Rating:

120/240 VAC

Number of Poles:

1

Current Rating:

15 A

TS PIK:

21505531

Eaton BAB2015HT Miniature Circuit Breakers (MCBs)

SKU:

C15-3668

Series:

BAB

Volts:

120/240 V

Amps:

15 A

Poles:

2

Frequency Rating:

50/60 Hz

Short Description:

QUICKLAG INDUSTRIAL THERMAL-MAGNETIC CIRCUIT BREAKER, TWO-POLE, RING OR SPADE LU

TS PIK:

115395276

Number of Poles:

3

Country of Origin:

Dominican Republic

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Interrupting Rating:

10 kA

Approval:

UL Listed CSA Certified

Eaton BAB2015HV Miniature Circuit Breakers (MCBs) BA 2P 15A 120/240V 50/60Hz 1Ph

SKU:

C15-1037

Country of Origin:

Dominican Republic

Voltage Rating:

120/240 VAC

Number of Poles:

2

Current Rating:

15 A

Interrupting Rating:

10 kA

Short Description:

Eaton BAB thermal magnetic circuit breaker,Quicklag industrial thermal-magnetic circuit breaker,Bolt-on mounting, Switching neutral,15 A,10 kAIC,Two-pole,120/240 V,Non-Interchangeable,Q7,BAB

Poles:

2

Approval:

UL, CSA, HACR

Eaton BAB3015C Miniature Circuit Breakers (MCBs) BA 3P 15A 240V 50/60Hz 1Ph

SKU:

C15-3904

Series:

BAB

Volts:

240 V

Amps:

15 A

Poles:

3

Frequency Rating:

50/60 Hz

Short Description:

EATON BAB THERMAL MAGNETIC CIRCUIT BREAKER,QUICKLAG INDUSTRIAL THERMAL-MAGNETIC

Number of Poles:

3

Country of Origin:

Dominican Republic

Current Rating:

15 A

Interrupting Rating:

10 kA

Voltage Rating:

120/240 VAC

Approval:

UL Listed CSA Certified

Eaton BABRP1015 Miniature Circuit Breakers (MCBs)

SKU:

C15-1113

Series:

BAB

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON TYPE BAB REMOTELY OPERATED BOLT-ON CIRCUIT BREAKER, 15A, SINGLE-POLE, 120V

Number of Poles:

1

Country of Origin:

Dominican Republic

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Approval:

UL Listed CSA Certified

Interrupting Rating:

10 kA

TS PIK:

119703635

Eaton BQC215215 Miniature Circuit Breakers (MCBs)

SKU:

C15-1160

Series:

BQC

Type:

Thermal Magnetic

Type:

Common Trip

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Loadcenter

Poles:

2

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole Outer/2-Pole Center, Plug-On Mount, BQC Breaker, Common Trip, Quadplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_89_CAT.pdf

TS PIK:

21493983

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Mounting:

Plug-On

Country of Origin:

Dominican Republic

Eaton BQL15 Miniature Circuit Breakers (MCBs)

SKU:

C15-1181

Series:

BQL

Type:

Common Trip

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

Bolt-On

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Screw

Wire Size:

14 to 8 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 1-Pole, 10 kA, Bolt-On Mount

Catalog:

Eaton_00069_60_CAT.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

1

TS PIK:

115729703

Eaton BR115 Miniature Circuit Breakers (MCBs)

SKU:

C15-1184

Series:

BR

Type:

Thermal Magnetic

Approval:

UL 489

Size:

3 Inch Length x 1 Inch Width x 3 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Load Center

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Lug Screw Terminal, Plug-On Mount, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

TS PIK:

21493844

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton BR115AF Miniature Circuit Breakers (MCBs)

SKU:

C15-1185

Series:

BR

Type:

Branch Feeder

Approval:

UL 1699

Size:

1 Inch Width

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Type Load Center

Mounting:

Plug-On

Interrupting Rating:

10 kA

Poles:

1

Construction Feature:

Arc Fault Circuit Interrupter

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Branch Feeder

Catalog:

Eaton_36650_V1T1_76_V1T1_78_CAT.pdf

TS PIK:

115463477

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton BR115CAFA Miniature Circuit Breakers (MCBs) BR 1P 15A 240V 50/60Hz 1Ph

SKU:

C15-1188

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

1 Inch W

Terminal Used On:

Loadcenter

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 1-Pole, Plug-On Mount, Arc Fault Circuit Breaker

Series:

BR

Catalog:

CUTHMRE01725_72_75.pdf

Used On:

Loadcenter

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Eaton BR115CAFCS Miniature Circuit Breakers (MCBs)

SKU:

C15-1189

Series:

BR

Volts:

240 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Number of Poles:

1

Mounting:

Plug-On

Current Rating:

15 A

Country of Origin:

Dominican Republic

Short Description:

Eaton BR115CAFCS is a 1-pole, 15 amp, 120V plug-on circuit breaker with combination arc fault protection, designed for use in BR loadcenters for residential branch circuit protection.

Approval:

UL 1699

Used On:

Type BR Loadcenters

Interrupting Rating:

10 kA

Voltage Rating:

120/240 VAC

Eaton BR115ST Miniature Circuit Breakers (MCBs)

SKU:

C15-2886

Series:

BR

Type:

Thermal Magnetic

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Shunt Trip, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

15 A

TS PIK:

110702224

Eaton BR215 Miniature Circuit Breakers (MCBs)

SKU:

C15-1220

Series:

BR

Type:

Thermal Magnetic

Type:

Common Trip

Approval:

UL 489

Approval:

CSA

Size:

1.9 Inch Length x 2.9 Inch Width x 2.5 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Load Center

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Lug

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Lug Screw Terminal, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

TS PIK:

21493855

Voltage Rating:

120/240 VAC

Number of Poles:

2

Current Rating:

15 A

Country of Origin:

Dominican Republic

Eaton BRACAF115 Miniature Circuit Breakers (MCBs)

SKU:

C15-1274

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

1 Inch W

Terminal Used On:

Loadcenter

Volts:

120/240 VAC

Gauge:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Diagnostic, Arc Fault Circuit Breaker

Series:

BR

Installation/Operator:

Eaton_00008_INST.pdf

Catalog:

Eaton_36651_V1T1_79_CAT.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Data Sheet:

Eaton_36652_1-4_DATA.pdf

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Used On:

Loadcenter

Number of Poles:

1

Country of Origin:

Dominican Republic

TS PIK:

124548670

Eaton BRAF115 Miniature Circuit Breakers (MCBs)

SKU:

C15-3263

Approval:

UL

Approval:

CSA

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Type:

Branch Feeder

Type:

Standard

Volts:

120/240 VAC

Gauge:

14 to 4 AWG Copper/Aluminum

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Wire Size:

14 to 4 AWG Copper/Aluminum

Data Sheet:

Eaton_37732_1_DATA.pdf

Short Description:

TYPE BR ARC FAULT CIRCUIT BREAkERS

Series:

BR

Country of Origin:

Dominican Republic

TS PIK:

124763689

Eaton BRC115AF Miniature Circuit Breakers (MCBs)

SKU:

C15-1279

Series:

BR

Size:

1 Inch W

Volts:

120/240 VAC

Amps:

32 A

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Poles:

1

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Clip Line Terminal, Plug-In Mount, Common Trip

Installation/Operator:

IdealIndustries-IDEALElectrical_00044_INST.pdf

Manufacturer Warranty:

IdealIndustries-IDEALElectrical_00010_WARR.pdf

Data Sheet:

Eaton_40736_1_DATA.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

TS PIK:

119527560

Eaton BRCAF115CS Miniature Circuit Breakers (MCBs)

SKU:

C15-1285

Series:

BR

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON BR AFCI CIRCUIT BREAKER

TS PIK:

124615682

Type:

Arc Fault

Number of Poles:

1

Mounting:

Plug-On

Current Rating:

15 A

Country of Origin:

Dominican Republic

Interrupting Rating:

10 kA

Voltage Rating:

120/240 VAC

Used On:

Type BR Loadcenters

Approval:

UL 1699

Eaton BRDC215220 Miniature Circuit Breakers (MCBs)

SKU:

C15-11217

Country of Origin:

Dominican Republic

Short Description:

Eaton BR thermal magnetic circuit breaker,Type BRDC, 1-Inch plug-on circuit breaker,(2) Single-Pole 20 A, (2) Two-Pole 15 A,10 kAIC,Four-pole,120/240V,Common breaker trip,#14-4 AWG Cu/Al,

Current Rating:

15 A

Number of Poles:

2

Interrupting Rating:

10 kA

Poles:

2

Voltage Rating:

120/240 VAC

Approval:

UL 489

Eaton BRF115 Miniature Circuit Breakers (MCBs)

SKU:

C15-10995

TS PIK:

124125307

Number of Poles:

1

Country of Origin:

Dominican Republic

Approval:

UL Listed, NFPA 72, HACR

Interrupting Rating:

10 kA

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Short Description:

Eaton BR thermal magnetic circuit breaker,Type BRF plug-on fire alarm circuit breaker,15 A,10 kAIC,Single-pole,120/240V,BRF,BRF

Eaton BRH115 Miniature Circuit Breakers (MCBs)

SKU:

C15-1299

TS PIK:

21494019

Number of Poles:

1

Short Description:

120/240 VAC, 15 A, 22 kA, 1-Pole, Plug-On Mount, Thermal Magnetic, Circuit Breaker

Type:

Thermal Magnetic

Voltage Rating:

120/240 VAC

Interrupting Rating:

22 kA

Mounting:

Plug-On

Used On:

Loadcenter

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Current Rating:

15 A

Series:

BR

Country of Origin:

Dominican Republic

Approval:

UL 489

Poles:

1

Eaton BRH215 Miniature Circuit Breakers (MCBs)

SKU:

C15-1305

Series:

BR

Type:

Thermal Magnetic

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

22 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 15 A, 22 kA, 2-Pole, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

Number of Poles:

2

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

TS PIK:

117083232

Eaton BRHN115GF Miniature Circuit Breakers (MCBs)

SKU:

C15-3048

Type:

Personal Protection

Size:

3.5 Inch Width x 4 Inch Depth x 1 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

CPM/CPL/CBRPM/CBRPL Load Center

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

22 kA

Terminal Type:

Plug-On

Wire Size:

14 to 8 AWG

Trip Sensitivity:

5 MilliA

Short Description:

120 VAC, 15 A, 1-Pole, 22 kA, Plug-On Mount, Personal Protection

Catalog:

Eaton_00001_V1T1_50_V1T1_86_CAT.pdf

TS PIK:

127411390

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Approval:

UL Listed and CSA Approved

Eaton BRL215AF Miniature Circuit Breakers (MCBs)

SKU:

C15-1330

Series:

BR

Type:

Class J

Approval:

UL 1699

Size:

1 Inch W

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Mounting:

Plug-On

Interrupting Rating:

10 kA

Application:

HARC

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Poles:

2

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Plug-On Mount, Common Trip, Branch Feeder

Catalog:

Eaton_36650_V1T1_76_V1T1_78_CAT.pdf

Data Sheet:

Eaton_40793_1_2_DATA.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Installation/Operator:

Eaton_00008_INST.pdf

TS PIK:

122939984

Eaton BRL215CAF Miniature Circuit Breakers (MCBs)

SKU:

C15-1332

Series:

BR

Type:

Class J

Approval:

UL

Size:

6 Inch Length x 3.5 Inch Width x 1.25 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Load Center

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Poles:

2

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Plug-On Mount, Common Trip

Catalog:

Eaton_36650_V1T1_76_V1T1_79_CAT.pdf

Data Sheet:

Mersen_00063_1_2_DATA.pdf

CAD Drawing:

Mersen_00368_1_CAD.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Number of Poles:

2

TS PIK:

124615678

Eaton BRN115EP Miniature Circuit Breakers (MCBs)

SKU:

C15-3906

Type:

Pigtail

Approval:

UL

Size:

4 Inch Length x 3.5 Inch Width x 1 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Load Center

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Trip Sensitivity:

30 MilliA

Short Description:

120 VAC, 15 A, 1-Pole, 10 kA, Trip to Center, Plug-On Mount

Installation/Operator:

Eaton_00008_INST.pdf

Manufacturer Warranty:

Eaton_00010_WARR.pdf

Number of Poles:

1

Current Rating:

15 A

Voltage Rating:

120/240 VAC

TS PIK:

127414004

Series:

BR

Country of Origin:

Dominican Republic

Eaton BRN115GF Miniature Circuit Breakers (MCBs) EA

SKU:

C15-7000

Approval:

UL

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

4 Inch Length x 3.5 Inch Width x 1 Inch Height

Terminal Trip Sensitivity:

5 Milliamp

Type:

Pigtail

Used On:

BR Load Center

Volts:

120/240 VAC

Gauge:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120 VAC, 15 A, 10 kA Interrupting, 1-Pole, 14 to 4 AWG Copper/Aluminum, Pigtail, Ground Fault, Circuit Breaker

Series:

BRN

Catalog:

Eaton_00001_V1T1_50_V1T1_86_CAT.pdf

Current Rating:

15 A

Number of Poles:

1

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

TS PIK:

127411332

Country of Origin:

Dominican Republic

Eaton BRN215GF Miniature Circuit Breakers (MCBs)

SKU:

C15-12269

TS PIK:

129348565

Short Description:

BR 2 POLE 15A GFST_ 120/240V_ 10 kAIC

Country of Origin:

Dominican Republic

Number of Poles:

2

Poles:

2

Interrupting Rating:

10 kA

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Approval:

UL 489 UL 943

Eaton BRP115GF Miniature Circuit Breakers (MCBs)

SKU:

C15-2235

Type:

Personal Protection

Size:

3.5 Inch Width x 4 Inch Depth x 1 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Plug-On

Wire Size:

14 to 8 AWG

Trip Sensitivity:

5 MilliA

Short Description:

120 VAC, 15 A, 1-Pole, 10 kA, Plug-On Mount, Personnel Protection

Catalog:

Eaton_00001_V1T1_50_V1T1_86_CAT.pdf

Current Rating:

15 A

Number of Poles:

1

Voltage Rating:

120/240 VAC

TS PIK:

127411325

Series:

BR

Country of Origin:

Dominican Republic

Approval:

UL Listed

Eaton CH115 Miniature Circuit Breakers (MCBs)

SKU:

C15-1363

Series:

CH

Type:

Current Limiting

Type:

Thermal Magnetic

Volts:

120/240 VAC

Amps:

32 A

Used On:

Type CH Loadcenters

Poles:

1

Mounting:

3/4 Plug-On

Interrupting Rating:

10 kA

Wire Size:

(1) 14 to 8 AWG

Wire Size:

(2) 14 to 10 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_36_V1T1_37_CAT.pdf

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Country of Origin:

Dominican Republic

Approval:

UL 489

TS PIK:

531256

Eaton CH115AF Miniature Circuit Breakers (MCBs)

SKU:

C15-1364

Series:

CH

Type:

Thermal Magnetic

Type:

Compact

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Used On:

CH Series Load Center

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

(1) 14 to 8 AWG (Copper/Aluminum)

Wire Size:

(2) 14 to 10 AWG Solid/Stranded (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Thermal Magnetic Trip, Arc Fault Circuit Interrupter

Catalog:

Eaton_36650_V1T1_33_CAT.pdf

TS PIK:

115463475

Terminal Type:

Clip Line

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Application:

HACR

Construction Feature:

Arc Fault Circuit Interrupter

Eaton CH115AFCS Miniature Circuit Breakers (MCBs)

SKU:

C15-2526

Type:

Class H

Approval:

UL 1699

Size:

3/4 Inch W

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Clip (Line Terminal)

Poles:

1

Short Description:

120/240 VAC, 15 A, 10 kA, Clip Line Terminal, Plug-On Mount

Data Sheet:

Eaton-Bussmann_00317_1_4_DATA.pdf

Current Rating:

15 A

Voltage Rating:

120/240 VAC

TS PIK:

115856728

Eaton CH115CAF Miniature Circuit Breakers (MCBs) CH 1P 15A 240V 50/60Hz 1Ph

SKU:

C15-1366

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

3/4 Inch W

Terminal Type:

Thermal Magnetic

Used On:

Loadcenter

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA Interrupt, 1-Pole, Plug-On Mount, Thermal Magnetic, Arc Fault Circuit Breaker

Series:

CH

Type:

Thermal Magnetic

Catalog:

CUTHMRE02076_V1T1_29_V1T1_30_V1T1_32.pdf

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Eaton CH115CAFCS Miniature Circuit Breakers (MCBs) CH 1P 15A 240V 50/60Hz 1Ph

SKU:

C15-1369

Application:

HACR

Approval:

UL

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Terminal Type:

Thermal Magnetic

Used On:

Load Center

Volts:

120/240 VAC

Gauge:

(1) 14 to 8 AWG (Copper/Aluminum)

Gauge:

14 to 10 AWG (Copper/Aluminum)

Gauge:

14 to 6 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 15 A, 1-Pole, 10 kA, Plug-On Mount, Wide, Combination Arc Fault Circuit Breaker

Series:

CH

Current Rating:

15 A

Voltage Rating:

120/240 VAC

Wire Size:

(1) 14 to 8 AWG (Copper/Aluminum), 14 to 10 AWG (Copper/Aluminum), 14 to 6 AWG (Copper/Aluminum)

Catalog:

CUTHMRE02076V1_T1_29-V1_T1_32_V1_T1_39.pdf

Type:

Thermal Magnetic

Eaton CH115CAFPN Miniature Circuit Breakers (MCBs) CH 1P 15A 240V 50/60Hz 1Ph

SKU:

C15-1630

Construction Feature:

Switching Neutral

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

3/4 Inch W

Terminal Type:

Plug-On

Used On:

Loadcenter

Volts:

120/240 VAC

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Plug-On Mount, Thermal Magnetic Trip, Neutral Arc Fault and Ground Fault, Load Center Circuit Breaker

Series:

CH

Voltage Rating:

120/240 VAC

Catalog:

Eaton_36657_3_CAT.pdf

Current Rating:

15 A

Country of Origin:

Dominican Republic

Number of Poles:

1

Approval:

UL Listed

Eaton CH215AF Miniature Circuit Breakers (MCBs)

SKU:

C15-1400

Series:

CH

Type:

Class K5/H

Approval:

UL

Size:

3/4 Inch W

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Mounting:

Plug-On

Interrupting Rating:

10 kA

Poles:

2

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Clip Line Terminal, Plug-On Mount, Common Trip, Thermal Magnetic, Branch Feeder

Catalog:

Eaton_36650_V1T1_31_V1T1_33_CAT.pdf

Data Sheet:

Eaton-Bussmann_00320_3_4_DATA.pdf

Wire Size:

14 to 8 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Construction Feature:

Arc Fault Circuit Interrupter

Application:

HACR

Terminal Type:

Clip Line

TS PIK:

117057235

Eaton CH215CAF Miniature Circuit Breakers (MCBs)

SKU:

C15-1402

Series:

CH

Type:

Class J

Approval:

UL

Size:

3/4 Inch W

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Mounting:

Plug-On

Interrupting Rating:

10 kA

Poles:

2

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Clip Line Terminal, Plug-On Mount, Thermal Magnetic, Branch Feeder

Catalog:

Eaton_00071_V1T1_36_V1T1_38_CAT.pdf

Data Sheet:

Eaton-Bussmann_00513_1_2_DATA.pdf

Voltage Rating:

120/240 VAC

Current Rating:

15 A

TS PIK:

124615680

Eaton CH215EPD Miniature Circuit Breakers (MCBs)

SKU:

C15-19153

Number of Poles:

2

Series:

CH

Short Description:

120/240 VAC, 15 A, 2-Pole, 10 kA, Plug-On Mount, Common Trip, Equipment Protector, Ground Fault Circuit Breaker

Size:

3/4 Inch Width

Current Rating:

15 A

Catalog:

Eaton_00001_V1T1_39_CAT.pdf

Voltage Rating:

120/240 VAC

Wire Size:

14 to 6 AWG (Copper/Aluminum) at 60/75 Deg C

Used On:

CH Loadcenter

Type:

Equipment Protector

Mounting:

Plug-On

Trip Sensitivity:

30 MilliA

Approval:

UL 489

Interrupting Rating:

10 kA

Eaton CH215GFT Miniature Circuit Breakers (MCBs)

SKU:

C15-1404

Approval:

UL 489

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

2

Size:

2.75 Inch Width x 4.5 Inch Depth x 2 Inch Height

Terminal Trip Sensitivity:

5 MilliA

Type:

Common Trip

Type:

Self-Test

Used On:

CH Load Center

Volts:

120/240 VAC

Gauge:

14 to 6 AWG Copper/Aluminum at 60 Deg C

TS PIK:

126241804

Voltage Rating:

120/240 VAC

Number of Poles:

2

Current Rating:

15 A

Catalog:

Eaton-CutlerHammer_00031_V1T1_36_V1T1_39_CAT.pdf

Wire Size:

14 to 6 AWG Copper/Aluminum at 60 Deg C

Short Description:

EATON CH GFCI CIRCUIT BREAKER,GROUND FAULT CIRCUIT BREAKER,15 A,10 kAIC,TWO-POLE

Series:

CH

Trip Sensitivity:

5 MilliA

Eaton CH215PMPCI Miniature Circuit Breakers (MCBs) EA
