Eaton HFD3125L Molded Case Breakers (MCCBs) 3P 125A 600V EA

SKU:

C15-7298

TS PIK:

119977705

Maximum DC Voltage Rating:

250 V

Terminal Type:

Standard Pressure Line and Load

Type:

Molded Case, Thermal Magnetic

Installation/Operator:

Eaton_00091_INST.pdf

Maximum AC Voltage Rating:

600 V

Size:

4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height

CAD Drawings:

Eaton_21588_1_CAD.pdf

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VDC, 22 kA at 250 VDC

Number of Poles:

3

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Current Rating:

125 A

Frame Type:

FD

Short Description:

600 VAC 50/60 Hz, 250 VDC, 125 A, 65/22 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker

Series:

C, HFD

Voltage Rating:

600 VAC, 250 VDC

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA C22.2

Eaton HFD3150L Molded Case Breakers (MCCBs) EA

SKU:

C15-7255

TS PIK:

21097533

Series:

C, HFD

Voltage Rating:

600 VAC, 250 VDC

Maximum DC Voltage Rating:

250 V

Maximum AC Voltage Rating:

600 V

Short Description:

600 VAC 50/60 Hz, 250 VDC, 150 A, 65/22 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker

Terminal Type:

Standard Pressure Line and Load

Number of Poles:

3

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VDC, 22 kA at 250 VDC

Type:

Molded Case, Thermal Magnetic

Size:

4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height

CAD Drawings:

Eaton_21588_1_CAD.pdf

Installation/Operator:

Eaton_00091_INST.pdf

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Frame Type:

FD

Current Rating:

150 A

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA C22.2

Eaton HFDDC2070L Molded Case Breakers (MCCBs) HFD 2P 70A 600V 50/60Hz 2Ph F Frame

SKU:

C15-3515

Application:

Commercial

Application:

Industrial

Application:

UPS Battery Supply Circuit

Application:

Solar System and Electric Vehicle Charging

Approval:

UL 489

Amps:

70 A

Interrupting Rating:

42 kA at 600 VDC

Poles:

2

Size:

2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height

Terminal Type:

Line and Load

Type:

Fixed Thermal Magnetic

Type:

High Interrupting Capacity

Type:

Direct Current

Volts:

600 VAC

Volts:

250 VDC

Gauge:

4 to 4/0 AWG Copper/Aluminum

TS PIK:

115321699

Data Sheet:

Eaton_07831_1-12_DATA.pdf

Catalog:

Eaton_03771_V4T2_443-V4T2_456_CAT.pdf

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

70 A

Short Description:

EATON SERIES C DC/PVGARD COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, HFD, COM

Series:

C

Country of Origin:

Dominican Republic

Wire Size:

4 to 4/0 AWG Copper/Aluminum

Eaton HMCP050G2 Molded Case Breakers (MCCBs)

SKU:

C15-16611

Current Rating:

50 A

Size:

7.5 Inch Length x 5 Inch Width x 4.9 Inch Height

Voltage Rating:

600 VAC, 250 VDC

Trip Setting:

80 to 120 A

Terminal Type:

Line and Load

Maximum DC Voltage Rating:

250 V

Maximum AC Voltage Rating:

600 V

Approval:

UL 489, CSA C22.2, CE

Number of Poles:

3

Short Description:

600 VAC, 250 VDC, 50 A, 80 to 120 A Trip, 3-Pole, NEMA 2, Line and Load Terminal, Low Magnetic, Molded Case, Motor Circuit Protector

Catalog:

Eaton_27487_V4T2_394_V4T2_395_CAT.pdf

CAD Drawings:

Eaton_00054_1-9_CAD.pdf

Installation/Operator:

Eaton_00176_INST.pdf

Type:

Molded Case, Magnetic

Starter Size:

NEMA 2

Eaton HMCP070M2 Molded Case Breakers (MCCBs)

SKU:

C15-16612

Frame Type:

F

Catalog:

Eaton_27487_V4T2_394_V4T2_395_CAT.pdf

Short Description:

600 VAC, 250 VDC, 70 A, 210 to 700 A Trip, 16.1 to 59.1 A FLA, 3-Pole, NEMA 2, Line and Load Terminal, F Frame, Magnetic, Molded Case, Motor Circuit Protector

Starter Size:

NEMA 2

Terminal Type:

Steel Line and Load Terminal

Series:

C, HMCP

Current Rating:

70 A

Installation/Operator:

Eaton_00176_INST.pdf

Type:

Molded Case, Magnetic

Voltage Rating:

600 VAC, 250 VDC

Maximum AC Voltage Rating:

600 VAC

Maximum DC Voltage Rating:

250 VDC

Approval:

UL 489, CSA C22.2, CE

Trip Setting:

210 to 700 A

Number of Poles:

3

CAD Drawings:

Eaton_00054_1-9_CAD.pdf

Eaton HMCP070M2C Motor Circuit Protector (MCPs) HMCP 3P 70A 600V 50/60Hz 3Ph M Frame

SKU:

C15-2638

Series:

C, HMCP

Type:

Molded Case

Type:

Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Approval:

CE

Volts:

600 VAC

Volts:

250 VDC

Amps:

32 A

Poles:

3

Terminal Type:

Non-Aluminum Line and Load Terminal

Frame Type:

F

Maximum AC Voltage Rating:

600 VAC

Motor FLA:

16.1 to 59.1 A

Maximum DC Voltage Rating:

250 VDC

Trip Setting:

210 to 700 A

Starter Size:

NEMA 2

Short Description:

600 VAC, 250 VDC, 70 A, 210 to 700 A Trip, 16.1 to 59.1 A FLA, 3-Pole, NEMA 2, Non-Aluminum Line and Load Terminal, F Frame, Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_394_V4T2_395_V4T2_398_CAT.pdf

Installation/Operator:

Eaton_00176_INST.pdf

CAD Drawing:

Eaton_00054_1-9_CAD.pdf

Current Rating:

70 A

CAD Drawings:

Eaton_00054_1-9_CAD.pdf

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Country of Origin:

Dominican Republic

Eaton HMCP100L3 Molded Case Breakers (MCCBs)

SKU:

C15-16613

Trip Setting:

160 to 240 A

Installation/Operator:

Eaton_00176_INST.pdf

Terminal Type:

Line and Load

Number of Poles:

3

Maximum AC Voltage Rating:

600 V

Frame Type:

F

Type:

Special Low Magnetic

Maximum DC Voltage Rating:

250 V

Catalog:

Eaton_03771_V4T2_360-V4T2_385_CAT.pdf

Approval:

UL 489, CSA C22.2, CE

Size:

4.9 Inch Width x 7.7 Inch Depth x 4.8 Inch Height

CAD Drawings:

Eaton_00054_3-6_CAD.pdf

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY MOTOR PROTECTION, MOTOR CIRCUIT PROT

Current Rating:

100 A

Starter Size:

NEMA 3

Voltage Rating:

600 VAC, 250 VDC

Eaton HMCP100R3 Molded Case Breakers (MCCBs)

SKU:

C15-16614

Series:

C, HMCP

Number of Poles:

3

Catalog:

Eaton_27487_V4T2_394_V4T2_395_CAT.pdf

Trip Setting:

300 to 1000 A

Frame Type:

F

Starter Size:

NEMA 3

Maximum DC Voltage Rating:

250 V

Terminal Type:

Steel Line and Load Terminal

Approval:

UL 489, CSA C22.2, CE

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

100 A

Short Description:

600 VAC, 250 VDC, 100 A, 300 to 1000 A Trip, 23 to 84.5 A FLA, 3-Pole, NEMA 3, Line and Load Terminal, F Frame, Magnetic, Molded Case, Motor Circuit Protector

Type:

Molded Case, Magnetic

Maximum AC Voltage Rating:

600 V

Country of Origin:

Dominican Republic

Eaton HMCP250A5C Molded Case Breakers (MCCBs)

SKU:

C15-19189

Starter Size:

NEMA 5

Current Rating:

250 A

Number of Poles:

3

Type:

Magnetic

Installation/Operator:

Eaton_00176_INST.pdf

Terminal Type:

Non-Aluminum Line and Load

Approval:

UL 489, CSA C22.2, CE

CAD Drawings:

Eaton_00054_1-9_CAD.pdf

Frame Type:

J

Short Description:

600 VAC, 250 VDC, 250 A, 350 to 700 A Trip, 3-Pole, J Frame, Size NEMA 5, Non-Aluminum Line and Load Terminal, Molded Case, Magnetic, Circuit Breaker Motor Protection

Series:

C, HMCP

Size:

4.13 Inch Width x 4.06 Inch Depth x 10 Inch Height

Catalog:

Eaton_03771_V4T2_360_V4T2_361_V4T2_367_CAT.pdf

Maximum AC Voltage Rating:

600 V

Trip Setting:

350 to 700 A

Voltage Rating:

600 VAC, 250 VDC

Maximum DC Voltage Rating:

250 V

Eaton HMCP250K5C Molded Case Breakers (MCCBs)

SKU:

C15-19192

Frame Type:

J

Voltage Rating:

600 VAC, 250 VDC

Starter Size:

NEMA 5

Maximum DC Voltage Rating:

250 V

Trip Setting:

1000 to 2000 A

Number of Poles:

3

Type:

Magnetic

Maximum AC Voltage Rating:

600 V

Catalog:

Eaton_03771_V4T2_360_V4T2_361_V4T2_367_CAT.pdf

Current Rating:

250 A

Installation/Operator:

Eaton_00176_INST.pdf

Size:

4.13 Inch Width x 4.06 Inch Depth x 10 Inch Height

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY MOTOR PROTECTION, MOTOR CIRCUIT PROT

CAD Drawings:

Eaton_00054_1-7_CAD.pdf

Terminal Type:

Non-Aluminum Line and Load

Approval:

UL 489, CSA C22.2, CE

Eaton HMCP250L5C Molded Case Breakers (MCCBs)

SKU:

U00-8206

Short Description:

600 VAC, 250 VDC, 250 A, 1125 to 2250 A Trip, 86.6 to 183.6 A FLA, 3-Pole, NEMA 5, Non-Aluminum Line and Load Terminal, J Frame, Magnetic, Molded Case, Motor Circuit Protector

Series:

C, HMCP

Size:

4.06 Inch W x 4.13 Inch D x 10 Inch H

Maximum AC Voltage Rating:

600 VAC

Frame Type:

J

Catalog:

Eaton_27487_V4T2_394_V4T2_395_V4T2_401_CAT.pdf

Type:

Molded Case, Magnetic

Starter Size:

NEMA 5

Terminal Type:

Non-Aluminum Line and Load Terminal

Approval:

UL 489, CSA C22.2, CE

Trip Setting:

1125 to 2250 A

Current Rating:

250 A

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Maximum DC Voltage Rating:

250 VDC

Eaton HMCP250W5C Motor Circuit Protector (MCPs)

SKU:

C15-6863

Frame Type:

J-K

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

250 A

Number of Poles:

3

Type:

Molded Case Magnetic

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

250 V

Terminal Type:

Non-Aluminum Line and Load Terminal

Size:

4.06 Inch Width x 4.13 Inch Depth x 10 Inch Height

Short Description:

Eaton molded case circuit breaker accessory motor protection, Motor circuit protector, 250 A, Three-pole, Frame J-K, 1250-2500 A, 600 V, 250 Vdc, Series C, Line and load, Non-aluminum

Catalog:

Eaton_27487_V4T2_394_V4T2_395_V4T2_401_CAT.pdf

Data Sheet:

Eaton_14356_1_2_SPEC.pdf

Series:

C, HMCP

Eaton HMCP400W5 Molded Case Breakers (MCCBs)

SKU:

C15-16624

Terminal Type:

Line and Load

Number of Poles:

3

Approval:

UL 489, CSA C22.2, CE

Maximum AC Voltage Rating:

600 V

Catalog:

Eaton_03771_V4T2_360_V4T2_361_V4T2_368_CAT.pdf

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY MOTOR PROTECTION, MOTOR CIRCUIT PROTECTOR, 400 A, THREE-POLE, FRAME K, 1250-2500 A, 600 V, 250 VDC, SERIES C, LINE AND LOAD

Size:

5.5 Inch Width x 4.1 Inch Depth x 10.13 Inch Height

CAD Drawings:

Eaton_00054_1_5_6_CAD.pdf

Starter Size:

NEMA 5

Installation/Operator:

Eaton_00176_INST.pdf

Type:

Magnetic

Maximum DC Voltage Rating:

250 V

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

400 A

Frame Type:

K

Trip Setting:

1250 to 2500 A

Eaton JD2200 Molded Case Breakers (MCCBs) EA

SKU:

C15-9314

Frame Type:

J

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

200 A

Number of Poles:

2

Interrupting Rating:

65 kA at 240 VAC, 35 kA at 480 VAC

Short Description:

Eaton Series C complete molded case circuit breaker, J-frame, JD, Complete breaker, Fixed thermal, fixed magnetic trip, Two-pole, 200A, 600 VAC, 250 VDC, 65 kA at 240 VAC, 35 kA at 480 VAC, Aluminum, Line and load, 50/60 Hz

Type:

Thermal Magnetic, Standard Interrupting Capacity, Molded Case

Catalog:

EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_298_CAT.pdf

CAD Drawings:

Eaton_10146_1_CAD.pdf

Maximum DC Voltage Rating:

250 V

Maximum AC Voltage Rating:

600 V

Size:

4.13 Inch Width x 4.06 Inch Depth x 10 Inch Height

Terminal Type:

Aluminum Line and Load

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA C22.2

Eaton JDB3200 Molded Case Breakers (MCCBs)

SKU:

C15-2841

TS PIK:

21512465

Series:

JDB

Short Description:

600 VAC, 250 VDC, 200 A, 18 kA, 3-Pole, Line/Load Terminal, JDB-Frame, Molded Case, Thermal Magnetic, Non-Interchangeable Trip Breaker

Current Rating:

200 A

Interrupting Rating:

65 kA at 240 VAC 50/60 Hertz, 35 kA at 480 VAC 50/60 Hertz, 18 kA at 600 VAC 50/60 Hertz, 10 kA at 250 VDC

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Terminal Type:

Line and Load

Catalog:

Eaton_14666_V4T2_294_CAT.pdf

Frame Type:

JDB

Maximum DC Voltage Rating:

250 V

Voltage Rating:

600 VAC, 250 VDC

Maximum AC Voltage Rating:

600 V

Eaton KDB3400 Molded Case Breakers (MCCBs)

SKU:

C15-19198

Maximum AC Voltage Rating:

600 V

Voltage Rating:

600 VAC, 250 VDC

Series:

KDB

Terminal Type:

Line and Load

Type:

Molded Case, Thermal Magnetic

Short Description:

600 VAC 50/60 Hz, 250 VDC, 400 A, 35 kA, 3-Pole, Line/Load Terminal, KDB Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker with Load and Line Side Terminal

Maximum DC Voltage Rating:

250 V

Interrupting Rating:

65 kA at 240 VAC 50/60 Hertz, 35 kA at 480 VAC 50/60 Hertz, 25 kA at 600 VAC 50/60 Hertz, 10 kA at 250 VDC (NEMA/UL 489/CSA), 65 kA at 240 VAC 50/60 Hertz, 40 kA at 380/415 VAC 50/60 Hertz, 10 kA at 250 VDC (IEC)

Approval:

UL

Catalog:

Eaton_46579_V4T2_254_V4T2_255_V4T2_258_V4T2_300-V4T2_322_CAT.pdf

Number of Poles:

3

Current Rating:

400 A

Frame Type:

KDB

Installation/Operator:

Eaton_00085_INST.pdf

Siemens ED63A001 Motor Circuit Protector (MCPs)

SKU:

C15-10392

TS PIK:

115555662

Voltage Rating:

600 VAC, 250 VDC

Short Description:

600 VAC, 250 VDC, 1 A, 18/25 kA, 2.6 to 9 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Frame Type:

ED

Catalog:

SiemensAG_01698_17_78-17_80_17_108_17_109_17_111_CAT.pdf

Terminal Type:

Load Lug

Number of Poles:

3

Type:

Thermal Magnetic

Maximum AC Voltage Rating:

600 V

Series:

ED6

Installation/Operator:

SiemensAG_00313_INST.pdf

Current Rating:

1 A

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Maximum DC Voltage Rating:

250 V

Country of Origin:

Mexico

Approval:

UL 489, CSA C22.2, IEC

Wire Type:

10 to 1/0 AWG (Copper/Aluminum)

Motor FLA:

0.46 to 0.56 A

Trip Setting:

2.6 to 9 A

Siemens ED63A002 Everything Else 2A

SKU:

C15-7558

TS PIK:

120152314

Short Description:

600 VAC, 250 VDC, 2 A, 18/25 kA, 7 to 22 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Terminal Type:

Load Lug

Country of Origin:

MEX

Voltage Rating:

600 VAC, 250 VDC

Series:

ED6

Current Rating:

2 A

Installation/Operator:

SiemensAG_00313_INST.pdf

Approval:

UL 489, CSA C22.2, IEC

Type:

Thermal Magnetic

Number of Poles:

3

Catalog:

SiemensAG_01698_17_78-17_80_17_108_17_109_17_111_CAT.pdf

Maximum AC Voltage Rating:

600 V

Trip Setting:

7 to 22 A

Frame Type:

ED

Maximum DC Voltage Rating:

250 V

Siemens ED63A003 Motor Circuit Protector (MCPs)

SKU:

C15-10393

TS PIK:

21367495

Short Description:

600 VAC, 250 VDC, 3 A, 18/25 kA, 10 to 35 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Current Rating:

3 A

Type:

Magnetic

Series:

ED63A

Voltage Rating:

600 VAC, 250 VDC

Country of Origin:

MEX

Frame Type:

ED

Approval:

UL 489, CSA C22.2, IEC

Number of Poles:

3

Terminal Type:

Load Lug

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Catalog:

SiemensAG_01698_9_111_CAT.pdf

Trip Setting:

10 to 35 A

Wire Type:

10 to 1/0 AWG (Copper/Aluminum)

Motor FLA:

0.76 to 3.18 A

Installation/Operator:

SiemensAG_00313_INST.pdf

Siemens ED63A005 Motor Circuit Protector (MCPs)

SKU:

C15-10394

TS PIK:

21367496

Series:

ED63A

Short Description:

600 VAC, 250 VDC, 5 A, 18/25 kA, 16 to 54 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Current Rating:

5 A

Country of Origin:

MEX

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Terminal Type:

Load Lug

Type:

Magnetic

Installation/Operator:

SiemensAG_00313_INST.pdf

Catalog:

SiemensAG_01698_17_78-17_80_17_108_17_109_17_111_CAT.pdf

Wire Type:

10 to 1/0 AWG (Copper/Aluminum)

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Motor FLA:

1.23 to 4.9 A

Approval:

UL 489, CSA C22.2, IEC

Frame Type:

ED

Trip Setting:

16 to 54 A

Siemens ED63A010 Everything Else 10A 600V

SKU:

C15-7559

TS PIK:

120152377

Series:

ED6-A

Number of Poles:

3

Country of Origin:

MEX

Voltage Rating:

600 VAC, 250 VDC

Short Description:

600 VAC, 250 VDC, 10 A, 18/25 kA, 30 to 100 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Approval:

UL 489

Size:

6 Inch Width x 4 Inch Depth x 7 Inch Height

Type:

Molded Case, Magnetic

Catalog:

SiemensAG_01698_9_111_CAT.pdf

Current Rating:

10 A

Terminal Type:

Not Included

Installation/Operator:

SiemensAG_00313_INST.pdf

Siemens ED63A025 Motor Circuit Protector (MCPs)

SKU:

C15-10395

TS PIK:

21367498

Short Description:

600 VAC, 250 VDC, 25 A, 18/25 kA, 55 to 180 A Instantaneous Trip, 3-Pole, 14 to 10 AWG Copper/12 to 10 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Series:

ED6

Country of Origin:

MEX

Number of Poles:

3

Current Rating:

25 A

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Type:

Magnetic

Approval:

UL 489, CSA C22.2, IEC

Terminal Type:

Load Lug

Maximum DC Voltage Rating:

250 V

Voltage Rating:

600 VAC, 250 VDC

Wire Type:

10 to 1/0 AWG (Copper/Aluminum)

Maximum AC Voltage Rating:

600 V

Installation/Operator:

SiemensAG_00313_INST.pdf

Motor FLA:

4.23 to 16.4 A

Trip Setting:

55 to 180 A

Frame Type:

ED

Catalog:

SiemensAG_01698_9_111_CAT.pdf

Siemens ED63A040 Motor Circuit Protector (MCPs)

SKU:

C15-7386

TS PIK:

106247604

Current Rating:

40 A

Short Description:

600 VAC, 250 VDC, 40 A, 18/25 kA, 115 to 375 A Instantaneous Trip, 3-Pole, 10 to 1/0 AWG Copper/Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Frame Type:

ED

Catalog:

SiemensAG_01698_9_111_CAT.pdf

Series:

ED63A

Terminal Type:

Load Lug

Type:

Magnetic

Voltage Rating:

600 VAC, 250 VDC

Installation/Operator:

SiemensAG_00313_INST.pdf

Size:

3 Inch Width x 4.56 Inch Depth x 6.35 Inch Height

Number of Poles:

3

Country of Origin:

Mexico

Approval:

UL 489, CSA C22.2, IEC

Motor FLA:

8.84 to 34 A

Wire Type:

10 to 1/0 AWG (Copper/Aluminum)

Trip Setting:

115 to 375 A

Siemens ED63A125 Motor Circuit Protector (MCPs)

SKU:

C15-7427

TS PIK:

21367502

Current Rating:

125 A

Catalog:

SiemensAG_01698_9_111_CAT.pdf

Short Description:

600 VAC, 250 VDC, 125 A, 18/25 kA, 500 to 1250 A Instantaneous Trip, 3-Pole, 3 to 3/0 AWG Copper/1 to 2/0 AWG Aluminum, Load Lug Terminal, ED Frame, Magnetic, ETI Motor, Molded Case Circuit Breaker

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Size:

6 Inch Width x 4 Inch Depth x 7 Inch Height

Terminal Type:

Not Included

Installation/Operator:

SiemensAG_00313_INST.pdf

Series:

ED6-A

Type:

Molded Case, Magnetic

Country of Origin:

Mexico

Approval:

UL 489

Maximum AC Voltage Rating (V):

600

Trip Setting:

500 to 1250 A

Motor FLA:

38.46 to 113.6 A

Siemens FXD63A250 Molded Case Breakers (MCCBs)

SKU:

U00-8127

Catalog:

SiemensAG_01698_17_78_17_82_17_108_17_111_CAT.pdf

Trip Setting:

1110 to 2500 A

Maximum AC Voltage Rating:

600 V

Short Description:

600 VAC 50/60 Hz, 250 VDC, 250 A, 35 kA at 480 VAC, 1100 to 2500 A Instantaneous Trip, 3-Pole, FD Frame, Magnetic, Non-Interchangeable Trip, ETI Motor, Molded Case Circuit Breaker

Installation/Operator:

SiemensAG_00224_INST.pdf

Series:

FXD6

Maximum DC Voltage Rating:

250 V

Approval:

UL 489

Type:

Magnetic

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

250 A

Number of Poles:

3

Country of Origin:

MEX

Siemens FXD63H150 Molded Case Breakers (MCCBs)

SKU:

C15-16319

Current Rating:

150 A

Voltage Rating:

600 VAC, 250 VDC

Country of Origin:

MEX

Type:

Thermal Magnetic

Number of Poles:

3

Frame Type:

FD

Maximum DC Voltage Rating:

250 V

Series:

FXD6

Short Description:

600 VAC 50/60 Hz, 250 VDC, 150 A, 35 kA at 480 VAC, 1100 to 2500 A Instantaneous Trip, 3-Pole, FD Frame, Magnetic, Non-Interchangeable Trip, ETI Motor, Molded Case Circuit Breaker

Size:

4.5 Inch Width x 4 Inch Depth x 9.5 Inch Height

Maximum AC Voltage Rating:

600 V

Trip Setting:

1100 to 2500 A

Catalog:

SiemensAG_01698_17_78_17_82_17_108_17_111_CAT.pdf

Terminal Type:

Not Included

Approval:

UL 489, IEC

Installation/Operator:

SiemensAG_00224_INST.pdf

Siemens JXD62B400 Molded Case Breakers (MCCBs)

SKU:

C15-10465

TS PIK:

21367647

Current Rating:

400 A

Catalog:

SiemensAG_01698_17_78_17_85_17_112_CAT.pdf

Terminal Type:

Not Included

Number of Poles:

2

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Country of Origin:

MEX

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

JD

Approval:

UL 489, IEC

Series:

JXD2-A

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at VAC (UL 489), 30 kA at 250 VDC (UL 489), 65 kA at 220/240 VAC (IEC), 40 kA at 380/415 VAC (IEC)

Short Description:

600 VAC, 250 VDC, 400 A, 35 kA at 480 VAC, 2-Pole, JD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Type:

Thermal Magnetic

Siemens LXD62B600 Molded Case Breakers (MCCBs)

SKU:

C15-7480

TS PIK:

126675151

Terminal Type:

Lug

Size:

7.5 Inch Width x 5.44 Inch Depth x 11 Inch Height

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

LD

Current Rating:

600 A

Series:

LXD6-A

Number of Poles:

2

Short Description:

600 VAC, 250 VDC, 600 A, 35 kA at 480 VAC, 2-Pole, LD Frame, Thermal Magnetic Trip Unit, Non-Interchangeable Trip, Molded Case Circuit Breaker

Interrupting Rating:

65 kA at 240 VAC (UL 489), 35 kA at 480 VAC (UL 489), 25 kA at 600 VAC (UL 489), 30 kA at 250 VDC (UL 489), 65/33 kA at 220/240 VAC (IEC), 40/20 kA at 380/415 VAC (IEC)

Catalog:

SiemensAG_00564_7_3-7_5_7_122_7_145_7_238_CAT.pdf

Type:

Thermal Magnetic

Country of Origin:

Mexico

Approval:

UL 489

Square D FA26015AC Molded Case Breakers (MCCBs)

SKU:

C15-16029

Voltage Rating:

600 VAC, 250 VDC

Type:

Molded Case, Thermal Magnetic

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_08709_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00096_21-23_25_CAT.pdf

Application:

Power Distribution

Interrupting Rating:

10 kA

Approval:

UL, CSA

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Short Description:

600 VAC/250 VDC, 15 A, 18 kA, 2-Pole, 100A-Frame, Thermal Magnetic, Panelboard Molded Case Circuit Breaker

Number of Poles:

2

Trip Setting:

275 to 600 A

Current Rating:

15 A

Square D FA26015BC Molded Case Breakers (MCCBs)

SKU:

C15-8625

Short Description:

600 VAC, 250 VDC, 15 A, 10/14/18/25 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Prop 65 Warning:

Yes

Interrupting Rating:

10 kA

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Type:

Molded Case, Thermal Magnetic

Number of Poles:

2

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Data Sheet:

SchneiderElectric-SquareD_04294_1_2_DATA.pdf

Trip Setting:

275 to 600 A

Current Rating:

15 A

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Approval:

UL, CSA

Voltage Rating:

600 VAC, 250 VDC

Application:

Power Distribution

Square D FA26020AC Molded Case Breakers (MCCBs)

SKU:

L19-6479

Series:

FA

Voltage Rating:

600 VAC, 250 VDC

Trip Setting:

275 A Hold, 600 A Trip

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Data Sheet:

SchneiderElectric-SquareD_04296_1_2_DATA.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Short Description:

600 VAC, 250 VDC, 20 A, 10/14/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

2

Used On:

I-Line Panelboard and Switchboard

Current Rating:

20 A

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Interrupting Rating:

14 kA at 600 VAC

Installation:

Plug-On

Square D FA26020BC Molded Case Breakers (MCCBs)

SKU:

L19-6480

Series:

FA

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

14 kA at 600 VAC

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Type:

Molded Case, Thermal Magnetic, Main

Number of Poles:

2

Short Description:

600 VAC, 250 VDC, 20 A, 10/14/18/25 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_04298_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Trip Setting:

275 A Hold, 600 A Trip

Used On:

I-Line Panelboard and Switchboard

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Current Rating:

20 A

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation:

Plug-On

Square D FA26030AB Molded Case Breakers (MCCBs)

SKU:

L19-6481

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Current Rating:

30 A

Short Description:

600 VAC, 250 VDC, 30 A, 10/14/18/25 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

FA

Interrupting Rating:

14 kA at 600 VAC

Type:

Molded Case, Thermal Magnetic, Main

Number of Poles:

2

Used On:

I-Line Panelboard and Switchboard

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Voltage Rating:

600 VAC, 250 VDC

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Trip Setting:

275 A Hold, 600 A Trip

Data Sheet:

SchneiderElectric-SquareD_04299_1_2_DATA.pdf

Installation:

Plug-On

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Square D FA26030AC Molded Case Breakers (MCCBs)

SKU:

L19-6482

Short Description:

600 VAC, 250 VDC, 30 A, 10/14/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

2

Series:

FA

Interrupting Rating:

14 kA at 600 VAC

Prop 65 Warning:

Yes

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Type:

Molded Case, Thermal Magnetic, Main

Used On:

I-Line Panelboard and Switchboard

Current Rating:

30 A

Data Sheet:

SchneiderElectric-SquareD_04300_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Installation:

Plug-On

Trip Setting:

275 A Hold, 600 A Trip

Square D FA26040AB Molded Case Breakers (MCCBs)

SKU:

L19-6484

Current Rating:

40 A

Used On:

I-Line Panelboard and Switchboard

Number of Poles:

2

Data Sheet:

SchneiderElectric-SquareD_04302_1_2_DATA.pdf

Trip Setting:

400 A Hold, 850 A Trip

Short Description:

600 VAC, 250 VDC, 40 A, 10/14/18/25 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Type:

Molded Case, Thermal Magnetic, Main

Series:

FA

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Voltage Rating:

600 VAC, 250 VDC

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation:

Plug-On

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Interrupting Rating:

14 kA at 600 VAC

Square D FA26060AC Molded Case Breakers (MCCBs)

SKU:

C15-16035

Current Rating:

60 A

Interrupting Rating:

10 kA

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Short Description:

600 VAC, 250 VDC, 60 A, 10/14/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Type:

Molded Case, Thermal Magnetic

Number of Poles:

2

Trip Setting:

800 to 1450 A

Application:

Power Distribution

Data Sheet:

SchneiderElectric-SquareD_04308_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Approval:

UL, CSA

Square D FA26070AB Molded Case Breakers (MCCBs)

SKU:

L19-6566

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Series:

FA

Number of Poles:

2

Data Sheet:

SchneiderElectric-SquareD_04310_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Current Rating:

70 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Used On:

I-Line Panelboard and Switchboard

Short Description:

600 VAC, 250 VDC, 70 A, 10/14/18/25 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Installation:

Plug-On

Trip Setting:

800 A Hold, 1450 A Trip

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Type:

Molded Case, Thermal Magnetic, Main

Interrupting Rating:

14 kA at 600 VAC

Square D FA26080AB Molded Case Breakers (MCCBs)

SKU:

C15-16037

Current Rating:

80 A

Number of Poles:

2

Interrupting Rating:

14 kA at 600 VAC

Series:

650, FA

Voltage Rating:

600 VAC, 250 VDC

Short Description:

600 VAC, 250 VDC, 80 A, 10/14/18/25 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_04313_1_2_DATA.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Used On:

I-Line Panelboard and Switchboard

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Trip Setting:

800 A Hold, 1450 A Trip

Installation:

Plug-On

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Prop 65 Warning:

Yes

Square D FA26080AC Molded Case Breakers (MCCBs)

SKU:

C15-16038

Short Description:

600 VAC, 250 VDC, 80 A, 10/14/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Interrupting Rating:

10 kA

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Approval:

UL, CSA

Application:

Power Distribution

Data Sheet:

SchneiderElectric-SquareD_04314_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Current Rating:

80 A

Type:

Molded Case, Thermal Magnetic

Number of Poles:

2

Series:

650, FA

Trip Setting:

800 to 1450 A

Square D FA26080BC Molded Case Breakers (MCCBs)

SKU:

C15-16039

Used On:

I-Line Panelboard and Switchboard

Type:

Molded Case, Thermal Magnetic, Main

Interrupting Rating:

14 kA at 600 VAC

Installation:

Plug-On

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Short Description:

600 VAC, 250 VDC, 80 A, 10/14/18/25 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Trip Setting:

800 A Hold, 1450 A Trip

Current Rating:

80 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Data Sheet:

SchneiderElectric-SquareD_04315_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Number of Poles:

2

Series:

650, FA

Square D FA26090AB Molded Case Breakers (MCCBs)

SKU:

C15-16040

Interrupting Rating:

14 kA at 600 VAC

Used On:

I-Line Panelboard and Switchboard

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Installation:

Plug-On

Trip Setting:

900 A Hold, 1700 A Trip

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04316_1_2_DATA.pdf

Short Description:

600 VAC, 250 VDC, 90 A, 10/14/18/25 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Current Rating:

90 A

Series:

650, FA

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Voltage Rating:

600 VAC, 250 VDC

Number of Poles:

2

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Square D FA26090AC Molded Case Breakers (MCCBs)

SKU:

L19-6489

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_04317_1_2_DATA.pdf

Installation:

Plug-On

Trip Setting:

900 A Hold, 1700 A Trip

Number of Poles:

2

Current Rating:

90 A

Type:

Molded Case, Thermal Magnetic, Main

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

14 kA at 600 VAC

Short Description:

600 VAC, 250 VDC, 90 A, 10/14/18/25 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Series:

FA

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Voltage Rating:

600 VAC, 250 VDC

Square D FA36035 Molded Case Breakers (MCCBs)

SKU:

L19-6501

Number of Poles:

3

Series:

FA

Short Description:

600 VAC, 250 VDC, 35 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Current Rating:

35 A

Prop 65 Warning:

Yes

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04360_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Trip Setting:

400 A Hold, 850 A Trip

Installation:

Plug-On

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

14 kA at 600 VAC

Used On:

I-Line Panelboard and Switchboard

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Square D FA36040 Molded Case Breakers (MCCBs)

SKU:

C15-8627

Series:

FA

Type:

Molded Case, Thermal Magnetic, Main

Voltage Rating:

600 VAC, 250 VDC

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation:

Plug-On

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Number of Poles:

3

Short Description:

600 VAC, 250 VDC, 40 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Trip Setting:

400 A Hold, 850 A Trip

Current Rating:

40 A

Interrupting Rating:

14 kA at 600 VAC

Data Sheet:

SchneiderElectric-SquareD_04361_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Used On:

I-Line Panelboard and Switchboard

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Square D FA360401021 Molded Case Breakers (MCCBs)

SKU:

C15-16046

Voltage Rating:

600 VAC, 250 VDC

Approval:

UL, CSA

Data Sheet:

SchneiderElectric-SquareD_04362_1_2_DATA.pdf

Prop 65 Warning:

Yes

Application:

Power Distribution

Short Description:

600 VAC, 250 VDC, 40 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker

Number of Poles:

3

Interrupting Rating:

10 kA

Trip Setting:

400 to 850 A

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Current Rating:

40 A

Type:

Molded Case, Thermal Magnetic

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Square D FA36050 Molded Case Breakers (MCCBs)

SKU:

C15-8603

Data Sheet:

SchneiderElectric-SquareD_04364_1_2_DATA.pdf

Trip Setting:

400 A Hold, 850 A Trip

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Interrupting Rating:

14 kA at 600 VAC

Series:

FA

Current Rating:

50 A

Short Description:

600 VAC, 250 VDC, 50 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

3

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Voltage Rating:

600 VAC, 250 VDC

Used On:

I-Line Panelboard and Switchboard

Installation:

Plug-On

Type:

Molded Case, Thermal Magnetic, Main

Square D FA36070 Everything Else

SKU:

E30-10197

Number of Poles:

3

Series:

FA

Short Description:

600 VAC, 250 VDC, 70 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04366_1_2_DATA.pdf

Interrupting Rating:

14 kA at 600 VAC

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Current Rating:

70 A

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Trip Setting:

800 A Hold, 1450 A Trip

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Country of Origin:

Mexico

Square D FA360701021 Molded Case Breakers (MCCBs)

SKU:

C15-16051

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Series:

650, FA

Data Sheet:

SchneiderElectric-SquareD_04367_1_2_DATA.pdf

Prop 65 Warning:

Yes

Short Description:

600 VAC, 250 VDC, 70 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker

Approval:

UL, CSA

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

70 A

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Trip Setting:

800 to 1450 A

Interrupting Rating:

10 kA

Application:

Power Distribution

Square D FA36080 Molded Case Breakers (MCCBs)

SKU:

L19-6502

Series:

FA

Voltage Rating:

600 VAC, 250 VDC

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04368_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Used On:

I-Line Panelboard and Switchboard

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Number of Poles:

3

Installation:

Plug-On

Current Rating:

80 A

Trip Setting:

800 A Hold, 1450 A Trip

Short Description:

600 VAC, 250 VDC, 80 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Interrupting Rating:

14 kA at 600 VAC

Square D FA36090 Molded Case Breakers (MCCBs)

SKU:

C15-7036

Type:

Molded Case, Thermal Magnetic, Main

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Series:

FA

Short Description:

600 VAC, 250 VDC, 90 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Current Rating:

90 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Number of Poles:

3

Interrupting Rating:

14 kA at 600 VAC

Data Sheet:

SchneiderElectric-SquareD_04369_1_2_DATA.pdf

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Trip Setting:

900 A Hold, 1700 A Trip

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Square D FA36100 Molded Case Breakers (MCCBs)

SKU:

C15-7751

Data Sheet:

SchneiderElectric-SquareD_04371_1_2_DATA.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Interrupting Rating:

14 kA at 600 VAC

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Series:

FA

Short Description:

600 VAC, 250 VDC, 100 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

100 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Trip Setting:

900 A Hold, 1700 A Trip

Type:

Molded Case, Thermal Magnetic, Main

Installation:

Plug-On

Catalog:

SchneiderElectric-SquareD_00096_25_28_CAT.pdf

Number of Poles:

3

Used On:

I-Line Panelboard and Switchboard

Square D FA361001021 Molded Case Breakers (MCCBs)

SKU:

C15-7041

Voltage Rating:

600 VAC, 250 VDC

Short Description:

600 VAC, 250 VDC, 100 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_04372_1_2_DATA.pdf

Interrupting Rating:

10 kA

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Current Rating:

100 A

Prop 65 Warning:

Yes

Approval:

UL, CSA

Trip Setting:

900 to 1700 A

Used On:

Class 650, 734, 820 Panelboard/Switchboard

Application:

Power Distribution

Square D FAB36015 Molded Case Breakers (MCCBs)

SKU:

C15-7047

Short Description:

600 VAC, 250 VDC, 15 A, 10/14/18/25 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_04378_1_2_DATA.pdf

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

14 kA at 600 VAC

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Series:

600, FAB

Current Rating:

15 A

Prop 65 Warning:

Yes

Trip Setting:

275 A Hold, 600 A Trip

Used On:

I-Line Panelboard and Switchboard

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Application:

Construction, Commercial Building, Control Equipment Panel, Industrial Building, OEM Commercial

Installation:

Bolt-On

Country of Origin:

Mexico

Square D FAL26015 Molded Case Breakers (MCCBs)

SKU:

C15-16085

Data Sheet:

SchneiderElectric-SquareD_04428_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Terminal Type:

Lug

Current Rating:

15 A

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Number of Poles:

2

Frame Type:

F

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Interrupting Rating:

14 kA at 600 VAC

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Voltage Rating:

600 VAC, 250 VDC

Series:

FA

Short Description:

600 VAC, 250 VDC, 15 A, 14/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Prop 65 Warning:

Yes

Type:

Thermal Magnetic

Square D FAL26020 Molded Case Breakers (MCCBs)

SKU:

C15-16086

Interrupting Rating:

14 kA at 600 VAC

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Type:

Thermal Magnetic

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Short Description:

600 VAC, 250 VDC, 20 A, 14/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

FA

Frame Type:

F

Number of Poles:

2

Prop 65 Warning:

Yes

Current Rating:

20 A

Terminal Type:

Lug

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Data Sheet:

SchneiderElectric-SquareD_04429_1_2_DATA.pdf

Square D FAL26030 Molded Case Breakers (MCCBs)

SKU:

C15-16087

Series:

FA

Frame Type:

F

Short Description:

600 VAC, 250 VDC, 30 A, 14/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Interrupting Rating:

14 kA at 600 VAC

Voltage Rating:

600 VAC, 250 VDC

Type:

Thermal Magnetic

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Prop 65 Warning:

Yes

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Current Rating:

30 A

Number of Poles:

2

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Terminal Type:

Lug

Data Sheet:

SchneiderElectric-SquareD_04430_1_2_DATA.pdf

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Square D FAL26040 Molded Case Breakers (MCCBs)

SKU:

C15-16088

Frame Type:

F

Terminal Type:

Lug

Short Description:

600 VAC, 250 VDC, 40 A, 14/10 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Type:

Thermal Magnetic

Data Sheet:

SchneiderElectric-SquareD_04431_1_2_DATA.pdf

Series:

650, FAL

Number of Poles:

2

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

40 A

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Interrupting Rating:

14 kA at 600 VAC

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Square D FAL36025 Molded Case Breakers (MCCBs)

SKU:

C15-16116

Prop 65 Warning:

Yes

Series:

FA

Short Description:

600 AC, 250 VDC, 25 A, 14/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Type:

Thermal Magnetic

Number of Poles:

3

Current Rating:

25 A

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

F

Terminal Type:

Lug

Data Sheet:

SchneiderElectric-SquareD_04485_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Interrupting Rating:

14 kA at 600 VAC

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Square D FAL36030 Molded Case Breakers (MCCBs)

SKU:

C15-7029

Terminal Type:

Line Lug, Load Lug

Catalog:

SchneiderElectric-SquareD_00096_25_26_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_04486_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

F

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Current Rating:

30 A

Short Description:

600 AC, 250 VDC, 30 A, 14/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Interrupting Rating:

18 kA at 480 VAC, 14 kA at 600 VAC, 25 kA at 240 VDC, 10 kA at 250 VDC

Type:

Molded Case, Thermal Magnetic

Number of Poles:

3

Series:

FA

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Prop 65 Warning:

Yes

Maximum AC Voltage Rating (V):

600

Approval:

UL, CSA

Maximum DC Voltage Rating (V):

250

Square D FAL360801021 Molded Case Breakers (MCCBs)

SKU:

C15-16125

Maximum DC Voltage Rating (V):

250

Number of Poles:

3

Short Description:

600 AC, 250 VDC, 80 A, 14/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Shunt Trip, Molded Case Circuit Breaker

Approval:

UL, CSA, IEC

Prop 65 Warning:

Yes

Size:

4.5 Inch L x 4.13 Inch W x 6 Inch H

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_04496_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Terminal Type:

Lug

Maximum AC Voltage Rating (V):

600

Interrupting Rating:

14 kA

Type:

Molded Case, Thermal Magnetic

Frame Type:

F

Current Rating:

80 A

Square D FAL36100 Molded Case Breakers (MCCBs)

SKU:

C15-6996

TS PIK:

120072265

Short Description:

600 VAC, 250 VDC, 100 A, 3-Pole, F-Frame, Line/Load Lug Terminal Unit Mount, Thermal Magnetic, Non-Interchangeable Trip, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

F

Number of Poles:

3

Series:

FAL

Current Rating:

100 A

Interrupting Rating:

25 kA at 120/240 VAC, 18 kA at 277/480 VAC, 14 kA at 347/600 VAC, 10 kA at 125/250 VDC Symmetrical

Data Sheet:

SchneiderElectric-SquareD_12909_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_03392_11_8_CAT.pdf

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Terminal Type:

Line and Load Lug

Type:

Thermal Magnetic, Molded Case

Prop 65 Warning:

Yes

Approval:

UL, CSA, IEC

Maximum AC Voltage Rating (V):

600

Maximum DC Voltage Rating (V):

250

Square D FH26020AB Molded Case Breakers (MCCBs)

SKU:

C15-7183

Interrupting Rating:

18 kA at 600 VAC

Short Description:

240/480/600 VAC, 250 VDC, 20 A, 65/25/18/10 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

650, FH

Voltage Rating:

600 VAC, 250 VDC

Data Sheet:

SchneiderElectric-SquareD_04531_1_2_DATA.pdf

Current Rating:

20 A

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Number of Poles:

2

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Prop 65 Warning:

Yes

Trip Setting:

275 A Hold, 600 A Trip

Application:

Construction

Used On:

I-Line Panelboard and Switchboard

Installation:

Plug-On

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Country of Origin:

Mexico

Square D FH26020AC Molded Case Breakers (MCCBs)

SKU:

L19-6505

Prop 65 Warning:

Yes

Number of Poles:

2

Current Rating:

20 A

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Used On:

I-Line Panelboard and Switchboard

Trip Setting:

275 A Hold, 600 A Trip

Series:

650, FH

Interrupting Rating:

18 kA at 600 VAC

Short Description:

240/480/600 VAC, 250 VDC, 20 A, 65/25/18/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Installation:

Plug-On

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Application:

Construction

Data Sheet:

SchneiderElectric-SquareD_04532_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Square D FH26020BC Molded Case Breakers (MCCBs)

SKU:

L19-6506

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04533_1_DATA.pdf

Series:

650, FH

Trip Setting:

275 A Hold, 600 A Trip

Current Rating:

20 A

Number of Poles:

2

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

18 kA at 600 VAC

Application:

Construction

Voltage Rating:

600 VAC, 250 VDC

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Short Description:

240/480/600 VAC, 250 VDC, 20 A, 65/25/18/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Installation:

Plug-On

Square D FH26030AC Molded Case Breakers (MCCBs)

SKU:

L19-6507

Installation:

Plug-On

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Trip Setting:

275 A Hold, 600 A Trip

Interrupting Rating:

18 kA at 600 VAC

Number of Poles:

2

Current Rating:

30 A

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Type:

Molded Case, Thermal Magnetic, Main

Voltage Rating:

600 VAC, 250 VDC

Data Sheet:

SchneiderElectric-SquareD_04535_1_2_DATA.pdf

Used On:

I-Line Panelboard and Switchboard

Application:

Construction

Short Description:

240/480/600 VAC, 250 VDC, 30 A, 65/25/18/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

650, FH

Square D FH26030BC Molded Case Breakers (MCCBs)

SKU:

L19-6508

Short Description:

240/480/600 VAC, 250 VDC, 30 A, 65/25/18/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

18 kA at 600 VAC

Data Sheet:

SchneiderElectric-SquareD_04536_1_2_DATA.pdf

Current Rating:

30 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Voltage Rating:

600 VAC, 250 VDC

Number of Poles:

2

Installation:

Plug-On

Series:

650, FH

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Prop 65 Warning:

Yes

Trip Setting:

275 A Hold, 600 A Trip

Application:

Construction

Square D FH26040AB Molded Case Breakers (MCCBs)

SKU:

L19-6509

Trip Setting:

400 A Hold, 850 A Trip

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Installation:

Plug-On

Application:

Construction

Current Rating:

40 A

Data Sheet:

SchneiderElectric-SquareD_04537_1_2_DATA.pdf

Number of Poles:

2

Interrupting Rating:

18 kA at 600 VAC

Series:

650, FH

Short Description:

240/480/600 VAC, 250 VDC, 40 A, 65/25/18/10 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Used On:

I-Line Panelboard and Switchboard

Square D FH26040AC Molded Case Breakers (MCCBs)

SKU:

L19-6510

Data Sheet:

SchneiderElectric-SquareD_04538_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Installation:

Plug-On

Series:

650, FH

Current Rating:

40 A

Prop 65 Warning:

Yes

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Type:

Molded Case, Thermal Magnetic, Main

Application:

Construction

Interrupting Rating:

18 kA at 600 VAC

Number of Poles:

2

Used On:

I-Line Panelboard and Switchboard

Trip Setting:

400 A Hold, 850 A Trip

Short Description:

240/480/600 VAC, 250 VDC, 40 A, 65/25/18/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Square D FH26040BC Molded Case Breakers (MCCBs)

SKU:

L19-6511

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Series:

650, FH

Short Description:

240/480/600 VAC, 250 VDC, 40 A, 65/25/18/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_04539_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Installation:

Plug-On

Trip Setting:

400 A Hold, 850 A Trip

Number of Poles:

2

Current Rating:

40 A

Application:

Construction

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

18 kA at 600 VAC

Square D FH26050AB Molded Case Breakers (MCCBs)

SKU:

C15-7184

Short Description:

240/480/600 VAC, 250 VDC, 50 A, 65/25/18/10 kA, 1-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Interrupting Rating:

18 kA at 600 VAC

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Series:

650, FH

Type:

Molded Case, Thermal Magnetic, Main

Current Rating:

50 A

Voltage Rating:

600 VAC, 250 VDC

Data Sheet:

SchneiderElectric-SquareD_04540_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Number of Poles:

2

Number of Phases:

1

Prop 65 Warning:

Yes

Application:

Construction

Trip Setting:

400 A Hold, 850 A Trip

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Country of Origin:

Mexico

Square D FH26060AC Molded Case Breakers (MCCBs)

SKU:

L19-6513

Prop 65 Warning:

Yes

Series:

650, FH

Data Sheet:

SchneiderElectric-SquareD_04544_1_2_DATA.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Interrupting Rating:

18 kA at 600 VAC

Current Rating:

60 A

Installation:

Plug-On

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Short Description:

240/480/600 VAC, 250 VDC, 60 A, 65/25/18/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Type:

Molded Case, Thermal Magnetic, Main

Number of Poles:

2

Voltage Rating:

600 VAC, 250 VDC

Used On:

I-Line Panelboard and Switchboard

Trip Setting:

800 A Hold, 1450 A Trip

Application:

Construction

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Square D FH26080AC Molded Case Breakers (MCCBs)

SKU:

C15-16275

Short Description:

240/480/600 VAC, 250 VDC, 80 A, 65/25/18/10 kA, 2-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

650, FH

Trip Setting:

800 A Hold, 1450 A Trip

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_04545_1_2_DATA.pdf

Number of Poles:

2

Interrupting Rating:

18 kA at 600 VAC

Type:

Molded Case, Thermal Magnetic, Main

Voltage Rating:

600 VAC, 250 VDC

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Current Rating:

80 A

Application:

Construction

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Square D FH26080BC Molded Case Breakers (MCCBs)

SKU:

C15-16276

Interrupting Rating:

18 kA at 600 VAC

Series:

650, FH

Short Description:

240/480/600 VAC, 250 VDC, 80 A, 65/25/18/10 kA, 4-Phase, 2-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Voltage Rating:

600 VAC, 250 VDC

Prop 65 Warning:

Yes

Data Sheet:

SchneiderElectric-SquareD_04546_1_2_DATA.pdf

Number of Poles:

2

Type:

Molded Case, Thermal Magnetic, Main

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Trip Setting:

800 A Hold, 1450 A Trip

Application:

Construction

Current Rating:

80 A

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Square D FH26100AC Molded Case Breakers (MCCBs)

SKU:

L19-6515

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Series:

650, FH

Number of Poles:

2

Short Description:

600 VAC/250 VDC, 100 A, 18 kA, 2-Pole, 100A-Frame, Thermal Magnetic, Panelboard Molded Case Circuit Breaker

Type:

Molded Case, Thermal Magnetic, Main

Catalog:

SchneiderElectric-SquareD_00096_29_CAT.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Data Sheet:

SchneiderElectric-SquareD_12915_1_2_DATA.pdf

Trip Setting:

900 A Hold, 1700 A Trip

Application:

Construction

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

18 kA at 600 VAC

Current Rating:

100 A

Installation:

Plug-On

Voltage Rating:

600 VAC, 250 VDC

Square D FH36015 Molded Case Breakers (MCCBs)

SKU:

C15-7187

Data Sheet:

SchneiderElectric-SquareD_04549_1_2_DATA.pdf

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Series:

650, FH

Current Rating:

15 A

Number of Poles:

3

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

18 kA at 600 VAC

Short Description:

240/480/600 VAC, 250 VDC, 15 A, 65/25/18/10 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Type:

Molded Case, Thermal Magnetic, Main

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Used On:

I-Line Panelboard and Switchboard

Installation:

Plug-On

Trip Setting:

275 A Hold, 600 A Trip

Application:

Construction

Square D FH36100 Molded Case Breakers (MCCBs) EA

SKU:

C15-7174

Short Description:

240/480/600 VAC, 250 VDC, 100 A, 65/25/18/10 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Interrupting Rating:

18 kA at 600 VAC

Data Sheet:

SchneiderElectric-SquareD_04564_1_2_DATA.pdf

Type:

Molded Case, Thermal Magnetic, Main

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Series:

650, FH

Voltage Rating:

600 VAC, 250 VDC

Current Rating:

100 A

Number of Poles:

3

Trip Setting:

900 A Hold, 1700 A Trip

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Application:

Construction

Square D FHL26015 Molded Case Breakers (MCCBs)

SKU:

C15-16282

Type:

Thermal Magnetic

Series:

650, FHL

Prop 65 Warning:

Yes

Number of Poles:

2

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

18 kA at 600 VAC

Current Rating:

15 A

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Frame Type:

F

Terminal Type:

Lug

Short Description:

600 VAC, 250 VDC, 15 A, 18/50 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Data Sheet:

SchneiderElectric-SquareD_04569_1_2_DATA.pdf

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Square D FHL26040 Molded Case Breakers (MCCBs)

SKU:

C15-7173

Short Description:

600 VAC, 250 VDC, 40 A, 18/50 kA, 2-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

2

Current Rating:

40 A

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Interrupting Rating:

18 kA at 600 VAC

Size:

3 Inch Width x 4.13 Inch Depth x 6 Inch Height

Series:

650, FHL

Type:

Thermal Magnetic

Frame Type:

F

Data Sheet:

SchneiderElectric-SquareD_04570_1_2_DATA.pdf

Voltage Rating:

600 VAC, 250 VDC

Terminal Type:

Lug

Prop 65 Warning:

Yes

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Country of Origin:

Mexico

Square D FHL36000M Molded Case Breakers (MCCBs)

SKU:

S21-2325

Prop 65 Warning:

Yes

Voltage Rating:

600 VAC, 250 VDC

Frame Type:

FA/LA

Short Description:

600 VAC, 100 A, 25 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Automatic Molded Case Switch

Terminal Type:

Line and Load Lug

Interrupting Rating:

65 kA at 240 VAC, 18 kA at 600 VAC, 25 kA at 480 VAC, 10 kA at 250 VDC

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Type:

Molded Case, Thermal Magnetic

Current Rating:

100 A

Size:

4.5 Inch Width x 4.13 Inch Depth x 6.4 Inch Height

Data Sheet:

SchneiderElectric-SquareD_04571_1_2_DATA.pdf

Catalog:

SchneiderElectric-SquareD_00935_11_20_CAT.pdf

Number of Poles:

3

Approval:

UL, CSA

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

250 V

Square D FHL36045 Molded Case Breakers (MCCBs)

SKU:

C15-16291

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Series:

650, FHL

Interrupting Rating:

18 kA at 600 VAC

Terminal Type:

Lug

Current Rating:

45 A

Frame Type:

F

Voltage Rating:

600 VAC, 250 VDC

Type:

Thermal Magnetic

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Short Description:

600 VAC, 250 VDC, 45 A, 18/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Number of Poles:

3

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_04575_1_2_DATA.pdf

Square D FHL36050 Molded Case Breakers (MCCBs)

SKU:

C15-6427

Type:

Thermal Magnetic

Number of Poles:

3

Frame Type:

F

Interrupting Rating:

18 kA at 600 VAC

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Current Rating:

50 A

Voltage Rating:

600 VAC, 250 VDC

Data Sheet:

SchneiderElectric-SquareD_04576_1_2_DATA.pdf

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Short Description:

600 VAC, 250 VDC, 50 A, 18/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Terminal Type:

Lug

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Series:

FH

Prop 65 Warning:

Yes

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Country of Origin:

Mexico

Square D FHP36100 Molded Case Breakers (MCCBs)

SKU:

C15-16299

Short Description:

600 VAC, 250 VDC, 100 A, 18/10 kA, 3-Pole, F-Frame, Unit Mount, Thermal Magnetic, Molded Case Circuit Breaker

Prop 65 Warning:

Yes

Terminal Type:

OFF End Lug

Series:

FH

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Frame Type:

F

Voltage Rating:

600 VAC, 250 VDC

Interrupting Rating:

18 kA at 600 VAC

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Data Sheet:

SchneiderElectric-SquareD_04585_1_2_DATA.pdf

Current Rating:

100 A

Type:

Thermal Magnetic

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Number of Poles:

3

Catalog:

SchneiderElectric-SquareD_00096_5-9_17_23_CAT.pdf

Square D FI36020 Molded Case Breakers (MCCBs)

SKU:

C15-16300

Installation:

Plug-On

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

200 kA at 240/480 VAC, 100 kA at 600 VAC

Data Sheet:

SchneiderElectric-SquareD_04587_1_DATA.pdf

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Voltage Rating:

600 VAC, 250 VDC

Trip Setting:

275 A Hold, 600 A Trip

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Current Rating:

20 A

Number of Poles:

3

Prop 65 Warning:

Yes

Series:

650, FI

Short Description:

600 VAC, 250 VDC, 20 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Square D FI36040 Molded Case Breakers (MCCBs)

SKU:

C15-16302

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Current Rating:

40 A

Short Description:

600 VAC, 250 VDC, 40 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

3

Interrupting Rating:

200 kA at 240/480 VAC, 100 kA at 600 VAC

Voltage Rating:

600 VAC, 250 VDC

Prop 65 Warning:

Yes

Used On:

I-Line Panelboard and Switchboard

Type:

Molded Case, Thermal Magnetic, Main

Installation:

Plug-On

Approval:

UL 489, CSA, IEC

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Series:

650, FI

Data Sheet:

SchneiderElectric-SquareD_04589_1_DATA.pdf

Trip Setting:

400 A Hold, 850 A Trip

Square D FI36050 Molded Case Breakers (MCCBs)

SKU:

C15-16303

Short Description:

600 VAC, 250 VDC, 50 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Prop 65 Warning:

Yes

Voltage Rating:

600 VAC, 250 VDC

Used On:

I-Line Panelboard and Switchboard

Interrupting Rating:

200 kA at 240/480 VAC, 100 kA at 600 VAC

Current Rating:

50 A

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Approval:

UL 489, CSA, IEC

Trip Setting:

400 A Hold, 850 A Trip

Number of Poles:

3

Installation:

Plug-On

Series:

650, FI

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04590_1_DATA.pdf

Square D FI36060 Molded Case Breakers (MCCBs)

SKU:

C15-8572

Interrupting Rating:

200 kA at 240/480 VAC, 100 kA at 600 VAC

Number of Poles:

3

Prop 65 Warning:

Yes

Short Description:

600 VAC, 250 VDC, 60 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_04591_1_DATA.pdf

Trip Setting:

800 A Hold, 1450 A Trip

Used On:

I-Line Panelboard and Switchboard

Series:

650, FI

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Current Rating:

60 A

Installation:

Plug-On

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Square D FI36100 Molded Case Breakers (MCCBs)

SKU:

C15-16308

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Prop 65 Warning:

Yes

Current Rating:

100 A

Type:

Molded Case, Thermal Magnetic, Main

Approval:

UL 489, CSA, IEC

Short Description:

600 VAC, 250 VDC, 100 A, 100 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Number of Poles:

3

Interrupting Rating:

200 kA at 240/480 VAC, 100 kA at 600 VAC

Installation:

Plug-On

Voltage Rating:

600 VAC, 250 VDC

Series:

650, FI

Trip Setting:

900 A Hold, 1700 A Trip

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_04592_1_DATA.pdf

Used On:

I-Line Panelboard and Switchboard

Square D FIL36020 Molded Case Breakers (MCCBs)

SKU:

C15-16310

Short Description:

600 VAC, 250 VDC, 20 A, 100 kA, 3-Pole, F-Frame, Individually Mount, Thermal Magnetic, Molded Case Circuit Breaker

Current Rating:

20 A

Data Sheet:

SchneiderElectric-SquareD_04593_1_DATA.pdf

Frame Type:

F

Terminal Type:

Lug

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Interrupting Rating:

100 kA at 600 VAC

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Type:

Thermal Magnetic

Prop 65 Warning:

Yes

Series:

650, FIL

Number of Poles:

3

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Voltage Rating:

600 VAC, 250 VDC

Square D FIL36030 Molded Case Breakers (MCCBs)

SKU:

C15-16311

Data Sheet:

SchneiderElectric-SquareD_04594_1_DATA.pdf

Current Rating:

30 A

Voltage Rating:

600 VAC, 250 VDC

Catalog:

SchneiderElectric_00256_11_8_CAT.pdf

Prop 65 Warning:

Yes

Approval:

UL, CSA, IEC, Federal Specification W-C-375B/GEN

Number of Poles:

3

Type:

Thermal Magnetic

Installation/Operator:

SchneiderElectric-SquareD_00425_INST.pdf

Series:

650, FIL

Short Description:

600 VAC, 250 VDC, 30 A, 100 kA, 3-Pole, F-Frame, Individually Mount, Thermal Magnetic, Molded Case Circuit Breaker

Frame Type:

F

Interrupting Rating:

100 kA at 600 VAC

Size:

4.5 Inch Width x 4.13 Inch Depth x 6 Inch Height

Terminal Type:

Lug

Square D FIL36050 Molded Case Breakers (MCCBs)
