Siemens HHFXD63B225 Molded Case Breakers (MCCBs)

SKU:

C15-23047

Country of Origin:

MEX

Voltage Rating:

600 VAC 50/60 Hertz

Series:

HHFXD6

Number of Poles:

3

Size:

4.5 Inch Width x 4 Inch Depth x 9.5 Inch Height

Interrupting Rating:

200 kA at 240 VAC, 100 kA at 480 VAC, 25 kA at 600 VAC (UL 489)

Catalog:

SiemensAG_00564_7_3-7_5_7_116_7_145_CAT.pdf

Terminal Type:

Not Included

Maximum AC Voltage Rating:

600 V

Current Rating:

225 A

Frame Type:

FX

Approval:

UL 489, IEC 947-2

Short Description:

600 VAC, 225 A, 100 kA at 480 VAC, 3-Pole, FD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Type:

Thermal Magnetic

Siemens HHFXD63B225L Molded Case Breakers (MCCBs)

SKU:

C15-7659

TS PIK:

115558453

Number of Poles:

3

Type:

Molded Case, Low Vage, Thermal Magnetic, Extra High Breaking Capacity, Extra High Interrupting

Catalog:

SiemensAG_09175_17_4_17_81_CAT.pdf

Installation/Operator:

SiemensAG_00590_INST.pdf

Voltage Rating:

600 VAC 50/60 Hertz

Current Rating:

225 A

Size:

4.5 Inch Width x 4 Inch Depth x 9 Inch Height

Maximum AC Voltage Rating:

600 V

Frame Type:

FD

Interrupting Rating:

25 kA at 600 VAC

Terminal Type:

Line and Load Lug

Short Description:

BRKR HHFD6 3P 600V 225A FX LUG

Country of Origin:

Mexico

Approval:

UL 489

Siemens HHJD63B350 Molded Case Breakers (MCCBs)

SKU:

C15-23053

Terminal Type:

Line and Load Lug

Approval:

UL 489

Interrupting Rating:

50 kA at 600 VAC

Country of Origin:

MEX

Catalog:

SiemensAG_09175_17_4_17_81_17_88_17_89_17_115_CAT.pdf

Voltage Rating:

600 VAC 50/60 Hertz

Type:

Molded Case, Low Vage, Thermal Magnetic, Extra High Breaking Capacity

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Number of Poles:

3

Current Rating:

350 A

Frame Type:

JD

Installation/Operator:

SiemensAG_00591_INST.pdf

Maximum AC Voltage Rating:

600 V

Siemens HHLD63B500 Molded Case Breakers (MCCBs)

SKU:

C15-23060

Number of Poles:

3

Approval:

UL 489

Terminal Type:

Line and Load Lug

Interrupting Rating:

50 kA at 600 VAC

Current Rating:

500 A

Country of Origin:

MEX

Maximum AC Voltage Rating:

600 V

Type:

Molded Case, Low Vage, Thermal Magnetic, Extra High Breaking Capacity

Catalog:

SiemensAG_09175_17_4_17_81_17_92_17_93_17_115_CAT.pdf

Installation/Operator:

SiemensAG_00591_INST.pdf

Voltage Rating:

600 VAC 50/60 Hertz

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Frame Type:

LD

Siemens HHLD63B600 Molded Case Breakers (MCCBs)

SKU:

C15-7519

TS PIK:

120632079

Short Description:

600 VAC, 600 A at 40 Deg C, 100 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, LD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Frame Type:

LD

Current Rating:

600 A

Number of Poles:

3

Series:

HHLD6

Interrupting Rating:

200 kA at 240 VAC (UL 489), 100 kA at 480 VAC (UL 489), 50 kA at 600 VAC (UL 489)

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Maximum AC Voltage Rating:

600 V

Type:

Molded Case, Thermal Magnetic

Voltage Rating:

600 VAC

Terminal Type:

Line/Load Lug

Catalog:

SiemensAG_00564_7_3-7_5_7_123_7_145_CAT.pdf

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens HJD63B200 Molded Case Breakers (MCCBs)

SKU:

C15-16560

Terminal Type:

Line and Load Lug

Series:

HJD6-A

Frame Type:

JD

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Type:

Molded Case, Thermal Magnetic, Adjustable Trip

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

500 V

Short Description:

600 VAC, 500 VDC, 200 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Number of Poles:

3

Interrupting Rating:

35 kA at 600 VAC/500 VDC (UL)

Current Rating:

200 A

Approval:

UL, CSA

Country of Origin:

MEX

Siemens HJD63B225 Molded Case Breakers (MCCBs)

SKU:

E30-11704

TS PIK:

115459686

Voltage Rating:

600 VAC 50/60 Hertz

Series:

HHJD6

Interrupting Rating:

200 kA at 240 VAC, 100 kA at 480 VAC, 50 kA at 600 VAC (UL 489)

Frame Type:

JD

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Current Rating:

225 A

Type:

Molded Case, Thermal Magnetic

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Maximum AC Voltage Rating:

600 V

Terminal Type:

Line/Load Lug

Number of Poles:

3

Short Description:

600 VAC, 500 VDC, 225 A at 40 Deg C, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens HJD63B250 Molded Case Breakers (MCCBs)

SKU:

C15-16561

Number of Poles:

3

Series:

HJD6-A

Short Description:

600 VAC, 500 VDC, 250 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Current Rating:

250 A

Maximum DC Voltage Rating:

500 V

Interrupting Rating:

35 kA at 600 VAC/500 VDC (UL)

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Maximum AC Voltage Rating:

600 V

Frame Type:

JD

Terminal Type:

Line and Load Lug

Type:

Molded Case, Thermal Magnetic, Adjustable Trip

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Country of Origin:

MEX

Approval:

UL, CSA

Siemens HJD63B300 Molded Case Breakers (MCCBs)

SKU:

C15-7701

TS PIK:

21330729

Terminal Type:

Lug

Number of Poles:

3

Short Description:

600 VAC, 500 VDC, 300 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Maximum AC Voltage Rating (V):

600

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Voltage Rating:

600 VAC

Current Rating:

300 A

Series:

HJD6

Frame Type:

JD

Country of Origin:

MEX

Approval:

UL 489

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 35 kA at 600 VAC, 35 kA at 500 VDC (UL 489)

Siemens HJD63B350 Molded Case Breakers (MCCBs)

SKU:

C15-16562

Voltage Rating:

600 VAC, 500 VDC

Country of Origin:

MEX

Number of Poles:

3

Type:

Molded Case, Thermal Magnetic

Maximum DC Voltage Rating:

500 V

Short Description:

600 VAC, 500 VDC, 350 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC (UL 489), 35 kA at 500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Series:

HJD6-A

Frame Type:

JD

Maximum AC Voltage Rating:

600 V

Terminal Type:

Line/Load Lug

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Approval:

UL 489, IEC 947-2

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Current Rating:

350 A

Siemens HJD63B400 Molded Case Breakers (MCCBs)

SKU:

C15-8481

TS PIK:

21331888

Frame Type:

JD

Number of Poles:

3

Country of Origin:

MEX

Type:

Thermal Magnetic

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC (UL 489), 35 kA at 500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Terminal Type:

Line/Load Lug

Voltage Rating:

600 VAC, 500 VDC

Catalog:

SiemensAG_00564_7_118_7_119_CAT.pdf

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Short Description:

600 VAC, 500 VDC, 400 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Approval:

UL 489, IEC 947-2

Current Rating:

400 A

Series:

HJD6-A

Siemens HJG3B400L Molded Case Breakers (MCCBs)

SKU:

C15-23063

Frame Type:

JG

Number of Poles:

3

Type:

Thermal Magnetic, Molded Case

Maximum AC Voltage Rating (V):

690 V

Catalog:

SiemensAG_00564_7_183_7_184_CAT.pdf

Current Rating:

400 A

Country of Origin:

DEU

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC, 35 kA at 500 VDC (UL), 100 kA at 220/240 VAC, 70 kA at 380/415 VAC, 15 kA at 690 VAC (IEC)

Approval:

UL, CE, CSA

Maximum DC Voltage Rating (V):

500 V

Size:

5.5 Inch W x 4.2 Inch D x 11 Inch H

Short Description:

600 VAC, 400 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 250 KCMIL Copper/Aluminum, Line/Load Lug Terminal, HJG Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Terminal Type:

Copper/Aluminum Standard Line and Load Lug Terminal Type

Voltage Rating:

240/480/600 VAC at 50/60 Hz, 250/500 VDC (UL), 220/240/380/415/690 VAC at 50/60 Hz (IEC)

Siemens HJX3G400 Molded Case Breakers (MCCBs)

SKU:

C15-23064

Country of Origin:

DEU

Voltage Rating:

480/600 VAC 50/60 Hertz

Interrupting Rating:

65 kA at 480 VAC, 25 kA at 600 VAC

Data Sheet:

SiemensAG_09579_1-4_DATA.pdf

Maximum AC Voltage Rating:

600 V

Approval:

UL, CSA, CCC, EAC

Current Rating:

400 A

Number of Poles:

3

Type:

Molded Case, Low Vage, Electronic Trip, High Breaking Capacity

Size:

5.5 Inch Width x 4.2 Inch Depth x 11 Inch Height

Frame Type:

HJG

Siemens HJXD63B250 Molded Case Breakers (MCCBs)

SKU:

C15-23067

Country of Origin:

MEX

Current Rating:

250 A

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Frame Type:

JD

Terminal Type:

Not Included

Catalog:

SiemensAG_09175_17_4_17_81_17_88_17_89_CAT.pdf

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Approval:

UL 489

Installation/Operator:

SiemensAG_00591_INST.pdf

Interrupting Rating:

35 kA at 600 VAC/500 VDC

Number of Poles:

3

Siemens HJXD63B300 Molded Case Breakers (MCCBs)

SKU:

C15-7461

TS PIK:

115558542

Short Description:

600 VAC, 300 A at 40 Deg C, 65 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Catalog:

SiemensAG_00564_7_188_CAT.pdf

Current Rating:

300 A

Series:

HJXD6

Number of Poles:

3

Frame Type:

JD

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC/500 VDC (UL 489), 100 kA at 220/240 VAC (IEC), 65 kA at 380/415 VAC (IEC), 42 kA at 500 VAC (IEC)

Voltage Rating:

600 VAC, 500 VDC

Country of Origin:

Mexico

Approval:

UL, IEC 947

Siemens HLD63B400 Molded Case Breakers (MCCBs)

SKU:

C15-16595

Catalog:

SiemensAG_09175_17_4_17_81_17_93_17_115_CAT.pdf

Number of Poles:

3

Current Rating:

400 A

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Interrupting Rating:

35 kA at 600 VAC/500 VDC

Maximum DC Voltage Rating:

500 V

Country of Origin:

MEX

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Installation/Operator:

SiemensAG_00591_INST.pdf

Frame Type:

LD

Terminal Type:

Line and Load Lug

Approval:

UL 489

Short Description:

BRKR HLD6 3P 600V 400A

Maximum AC Voltage Rating:

600 V

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Siemens HLD63B450 Molded Case Breakers (MCCBs)

SKU:

C15-23076

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Catalog:

SiemensAG_09175_17_4_17_81_17_93_17_115_CAT.pdf

Maximum DC Voltage Rating:

500 V

Number of Poles:

3

Country of Origin:

MEX

Terminal Type:

Line and Load Lug

Frame Type:

LD

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Approval:

UL 489

Installation/Operator:

SiemensAG_00591_INST.pdf

Maximum AC Voltage Rating:

600 V

Interrupting Rating:

35 kA at 600 VAC/500 VDC

Current Rating:

450 A

Siemens HLD63B500 Molded Case Breakers (MCCBs)

SKU:

C15-16596

Country of Origin:

MEX

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC (UL 489), 35 kA at 500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Number of Poles:

3

Frame Type:

LD

Voltage Rating:

600 VAC, 500 VDC

Catalog:

SiemensAG_01698_17_78_17_90_CAT.pdf

Current Rating:

500 A

Series:

HLD6-A

Type:

Thermal Magnetic

Short Description:

600 VAC, 500 VDC, 500 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, LD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Approval:

UL 489, IEC 947-2

Siemens HLD63B600 Molded Case Breakers (MCCBs)

SKU:

C15-16597

Short Description:

600 VAC, 500 VDC, 600 A, 65 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, LD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Current Rating:

600 A

Series:

HLD6-A

Voltage Rating:

600 VAC, 500 VDC

Frame Type:

LD

Catalog:

SiemensAG_01698_17_78_17_90_CAT.pdf

Type:

Thermal Magnetic

Approval:

UL 489, IEC 947-2

Number of Poles:

3

Country of Origin:

MEX

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC (UL 489), 35 kA at 500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Siemens HLD63F600 Molded Case Breakers (MCCBs)

SKU:

C15-7462

TS PIK:

126674911

Terminal Type:

Line Lug, Load Lug

Short Description:

600 VAC, 500 VDC, 250 to 600 A, 35 kA, 3-Pole, Molded Case, Thermal Magnetic, LD Frame, Circuit Breaker Frame

Current Rating:

250 to 600 A

Type:

LD Frame

Number of Poles:

3

Catalog:

SiemensAG_01698_17_78_17_90_CAT.pdf

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 35 kA at 600 VAC/500 VDC (UL), 100 kA at 220/240 VAC, 65 kA at 380/415 VAC (IEC)

Size:

11 Inch L x 7.5 Inch W x 4 Inch D

Maximum DC Voltage Rating:

500 V

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Maximum AC Voltage Rating:

600 V

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Country of Origin:

Mexico

Siemens HLMD63B600 Molded Case Breakers (MCCBs)

SKU:

C15-16608

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Current Rating:

600 A

Size:

7.5 Inch Width x 4.5 Inch Depth x 16 Inch Height

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Catalog:

SiemensAG_09175_17_4_17_81_17_97_17_116_CAT.pdf

Maximum DC Voltage Rating:

500 V

Installation/Operator:

SiemensAG_00597_INST.pdf

Terminal Type:

Line and Load Lug

Approval:

UL 489

Short Description:

BRKR HLMD6 3P 600V 600A

Number of Poles:

3

Maximum AC Voltage Rating:

600 V

Country of Origin:

MEX

Interrupting Rating:

50 kA at 600 VAC/500 VDC

Frame Type:

LMD

Siemens HLMD63B700 Molded Case Breakers (MCCBs)

SKU:

C15-23080

Number of Poles:

3

Country of Origin:

MEX

Interrupting Rating:

50 kA at 600 VAC/500 VDC

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Catalog:

SiemensAG_09175_17_4_17_81_17_97_17_116_CAT.pdf

Current Rating:

700 A

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Installation/Operator:

SiemensAG_00597_INST.pdf

Terminal Type:

Line and Load Lug

Size:

7.5 Inch Width x 4.5 Inch Depth x 16 Inch Height

Approval:

UL 489

Frame Type:

LMD

Siemens HLMD63B800 Molded Case Breakers (MCCBs)

SKU:

C15-7608

TS PIK:

126673644

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 50 kA at 500/600 VAC/DC (UL 489)

Current Rating:

800 A

Size:

7.5 Inch Width x 5.93 Inch Depth x 16 Inch Height

Frame Type:

LMD

Type:

Thermal Magnetic

Data Sheet:

SiemensAG_06156_1_2_DATA.pdf

Number of Poles:

3

Catalog:

SiemensAG_00564_7_5_7_127_7_146_CAT.pdf

Country of Origin:

MEX

Series:

HLMD6

Approval:

UL 489

Short Description:

600 VAC, 500 VDC, 800 A, 65 kA at 480 VAC, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, LMD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 500 VDC

Siemens HLMXD63B800 Molded Case Breakers (MCCBs)

SKU:

C15-7609

Series:

HLMXD6

Frame Type:

MD

Number of Poles:

3

Short Description:

600 VAC, 500 VDC, 800 A, 65 kA at 480 VAC, 3-Pole, LMD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Data Sheet:

SiemensAG_06156_1_2_DATA.pdf

Type:

Thermal Magnetic

Voltage Rating:

600 VAC, 500 VDC

Current Rating:

800 A

Catalog:

SiemensAG_00564_7_5_7_127_7_146_CAT.pdf

Terminal Type:

Not Included

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

500 V

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 50 kA at 600 VAC/500 VDC (UL 489)

Size:

7.5 Inch Width x 5.93 Inch Depth x 16 Inch Height

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens HLXD63B450 Molded Case Breakers (MCCBs)

SKU:

C15-23083

Number of Poles:

3

Interrupting Rating:

35 kA at 600 VAC/500 VDC

Current Rating:

450 A

Country of Origin:

MEX

Terminal Type:

Load and Line Lug

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Short Description:

600 VAC, 500 VDC, 450 A, 65 kA at 480 VAC, 3-Pole, LD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Series:

HLXD6-A

Frame Type:

LD

Type:

Molded Case, Thermal Magnetic

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Catalog:

SiemensAG_00564_7_5_7_123_CAT.pdf

Approval:

UL, CSA, CE

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Siemens HLXD63B500 Molded Case Breakers (MCCBs)

SKU:

C15-10445

TS PIK:

115558594

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Frame Type:

LD

Voltage Rating:

600 VAC

Country of Origin:

Mexico

Interrupting Rating:

35 kA

Catalog:

SiemensAG_00564_7_5_7_123_CAT.pdf

Current Rating:

500 A

Terminal Type:

Not Included

Number of Poles:

3

Short Description:

600 VAC, 500 VDC, 500 A, 65 kA at 480 VAC, 3-Pole, LD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Series:

HLXD6-A

Maximum AC Voltage Rating (V):

600

Siemens HLXD63B600 Molded Case Breakers (MCCBs)

SKU:

C15-10446

TS PIK:

115558596

Country of Origin:

Mexico

Short Description:

600 VAC, 500 VDC, 600 A, 65 kA at 480 VAC, 3-Pole, LD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Number of Poles:

3

Data Sheet:

SiemensAG_06155_1_2_DATA.pdf

Current Rating:

600 A

Series:

HLXD6-A

Catalog:

SiemensAG_00564_7_5_7_123_CAT.pdf

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 35 kA at 600 VAC/500 VDC (UL 489), 100 kA at 220/240 VAC (IEC), 65 kA at 380/415 VAC (IEC)

Voltage Rating:

600 VAC, 500 VDC

Frame Type:

LD

Type:

Thermal Magnetic

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Approval:

UL 489, IEC

Siemens HMD63B500 Molded Case Breakers (MCCBs)

SKU:

C15-23086

Number of Poles:

3

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Size:

9 Inch Width x 6 Inch Depth x 16 Inch Height

Terminal Type:

Line and Load Lug

Country of Origin:

MEX

Installation/Operator:

SiemensAG_00592_INST.pdf

Current Rating:

500 A

Interrupting Rating:

50 kA at 600 VAC/500 VDC

Frame Type:

MD

Approval:

UL 489

Catalog:

SiemensAG_09175_17_5_17_81_17_99_17_100_17_116_CAT.pdf

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Siemens HMD63B600 Molded Case Breakers (MCCBs)

SKU:

C15-23087

Number of Poles:

3

Series:

HMD6

Short Description:

600 VAC, 500 VDC, 600 A, 65 kA, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, MD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Current Rating:

600 A

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 50 kA at 600 VAC/500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Terminal Type:

Line/Load Lug

Catalog:

SiemensAG_00564_7_3-7_5_7_130_7_146_CAT.pdf

Country of Origin:

MEX

Size:

9 Inch Width x 8.25 Inch Depth x 16 Inch Height

Type:

Molded Case, Thermal Magnetic

Voltage Rating:

600 VAC, 500 VDC

Frame Type:

MD

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Approval:

UL 489, IEC 947-2

Siemens HMX3B800L Molded Case Breakers (MCCBs)

SKU:

C15-23098

Number of Poles:

3

Frame Type:

HMG

Country of Origin:

MEX

Current Rating:

800 A

Voltage Rating:

480/600 V

Approval:

UL

Terminal Type:

Line and Load Lug

Interrupting Rating:

65 kA at 480 V, 35 kA at 600 V

Size:

7.5 Inch Width x 4.7 Inch Depth x 16 Inch Height

Type:

Molded Case, Low Vage, Thermal Magnetic, High Breaking Capacity

Siemens HMXD63B800 Molded Case Breakers (MCCBs)

SKU:

C15-23107

Series:

HMXD6

Maximum DC Voltage Rating:

500 V

Catalog:

SiemensAG_00564_7_3-7_5_7_130_7_146_CAT.pdf

Short Description:

600 VAC, 500 VDC, 800 A, 65 kA, 3-Pole, MD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Approval:

UL, CSA

Type:

Molded Case, Thermal Magnetic

Interrupting Rating:

50 kA at 600 VAC/500 VDC

Frame Type:

MD

Country of Origin:

MEX

Terminal Type:

Not Included

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Maximum AC Voltage Rating:

600 V

Current Rating:

800 A

Size:

9 Inch W x 8.25 Inch D x 16 Inch H

Number of Poles:

3

Siemens HND63B100 Molded Case Breakers (MCCBs)

SKU:

C15-23109

Voltage Rating:

600 VAC, 500 VDC

Number of Poles:

3

Size:

9 Inch Width x 8.25 Inch Depth x 16 Inch Height

Current Rating:

1000 A

Maximum AC Voltage Rating:

600 V

Terminal Type:

Line/Load Lug

Short Description:

600 VAC, 500 VDC, 1000 A, 65 kA at 480 VAC, 3-Pole, 250 to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, ND Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Series:

HND6

Country of Origin:

MEX

Frame Type:

ND

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 50 kA at 600 VAC/500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Catalog:

SiemensAG_00564_7_3-7_5_7_134_7_146_7_237_CAT.pdf

Maximum DC Voltage Rating:

500 V

Approval:

UL 489, IEC 947-2

Type:

Molded Case, Thermal Magnetic

Siemens HND63B120 Molded Case Breakers (MCCBs)

SKU:

C15-7463

TS PIK:

115459920

Short Description:

600 VAC, 500 VDC, 1200 A, 65 kA at 480 VAC, 3-Pole, 250 to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, ND Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Number of Poles:

3

Series:

HND6

Interrupting Rating:

100 kA at 240 VAC (UL 489), 65 kA at 480 VAC (UL 489), 50 kA at 600 VAC/500 VDC (UL 489), 100/50 kA at 220/240 VAC (IEC), 65/33 kA at 380/415 VAC (IEC)

Current Rating:

1200 A

Country of Origin:

MEX

Voltage Rating:

600 VAC, 500 VDC

Type:

Molded Case, Thermal Magnetic

Frame Type:

ND

Terminal Type:

Line/Load Lug

Maximum AC Voltage Rating:

600 V

Size:

9 Inch Width x 8.25 Inch Depth x 16 Inch Height

Maximum DC Voltage Rating:

500 V

Approval:

UL 489, IEC 947-2

Catalog:

SiemensAG_00564_7_3-7_5_7_134_7_146_7_237_CAT.pdf

Siemens HQJ23B225H Molded Case Breakers (MCCBs) HQJ2H 3P 225A 240V 50/60Hz 3Ph QJ Frame

SKU:

C15-1429

Frame Type:

Q

Voltage Rating:

240 V

Current Rating:

225 A

Number of Poles:

3

Short Description:

HQJ2H 3P 225A 240V 50/60Hz 3Ph QJ Frame

Siemens HQR23B125 Molded Case Breakers (MCCBs)

SKU:

C15-10454

TS PIK:

126908870

Voltage Rating:

240 VAC 50/60 Hertz

Interrupting Rating:

65 kA at 240 VAC

Country of Origin:

Mexico

Frame Type:

QR

Number of Poles:

3

Current Rating:

125 A

Type:

Molded Case, Low Vage, Thermal Magnetic

Installation/Operator:

SiemensAG_00598_INST.pdf

Data Sheet:

SiemensAG_09583_1_2_DATA.pdf

Size:

4.5 Inch Width x 2.53 Inch Depth x 7 Inch Height

Catalog:

SiemensAG_09175_17_1_17_10_CAT.pdf

Maximum AC Voltage Rating:

240 V

Terminal Type:

Not Included

Approval:

UL 489, CSA C22.2

Siemens HQR23B150 Molded Case Breakers (MCCBs)

SKU:

C15-10455

TS PIK:

126908871

Voltage Rating:

240 VAC 50/60 Hertz

Country of Origin:

Mexico

Frame Type:

QR

Catalog:

SiemensAG_09175_17_1_17_10_CAT.pdf

Installation/Operator:

SiemensAG_00598_INST.pdf

Type:

Molded Case, Low Vage, Thermal Magnetic

Number of Poles:

3

Interrupting Rating:

65 kA at 240 VAC

Maximum AC Voltage Rating:

240 V

Data Sheet:

SiemensAG_09584_1_2_DATA.pdf

Terminal Type:

Not Included

Size:

4.5 Inch Width x 2.53 Inch Depth x 7 Inch Height

Current Rating:

150 A

Approval:

UL 489, CSA C22.2

Siemens HQR23B200 Molded Case Breakers (MCCBs)

SKU:

C15-10457

TS PIK:

126824613

Short Description:

240 VAC, 200 A, 65 kA, 3-Pole, QR Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Frame Type:

QR

Voltage Rating:

240 VAC

Country of Origin:

Mexico

Number of Poles:

3

Interrupting Rating:

65 kA at 240 VAC

Current Rating:

200 A

Data Sheet:

SiemensAG_06240_1_DATA.pdf

Size:

3 Inch Width x 2.53 Inch Depth x 7 Inch Height

Catalog:

SiemensAG_00564_7_3-7_5_7_40_CAT.pdf

Maximum AC Voltage Rating:

240 V

Type:

Molded Case, Thermal Magnetic

Approval:

UL 489, CSA 22.2

Siemens JD63B200 Molded Case Breakers (MCCBs)

SKU:

C15-7465

TS PIK:

21367660

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Number of Poles:

3

Terminal Type:

Line/Load Lug

Catalog:

SiemensAG_01698_17_78_17_85_17_110_CAT.pdf

Type:

Molded Case, Thermal Magnetic

Short Description:

600 VAC, 500 VDC, 200 A at 40 Deg C, 35 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

500 V

Frame Type:

JD

Series:

JD6-A

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at 600 VAC (UL 489), 25 kA at 500 VDC (UL 489), 65/33 kA at 220/240 VAC (IEC), 40/20 kA at 380/415 VAC (IEC)

Voltage Rating:

600 VAC, 500 VDC

Current Rating:

200 A

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens JD63B400 Molded Case Breakers (MCCBs) 600VAC

SKU:

C15-7532

TS PIK:

21367665

Maximum AC Voltage Rating:

600 V

Terminal Type:

Line and Load Side Lug

Type:

Molded Case, Thermal Magnetic, Low Vage, Standard Breaking Capacity

Number of Poles:

3

Maximum DC Voltage Rating:

500 V

Frame Type:

JD

Current Rating:

400 A at 40 Deg C

Interrupting Rating:

25 kA at 600 V AC/500 V DC (UL)

Series:

JD6

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Short Description:

600 VAC, 500 VDC, 400 A at 40 Deg C, 35 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 KCMIL Copper/4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Catalog:

SiemensAG_01698_17_78_17_85_17_110_CAT.pdf

Voltage Rating:

600 V AC 50/60 Hertz, 500 V DC

Siemens JD63F400 Molded Case Breakers (MCCBs)

SKU:

C15-7520

TS PIK:

21367667

Short Description:

600 VAC, 500 VDC, 200 to 400 A, 25 kA, 3-Pole, Molded Case, Thermal Magnetic, JD Frame, Circuit Breaker Frame

Type:

JD Frame

Number of Poles:

3

Maximum AC Voltage Rating:

600 V

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Terminal Type:

Line Lug, Load Lug

Current Rating:

200 to 400 A

Size:

11 Inch L x 7.5 Inch W x 4 Inch D

Maximum DC Voltage Rating:

500 V

Interrupting Rating:

65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at 600 VAC/500 VDC (UL), 65 kA at 220/240 VAC, 40 kA at 380/415 VAC (IEC)

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Country of Origin:

Mexico

Siemens JD63T225 Molded Case Breakers (MCCBs)

SKU:

C15-7466

TS PIK:

126675143

Short Description:

600 VAC, 500 VDC, 225 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Type:

Thermal Magnetic, Interchangeable

Frame Type:

JD

Series:

JD63T

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Number of Poles:

3

Current Rating:

225 A

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens JD63T250 Molded Case Breakers (MCCBs)

SKU:

C15-7613

Short Description:

600 VAC, 500 VDC, 250 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Series:

JD63T

Frame Type:

JD

Current Rating:

250 A

Number of Poles:

3

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Type:

Thermal Magnetic, Interchangeable

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens JD63T350 Molded Case Breakers (MCCBs)

SKU:

C15-7467

TS PIK:

126672093

Series:

JD63T

Short Description:

600 VAC, 500 VDC, 350 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Current Rating:

350 A

Frame Type:

JD

Type:

Thermal Magnetic, Interchangeable

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Number of Poles:

3

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens JD63T400 Molded Case Breakers (MCCBs)

SKU:

C15-7468

TS PIK:

126672091

Series:

JD63T

Short Description:

600 VAC, 500 VDC, 400 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Frame Type:

JD

Type:

Thermal Magnetic, Interchangeable

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Number of Poles:

3

Current Rating:

400 A

Country of Origin:

Mexico

Approval:

UL 489, IEC 947-2

Siemens JXD23B200 Molded Case Breakers (MCCBs)

SKU:

C15-16708

Series:

JXD2-A

Short Description:

240 VAC, 250 VDC, 200 A, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

240 VAC

Country of Origin:

MEX

Type:

Thermal Magnetic

Current Rating:

200 A

Number of Poles:

3

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Frame Type:

JD

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Terminal Type:

Not Included

Approval:

UL 489

Siemens JXD23B225 Molded Case Breakers (MCCBs)

SKU:

C15-16709

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Series:

JXD2-A

Country of Origin:

MEX

Number of Poles:

3

Voltage Rating:

240 VAC

Type:

Molded Case, Thermal Magnetic

Approval:

UL 489

Frame Type:

JD

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Current Rating:

225 A

Terminal Type:

Not Included

Short Description:

240 VAC, 250 VDC, 225 A, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Siemens JXD23B250 Molded Case Breakers (MCCBs)

SKU:

C15-1466

Series:

JXD2-A

Type:

Molded Case

Type:

Fixed Thermal Fixed Magnetic

Approval:

UL 489

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Volts:

240 VAC

Amps:

32 A

Poles:

3

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Terminal Type:

Not Included

Frame Type:

JD

Short Description:

240 VAC, 250 VDC, 250 A at 40 Deg C, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Current Rating:

250 A

Voltage Rating:

240 VAC

Number of Poles:

3

Country of Origin:

Mexico

TS PIK:

21367638

Siemens JXD23B300 Molded Case Breakers (MCCBs)

SKU:

C15-1465

Series:

JXD2-A

Type:

Thermal Magnetic

Approval:

UL 489

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Volts:

240 VAC

Amps:

300 A

Poles:

3

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Terminal Type:

Not Included

Frame Type:

JD

Short Description:

240 VAC, 250 VDC, 300 A at 40 Deg C, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip

Catalog:

SiemensAG_01698_17_78_17_85_17_110_17_112_CAT.pdf

Current Rating:

300 A

Number of Poles:

3

Voltage Rating:

240 VAC

Country of Origin:

MEX

TS PIK:

21367639

Siemens JXD23B350 Molded Case Breakers (MCCBs)

SKU:

C15-10463

TS PIK:

21367640

Country of Origin:

MEX

Voltage Rating:

240 VAC

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Number of Poles:

3

Type:

Thermal Magnetic

Current Rating:

350 A

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Frame Type:

JD

Approval:

UL 489, IEC 947-2

Maximum AC Voltage Rating:

240 V

Short Description:

240 VAC, 250 VDC, 350 A, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Series:

JXD2-A

Terminal Type:

Not Included

Catalog:

SiemensAG_01698_17_78_17_85_17_110_17_112_CAT.pdf

Siemens JXD23B400 Molded Case Breakers (MCCBs)

SKU:

C15-7470

TS PIK:

126672328

Number of Poles:

3

Voltage Rating:

240 VAC

Catalog:

SiemensAG_01698_17_78_17_85_17_110_17_112_CAT.pdf

Current Rating:

400 A

Type:

Thermal Magnetic

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Frame Type:

JD

Series:

JXD2-A

Short Description:

240 VAC, 250 VDC, 400 A, 65 kA, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Country of Origin:

MEX

Terminal Type:

Not Included

Approval:

UL 489

Siemens JXD23S400A Molded Case Breakers (MCCBs)

SKU:

C15-19007

Short Description:

240 VAC, 400 A, 6000 A Self-Productive Instantaneous Override, 3-Pole, JD Frame, Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker Switch

Country of Origin:

MEX

Type:

Thermal Magnetic

Voltage Rating:

240 VAC

Series:

JXD2-A

Terminal Type:

Not Included

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Current Rating:

400 A

Frame Type:

JD

Approval:

UL 489

Catalog:

SiemensAG_01698_17_78_17_114_CAT.pdf

Maximum AC Voltage Rating:

240 V

Interrupting Rating:

65 kA at 240 VAC (UL 489)

Number of Poles:

3

Siemens JXD63B200 Molded Case Breakers (MCCBs)

SKU:

C15-10466

TS PIK:

21367648

Series:

JXD6-A

Type:

Molded Case, Thermal Magnetic

Maximum DC Voltage Rating:

500 V

Country of Origin:

MEX

Short Description:

600 VAC, 500 VDC, 200 A, 3-Pole, Adjustable, Instantaneous Magnetic Trip, Molded Case Circuit Breaker

Maximum AC Voltage Rating:

600 V

Approval:

UL, CSA

Frame Type:

JD

Catalog:

SiemensAG_00876_5_36_5_63_CAT.pdf

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Number of Poles:

3

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Current Rating:

200 A

Terminal Type:

Not Included

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Siemens JXD63B225 Molded Case Breakers (MCCBs)

SKU:

C15-7471

TS PIK:

126672327

Frame Type:

JD

Series:

JXD2-A

Terminal Type:

Not Included

Number of Poles:

3

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at VAC (UL 489), 25 kA at 500 VDC (UL 489), 65 kA at 220/240 VAC (IEC), 40 kA at 380/415 VAC (IEC)

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Short Description:

600 VAC, 500 VDC, 225 A, 35 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Type:

Thermal Magnetic

Current Rating:

225 A

Voltage Rating:

600 VAC, 500 VDC

Country of Origin:

Mexico

Approval:

UL 489, IEC

Siemens JXD63B250 Molded Case Breakers (MCCBs)

SKU:

C15-10467

TS PIK:

21367650

Short Description:

600 VAC, 500 VDC, 250 A, 35 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Country of Origin:

Mexico

Frame Type:

JD

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Series:

JXD6-A

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Number of Poles:

3

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Maximum AC Voltage Rating:

600 V

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Maximum DC Voltage Rating:

500 V

Type:

Molded Case, Thermal Magnetic

Current Rating:

250 A

Terminal Type:

Not Included

Approval:

UL, CSA

Siemens JXD63B300 Molded Case Breakers (MCCBs)

SKU:

C15-7616

TS PIK:

126673848

Series:

JXD2-A

Type:

Thermal Magnetic

Short Description:

600 VAC, 500 VDC, 300 A, 35 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Frame Type:

JD

Voltage Rating:

600 VAC, 500 VDC

Current Rating:

300 A

Terminal Type:

Not Included

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at VAC (UL 489), 25 kA at 500 VDC (UL 489), 65 kA at 220/240 VAC (IEC), 40 kA at 380/415 VAC (IEC)

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Number of Poles:

3

Country of Origin:

Mexico

Approval:

UL 489, IEC

Siemens JXD63B300L Molded Case Breakers (MCCBs)

SKU:

C15-7472

TS PIK:

126672330

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Series:

JXD6

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Frame Type:

JD

Short Description:

600 VAC, 500 VDC, 300 A at 40 Deg C, 35 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 MCM Copper/4/0 AWG to 500 MCM Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Current Rating:

300 A

Terminal Type:

Line and Load Side Lug

Country of Origin:

Mexico

Approval:

UL 489

Siemens JXD63B350 Molded Case Breakers (MCCBs)

SKU:

C15-10470

TS PIK:

21367652

Short Description:

600 VAC, 500 VDC, 350 A, 35 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Number of Poles:

3

Type:

Thermal Magnetic

Frame Type:

JD

Voltage Rating:

600 VAC, 500 VDC

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Series:

JXD2-A

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Terminal Type:

Not Included

Current Rating:

350 A

Country of Origin:

Mexico

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at VAC (UL 489), 25 kA at 500 VDC (UL 489), 65 kA at 220/240 VAC (IEC), 40 kA at 380/415 VAC (IEC)

Approval:

UL 489, IEC

Siemens JXD63B350L Molded Case Breakers (MCCBs) 350A

SKU:

C15-7473

TS PIK:

115558787

Current Rating:

350 A at 40 Deg C

Number of Poles:

3

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Series:

JXD6-A

Frame Type:

JD

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Short Description:

600 VAC, 500 VDC, 350 A at 40 Deg C, 35 kA at 480 VAC, 3-Pole, 3/0 AWG to 500 MCM Copper/4/0 AWG to 500 MCM Aluminum, Line/Load Lug Terminal, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Terminal Type:

Line Lug

Maximum DC Voltage Rating:

500 V

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Type:

Molded Case, Thermal Magnetic

Maximum AC Voltage Rating:

600 V

Siemens JXD63B400 Molded Case Breakers (MCCBs) 400A 600V

SKU:

C15-7475

TS PIK:

21367653

Series:

JXD6-A

Interrupting Rating:

65 kA at 240 VAC, 35 kA at 480 VAC, 25 kA at VAC, 25 kA at 500 VDC (UL 489), 65 kA at 220/240 VAC, 40 kA at 380/415 VAC (IEC)

Current Rating:

400 A

Catalog:

SiemensAG_01698_17_78_17_85_CAT.pdf

Maximum AC Voltage Rating:

600 V

Short Description:

600 VAC, 500 VDC, 400 A at 40 Deg C, 35 kA at 480 VAC, 3-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Type:

Molded Case, Thermal Magnetic

Frame Type:

JD

Terminal Type:

Not Included

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Number of Poles:

3

Voltage Rating:

600 VAC, 500 VDC

Country of Origin:

Mexico

Approval:

UL 489

Siemens JXD63H400 Motor Circuit Protector (MCPs)

SKU:

C15-10473

TS PIK:

21367683

Short Description:

600 VAC, 250 VDC, 400 A, 35 kA at 480 VAC, 2000 to 4000 A Instantaneous Trip, 3-Pole, JD Frame, Magnetic, Non-Interchangeable Trip, ETI Motor, Molded Case Circuit Breaker

Country of Origin:

MEX

Voltage Rating:

600 VAC/250 VDC

Series:

JXD

Number of Poles:

3

Type:

Adjustable Trip, Molded Case, Thermal Magnetic

Current Rating:

400 A

Frame Type:

JD

Approval:

UL, CSA

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Terminal Type:

Not Included

Maximum DC Voltage Rating:

250 V

Maximum AC Voltage Rating:

600 V

Wire Type:

3/0 AWG to 500 KCMIL (Copper), 4/0 AWG to 500 KCMIL (Aluminum)

Catalog:

SiemensAG_01698_17_78_17_108_17_109_17_112_CAT.pdf

Motor FLA:

220 to 242 A

Trip Setting:

2000 to 4000 A

Siemens JXD63L400 Molded Case Breakers (MCCBs)

SKU:

C15-16710

Terminal Type:

Not Included

Country of Origin:

MEX

Current Rating:

400 A

Maximum DC Voltage Rating:

250 V

Voltage Rating:

600 VAC/250 VDC

Maximum AC Voltage Rating:

600 V

Short Description:

600 VAC, 250 VDC, 400 A, 35 kA at 480 VAC, 1250 to 2500 A Instantaneous Trip, 3-Pole, JD Frame, Magnetic, Non-Interchangeable Trip, ETI Motor, Molded Case Circuit Breaker

Trip Setting:

1250 to 2500 A

Approval:

UL, CSA

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Series:

JXD

Catalog:

SiemensAG_01698_17_78_17_108_17_109_17_112_CAT.pdf

Type:

Adjustable Trip, Molded Case, Thermal Magnetic

Frame Type:

JD

Number of Poles:

3

Siemens JXD63S400A Molded Case Breakers (MCCBs)

SKU:

C15-10475

TS PIK:

21367685

Current Rating:

400 A

Country of Origin:

MEX

Short Description:

600 VAC, 400 A, 6000 A Self-Productive Instantaneous Override, 3-Pole, JD Frame, Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker Switch

Number of Poles:

3

Frame Type:

JD

Series:

JXD6-A

Terminal Type:

Not Included

Catalog:

SiemensAG_01698_17_78_17_114_CAT.pdf

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Voltage Rating:

600 VAC at 50/60 Hz, 500 VDC

Maximum AC Voltage Rating:

600 V

Size:

7.5 Inch W x 5.44 Inch D x 11 Inch H

Type:

Molded Case, Thermal Magnetic

Approval:

UL, CSA

Maximum DC Voltage Rating:

500 V

Siemens LD63B350 Molded Case Breakers (MCCBs)

SKU:

C15-23173

Country of Origin:

MEX

Interrupting Rating:

25 kA at 600 VAC/500 VDC

Current Rating:

350 A

Number of Poles:

3

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Size:

7.5 Inch Width x 4 Inch Depth x 11 Inch Height

Maximum DC Voltage Rating:

500 V

Maximum AC Voltage Rating:

600 V

Approval:

UL 489

Catalog:

SiemensAG_09175_17_4_17_92_17_93_17_115_CAT.pdf

Frame Type:

LD

Terminal Type:

Line and Load Lug

Type:

Molded Case, Low Vage, Thermal Magnetic, Standard Breaking Capacity

Installation/Operator:

SiemensAG_00591_INST.pdf

Siemens LD63F600 Molded Case Breakers (MCCBs)

SKU:

C15-7620

Type:

Molded Case, LD Frame

Voltage Rating:

600 VAC, 500 VDC

Number of Poles:

3

Short Description:

7.5" x 4" x 11", 600 VAC, 500 VDC, 600 A, 3-Pole, Circuit Breaker Frame

Current Rating:

250 to 600 A

Terminal Type:

Line/Load Lug

Size:

11 Inch L x 7.5 Inch W x 4 Inch D

Catalog:

SiemensAG_00876_5_40_CAT.pdf

Series:

LD6-A

Interrupting Rating:

65 kA at 240 VAC 50/60 Hertz (UL), 35 kA at 480 VAC 50/60 Hertz (UL), 25 kA at 600 VAC 50/60 Hertz (UL), 30 kA at 250 VDC 50/60 Hertz (UL)

Country of Origin:

Mexico

Maximum AC Voltage Rating (V):

600 V

Maximum DC Voltage Rating (V):

500 V

Siemens LD63T500 Molded Case Breakers (MCCBs)

SKU:

C15-7523

TS PIK:

115459729

Short Description:

600 VAC, 500 VDC, 500 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, LD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Frame Type:

LD

Current Rating:

500 A

Type:

Thermal Magnetic, Interchangeable

Catalog:

SiemensAG_00564_7_3-7_5_7_112_7_145_CAT.pdf

Number of Poles:

3

Series:

LD63

Country of Origin:

Mexico

Siemens LD63T600 Molded Case Breakers (MCCBs)

SKU:

C15-7524

TS PIK:

115459748

Series:

LD63

Frame Type:

LD

Type:

Thermal Magnetic, Interchangeable

Short Description:

600 VAC, 500 VDC, 600 A, 22/35 kA, 3-Pole, 3/0 AWG to 500 KCMIL Copper, 4/0 AWG to 500 KCMIL Aluminum, Line/Load Lug Terminal, LD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Current Rating:

600 A

Catalog:

SiemensAG_00564_7_3-7_5_7_112_7_145_CAT.pdf

Number of Poles:

3

Country of Origin:

Mexico

Siemens LGB3B015B Molded Case Breakers (MCCBs)

SKU:

C15-10478

TS PIK:

125266285

Voltage Rating:

480 V

Number of Poles:

3

Series:

LGB

Country of Origin:

Mexico

Short Description:

600 VAC Star/347 VAC, 15 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 14 to 10 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Current Rating:

15 A

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC Star/347 VAC, 14 kA at 600 VAC Star/347 VAC (UL)

Terminal Type:

Load Lug

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Wire Size:

14 to 10 AWG (Copper/Aluminum)

Used On:

Panelboard

Approval:

UL

Siemens LGB3B020B Molded Case Breakers (MCCBs)

SKU:

C15-10479

TS PIK:

125266286

Short Description:

600 VAC Star/347 VAC, 20 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 14 to 10 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Terminal Type:

Load Lug

Number of Poles:

3

Type:

Thermal Magnetic

Approval:

UL

Wire Size:

14 to 10 AWG (Copper/Aluminum)

Used On:

Panelboard

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Voltage Rating:

480 V

Country of Origin:

MEX

Interrupting Rating:

65 kA

Current Rating:

20 A

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Series:

LGB

Siemens LGB3B025B Molded Case Breakers (MCCBs)

SKU:

C15-10480

TS PIK:

125266287

Current Rating:

25 A

Catalog:

SiemensAG_10807_1-5_CAT.pdf

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Interrupting Rating:

14 kA at 600 Star/347 VAC

Number of Poles:

3

Country of Origin:

Mexico

Short Description:

240/480 Star/277/600 Star/347 VAC 50/60 Hz, 125/250 VDC, 25 A, 100 kA Interrupt, 3-Pole, Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity, Panelboard Circuit Breaker

Approval:

UL 489

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Siemens LGB3B030B Molded Case Breakers (MCCBs)

SKU:

C15-9231

Catalog:

SiemensAG_10807_1-5_CAT.pdf

Current Rating:

30 A

Short Description:

240/480 Star/277/600 Star/347 VAC 50/60 Hz, 125/250 VDC, 30 A, 100 kA Interrupt, 3-Pole, Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity, Panelboard Circuit Breaker

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Number of Poles:

3

Interrupting Rating:

14 kA at 600 Star/347 VAC

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Country of Origin:

Mexico

Used On:

P1/P2/P3/P4/P5 Panelboard

Approval:

UL 489

Application:

Lighting, Distribution

Siemens LGB3B035B Molded Case Breakers (MCCBs)

SKU:

C15-19012

Short Description:

240/480 Star/277/600 Star/347 VAC 50/60 Hz, 125/250 VDC, 35 A, 100 kA Interrupt, 3-Pole, Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity, Panelboard Circuit Breaker

Number of Poles:

3

Current Rating:

35 A

Interrupting Rating:

14 kA at 600 Star/347 VAC

Country of Origin:

MEX

Catalog:

SiemensAG_10807_1-5_CAT.pdf

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Approval:

UL 489

Used On:

P1/P2/P3/P4/P5 Panelboard

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Application:

Lighting, Distribution

Siemens LGB3B040B Molded Case Breakers (MCCBs)

SKU:

C15-10481

TS PIK:

125266290

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Country of Origin:

MEX

Short Description:

600 VAC Star/347 VAC, 40 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Voltage Rating:

480 V

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC Star/347 VAC, 14 kA at 600 VAC Star/347 VAC (UL)

Approval:

UL

Used On:

Panelboard

Terminal Type:

Load Lug

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Series:

LGB

Number of Poles:

3

Current Rating:

40 A

Siemens LGB3B045B Molded Case Breakers (MCCBs)

SKU:

C15-10482

TS PIK:

125266291

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Catalog:

SiemensAG_01796_7_7_7_33_CAT.pdf

Current Rating:

45 A

Number of Poles:

3

Interrupting Rating:

14 kA at 600 Star/347 VAC

Country of Origin:

Mexico

Approval:

UL 489

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Short Description:

BRKR LGB 45A 3P 480Y 65K LD LUG

Siemens LGB3B050B Molded Case Breakers (MCCBs) LGB 3P 50A 480V 50/60Hz 3Ph

SKU:

C15-4182

Series:

LGB

Approval:

UL

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Volts:

480 V

Amps:

50 A

Used On:

Panelboard

Poles:

3

Interrupting Rating:

100 kA at 240 VAC

Interrupting Rating:

65 kA at 480 Volt AC Star/347 Volt AC

Interrupting Rating:

14 kA at 600 Volt AC Star/347 Volt AC (UL)

Terminal Type:

Load Lug

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Short Description:

600 VAC Star/347 VAC, 50 A at 40 Deg C, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Current Rating:

50 A

Voltage Rating:

480 V

Number of Poles:

3

Country of Origin:

Mexico

Siemens LGB3B060 Molded Case Breakers (MCCBs) LGB 3P 60A 600V 50/60Hz 3Ph

SKU:

C15-1464

Frame Type:

LGB

Voltage Rating:

600 VAC

Current Rating:

60 A

Number of Poles:

3

Short Description:

Siemens, VL Series, type LGB, 3P, 3PH, 50A, 600V, 100kA@240V, high interrupting capacity, panelboard mounting, suitable for reverse feed applications, bolt-on

Siemens LGB3B060B Molded Case Breakers (MCCBs)

SKU:

C15-10483

TS PIK:

125266293

Voltage Rating:

240 VAC, 480 VAC Star/277 VAC, 600 VAC Star/347 VAC (UL), 125/250 VDC

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Current Rating:

60 A

Number of Poles:

3

Short Description:

240/480 Star/277 VAC, 125/250 VDC, 60 A, 100 kA, 3-Pole, Molded Case, Thermal Magnetic Trip Unit, Panelboard Circuit Breaker

Type:

Molded Case, Thermal Magnetic

Country of Origin:

Mexico

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 Star/277 VAC, 14 kA at 600 Star/347 VAC (UL), 14 kA at 125/250 VDC

Used On:

Panelboard

Approval:

UL 489

Siemens LGB3B070B Molded Case Breakers (MCCBs)

SKU:

C15-10484

TS PIK:

125266294

Number of Poles:

3

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Interrupting Rating:

14 kA at 600 Star/347 VAC

Current Rating:

70 A

Catalog:

SiemensAG_01796_7_7_7_33_CAT.pdf

Country of Origin:

Mexico

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Approval:

UL 489

Short Description:

BRKR LGB 70A 3P 480Y 65K LD LUG

Siemens LGB3B080B Molded Case Breakers (MCCBs)

SKU:

C15-10485

TS PIK:

125266295

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Interrupting Rating:

14 kA at 600 Star/347 VAC

Application:

Lighting, Distribution

Catalog:

SiemensAG_01796_7_7_7_33_CAT.pdf

Approval:

UL 489

Short Description:

BRKR LGB 80A 3P 480Y 65K LD LUG

Current Rating:

80 A

Number of Poles:

3

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Used On:

P1/P2/P3/P4/P5 Panelboard

Country of Origin:

MEX

Siemens LGB3B090B Molded Case Breakers (MCCBs)

SKU:

C15-16826

Short Description:

BRKR LGB 90A 3P 480Y 65K LD LUG

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Interrupting Rating:

14 kA at 600 Star/347 VAC

Country of Origin:

MEX

Application:

Lighting, Distribution

Current Rating:

90 A

Number of Poles:

3

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Catalog:

SiemensAG_01796_7_7_7_33_CAT.pdf

Used On:

P1/P2/P3/P4/P5 Panelboard

Approval:

UL 489

Siemens LGB3B100B Molded Case Breakers (MCCBs)

SKU:

C15-10486

TS PIK:

125266297

Interrupting Rating:

65 kA

Terminal Type:

Load Lug

Type:

Thermal Magnetic

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Number of Poles:

3

Series:

LGB

Short Description:

600 VAC Star/347 VAC, 100 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Current Rating:

100 A

Voltage Rating:

480 V

Country of Origin:

Mexico

Approval:

UL

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Used On:

Panelboard

Siemens LGB3B125B Molded Case Breakers (MCCBs) 3P 125A

SKU:

C15-7703

TS PIK:

21331323

Series:

LGB

Voltage Rating:

480 V

Catalog:

SiemensAG_00564_7_33_CAT.pdf

Number of Poles:

3

Terminal Type:

Load Lug

Current Rating:

125 A

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Short Description:

600 VAC Star/347 VAC, 125 A, 65 kA at 480 VAC Star/277 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, LGB Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker for Panelboard

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC Star/347 VAC, 14 kA at 600 VAC Star/347 VAC (UL)

Country of Origin:

Mexico

Approval:

UL

Used On:

Panelboard

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Siemens LGB3K020B Molded Case Breakers (MCCBs)

SKU:

C15-16828

Current Rating:

20 A

Country of Origin:

MEX

Interrupting Rating:

25 kA at 600 Star/347 VAC

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Number of Poles:

3

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Catalog:

SiemensAG_01796_7_7_7_34_CAT.pdf

Short Description:

BRKR LGB 20A 3P 480V 65K LD LUG

Approval:

UL 489

Siemens LGB3K060B Molded Case Breakers (MCCBs)

SKU:

U00-8305

Current Rating:

60 A

Catalog:

SiemensAG_01796_7_7_7_34_CAT.pdf

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Used On:

P1/P2/P3/P4/P5 Panelboard

Application:

Lighting, Distribution

Approval:

UL 489

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Country of Origin:

MEX

Number of Poles:

3

Interrupting Rating:

25 kA at 600 Star/347 VAC

Short Description:

BRKR LGB 60A 3P 480V 65K LD LUG

Siemens LGB3K070B Molded Case Breakers (MCCBs)

SKU:

C15-16829

Number of Poles:

3

Current Rating:

70 A

Used On:

P1/P2/P3/P4/P5 Panelboard

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Country of Origin:

MEX

Interrupting Rating:

25 kA at 600 Star/347 VAC

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Short Description:

BRKR LGB 70A 3P 480V 65K LD LUG

Approval:

UL 489

Catalog:

SiemensAG_01796_7_7_7_34_CAT.pdf

Application:

Lighting, Distribution

Siemens LGB3K080B Molded Case Breakers (MCCBs)

SKU:

C15-16830

Used On:

P1/P2/P3/P4/P5 Panelboard

Application:

Lighting, Distribution

Short Description:

BRKR LGB 80A 3P 480V 65K LD LUG

Current Rating:

80 A

Country of Origin:

MEX

Interrupting Rating:

25 kA at 600 Star/347 VAC

Number of Poles:

3

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Catalog:

SiemensAG_01796_7_7_7_34_CAT.pdf

Approval:

UL 489

Siemens LGB3K100B Molded Case Breakers (MCCBs)

SKU:

C15-16831

Number of Poles:

3

Catalog:

SiemensAG_01796_7_7_7_34_CAT.pdf

Approval:

UL 489

Short Description:

BRKR LGB 100A 3P 480V 65K LD LUG

Interrupting Rating:

25 kA at 600 Star/347 VAC

Country of Origin:

MEX

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Application:

Lighting, Distribution

Used On:

P1/P2/P3/P4/P5 Panelboard

Current Rating:

100 A

Type:

Molded Case, Low Vage, Thermal and Fixed Magnetic, Very High Breaking Capacity

Siemens LGG3B015L Molded Case Breakers (MCCBs)

SKU:

C15-19013

Interrupting Rating:

14 kA at 600 Star/347 VAC

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Installation/Operator:

SiemensAG_00699_INST.pdf

Catalog:

SiemensAG_01796_7_9_7_43_7_156_CAT.pdf

Terminal Type:

Line and Load Lug

Mounting:

Cable In, Cable Out

Type:

Low Vage, Thermal Magnetic, High Breaking Capacity

Current Rating:

15 A

Country of Origin:

MEX

Size:

3 Inch Width x 2.9 Inch Depth x 5.4 Inch Height

Number of Poles:

3

Short Description:

BRKR LGG 15A 3P 480V 65K LUGS

Approval:

UL 489

Wire Size:

14 to 10 AWG (Copper/Aluminum)

Siemens LGG3B025L Din Rail Mounted Circuit Breakers

SKU:

C15-23211

Current Rating:

25 A

Voltage Rating:

480 V

Terminal Type:

Line and Load Lug

Mounting:

Cable-In/Out, DIN Rail/Screw

Series:

LGG

Wire Size:

14 to 10 AWG (Copper/Aluminum)

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Approval:

UL, CSA

Short Description:

600 VAC Star/347 VAC, 25 A, 65 kA at 480 VAC, 3-Pole, 14 to 10 AWG Copper/Aluminum, Line/Load Lug Terminal, LGG Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Catalog:

SiemensAG_00564_7_43_CAT.pdf

Interrupting Rating:

65 kA at 240 VAC, 65 kA at 480 VAC, 14 kA at 600 VAC Star/347 VAC, 14 kA at 125/250 VAC

Country of Origin:

MEX

Number of Poles:

3

Siemens LGG3B040L Molded Case Breakers (MCCBs)

SKU:

C15-10489

TS PIK:

125266380

Series:

LGG

Short Description:

600 VAC Star/347 VAC, 40 A, 65 kA at 480 VAC, 3-Pole, 8 to 1/0 AWG Copper/Aluminum, Line/Load Lug Terminal, LGG Frame, Thermal Magnetic Trip Unit, Molded Case Circuit Breaker

Number of Poles:

3

Current Rating:

40 A

Voltage Rating:

480 V

Interrupting Rating:

65 kA at 240 VAC, 65 kA at 480 VAC, 14 kA at 600 VAC Star/347 VAC, 14 kA at 125/250 VAC

Country of Origin:

Mexico

Size:

3 Inch Width x 2.8 Inch Depth x 5.4 Inch Height

Catalog:

SiemensAG_00564_7_43_CAT.pdf

Terminal Type:

Line and Load Lug

Approval:

UL, CSA

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Mounting:

Cable-In/Out, DIN Rail/Screw

Siemens LGG3B050L Molded Case Breakers (MCCBs)

SKU:

C15-19014

Number of Poles:

3

Size:

3 Inch Width x 2.9 Inch Depth x 5.4 Inch Height

Interrupting Rating:

14 kA at 600 Star/347 VAC

Current Rating:

50 A

Country of Origin:

MEX

Terminal Type:

Line and Load Lug

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Catalog:

SiemensAG_01796_7_9_7_43_7_156_CAT.pdf

Type:

Low Vage, Thermal Magnetic, High Breaking Capacity

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Installation/Operator:

SiemensAG_00699_INST.pdf

Mounting:

Cable In, Cable Out

Approval:

UL 489

Short Description:

BRKR LGG 50A 3P 480V 65K LUGS

Siemens LGG3B060L Molded Case Breakers (MCCBs)

SKU:

C15-10490

TS PIK:

125266383

Country of Origin:

Mexico

Number of Poles:

3

Current Rating:

60 A

Catalog:

SiemensAG_01796_7_9_7_43_7_156_CAT.pdf

Type:

Low Vage, Thermal Magnetic, High Breaking Capacity

Installation/Operator:

SiemensAG_00699_INST.pdf

Terminal Type:

Line and Load Lug

Interrupting Rating:

14 kA at 600 Star/347 VAC

Voltage Rating:

600 Star/347 VAC 50/60 Hertz

Size:

3 Inch Width x 2.9 Inch Depth x 5.4 Inch Height

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Approval:

UL 489

Mounting:

Cable In, Cable Out

Short Description:

BRKR LGG 60A 3P 480V 65K LUGS

Siemens LMD63B700 Molded Case Breakers (MCCBs)

SKU:

C15-23217

Current Rating:

700 A

Interrupting Rating:

65 kA at 240 VAC (UL 489), 50 kA at 480 VAC (UL 489), 25 kA at 600 VAC (UL 489), 25 kA at 500 VDC (UL 489)

Maximum AC Voltage Rating:

600 V

Frame Type:

LMD

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Size:

7.5 Inch Width x 5.93 Inch Depth x 16 Inch Height

Maximum DC Voltage Rating:

500 V

Approval:

UL 489, IEC 947-2

Country of Origin:

MEX

Terminal Type:

Line/Load Lug

Catalog:

SiemensAG_00564_7_3-7_5_7_126_7_143_CAT.pdf

Short Description:

600 VAC, 500 VDC, 700 A, 50 kA at 480 VAC, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, LMD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 500 VDC

Series:

LMD6

Siemens LMD63B800 Molded Case Breakers (MCCBs)

SKU:

C15-16873

Short Description:

600 VAC, 500 VDC, 800 A, 50 kA at 480 VAC, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, LMD Frame, Thermal Magnetic Trip Unit, Interchangeable Trip, Molded Case Circuit Breaker

Country of Origin:

MEX

Number of Poles:

3

Interrupting Rating:

65 kA at 240 VAC (UL 489), 50 kA at 480 VAC (UL 489), 25 kA at 600 VAC (UL 489), 25 kA at 500 VDC (UL 489)

Frame Type:

LMD

Current Rating:

800 A

Voltage Rating:

600 VAC, 500 VDC

Series:

LMD6

Type:

Thermal Magnetic

Approval:

UL 489

Size:

7.5 Inch Width x 5.93 Inch Depth x 16 Inch Height

Catalog:

SiemensAG_00564_7_3-7_5_7_126_7_143_CAT.pdf

Siemens LMD63T800 Molded Case Breakers (MCCBs)

SKU:

C15-7705

TS PIK:

21331553

Number of Poles:

3

Type:

Interchangeable Trip, Thermal Magnetic

Catalog:

SiemensAG_00564_7_3-7_5_7_126_7_127_CAT.pdf

Country of Origin:

MEX

Short Description:

600 VAC, 500 VDC, 800 A, 25/50 kA, 3-Pole, 1/0 AWG to 500 KCMIL Copper/Aluminum, Line/Load Lug Terminal, LMD Frame, Thermal Magnetic, Interchangeable Molded Case Circuit Breaker Trip Unit

Current Rating:

800 A

Adjustment:

Thermal Magnetic Trip

Approval:

UL 489

Frame Type:

LMD

Siemens LMXD63B800 Molded Case Breakers (MCCBs)

SKU:

C15-7478

TS PIK:

126672559

Type:

Thermal Magnetic

Size:

7.5 Inch Width x 5.93 Inch Depth x 5.93 Inch Height

Frame Type:

MD

Number of Poles:

3

Short Description:

600 VAC, 800 A at 40 Deg C, 50 kA at 480 VAC, 3-Pole, LMD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 V

Terminal Type:

Not Included

Interrupting Rating:

65 kA at 240 VAC (UL 489), 50 kA at 480 VAC (UL 489), 25 kA at 600 VAC/250 VDC (UL 489)

Current Rating:

800 A

Catalog:

SiemensAG_00564_7_3-7_5_7_126_7_145_CAT.pdf

Series:

LMXD6

Country of Origin:

Mexico

Approval:

UL 489

Siemens LMXD63S800A Molded Case Breakers (MCCBs)
