Schneider Electric MGN61308 Molded Case Breakers (MCCBs)

SKU:

C15-12106

Short Description:

277 VAC 50/60 Hz, 10 A, 10 kA Interrupt, 1-Pole, Gray, 35 MM DIN Rail Mount, Tunnel Terminal, C Curve, Toggle Control, Thermal Magnetic, Miniature Circuit Breaker

Current Rating:

10 A

Number of Poles:

1

Size:

0.71 Inch W x 2.76 Inch D x 3.19 Inch H

Interrupting Rating:

10 kA at 277 VAC

Voltage Rating:

277 VAC at 50/60 Hz

Type:

Thermal Magnetic

Series:

MGN

Wire Size:

(2) 18 to 10 AWG (Copper)

Approval:

UL 489, CSA C22.2, CE

Catalog:

SchneiderElectric-SquareD_00103_19_20_CAT.pdf

Installation/Operator:

SchneiderElectric_00301_INST.pdf

Terminal Type:

Lug

Data Sheet:

SchneiderElectric_05777_1_2_DATA.pdf

Country of Origin:

China

Schneider Electric QO120PCAFIC Miniature Circuit Breakers (MCBs) QO 1P 20A 120V 50/60Hz 1Ph

SKU:

C15-3665

Volts:

120 V

Amps:

20 A

Poles:

1

Frequency Rating:

50/60 Hz

Number of Poles:

1

Current Rating:

20 A

Series:

Q

Country of Origin:

Mexico

Siemens 3VA4120-4ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-10277

TS PIK:

128131363

Short Description:

120/277/347 VAC 50/60 Hz, 125 VDC, 20 A, 14/65/25 kA Interrupt, 1-Pole, 125A Frame, Load Lug Terminal, Low Vage, Thermal Magnetic, Standard Breaking Capacity, Molded Case, Non-Interchangeable Trip Circuit Breaker

Terminal Type:

Load Lug

Country of Origin:

MEX

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Breaking Capacity

Interrupting Rating:

65 kA at 120 VAC, 25 kA at 277 VAC, 14 kA at 347 VAC/125 VDC

Maximum DC Voltage Rating:

125 V

Installation/Operator:

SiemensAG_01030_INST.pdf

Approval:

UL 489

Number of Poles:

1

Maximum AC Voltage Rating:

347 V

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Catalog:

SiemensAG_57191_7_46-7_48_CAT.pdf

Current Rating:

20 A

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Siemens 3VA4120-6ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-14577

Terminal Type:

Load Lug

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Short Description:

BRKR 3VA41 1P 20A 65kA FTFM LD LUG

Installation/Operator:

SiemensAG_00547_INST.pdf

Maximum AC Voltage Rating:

347 V

Catalog:

SiemensAG_09175_17_7_17_16_17_17_CAT.pdf

Maximum DC Voltage Rating:

125 V

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Approval:

UL 489

Current Rating:

20 A

Number of Poles:

1

Country of Origin:

MEX

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Interrupting Rating:

150 kA at 120 VAC, 65 kA at 277 VAC, 25 kA at 347 VAC, 30 kA at 125 VDC

Data Sheet:

SiemensAG_09521_1-5_DATA.pdf

Siemens 3VA4130-4ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-18890

Number of Poles:

1

Current Rating:

30 A

Country of Origin:

MEX

Short Description:

BRKR 3VA41 1P 30A 25kA FTFM LD LUG

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Breaking Capacity

Terminal Type:

Load Lug

Interrupting Rating:

65 kA at 120 VAC, 25 kA at 277 VAC, 14 kA at 347 VAC/125 VDC

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Maximum DC Voltage Rating:

125 V

Maximum AC Voltage Rating:

347 V

Approval:

UL 489

Catalog:

SiemensAG_09175_17_7_17_16_17_17_CAT.pdf

Data Sheet:

SiemensAG_09522_1-5_DATA.pdf

Installation/Operator:

SiemensAG_00547_INST.pdf

Siemens 3VA4140-4ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-18893

Number of Poles:

1

Short Description:

BRKR 3VA41 1P 40A 25kA FTFM LD LUG

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Breaking Capacity

Maximum AC Voltage Rating:

347 V

Current Rating:

40 A

Installation/Operator:

SiemensAG_00547_INST.pdf

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Maximum DC Voltage Rating:

125 V

Interrupting Rating:

65 kA at 120 VAC, 25 kA at 277 VAC, 14 kA at 347 VAC/125 VDC

Terminal Type:

Load Lug

Data Sheet:

SiemensAG_09523_1-5_DATA.pdf

Approval:

UL 489

Catalog:

SiemensAG_09175_17_7_17_16_17_17_CAT.pdf

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Country of Origin:

MEX

Siemens 3VA4195-4ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-18901

Data Sheet:

SiemensAG_09524_1-5_DATA.pdf

Country of Origin:

MEX

Interrupting Rating:

65 kA at 120 VAC, 25 kA at 277 VAC, 14 kA at 347 VAC/125 VDC

Current Rating:

15 A

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Number of Poles:

1

Approval:

UL 489

Terminal Type:

Load Lug

Catalog:

SiemensAG_09175_17_7_17_16_17_17_CAT.pdf

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Breaking Capacity

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Maximum AC Voltage Rating:

347 V

Installation/Operator:

SiemensAG_00554_INST.pdf

Short Description:

BRKR 3VA41 1P 15A 25kA FTFM LD LUG

Maximum DC Voltage Rating:

125 V

Siemens 3VA4195-6ED14-0AA0 Molded Case Breakers (MCCBs)

SKU:

C15-14617

Catalog:

SiemensAG_09175_17_7_17_16_17_17_CAT.pdf

Number of Poles:

1

Approval:

UL 489

Country of Origin:

MEX

Maximum DC Voltage Rating:

125 V

Short Description:

BRKR 3VA41 1P 15A 65kA FTFM LD LUG

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Terminal Type:

Load Lug

Data Sheet:

SiemensAG_09525_1-5_DATA.pdf

Voltage Rating:

120/277/347 VAC 50/60 Hertz, 125 VDC

Interrupting Rating:

150 kA at 120 VAC, 65 kA at 277 VAC, 25 kA at 347 VAC, 30 kA at 125 VDC

Installation/Operator:

SiemensAG_00554_INST.pdf

Maximum AC Voltage Rating:

347 V

Size:

1 Inch Width x 3.6 Inch Depth x 5.1 Inch Height

Current Rating:

15 A

Siemens 5SX2106-7 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-8989

Short Description:

230/400 VAC, 6 A, 6 kA, 1-Pole, 55 MM Mounting Depth, Curve C, Miniature Circuit Breaker

Voltage Rating:

230/400 V

Catalog:

SiemensAG_01748_12_4_CAT.pdf

Number of Poles:

1

Current Rating:

6 A

Series:

5SX2

Interrupting Rating:

6 kA

Country of Origin:

Mexico

Siemens B115 Miniature Circuit Breakers (MCBs)

SKU:

C15-6105

TS PIK:

21368372

Number of Poles:

1

Short Description:

120 VAC, 15 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Interrupting Rating:

10 kA

Voltage Rating:

120 VAC

Current Rating:

15 A

Data Sheet:

SiemensAG_05158_1_DATA.pdf

Installation/Operator:

SiemensAG_00215_INST.pdf

Installation:

Bolt-On

Approval:

UL, CSA

Used On:

Panelboard

Country of Origin:

Mexico

Siemens B115 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-9618

TS PIK:

21368372

Interrupting Rating:

10 kA

Current Rating:

15 A

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Installation/Operator:

SiemensAG_00215_INST.pdf

Number of Poles:

1

Short Description:

120 VAC, 15 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Data Sheet:

SiemensAG_05158_1_DATA.pdf

Used On:

Panelboard

Voltage Rating:

120 VAC

Mounting:

Bolt-On

Installation:

Bolt-On

Approval:

UL, CSA

Country of Origin:

MEX

Siemens B11500S01 Miniature Circuit Breakers (MCBs)

SKU:

C15-10300

TS PIK:

115554943

Approval:

UL 489, CSA C22.2

Number of Poles:

1

Current Rating:

15 A

Short Description:

120 VAC, 15 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Shunt Trip, Panelboard Circuit Breaker

Country of Origin:

MEX

Used On:

P1/P2/P3/P4/P5 Panelboard

Data Sheet:

SiemensAG_05159_1_DATA.pdf

Application:

Lighting, Distribution

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Type:

Molded Case, Thermal and Fixed Magnetic

Installation:

Bolt-On

Interrupting Rating:

10 kA at 120 VAC (UL)

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Siemens B115H Miniature Circuit Breakers (MCBs) 15A

SKU:

C15-6209

TS PIK:

115370793

Short Description:

120 VAC, 15 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Voltage Rating:

120 VAC

Used On:

P1/P2/P3/P4/P5 Panelboard

Interrupting Rating:

22 kA at 120 VAC (UL)

Number of Poles:

1

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Data Sheet:

SiemensAG_05160_1_DATA.pdf

Current Rating:

15 A

Installation/Operator:

SiemensAG_00215_INST.pdf

Type:

Molded Case, Thermal and Fixed Magnetic, Branch

Country of Origin:

Mexico

Approval:

UL 489, CSA C22.2

Application:

Lighting, Distribution

Installation:

Bolt-On

Siemens B115HH Miniature Circuit Breakers (MCBs)

SKU:

C15-18951

Data Sheet:

SiemensAG_05161_1_DATA.pdf

Current Rating:

15 A

Interrupting Rating:

65 kA at 120 VAC (UL)

Approval:

UL 489, CSA C22.2

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Installation:

Bolt-On

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Application:

Lighting, Distribution

Installation/Operator:

SiemensAG_00215_INST.pdf

Short Description:

120 VAC, 15 A, 65 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Country of Origin:

MEX

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic

Used On:

P1/P2/P3/P4/P5 Panelboard

Siemens B12000S01 Miniature Circuit Breakers (MCBs) B 1P 20A 120/240V 50/60Hz 1Ph

SKU:

C15-3108

Type:

Shunt Trip

Approval:

UL 489

Size:

4.4 Inch Width x 5.5 Inch Depth x 3.8 Inch Height

Volts:

120 VAC

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA

Terminal Type:

Bolt-On

Frame Type:

BL

Maximum AC Voltage Rating:

120 V

Short Description:

120 VAC, 20 A, 10 kA, 1-Pole, Bolt-On Mount, Factory Installed, Shunt Trip

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Data Sheet:

SiemensAG_05162_1_DATA.pdf

Voltage Rating:

120 VAC

Number of Poles:

1

Country of Origin:

MEX

Current Rating:

20 A

Siemens B120DF Miniature Circuit Breakers (MCBs)

SKU:

C15-18952

Current Rating:

20 A

Voltage Rating:

120 V AC

Type:

Molded Case

Number of Poles:

1

Size:

3.5 Inch Width x 1 Inch Depth x 5 Inch Height

Approval:

UL 1699/943

Used On:

Panelboard

Country of Origin:

PHL

Short Description:

120 VAC, 20 A, 10 kA Interrupt, 1-Pole, Bolt-On Mount, Dual Function Circuit Breaker

Installation/Operator:

SiemensAG_00692_INST.pdf

Interrupting Rating:

10 kA

Mounting:

Bolt-On

Siemens B120H00S01 Miniature Circuit Breakers (MCBs)

SKU:

C15-6106

Interrupting Rating:

22 kA at 120 VAC (UL)

Used On:

P1/P2/P3/P4/P5 Panelboard

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Number of Poles:

1

Current Rating:

20 A

Data Sheet:

SiemensAG_05165_1_DATA.pdf

Type:

Molded Case, Thermal and Fixed Magnetic

Short Description:

120 VAC, 20 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Shunt Trip, Panelboard Circuit Breaker

Country of Origin:

Mexico

TS PIK:

115271076

Approval:

UL 489, CSA C22.2

Installation:

Bolt-On

Application:

Lighting, Distribution

Siemens B120HH Miniature Circuit Breakers (MCBs) 20A

SKU:

C15-1456

Type:

Molded Case

Type:

Thermal and Fixed Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Volts:

120 VAC at 50/60 Hz (UL)

Amps:

32 A

Used On:

P1/P2/P3/P4/P5 Panelboard

Poles:

1

Interrupting Rating:

65 kA at 120 VAC (UL)

Application:

Lighting

Application:

Distribution

Installation:

Bolt-On

Short Description:

120 VAC, 20 A, 65 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic

Catalog:

SiemensAG_00876_5_18_5_19_CAT.pdf

Data Sheet:

SiemensAG_01598_1_DATA.pdf

TS PIK:

21368427

Current Rating:

20 A

Voltage Rating:

120 VAC

Number of Poles:

1

Mounting:

Bolt-On

Series:

B

Country of Origin:

Mexico

Siemens B125H Miniature Circuit Breakers (MCBs)

SKU:

C15-10302

TS PIK:

115554949

Country of Origin:

MEX

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic

Approval:

UL 489, CSA C22.2

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Current Rating:

25 A

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Short Description:

120 VAC, 25 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Interrupting Rating:

22 kA at 120 VAC (UL)

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Data Sheet:

SiemensAG_05167_1_DATA.pdf

Installation:

Bolt-On

Installation/Operator:

SiemensAG_00215_INST.pdf

Siemens B125HH Miniature Circuit Breakers (MCBs)

SKU:

C15-18953

Type:

Branch

Interrupting Rating:

65 kA

Number of Poles:

1

Application:

Lighting/Distribution

Voltage Rating:

120 VAC at 50/60 Hz

Country of Origin:

MEX

Current Rating:

25 A

Used On:

P1/P2/P3/P4/P5 Series Panelboard

Short Description:

120 VAC, 25 A, 65 kA, 1-Pole, Bolt-On Mount, Branch, Panelboard Circuit Breaker

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Data Sheet:

SiemensAG_05168_1_DATA.pdf

Approval:

UL 489, CSA C22.2

Installation/Operator:

SiemensAG_00215_INST.pdf

Installation:

Bolt-On

Siemens B130 Miniature Circuit Breakers (MCBs)

SKU:

C15-6110

Used On:

P1/P2/P3/P4/P5 Panelboard

Short Description:

120 VAC 50/60 Hz, 30 A, 10 kA, 1-Pole, BL Frame, Bolt-On, Molded Case, Thermal and Fixed Magnetic Trip, Common Trip, Panelboard Circuit Breaker

Voltage Rating:

120 VAC

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic, Branch

Current Rating:

30 A

Interrupting Rating:

10 kA at 120 VAC

Catalog:

SiemensAG_01502_5_8_5_19_10_14_CAT.pdf

Mounting:

Bolt-On

Installation/Operator:

RegalBeloit-Century_00001_INST.pdf

CAD Drawings:

RegalBeloit-Century_01778_1_CAD.pdf

Data Sheet:

RegalBeloit-Century_00562_1_2_DATA.pdf

Country of Origin:

Mexico

Application:

Lighting, Distribution

Approval:

UL 489, CSA C22.2

Installation:

Bolt-On

Siemens B13000S01 Miniature Circuit Breakers (MCBs)

SKU:

C15-10303

TS PIK:

115554955

Short Description:

120 VAC, 30 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Shunt Trip, Panelboard Circuit Breaker

Type:

Molded Case, Thermal and Fixed Magnetic

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Current Rating:

30 A

Interrupting Rating:

10 kA at 120 VAC (UL)

Number of Poles:

1

Used On:

P1/P2/P3/P4/P5 Panelboard

Data Sheet:

SiemensAG_05169_1_DATA.pdf

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Country of Origin:

Mexico

Approval:

UL 489, CSA C22.2

Installation:

Bolt-On

Application:

Lighting, Distribution

Siemens B130HH Miniature Circuit Breakers (MCBs)

SKU:

C15-18954

Short Description:

120 VAC, 30 A, 65 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Number of Poles:

1

Country of Origin:

MEX

Type:

Molded Case, Thermal and Fixed Magnetic

Interrupting Rating:

65 kA at 120 VAC (UL)

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Current Rating:

30 A

Used On:

P1/P2/P3/P4/P5 Panelboard

Application:

Lighting, Distribution

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Approval:

UL 489, CSA C22.2

Data Sheet:

SiemensAG_05171_1_DATA.pdf

Installation/Operator:

SiemensAG_00215_INST.pdf

Installation:

Bolt-On

Siemens B135H Miniature Circuit Breakers (MCBs)

SKU:

C15-10305

TS PIK:

120831405

Country of Origin:

MEX

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Type:

Branch

Current Rating:

35 A

Number of Poles:

1

Approval:

UL 489, CSA C22.2

Application:

Lighting/Distribution

Installation/Operator:

SiemensAG_00215_INST.pdf

Short Description:

120 VAC, 35 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Data Sheet:

SiemensAG_05173_1_DATA.pdf

Used On:

P1/P2/P3/P4/P5 Series Panelboard

Installation:

Bolt-On

Voltage Rating:

120 VAC at 50/60 Hz

Interrupting Rating:

22 kA

Siemens B140H Miniature Circuit Breakers (MCBs)

SKU:

C15-10306

TS PIK:

111063526

Number of Poles:

1

Short Description:

120 VAC, 40 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Current Rating:

40 A

Data Sheet:

SiemensAG_05174_1_DATA.pdf

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Country of Origin:

MEX

Voltage Rating:

120 VAC

Installation/Operator:

SiemensAG_00215_INST.pdf

Type:

Molded Case

Approval:

UL 489

Used On:

Panelboard

Interrupting Rating:

22 kA at 120 VAC

Installation:

Bolt-On

Application:

Lighting

Siemens B145 Miniature Circuit Breakers (MCBs)

SKU:

C15-18957

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Series:

BL

Voltage Rating:

120/240 VAC

Number of Poles:

1

Interrupting Rating:

10000 A

Current Rating:

45 A

Short Description:

120 VAC, 45 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Data Sheet:

SiemensAG_05175_1_DATA.pdf

Approval:

UL 489, CSA C22.2

Installation/Operator:

SiemensAG_00215_INST.pdf

Used On:

P1/P2/P3/P4/P5 Panelboard

Country of Origin:

MEX

Siemens B150 Miniature Circuit Breakers (MCBs)

SKU:

C15-6073

Used On:

Combination Service Entrance Device, Load Center

Catalog:

SchneiderElectric-SquareD_03264_1_33_1_40_CAT.pdf

Mounting:

Bolt-On

Data Sheet:

SchneiderElectric-SquareD_12321_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00004_INST.pdf

Short Description:

1-1/2", Bolt-On Mount, Rainproof, Load Center Hub

Number of Poles:

1

Size:

Standard

Type:

Bathroom Tissue, Roll

Country of Origin:

Mexico

Siemens B150H Miniature Circuit Breakers (MCBs)

SKU:

C15-12078

Interrupting Rating:

22 kA at 120 VAC (UL)

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic

Approval:

UL 489, CSA C22.2

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Installation:

Bolt-On

Country of Origin:

MEX

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Data Sheet:

SiemensAG_05177_1_DATA.pdf

Used On:

P1/P2/P3/P4/P5 Panelboard

Application:

Lighting, Distribution

Installation/Operator:

SiemensAG_00215_INST.pdf

Short Description:

120 VAC, 50 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Current Rating:

50 A

Siemens B160H Miniature Circuit Breakers (MCBs)

SKU:

C15-18960

Approval:

UL 489

Country of Origin:

USA

Short Description:

120 VAC, 60 A, 22 kA, 1-Pole, Bolt-On Mount, Molded Case, Branch, Panelboard Circuit Breaker

Application:

Lighting

Data Sheet:

SiemensAG_05179_1_DATA.pdf

Installation/Operator:

SiemensAG_00215_INST.pdf

Number of Poles:

1

Type:

Molded Case

Used On:

Panelboard

Installation:

Bolt-On

Interrupting Rating:

22 kA at 120 VAC

Current Rating:

60 A

Voltage Rating:

120 VAC

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Siemens B170 Miniature Circuit Breakers (MCBs)

SKU:

C15-15387

Approval:

UL 489, CSA C22.2

Installation/Operator:

SiemensAG_00215_INST.pdf

Interrupting Rating:

10 kA at 120 VAC (UL)

Number of Poles:

1

Country of Origin:

MEX

Short Description:

120 VAC, 70 A, 10 kA, 1-Pole, Bolt-On Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Current Rating:

70 A

Catalog:

SiemensAG_00564_7_29_CAT.pdf

Data Sheet:

SiemensAG_05180_1_DATA.pdf

Installation:

Bolt-On

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Type:

Molded Case, Thermal and Fixed Magnetic

Siemens B170H Miniature Circuit Breakers (MCBs)

SKU:

C15-10307

TS PIK:

115554972

Type:

Molded Case, Thermal Magnetic

Number of Poles:

1

Interrupting Rating:

22 kA at 120 VAC

Installation/Operator:

SiemensAG_00053_INST.pdf

Country of Origin:

MEX

Short Description:

120 VAC, 70 A, 22 kA Interrupt, 1-Pole, Molded Case, Thermal Magnetic, Panelboard Circuit Breaker

Installation:

Bolt-On

Catalog:

SiemensAG_23946_10_16_CAT.pdf

Application:

Lighting, Distribution

Approval:

UL 489, CSA C22.2

Used On:

Panelboard

Current Rating:

70 A

Voltage Rating:

120 VAC

Siemens BE115 Miniature Circuit Breakers (MCBs)

SKU:

C15-10344

TS PIK:

115554685

Type:

Molded Case, Low Vage, Circuit Protector, Thermal Magnetic

Voltage Rating:

120 VAC

Current Rating:

15 A

Installation/Operator:

SiemensAG_00694_INST.pdf

Size:

1 Inch Width

Interrupting Rating:

10 kA

Used On:

Panelboard

Mounting:

Bolt-On

Number of Poles:

1

Short Description:

120 VAC, 15 A, 10 kA Interrupt, 1-Pole, Bolt-On, Thermal Magnetic, Circuit Protector, Low Vage, Molded Case Ground Fault Circuit Breaker

Country of Origin:

Philippines

Approval:

UL 489

Trip Sensitivity:

30 MilliA

Siemens BE120 Miniature Circuit Breakers (MCBs) 1P 20A EA

SKU:

C15-6246

TS PIK:

21368440

Type:

Equipment Protector

Voltage Rating:

120 VAC

Terminal Type:

Load Lug

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Size:

1 Inch W

Interrupting Rating:

10 kA

Wire Size:

14 to 10 AWG (Copper), 12 to 8 AWG (Aluminum)

Number of Poles:

1

Short Description:

120 VAC, 20 A, 10 kA, 30 mA, 1-Pole, Bolt-On Mount, BLE Frame, Ground Fault Equipment Protector, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Mounting:

Bolt-On

Current Rating:

20 A

Data Sheet:

SiemensAG_05300_1_DATA.pdf

Country of Origin:

Philippines

Trip Sensitivity:

30 MilliA

Approval:

UL 489, CSA C22.2

Siemens BE120 Molded Case Breakers (MCCBs)

SKU:

C15-8936

TS PIK:

21368440

Type:

Equipment Protector

Terminal Type:

Load Lug

Number of Poles:

1

Data Sheet:

SiemensAG_05300_1_DATA.pdf

Voltage Rating:

120 VAC

Current Rating:

20 A

Mounting:

Bolt-On

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Interrupting Rating:

10 kA

Wire Size:

14 to 10 AWG (Copper), 12 to 8 AWG (Aluminum)

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Short Description:

120 VAC, 20 A, 10 kA, 30 mA, 1-Pole, Bolt-On Mount, BLE Frame, Ground Fault Equipment Protector, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Size:

1 Inch W

Country of Origin:

PHL

Approval:

UL 489, CSA C22.2

Siemens BE120H Miniature Circuit Breakers (MCBs) 1P 20A

SKU:

C15-7536

Short Description:

120 VAC, 20 A, 22 kA, 30 mA, 1-Pole, Bolt-On Mount, BLEH Frame, Ground Fault Equipment Protector, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Type:

Equipment Protector

Voltage Rating:

120 VAC

Current Rating:

20 A

Terminal Type:

Load Lug

Mounting:

Bolt-On

Size:

1 Inch W

Number of Poles:

1

Interrupting Rating:

22 kA

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Wire Size:

14 to 10 AWG (Copper), 12 to 8 AWG (Aluminum)

Data Sheet:

SiemensAG_05301_1_DATA.pdf

Country of Origin:

Philippines

Siemens BE130 Miniature Circuit Breakers (MCBs) 1P 30A 120V

SKU:

C15-4914

Series:

BLE

Type:

Molded Case

Type:

Thermal Magnetic

Type:

Equipment Protector

Approval:

UL 489

Size:

3.6 Inch Width x 5.6 Inch Depth x 1.4 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Loadcenter

Used On:

P1/P2/P3/P4/P5 Panelboard

Poles:

1

Mounting:

Bolt-On

Interrupting Rating:

10 kA

Terminal Type:

Load Lug

Wire Size:

12 to 8 AWG (Aluminum)

Wire Size:

14 to 10 AWG (Copper)

Trip Sensitivity:

30 MilliA

Short Description:

120 VAC, 30 A, 10 kA, 30 mA, 1-Pole, Bolt-On Mount, BLE Frame, Ground Fault Equipment Protector, Thermal Magnetic Trip Unit

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Data Sheet:

SiemensAG_05302_1_DATA.pdf

TS PIK:

578159

Voltage Rating:

120 VAC

Number of Poles:

1

Current Rating:

30 A

Country of Origin:

Philippines

Siemens BE130H Miniature Circuit Breakers (MCBs)

SKU:

C15-18969

Interrupting Rating:

22 kA

Current Rating:

30 A

Trip Sensitivity:

30 MilliA

Approval:

UL 489

Data Sheet:

SiemensAG_05303_1_DATA.pdf

Short Description:

120 VAC, 30 A, 22 kA, 30 mA, 1-Pole, Bolt-On Mount, BLEH Frame, Ground Fault Equipment Protector, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Mounting:

Bolt-On

Country of Origin:

PHL

Type:

Equipment Protector

Voltage Rating:

120 VAC

Size:

4 Inch W x 1 Inch D x 5 Inch H

Number of Poles:

1

Used On:

Panelboard

Siemens BF115 Miniature Circuit Breakers (MCBs) B 1P 15A 120/240V 50/60Hz 1Ph

SKU:

C15-3029

Approval:

UL 489/943

Approval:

CSA C22.2

Amps:

15 A

Interrupting Rating:

10 kA

Mounting:

Bolt-On

Poles:

1

Size:

1 Inch W

Terminal Type:

Load Lug

Trip Sensitivity:

5 MilliA

Type:

Circuit Interrupter

Used On:

Loadcenter

Used On:

P1/P2/P3/P4/P5 Panelboard

Volts:

120 VAC

Gauge:

14 to 10 AWG (Copper)

Gauge:

12 to 8 AWG (Aluminum)

Short Description:

120 VAC, 15 A, 10 kA, 5 mA, 1-Pole, Bolt-On Mount, BLF Frame, GFCI, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Data Sheet:

SiemensAG_05308_1_DATA.pdf

Current Rating:

15 A

Wire Size:

14 to 10 AWG (Copper), 12 to 8 AWG (Aluminum)

Number of Poles:

1

Voltage Rating:

120 VAC

Siemens BF115A Miniature Circuit Breakers (MCBs)

SKU:

C15-10348

TS PIK:

126617514

Voltage Rating:

120 VAC

Interrupting Rating:

10 kA

Current Rating:

15 A

Type:

Circuit Interrupter

Data Sheet:

SiemensAG_05309_1_DATA.pdf

Number of Poles:

1

Used On:

Panelboard

Short Description:

120 VAC, 15 A, 10 kA, 5 mA, 1-Pole, Bolt-On Mount, BLF Frame, GFCI, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Mounting:

Bolt-On

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Country of Origin:

Philippines

Trip Sensitivity:

5 MilliA

Siemens BF120 Miniature Circuit Breakers (MCBs) B 1P 20A 120/240V 50/60Hz 1Ph

SKU:

C15-4915

TS PIK:

21368437

Data Sheet:

SiemensAG_01606_1_DATA.pdf

Terminal Type:

Load Lug

Current Rating:

20 A

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Series:

BF

Type:

Thermal Magnetic, Circuit Protector

Size:

5.7 Inch Width x 3.8 Inch Depth x 1.8 Inch Height

Number of Poles:

1

Interrupting Rating:

10 kA

Voltage Rating:

120 VAC

Wire Size:

12 to 8 AWG (Aluminum), 14 to 10 AWG (Copper)

Mounting:

Bolt-On

Short Description:

120 VAC, 20 A, 10 kA Interrupt, 1-Pole, Thermal Magnetic, Circuit Protector, Ground Fault Circuit Breaker

Siemens BF120A Miniature Circuit Breakers (MCBs)

SKU:

C15-2958

TS PIK:

126617515

Interrupting Rating:

10 kA

Number of Poles:

1

Type:

Circuit Interrupter

Short Description:

120 VAC, 20 A, 10 kA, 5 mA, 1-Pole, Bolt-On Mount, BLF Frame, GFCI, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Current Rating:

20 A

Voltage Rating:

120 VAC

Trip Sensitivity:

5 MilliA

Mounting:

Bolt-On

Data Sheet:

SiemensAG_05310_1_DATA.pdf

Used On:

Panelboard

Country of Origin:

PHL

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Siemens BF120AH Miniature Circuit Breakers (MCBs) 1P 20A

SKU:

C15-7382

Short Description:

120 VAC, 20 A, 22 kA Interrupt, 5 mA Trip Level, 1-Pole, Bolt-On, Circuit Protector, Low Vage, Type BLHF, Molded Case Ground Fault Circuit Breaker

Used On:

Load Center, Panelboard

Type:

Molded Case, Low Vage, Thermal Magnetic

Voltage Rating:

120 VAC

Approval:

UL 943, CSA

Size:

1 Inch Width

Number of Poles:

1

Terminal Type:

Load Lug

Interrupting Rating:

22 kA

Mounting:

Bolt-On

Country of Origin:

PHL

Current Rating:

20 A

Installation/Operator:

SiemensAG_00696_INST.pdf

Trip Sensitivity:

5 MilliA

Catalog:

SiemensAG_23946_10_17_CAT.pdf

Data Sheet:

SiemensAG_57213_1_2_DATA.pdf

Siemens BF120H Miniature Circuit Breakers (MCBs)

SKU:

C15-6081

TS PIK:

115270495

Data Sheet:

SiemensAG_05311_1_DATA.pdf

Mounting:

Bolt-On

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Type:

Circuit Interrupter

Catalog:

SiemensAG_00564_7_30_CAT.pdf

Voltage Rating:

120 VAC

Short Description:

120 VAC, 20 A, 22 kA, 5 mA, 1-Pole, Bolt-On Mount, BLHF Frame, GFCI, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Wire Size:

14 to 10 AWG (Copper), 12 to 8 AWG (Aluminum)

Number of Poles:

1

Current Rating:

20 A

Size:

1 Inch W

Interrupting Rating:

22 kA

Terminal Type:

Load Lug

Siemens BF130 Miniature Circuit Breakers (MCBs)

SKU:

C15-6126

TS PIK:

21368438

Interrupting Rating:

10 kA

Terminal Type:

Load Lug

Type:

Molded Case, Thermal Magnetic, Circuit Interrupter

Series:

BLF

Current Rating:

30 A

Voltage Rating:

120 VAC

Number of Poles:

1

Used On:

Loadcenter, P1/P2/P3/P4/P5 Panelboard

Short Description:

120 VAC, 30 A, 10 kA, 5 mA, 1-Pole, Bolt-On Mount, BLF Frame, GFCI, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Data Sheet:

SiemensAG_05312_1_DATA.pdf

Mounting:

Bolt-On

Wire Size:

12 to 8 AWG (Aluminum), 14 to 10 AWG (Copper)

Size:

4 Inch Width x 1 Inch Depth x 5 Inch Height

Country of Origin:

PHL

Approval:

UL 943

Trip Sensitivity:

5 MilliA

Siemens BF130A Miniature Circuit Breakers (MCBs) EA

SKU:

C15-10349

TS PIK:

127112407

Type:

Molded Case, Low Vage, Thermal Magnetic

Short Description:

120 VAC, 30 A, 10 kA Interrupt, 5 mA Trip Level, 1-Pole, Bolt-On, Circuit Protector, Low Vage, Type BLF2, Molded Case Ground Fault Circuit Breaker

Voltage Rating:

120 VAC

Interrupting Rating:

10 kA

Terminal Type:

Load Lug

Number of Poles:

1

Size:

1 Inch Width

Mounting:

Bolt-On

Used On:

Load Center, Panelboard

Installation/Operator:

SiemensAG_00697_INST.pdf

Catalog:

SiemensAG_23946_10_17_CAT.pdf

Data Sheet:

SiemensAG_10277_1_DATA.pdf

Current Rating:

30 A

Country of Origin:

Philippines

Trip Sensitivity:

5 MilliA

Approval:

UL 943, CSA

Siemens BF130AH Miniature Circuit Breakers (MCBs)

SKU:

C15-18970

Approval:

UL 943, CSA

Data Sheet:

SiemensAG_10278_1_2_DATA.pdf

Type:

Molded Case, Low Vage, Thermal Magnetic

Country of Origin:

PHL

Size:

1 Inch Width

Catalog:

SiemensAG_01796_7_30_CAT.pdf

Number of Poles:

1

Trip Sensitivity:

5 MilliA

Interrupting Rating:

22 kA

Voltage Rating:

120 V AC

Installation/Operator:

SiemensAG_00696_INST.pdf

Current Rating:

30 A

Short Description:

BRKR BLHF2 GFCI 5MA 1P 120V 30A 22kA

Used On:

Load Center, Panelboard

Mounting:

Bolt-On

Terminal Type:

Load Lug

Siemens BG2B020 Miniature Circuit Breakers (MCBs)

SKU:

C15-15499

Number of Poles:

1

Type:

Low Vage, Circuit Protector, Thermal Magnetic, Switching Neutral

Mounting:

Bolt-On

Approval:

UL 489

Interrupting Rating:

10 kA

Current Rating:

20 A

Data Sheet:

SiemensAG_10291_1_2_DATA.pdf

Voltage Rating:

120 V

Size:

5 Inch Width x 6 Inch Depth x 4 Inch Height

Siemens BQ1B015 Miniature Circuit Breakers (MCBs)

SKU:

C15-6082

TS PIK:

21366171

Number of Poles:

1

Interrupting Rating:

10 kA

Type:

Molded Case, Thermal and Fixed Magnetic Trip, Low Vage

Size:

1 Inch Width x 2.37 Inch Depth x 3.75 Inch Height

Series:

BQ

Voltage Rating:

120 VAC 50/60 Hertz

Data Sheet:

SiemensAG_05348_1_DATA.pdf

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Terminal Type:

Load Side Lug, Bolt-On

Current Rating:

15 A

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Country of Origin:

Mexico

Siemens BQ1B015H Miniature Circuit Breakers (MCBs) 15A 120V

SKU:

C15-6127

TS PIK:

124819774

Catalog:

SiemensAG_09175_0_8_17_1_17_8_17_133_CAT.pdf

Size:

1 Inch Width x 3 Inch Depth x 4 Inch Height

Interrupting Rating:

22 kA

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Type:

Molded Case, Low Vage, Circuit Protector

Number of Poles:

1

Data Sheet:

SiemensAG_09541_1_2_DATA.pdf

Terminal Type:

Load Lug

Country of Origin:

Mexico

Short Description:

BRKR BQH 1P 120V 15A 22K

Approval:

UL 489

Maximum AC Voltage Rating:

240 V

Siemens BQ1B015QLD Molded Case Breakers (MCCBs)

SKU:

C15-15614

Short Description:

120/240 VAC, 15 A, 10 kA, 1-Pole, Line/Load Lug Terminal, DIN Rail Mount, BQLD Frame, Bolt-On, Molded Case Circuit Breaker

Series:

BQXD

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Number of Poles:

1

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Current Rating:

15 A

Size:

1 Inch W x 3 Inch D x 4-1/2 Inch H

Country of Origin:

MEX

Type:

Molded Case, Thermal and Fixed Magnetic Trip

Terminal Type:

Line Lug

Wire Size:

14 to 6 AWG (Copper), 12 to 6 AWG (Aluminum)

Catalog:

SiemensAG_01698_17_1_17_8_CAT.pdf

Used On:

P1/P2/P3/P4/P5 Panelboard

Mounting:

DIN Rail

Data Sheet:

SiemensAG_05349_1_DATA.pdf

Approval:

UL

Siemens BQ1B020H Miniature Circuit Breakers (MCBs) 20A 120V

SKU:

C15-6250

TS PIK:

21366738

Wire Size:

14 to 10 AWG (Copper), 12 to 10 AWG (Aluminum)

Number of Poles:

1

Series:

BQH

Type:

Molded Case, Thermal and Fixed Magnetic

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Data Sheet:

SiemensAG_05351_1_DATA.pdf

Terminal Type:

Load Lug

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Short Description:

120/240 VAC, 20 A, 22 kA, 1-Pole, Load Lug Terminal, BQH Frame, Bolt-On, Molded Case Circuit Breaker

Current Rating:

20 A

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Interrupting Rating:

22 kA at 120 VAC Symmetrical (UL)

Used On:

P1/P2/P3/P4/P5 Panelboard

Mounting:

Bolt-On

Country of Origin:

Mexico

Approval:

UL

Siemens BQ1B025 Molded Case Breakers (MCCBs)

SKU:

C15-15615

Short Description:

120/240 VAC, 25 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Series:

BQ

Current Rating:

25 A

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Wire Size:

14 to 6 AWG (Copper), 12 to 6 AWG (Aluminum)

Country of Origin:

MEX

Data Sheet:

SiemensAG_05354_1_DATA.pdf

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic

Terminal Type:

Load Lug

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Approval:

UL

Used On:

P1/P2/P3/P4/P5 Panelboard

Siemens BQ1B035 Molded Case Breakers (MCCBs)

SKU:

C15-15619

Series:

BQ

Short Description:

120/240 VAC, 35 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Country of Origin:

MEX

Number of Poles:

1

Type:

Molded Case, Thermal and Fixed Magnetic

Current Rating:

35 A

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Terminal Type:

Load Lug

Data Sheet:

SiemensAG_05356_1_DATA.pdf

Approval:

UL

Used On:

P1/P2/P3/P4/P5 Panelboard

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Wire Size:

14 to 6 AWG (Copper), 12 to 6 AWG (Aluminum)

Siemens BQ1B040 Miniature Circuit Breakers (MCBs)

SKU:

C15-8428

TS PIK:

124819775

Number of Poles:

1

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Terminal Type:

Load Lug

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Data Sheet:

SiemensAG_05357_1_DATA.pdf

Voltage Rating:

120 VAC

Wire Size:

8 to 6 AWG (Copper), 8 to 4 AWG (Aluminum)

Used On:

P1/P2/P3/P4/P5 Panelboard

Short Description:

120/240 VAC, 40 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Series:

BQ

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Current Rating:

40 A

Type:

Molded Case, Thermal and Fixed Magnetic

Country of Origin:

Mexico

Approval:

UL

Siemens BQ1B040H Miniature Circuit Breakers (MCBs)

SKU:

C15-18976

Country of Origin:

MEX

Interrupting Rating:

22 kA

Short Description:

BRKR BQH 1P 120V 40A 22K

Number of Poles:

1

Size:

1 Inch Width x 3 Inch Depth x 4 Inch Height

Catalog:

SiemensAG_09175_0_8_17_1_17_8_17_133_CAT.pdf

Approval:

UL 489

Voltage Rating:

120/240 VAC

Type:

Molded Case, Low Vage, Circuit Protector

Current Rating:

40 A

Terminal Type:

Load Lug

Data Sheet:

SiemensAG_09543_1_2_DATA.pdf

Maximum AC Voltage Rating:

240 V

Siemens BQ1B045 Molded Case Breakers (MCCBs)

SKU:

C15-15620

Series:

BQ

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Terminal Type:

Load Lug

Short Description:

120/240 VAC, 45 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Country of Origin:

MEX

Type:

Molded Case, Thermal and Fixed Magnetic

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Data Sheet:

SiemensAG_05358_1_DATA.pdf

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Current Rating:

45 A

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Approval:

UL

Number of Poles:

1

Used On:

P1/P2/P3/P4/P5 Panelboard

Wire Size:

8 to 6 AWG (Copper), 8 to 4 AWG (Aluminum)

Siemens BQ1B050 Miniature Circuit Breakers (MCBs) 50A 120V

SKU:

C15-6129

TS PIK:

115270499

Terminal Type:

Load Lug

Short Description:

120/240 VAC, 50 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Series:

BQ

Voltage Rating:

120 VAC

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Current Rating:

50 A

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Number of Poles:

1

Size:

1 Inch W x 3 Inch D x 3-3/4 Inch H

Data Sheet:

SiemensAG_05359_1_DATA.pdf

Wire Size:

8 to 6 AWG (Copper), 8 to 4 AWG (Aluminum)

Used On:

P1/P2/P3/P4/P5 Panelboard

Type:

Molded Case, Thermal and Fixed Magnetic

Country of Origin:

Mexico

Approval:

UL

Siemens BQ1B060 Miniature Circuit Breakers (MCBs) 60A 120V

SKU:

C15-6130

TS PIK:

124234485

Series:

BQ

Type:

Molded Case, Thermal and Fixed Magnetic

Current Rating:

60 A

Data Sheet:

SiemensAG_05361_1_DATA.pdf

Short Description:

120/240 VAC, 60 A, 10 kA, 1-Pole, Load Lug Terminal, BQ Frame, Bolt-On, Molded Case Circuit Breaker

Number of Poles:

1

Voltage Rating:

120 VAC at 50/60 Hz (UL)

Size:

1 Inch W x 3 Inch D x 4 Inch H

Terminal Type:

Load Lug

Wire Size:

8 to 4 AWG (Copper), 8 to 2 AWG (Aluminum)

Used On:

P1/P2/P3/P4/P5 Panelboard

Catalog:

SiemensAG_01698_17_1_17_7_CAT.pdf

Interrupting Rating:

10 kA at 120 VAC Symmetrical (UL)

Mounting:

Bolt-On

Country of Origin:

Mexico

Approval:

UL

Siemens BQ1B070 Miniature Circuit Breakers (MCBs) 70A 120V

SKU:

C15-6131

TS PIK:

124234486

Catalog:

SiemensAG_57191_7_4_7_5_7_8_7_38_7_39_7_156_CAT.pdf

Short Description:

120/240 VAC, 70 A, 10 kA Interrupt, 1-Pole, BQ Frame, Load Lug Terminal, Low Vage, Circuit Protector, Molded Case, Non-Interchangeable Trip Circuit Breaker

Number of Poles:

1

Type:

Molded Case, Low Vage, Circuit Protector

Size:

1 Inch Width x 3 Inch Depth x 4 Inch Height

Interrupting Rating:

10 kA

Terminal Type:

Load Lug

Voltage Rating:

120/240 VAC

Current Rating:

70 A

Country of Origin:

Mexico

Approval:

UL 489

Maximum AC Voltage Rating:

240 V

Siemens BQD1100 Miniature Circuit Breakers (MCBs)

SKU:

C15-10365

TS PIK:

21368638

Frame Type:

BQD

Type:

Molded Case, Low Vage, Low Tab

Catalog:

SiemensAG_57191_7_4_7_5_7_32_7_35_CAT.pdf

Interrupting Rating:

65 kA at 120 V AC, 14 kA at 125 V DC

Maximum AC Voltage Rating:

120 V

Number of Poles:

1

Country of Origin:

MEX

Size:

3 Inch Width x 4 Inch Depth x 1 Inch Height

Approval:

UL 489, CSA C22.2

Terminal Type:

Load Lug

Short Description:

277 VAC, 125 VDC, 100 A, 14/65 kA Interrupt, 1-Pole, BQD Frame, Load Lug Terminal, Low Vage, Low Tab, Molded Case, Non-Interchangeable Trip Circuit Breaker

Current Rating:

100 A

Voltage Rating:

120 V AC 50/60 Hertz, 125 V DC

Siemens BQD115 Miniature Circuit Breakers (MCBs) 15A 277V

SKU:

C15-6148

TS PIK:

21366177

Short Description:

277 VAC, 15 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Panelboard Circuit Breaker

Series:

BQD

Installation/Operator:

SiemensAG_00221_INST.pdf

Data Sheet:

SiemensAG_01385_1_DATA.pdf

Interrupting Rating:

14 kA

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Type:

Molded Case, Thermal and Fixed Magnetic Trip

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Current Rating:

15 A

Number of Poles:

1

Used On:

P1 Panelboard

Country of Origin:

Mexico

Application:

Construction

Approval:

UL 489, CSA-C22.2

Siemens BQD12000S01 Miniature Circuit Breakers (MCBs)

SKU:

C15-15675

Catalog:

SiemensAG_00564_7_29_7_32_CAT.pdf

Number of Poles:

1

Current Rating:

20 A

Installation:

Bolt-On

Data Sheet:

SiemensAG_05412_1_DATA.pdf

Interrupting Rating:

14 kA

Installation/Operator:

SiemensAG_00221_INST.pdf

Application:

Electrical Distribution

Approval:

CSA C22.2, HACR

Country of Origin:

MEX

Short Description:

277 VAC, 20 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Shunt Trip, Panelboard Circuit Breaker

Voltage Rating:

277 VAC

Siemens BQD140 Miniature Circuit Breakers (MCBs) 1P 40A 277V

SKU:

C15-6087

TS PIK:

115270729

Data Sheet:

SiemensAG_05416_1_DATA.pdf

Series:

BQD

Current Rating:

40 A

Short Description:

277 VAC, 40 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Type:

Molded Case, Thermal and Fixed Magnetic Trip

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Interrupting Rating:

14 kA

Used On:

P1 Panelboard

Number of Poles:

1

Installation/Operator:

SiemensAG_00221_INST.pdf

Country of Origin:

Mexico

Application:

Construction

Approval:

UL 489, CSA-C22.2

Siemens BQD150 Miniature Circuit Breakers (MCBs) 1P 50A 277V

SKU:

C15-6154

TS PIK:

21368629

Installation/Operator:

SiemensAG_00221_INST.pdf

Voltage Rating:

277 VAC at 50/60 Hz, 125 VDC (UL)

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Current Rating:

50 A

Data Sheet:

SiemensAG_05418_1_DATA.pdf

Short Description:

277 VAC, 50 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Interrupting Rating:

14 kA at 277 VAC/125 VDC (UL)

Series:

BQD

Used On:

P1/P2/P3/P4/P5 Panelboard

Number of Poles:

1

Type:

Branch, Molded Case, Thermal and Fixed Magnetic

Country of Origin:

Mexico

Installation:

Bolt-On

Approval:

UL

Application:

Lighting, Distribution

Siemens BQD160 Miniature Circuit Breakers (MCBs) 1P 60A 277V

SKU:

C15-6156

TS PIK:

21368631

Short Description:

277 VAC, 60 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Series:

BQD

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Number of Poles:

1

Used On:

P1 Panelboard

Data Sheet:

SiemensAG_05419_1_DATA.pdf

Current Rating:

60 A

Type:

Molded Case, Thermal and Fixed Magnetic Trip

Interrupting Rating:

14 kA

Installation/Operator:

SiemensAG_00221_INST.pdf

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Country of Origin:

Mexico

Approval:

UL 489, CSA-C22.2

Application:

Construction

Siemens BQD170 Miniature Circuit Breakers (MCBs)

SKU:

C15-15676

Country of Origin:

MEX

Series:

BQD

Number of Poles:

1

Voltage Rating:

277 VAC at 50/60 Hz, 125 VDC (UL)

Short Description:

277 VAC, 70 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Installation/Operator:

SiemensAG_00221_INST.pdf

Interrupting Rating:

14 kA at 277 VAC/125 VDC (UL)

Type:

Branch, Molded Case, Thermal and Fixed Magnetic

Approval:

UL

Used On:

P1/P2/P3/P4/P5 Panelboard

Application:

Lighting, Distribution

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Installation:

Bolt-On

Data Sheet:

SiemensAG_05420_1_DATA.pdf

Current Rating:

70 A

Siemens BQD180 Miniature Circuit Breakers (MCBs)

SKU:

C15-15677

Number of Poles:

1

Country of Origin:

MEX

Current Rating:

180 A

Interrupting Rating:

65 kA at 120 V AC, 14 kA at 125 V DC

Type:

Molded Case, Low Vage, Low Tab

Short Description:

BREAKER BQD 1P 80A 277VAC 14kA

Approval:

UL 489, CSA C22.2

Terminal Type:

Load Lug

Size:

3 Inch Width x 4 Inch Depth x 1 Inch Height

Voltage Rating:

120 V AC 50/60 Hertz, 125 V DC

Frame Type:

BQD

Catalog:

SiemensAG_09188_1_2_CAT.pdf

Maximum AC Voltage Rating:

120 V

Data Sheet:

SiemensAG_09569_1_2_DATA.pdf

Siemens BQD190 Miniature Circuit Breakers (MCBs)

SKU:

C15-15678

Country of Origin:

MEX

Series:

BQD

Interrupting Rating:

14 kA at 277 VAC/125 VDC (UL)

Approval:

UL

Used On:

P1/P2/P3/P4/P5 Panelboard

Data Sheet:

SiemensAG_05421_1_DATA.pdf

Current Rating:

90 A

Installation/Operator:

SiemensAG_00221_INST.pdf

Catalog:

SiemensAG_00565_11_16_CAT.pdf

Application:

Lighting, Distribution

Number of Poles:

1

Type:

Branch, Molded Case, Thermal and Fixed Magnetic

Short Description:

277 VAC, 90 A, 14 kA, 1-Pole, Low-Tab Mount, Molded Case, Thermal Magnetic Trip Unit, Branch, Panelboard Circuit Breaker

Voltage Rating:

277 VAC at 50/60 Hz, 125 VDC (UL)

Installation:

Bolt-On

Siemens CQD115 Molded Case Breakers (MCCBs)

SKU:

C15-15809

Type:

Molded Case, Thermal and Fixed Magnetic

Approval:

UL

Number of Poles:

1

Series:

CQD

Mounting:

Cable In, Cable Out, DIN Rail

Size:

1 Inch W x 2.88 Inch D x 4.9 Inch H

Interrupting Rating:

65 kA at 120 VAC, 14 kA at 277 VAC/125 VDC (UL)

Short Description:

277 VAC, 125 VDC, 15 A, 14 kA, 1-Pole, 14 to 6 AWG Copper/12 to 6 AWG Aluminum, Load Lug Terminal, DIN Rail Mount, CQD Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Wire Size:

14 to 6 AWG (Copper), 12 to 6 AWG (Aluminum)

Terminal Type:

Load Lug

Current Rating:

15 A

Voltage Rating:

277 VAC at 50/60 Hz, 125 VDC (UL)

Country of Origin:

MEX

Catalog:

SiemensAG_01698_17_1_17_11_CAT.pdf

Siemens CQD120 Din Rail Mounted Circuit Breakers

SKU:

C15-10369

TS PIK:

115555332

Number of Poles:

1

Short Description:

277 VAC, 20 A, 14 kA Interrupt, 1-Pole, DIN Rail Mount, Low Vage, Circuit Protector, General Purpose, Type CQD, Molded Case Circuit Breaker

Current Rating:

20 A

Interrupting Rating:

14 kA at 277 VAC/125 VDC

Mounting:

Cable In, Cable Out, DIN Rail

Terminal Type:

Load Lug

Wire Size:

14 to 6 AWG (Copper), 12 to 6 AWG (Aluminum)

Type:

Low Vage, Circuit Protector, Thermal Magnetic

Size:

1 Inch Width x 2.88 Inch Depth x 4.9 Inch Height

Approval:

UL 489

Installation/Operator:

SiemensAG_00612_INST.pdf

Country of Origin:

MEX

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Siemens D130 Miniature Circuit Breakers (MCBs) 1P 30A

SKU:

C15-6347

TS PIK:

110611689

Voltage Rating:

115 VAC 1-Phase

Short Description:

1/40 HP, 115 VAC 60 Hz 1-Phase, 1 A, 4-Pole, 1550 RPM, 1-Speed, Steel Frame, Class B Insulation, Extended Stud Mount, Clockwise Shaft End, Sleeve Drive End Bearing, Flat Shaft, Shaded Pole, OAO, HVAC/R Motor

Data Sheet:

RegalRexnordCorp-Link-Fasco_00320_1_2_DATA.pdf

Mounting:

Extended Stud

CAD Drawings:

RegalRexnordCorp-Link-Fasco_00836_1_2_CAD.pdf

Installation/Operator:

RegalRexnordCorp-Link-Fasco_00001_INST.pdf

Number of Poles:

1

Country of Origin:

Mexico

Siemens ED21B015 Molded Case Breakers (MCCBs)

SKU:

C15-15817

Series:

ED2

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Number of Poles:

1

Short Description:

120 VAC 50/60 Hz, 125 VDC, 15 A, 10 kA, 1-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Country of Origin:

MEX

Voltage Rating:

120 VAC, 125 VDC

Approval:

UL 489, IEC 947-2

Current Rating:

15 A

Type:

Thermal Magnetic

Interrupting Rating:

10 kA at 120 VAC (UL 489), 5 kA at 125 VDC (UL 489)

Maximum AC Voltage Rating:

120 V

Installation/Operator:

SiemensAG_00313_INST.pdf

Terminal Type:

Load Lug

Frame Type:

ED

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Maximum DC Voltage Rating:

125 V

Siemens ED21B020 Molded Case Breakers (MCCBs)

SKU:

C15-6172

TS PIK:

21367310

Current Rating:

20 A

Series:

ED2

Country of Origin:

MEX

Interrupting Rating:

10 kA at 120 VAC (UL 489), 5 kA at 125 VDC (UL 489)

Number of Poles:

1

Short Description:

120 VAC 50/60 Hz, 125 VDC, 20 A, 10 kA, 1-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Voltage Rating:

120 VAC, 125 VDC

Type:

Thermal Magnetic

Terminal Type:

Load Lug

Frame Type:

ED

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Approval:

UL 489

Installation/Operator:

SiemensAG_00313_INST.pdf

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Siemens ED21B040 Miniature Circuit Breakers (MCBs)

SKU:

C15-15820

Voltage Rating:

120 V AC, 125 V DC

Short Description:

120 VAC 50/60 Hz, 125 VDC, 40 A, 10 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Country of Origin:

MEX

Terminal Type:

Load Lug

Installation/Operator:

SiemensAG_00313_INST.pdf

Type:

Thermal Magnetic

Approval:

UL 489

Current Rating:

40 A

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Interrupting Rating:

10 kA at 120 V AC (UL 489), 5 kA at 125 V DC (UL 489)

Frame Type:

ED

Series:

ED2

Number of Poles:

1

Siemens ED21B050 Molded Case Breakers (MCCBs)

SKU:

C15-15821

Terminal Type:

Load Lug

Short Description:

120 VAC 50/60 Hz, 125 VDC, 50 A, 10 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Type:

Thermal Magnetic

Current Rating:

50 A

Voltage Rating:

120 VAC, 125 VDC

Frame Type:

ED

Installation/Operator:

SiemensAG_00313_INST.pdf

Maximum DC Voltage Rating:

125 V

Interrupting Rating:

10 kA at 120 VAC (UL 489), 5 kA at 125 VDC (UL 489)

Country of Origin:

USA

Maximum AC Voltage Rating:

120 V

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Series:

ED2

Number of Poles:

1

Approval:

UL 489, IEC 947-2

Siemens ED21B100 Molded Case Breakers (MCCBs)

SKU:

C15-15823

Voltage Rating:

120 VAC, 125 VDC

Number of Poles:

1

Terminal Type:

Load Lug

Approval:

UL 489, IEC 947-2

Maximum DC Voltage Rating:

125 V

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Frame Type:

ED

Type:

Thermal Magnetic

Maximum AC Voltage Rating:

120 V

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Installation/Operator:

SiemensAG_00313_INST.pdf

Interrupting Rating:

10 kA at 120 VAC (UL 489), 5 kA at 125 VDC (UL 489)

Country of Origin:

MEX

Series:

ED2

Current Rating:

100 A

Short Description:

120 VAC 50/60 Hz, 125 VDC, 100 A, 10 kA, 1-Pole, 6 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Siemens ED41B015 Molded Case Breakers (MCCBs)

SKU:

C15-6264

TS PIK:

119495727

Number of Poles:

1

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 15 A, 22 kA, 1-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Interrupting Rating:

65 kA at 120 VAC (UL 489), 22 kA at 277 VAC (UL 489), 30 kA at 125 VDC (UL 489)

Series:

ED4

Current Rating:

15 A

Voltage Rating:

120/277 VAC, 125 VDC

Type:

Thermal Magnetic

Terminal Type:

Load Lug

Installation/Operator:

SiemensAG_00313_INST.pdf

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Frame Type:

ED

Country of Origin:

MEX

Approval:

UL 489

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Siemens ED41B025 Molded Case Breakers (MCCBs)

SKU:

C15-10385

TS PIK:

21367349

Country of Origin:

MEX

Maximum AC Voltage Rating:

277 V

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Rating

Maximum DC Voltage Rating:

125 V

Short Description:

BRKR ED4 1P 480V 25A

Current Rating:

25 A

Voltage Rating:

120/277 VAC 50/60 Hertz, 125 VDC

Approval:

UL 489

Catalog:

SiemensAG_09175_17_1_17_4_17_81-17_84_17_112_17_113_17_123_17_133_CAT.pdf

Interrupting Rating:

65 kA at 120 VAC, 22 kA at 277 VAC, 30 kA at 125 VDC

Number of Poles:

1

Terminal Type:

Load Lug

Installation/Operator:

SiemensAG_00593_INST.pdf

Frame Type:

ED

Size:

1 Inch Width x 3.92 Inch Depth x 6.35 Inch Height

Siemens ED41B030 Molded Case Breakers (MCCBs) 30A 277V

SKU:

C15-4874

Series:

ED4

Type:

Thermal Magnetic

Approval:

UL 489

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Volts:

120/277 VAC

Volts:

125 VDC

Amps:

30 A

Poles:

1

Interrupting Rating:

65 kA at 120 VAC (UL 489)

Interrupting Rating:

22 kA at 277 Volt AC (UL 489)

Interrupting Rating:

30 kA at 125 Volt DC (UL 489)

Terminal Type:

Load Lug

Frame Type:

ED

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 30 A at 40 Deg C, 22 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Installation/Operator:

SiemensAG_00313_INST.pdf

TS PIK:

127544541

Current Rating:

30 A

Number of Poles:

1

Voltage Rating:

120/277 VAC, 125 VDC

Country of Origin:

Mexico

Siemens ED41B035 Molded Case Breakers (MCCBs) 35A 277V

SKU:

C15-6175

TS PIK:

21368410

Type:

Molded Case, Thermal and Fixed Magnetic

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Interrupting Rating:

65 kA at 120 VAC, 22 kA at 277 VAC, 30 kA at 125 VDC (UL)

Installation/Operator:

SiemensAG_00313_INST.pdf

Number of Poles:

1

Series:

ED4

Current Rating:

35 A

Size:

1 Inch W x 4.56 Inch D x 6.35 Inch H

Voltage Rating:

120/277 VAC at 50/60 Hz, 125 VDC (UL)

Terminal Type:

Load Lug

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 35 A at 40 Deg C, 22 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Country of Origin:

Mexico

Approval:

UL 489, CSA C22.2

Wire Size:

10 to 4 AWG (Copper/Aluminum)

Used On:

P1/P2/P3/P4/P5 Panelboard

Mounting:

Plug-On

Siemens ED41B045 Molded Case Breakers (MCCBs)

SKU:

C15-10386

TS PIK:

21367353

Catalog:

SiemensAG_09175_17_1_17_4_17_81-17_84_17_112_17_113_17_123_17_133_CAT.pdf

Voltage Rating:

120/277 VAC 50/60 Hertz, 125 VDC

Frame Type:

ED

Interrupting Rating:

65 kA at 120 VAC, 22 kA at 277 VAC, 30 kA at 125 VDC

Number of Poles:

1

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Rating

Country of Origin:

MEX

Size:

1 Inch Width x 3.92 Inch Depth x 6.35 Inch Height

Approval:

UL 489

Maximum DC Voltage Rating:

125 V

Terminal Type:

Load Lug

Installation/Operator:

SiemensAG_00593_INST.pdf

Maximum AC Voltage Rating:

277 V

Current Rating:

45 A

Short Description:

BRKR ED4 1P 480V 45A

Siemens ED41B050 Molded Case Breakers (MCCBs) 50A 277V

SKU:

C15-6176

TS PIK:

115554986

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 50 A at 40 Deg C, 22 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Current Rating:

50 A

Terminal Type:

Load Lug

Voltage Rating:

120/277 VAC at 50/60 Hz, 125 VDC (UL)

Number of Poles:

1

Size:

1 Inch W x 4.56 Inch D x 6.35 Inch H

Type:

Molded Case, Thermal and Fixed Magnetic

Series:

ED4

Interrupting Rating:

65 kA at 120 VAC, 22 kA at 277 VAC, 30 kA at 125 VDC (UL)

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Installation/Operator:

SiemensAG_00313_INST.pdf

Country of Origin:

Mexico

Mounting:

Plug-On

Used On:

P1/P2/P3/P4/P5 Panelboard

Wire Size:

10 to 4 AWG (Copper/Aluminum)

Approval:

UL 489, CSA C22.2

Siemens ED41B060 Molded Case Breakers (MCCBs)

SKU:

C15-10387

TS PIK:

21367355

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 60 A, 22 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Current Rating:

60 A

Interrupting Rating:

65 kA at 120 VAC, 22 kA at 277 VAC, 30 kA at 125 VDC (UL)

Voltage Rating:

120/277 VAC at 50/60 Hz, 125 VDC (UL)

Installation/Operator:

SiemensAG_00313_INST.pdf

Country of Origin:

Mexico

Type:

Molded Case, Thermal and Fixed Magnetic

Terminal Type:

Load Lug

Number of Poles:

1

Size:

1 Inch W x 4.56 Inch D x 6.35 Inch H

Series:

ED4

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Used On:

P1/P2/P3/P4/P5 Panelboard

Wire Size:

10 to 4 AWG (Copper/Aluminum)

Approval:

UL 489, CSA C22.2

Mounting:

Plug-On

Siemens ED41B100 Molded Case Breakers (MCCBs)

SKU:

C15-15842

Maximum AC Voltage Rating:

277 V

Voltage Rating:

120/277 VAC, 125 VDC

Country of Origin:

MEX

Type:

Thermal Magnetic

Current Rating:

100 A

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Frame Type:

ED

Number of Poles:

1

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Installation/Operator:

SiemensAG_00313_INST.pdf

Approval:

UL 489, IEC 947-2

Interrupting Rating:

65 kA at 120 V AC (UL 489), 22 kA at 277 V AC (UL 489), 30 kA at 125 V DC (UL 489)

Maximum DC Voltage Rating:

125 V

Terminal Type:

Load Lug

Short Description:

120/277 VAC 50/60 Hz, 125 VDC, 100 A, 22 kA, 1-Pole, 6 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Series:

ED4

Siemens ED61B015 Molded Case Breakers (MCCBs)

SKU:

C15-15847

Installation/Operator:

SiemensAG_00593_INST.pdf

Terminal Type:

Load Lug

Size:

1 Inch Width x 3.92 Inch Depth x 6.35 Inch Height

Catalog:

SiemensAG_09175_17_1_17_4_17_81-17_84_17_112_17_113_17_123_17_133_CAT.pdf

Voltage Rating:

347 VAC 50/60 Hertz

Number of Poles:

1

Approval:

CSA

Short Description:

BRKR ED6 1P 600V 15A

Interrupting Rating:

30 kA at 347 VAC

Country of Origin:

MEX

Frame Type:

ED

Maximum AC Voltage Rating:

347 V

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Rating

Current Rating:

15 A

Siemens ED61B020 Molded Case Breakers (MCCBs)

SKU:

C15-10391

TS PIK:

115410443

Number of Poles:

1

Country of Origin:

MEX

Voltage Rating:

347 VAC at 50/60 Hz

Series:

ED6

Size:

1 Inch W x 4.56 Inch D x 6.35 Inch H

Type:

Molded Case, Thermal and Fixed Magnetic

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Current Rating:

20 A

Approval:

UL 489, CSA C22.2

Installation/Operator:

SiemensAG_00313_INST.pdf

Short Description:

347 VAC 50/60 Hz, 20 A, 30 kA, 1-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Mounting:

Plug-On

Terminal Type:

Load Lug

Interrupting Rating:

30 kA at 347 VAC (UL)

Used On:

P1/P2/P3/P4/P5 Panelboard

Siemens ED61B030 Molded Case Breakers (MCCBs)

SKU:

C15-15848

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Rating

Short Description:

BRKR ED6 1P 600V 30A

Size:

1 Inch Width x 3.92 Inch Depth x 6.35 Inch Height

Number of Poles:

1

Country of Origin:

MEX

Installation/Operator:

SiemensAG_00593_INST.pdf

Frame Type:

ED

Maximum AC Voltage Rating:

347 V

Terminal Type:

Load Lug

Catalog:

SiemensAG_09175_17_1_17_4_17_81-17_84_17_112_17_113_17_123_17_133_CAT.pdf

Voltage Rating:

347 VAC 50/60 Hertz

Approval:

CSA

Current Rating:

30 A

Interrupting Rating:

30 kA at 347 VAC

Siemens HED41B020L Molded Case Breakers (MCCBs)

SKU:

C15-7449

TS PIK:

115558195

Short Description:

BRKR HED4 1P 480V 20A LUG

Interrupting Rating:

65 kA at 277 VAC, 30 kA at 125 VDC

Frame Type:

ED

Catalog:

SiemensAG_09175_17_1_17_4_17_81-17_84_17_112_17_113_17_123_17_133_CAT.pdf

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Size:

1 Inch Width x 3.92 Inch Depth x 6.35 Inch Height

Type:

Molded Case, Low Vage, Thermal Magnetic, High IC Rating

Installation/Operator:

SiemensAG_00593_INST.pdf

Maximum AC Voltage Rating:

277 V

Terminal Type:

Line and Load Lug

Maximum DC Voltage Rating:

125 V

Current Rating:

20 A

Number of Poles:

1

Country of Origin:

Mexico

Approval:

UL 489

Siemens HED41B025 Molded Case Breakers (MCCBs)

SKU:

C15-16448

Interrupting Rating:

100 kA at 120 VAC, 65 kA at 277 VAC, 30 kA at 125 VDC (UL)

Short Description:

277 VAC, 125 VDC, 25 A, 65 kA, 1-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Country of Origin:

MEX

Current Rating:

25 A

Used On:

P1/P2/P3/P4/P5 Panelboard

Installation/Operator:

SiemensAG_00313_INST.pdf

Mounting:

Plug-On

Series:

HED4

Number of Poles:

1

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Terminal Type:

Load Lug

Size:

1 Inch W x 4.56 Inch D x 6.35 Inch H

Type:

Molded Case, Thermal and Fixed Magnetic

Approval:

UL 489, CSA C22.2

Voltage Rating:

277 VAC at 50/60 Hz, 125 VDC (UL)

Siemens HED41B030 Molded Case Breakers (MCCBs)

SKU:

C15-7584

Series:

HED4

Voltage Rating:

277 VAC, 125 VDC

Size:

1 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Current Rating:

30 A

Country of Origin:

MEX

Type:

Molded Case, Thermal Magnetic

Catalog:

SiemensAG_01698_17_78-17_80_CAT.pdf

Terminal Type:

Load Lug

Approval:

UL 489

Installation/Operator:

SiemensAG_00313_INST.pdf

Short Description:

277 VAC, 125 VDC, 30 A, 65 kA, 1-Pole, 10 to 4 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Interrupting Rating:

100 kA at 120 VAC, 65 kA at 277 VAC, 30 kA at 125 VDC (UL)

Number of Poles:

1

Siemens HED41B040 Molded Case Breakers (MCCBs)
