Circuit Breakers
Our selection of circuit breakers spans a wide range of applications, from heavy-duty air circuit breakers (ACBs) to compact miniature circuit breakers (MCBs). We offer leading brands like Eaton, Siemens, and Square D, known for their reliability and performance. Whatever your power management needs, you can find the perfect solution here at ARCA Supply.
-
Din Rail Mounted Circuit Breakers
-
Main Breakers
-
Miniature Circuit Breakers (MCBs)
-
Molded Case Breakers (MCCBs)
-
Motor Circuit Protector (MCPs)
-
Lug Terminal Kits
-
Auxiliary, Shunt, Trip Units and UVRs
-
Circuit Breaker Accessories
- Product
- Qty in Cart
- Price
-
Contact Us For Quote
Eaton FAZ-Z1.6/1 Miniature Circuit Breakers (MCBs) FAZ 1P 1.6A 277V 50/60Hz 1Ph
MSRP $165.00Surplus $43.96Eaton FAZ-Z1.6/1 Miniature Circuit Breakers (MCBs) FAZ 1P 1.6A 277V 50/60Hz 1Ph​ ARCA SKU: C15-3352 Brand: Eaton MPN: FAZ-Z1.6/1 UPC: 015082786193 Shipping Weight: 0.25 Shipping Height: 1...- SKU:
- C15-3352
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 1.6 A
- Interrupting Rating:
- 10 kA
- Mounting:
- DIN Rail
- Poles:
- 1
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Terminal Type:
- Line/Load
- Trip Setting:
- 2 to 3 x Rated Current
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Volts:
- 277/480 VAC
- Gauge:
- 18 to 4/18 to 8 AWG
- Short Description:
- 277/480 VAC 50/60 Hz, 1.6 A, 1-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- Wire Size:
- 18 to 4/18 to 8 AWG
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54377_1-9_DATA.pdf
- Number of Poles:
- 1
- Current Rating:
- 1.6 A
- Voltage Rating:
- 277/480 VAC
MSRP $165.00Surplus $43.96 -
Eaton FAZ-Z10/2 Miniature Circuit Breakers (MCBs) FAZ 2P 10A 277V 50/60Hz 1Ph
MSRP $272.00Surplus $23.46Eaton FAZ-Z10/2 Miniature Circuit Breakers (MCBs) FAZ 2P 10A 277V 50/60Hz 1Ph​ ARCA SKU: C15-3732 Brand: Eaton MPN: FAZ-Z10/2 UPC: 015082788241 Shipping Weight: 0.50 Shipping Height: 2.00...- SKU:
- C15-3732
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 2 to 3 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 10 A, 2-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54386_1-9_DATA.pdf
- Current Rating:
- 10 A
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 2
- Curve Type:
- Z
- Country of Origin:
- Germany
MSRP $272.00Surplus $23.46 -
Contact Us For Quote
Eaton FAZ-Z10/3 Din Rail Mounted Circuit Breakers
MSRP $436.05Surplus $156.98Eaton FAZ-Z10/3 Din Rail Mounted Circuit Breakers​ ARCA SKU: C15-5175 Brand: Eaton MPN: FAZ-Z10/3 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- C15-5175
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Current Rating:
- 10 A
- Number of Poles:
- 3
- Size:
- 0.69 Inch Length
- Interrupting Rating:
- 5 kA at 480 Star/277 VAC, 5 kA at 96 VDC (UL, CSA)
- Terminal Type:
- Screw
- Series:
- FAZ
- Type:
- Current Limiting, Thermal Magnetic
- Mounting:
- DIN Rail
- Voltage Rating:
- 480 VAC Star/277 VAC, 96 VDC (UL/CSA)
- Data Sheet:
- Eaton_56908_1-9_DATA.pdf
- Trip Setting:
- 2 to 3 x Rated Current
- Approval:
- UL 1077, CSA C22.2, CCC
- Short Description:
- 277/480 VAC 50/60 Hz, 10 A, 3-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
MSRP $436.05Surplus $156.98 -
Eaton FAZ-Z16/2 Miniature Circuit Breakers (MCBs) EA
MSRP $282.82Surplus $46.66Eaton FAZ-Z16/2 Miniature Circuit Breakers (MCBs) EA​ ARCA SKU: C15-9041 Brand: Eaton MPN: FAZ-Z16/2 UPC: 4015082788254 Shipping Weight: 0.55 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-9041
- Short Description:
- 277/480 VAC 50/60 Hz, 16 A, 2-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Voltage Rating:
- 277/480 VAC
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Series:
- FAZ
- Type:
- Thermal Magnetic
- Mounting:
- DIN Rail
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Number of Poles:
- 2
- Data Sheet:
- Eaton_54393_1-9_DATA.pdf
- Interrupting Rating:
- 10 kA
- Current Rating:
- 16 A
- Curve Type:
- Z
- Approval:
- UL 1077, UL (Canada and US), CSA C22.2, CE
- Country of Origin:
- Germany
- Trip Setting:
- 2 to 3 x Rated Current
MSRP $282.82Surplus $46.66 -
Contact Us For Quote
Eaton FAZ-Z2/1 Miniature Circuit Breakers (MCBs) FAZ 1P 2A 277V 50/60Hz 1Ph
MSRP $165.00Surplus $14.90Eaton FAZ-Z2/1 Miniature Circuit Breakers (MCBs) FAZ 1P 2A 277V 50/60Hz 1Ph​ ARCA SKU: C15-3955 Brand: Eaton MPN: FAZ-Z2/1 UPC: 015082786209 Shipping Weight: 0.25 Shipping Height: 1.00 In...- SKU:
- C15-3955
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 2 A
- Interrupting Rating:
- 10 kA
- Mounting:
- DIN Rail
- Poles:
- 1
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Terminal Type:
- Line/Load
- Trip Setting:
- 2 to 3 x Rated Current
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Volts:
- 277/480 VAC
- Gauge:
- 18 to 4/18 to 8 AWG
- Short Description:
- 277/480 VAC 50/60 Hz, 2 A, 1-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- Current Rating:
- 2 A
- Voltage Rating:
- 277/480 VAC
- Data Sheet:
- Eaton_54396_1-9_DATA.pdf
- Wire Size:
- 18 to 4/18 to 8 AWG
- Number of Poles:
- 1
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Country of Origin:
- Germany
MSRP $165.00Surplus $14.90 -
Eaton FAZ-Z20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph
MSRP $290.00Surplus $51.98Eaton FAZ-Z20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph​ ARCA SKU: C15-3198 Brand: Eaton MPN: FAZ-Z20/2 UPC: 015082788265 Shipping Weight: 0.55 Shipping Height: 2...- SKU:
- C15-3198
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 2 to 3 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 2-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54401_1-9_DATA.pdf
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Voltage Rating:
- 277/480 VAC
- Curve Type:
- Z
- Country of Origin:
- Germany
MSRP $290.00Surplus $51.98 -
Eaton FAZ-Z20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph
MSRP $460.00Surplus $81.10Eaton FAZ-Z20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph​ ARCA SKU: C15-2694 Brand: Eaton MPN: FAZ-Z20/3 UPC: 015082789286 Shipping Weight: 0.75 lbs. Shipping...- SKU:
- C15-2694
- TS PIK:
- 124503387
- Number of Poles:
- 3
- Mounting:
- DIN Rail
- Terminal Type:
- Screw
- Size:
- 2.09 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Interrupting Rating:
- 10 kA
- Type:
- Thermal Magnetic
- Data Sheet:
- Eaton_54402_1-9_DATA.pdf
- Wire Size:
- 18 to 4/18 to 8 AWG
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 3-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- Curve Type:
- Z
- Approval:
- UL 1077, UL (Canada and US), CSA C22.2, CE
- Country of Origin:
- Germany
- Trip Setting:
- 2 to 3 x Rated Current
MSRP $460.00Surplus $81.10 -
Eaton FAZ-Z32/3 Din Rail Mounted Circuit Breakers EA
MSRP $436.05Surplus $39.41Eaton FAZ-Z32/3 Din Rail Mounted Circuit Breakers EA​ ARCA SKU: C15-5176 Brand: Eaton MPN: FAZ-Z32/3 UPC: Shipping Weight: 0.85 Shipping Height: 3.00 In. Shipping Length: 3.00...- SKU:
- C15-5176
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 2.09 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 3
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 2 to 3 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 32 A, 3-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54414_1-9_DATA.pdf
- Current Rating:
- 32 A
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 3
- Curve Type:
- Z
- Country of Origin:
- Germany
MSRP $436.05Surplus $39.41 -
Contact Us For Quote
Eaton FAZ-Z4/1 Miniature Circuit Breakers (MCBs) FAZ 1P 4A 415V 50/60Hz 1Ph EA
MSRP $165.00Surplus $22.39Eaton FAZ-Z4/1 Miniature Circuit Breakers (MCBs) FAZ 1P 4A 415V 50/60Hz 1Ph EA​ ARCA SKU: C15-4074 Brand: Eaton MPN: FAZ-Z4/1 UPC: 4015082786229 Shipping Weight: 0.25 lbs. Shipping...- SKU:
- C15-4074
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 4 A
- Interrupting Rating:
- 10 kA
- Mounting:
- DIN Rail
- Poles:
- 1
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Terminal Type:
- Line/Load
- Trip Setting:
- 2 to 3 x Rated Current
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Volts:
- 277/480 VAC
- Gauge:
- 18 to 4/18 to 8 AWG
- Short Description:
- 277/480 VAC 50/60 Hz, 4 A, 1-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- TS PIK:
- 124503194
- Current Rating:
- 4 A
- Voltage Rating:
- 277/480 V
- Data Sheet:
- Eaton_54416_1-9_DATA.pdf
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Wire Size:
- 18 to 4/18 to 8 AWG
- Number of Poles:
- 1
- Country of Origin:
- Germany
MSRP $165.00Surplus $22.39 -
Eaton FAZ-Z50/2 Miniature Circuit Breakers (MCBs) FAZ 2P 50A 480V 50/60Hz 1Ph
MSRP $440.00Surplus $39.22Eaton FAZ-Z50/2 Miniature Circuit Breakers (MCBs) FAZ 2P 50A 480V 50/60Hz 1Ph​ ARCA SKU: C15-3329 Brand: Eaton MPN: FAZ-Z50/2 UPC: 015082788302 Shipping Weight: 0.60 Shipping Height: 1.00...- SKU:
- C15-3329
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 2 to 3 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 50 A, 2-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54425_1-9_DATA.pdf
- Current Rating:
- 50 A
- Number of Poles:
- 2
- Voltage Rating:
- 277/480 VAC
- Curve Type:
- Z
- Country of Origin:
- Germany
MSRP $440.00Surplus $39.22 -
Contact Us For Quote
Eaton FAZPLOFF Circuit Breaker Accessories EA
MSRP $85.00Surplus $15.50Eaton FAZPLOFF Circuit Breaker Accessories EA​ ARCA SKU: C15-2752 Brand: Eaton MPN: FAZPLOFF UPC: 786685759487 Shipping Weight: 0.10 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-2752
- Type:
- Lockoff Device
- Used On:
- DIN Rail Miniature Circuit Breaker
- Short Description:
- Lockoff Device for DIN Rail Miniature Circuit Breaker
- Specification/Technical:
- Eaton_19016_1_SPEC.pdf
- Catalog:
- Eaton_03771_V4T1_62_V4T1_72_V4T1_84_V4T1_96_V4T1_102_CAT.pdf
MSRP $85.00Surplus $15.50 -
Eaton FB3015 Molded Case Breakers (MCCBs)
MSRP $7,692.58Surplus $432.78SKU: C15-6774 Brand: Eaton MPN: FB3015 UPC: Shipping Weight: 4.35 lbs. Shipping Height: 5.00 In. Shipping Length: 9.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-6774
- Voltage Rating:
- 600 VAC 50/60 Hertz
- Terminal Type:
- Load
- Current Rating:
- 15 A
- Maximum AC Voltage Rating:
- 600 V
- Frame Type:
- F
- Type:
- Thermal Magnetic, Standard
- Number of Poles:
- 3
- Catalog:
- Eaton_03653_V12T3_2-V12T3_17_V12T3_119_CAT.pdf
- Approval:
- UL
MSRP $7,692.58Surplus $432.78 -
Eaton FB3015PL Molded Case Breakers (MCCBs) FB 3P 15A 600V 50/60Hz 3Ph F Frame EA
MSRP $7,111.00Surplus $371.60SKU: C15-5141 Brand: Eaton MPN: FB3015PL UPC: 786679765487 Shipping Weight: 6.55 lbs. Shipping Height: 7.00 In. Shipping Length: 11.00 In. Shipping Width: 7.00 In...- SKU:
- C15-5141
- Series:
- C
- Volts:
- 600 V
- Amps:
- 15 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FB, COMPLETE BREAK
- Country of Origin:
- Dominican Republic
MSRP $7,111.00Surplus $371.60 -
Eaton FCL3020L Molded Case Breakers (MCCBs) FCL 3P 20A 480V 50/60Hz 3Ph F Frame EA
MSRP $10,308.10Surplus $740.27SKU: C15-5028 Brand: Eaton MPN: FCL3020L UPC: Shipping Weight: 8.05 lbs. Shipping Height: 7.00 In. Shipping Length: 11.00 In. Shipping Width: 7.00 In. Product...- SKU:
- C15-5028
- Series:
- C
- Volts:
- 480 V
- Amps:
- 20 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON CLASSIC COMPLETE MOLDED CASE CIRCUIT BREAKER, FCL, COMPLETE BREAKER, THERM
- Country of Origin:
- United States
MSRP $10,308.10Surplus $740.27 -
Eaton FCL3025L Molded Case Breakers (MCCBs) FCL 3P 25A 480V 50/60Hz 3Ph F Frame EA
MSRP $10,308.10Surplus $980.71SKU: C15-5029 Brand: Eaton MPN: FCL3025L UPC: Shipping Weight: 8.05 lbs. Shipping Height: 7.00 In. Shipping Length: 11.00 In. Shipping Width: 7.00 In. Product...- SKU:
- C15-5029
- Series:
- C
- Volts:
- 480 V
- Amps:
- 25 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON CLASSIC COMPLETE MOLDED CASE CIRCUIT BREAKER, FCL, COMPLETE BREAKER, THERM
- Country of Origin:
- United States
MSRP $10,308.10Surplus $980.71 -
Eaton FCL3070L Molded Case Breakers (MCCBs) EA
MSRP $13,929.81Surplus $3,190.03SKU: C15-9503 Brand: Eaton MPN: FCL3070L UPC: 786679828724 Shipping Weight: 8.10 lbs. Shipping Height: 7.00 In. Shipping Length: 7.00 In. Shipping Width: 11.00 In...- SKU:
- C15-9503
- TS PIK:
- 21516604
- Short Description:
- EATON CLASSIC COMPLETE MOLDED CASE CIRCUIT BREAKER, FCL, COMPLETE BREAKER, THERM
- Country of Origin:
- United States
MSRP $13,929.81Surplus $3,190.03 -
Contact Us For Quote
Eaton FCWTK Circuit Breaker Accessories Control Wire Terminal Kit 150A 12EA
MSRP $2.40Surplus $1.23Eaton FCWTK Circuit Breaker Accessories Control Wire Terminal Kit 150A 12EA​ ARCA SKU: C15-2927 Brand: Eaton MPN: FCWTK UPC: 786679072943 Shipping Weight: 0.10 lbs. Shipping...- SKU:
- C15-2927
- Amps:
- 150 A
- Short Description:
- EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY MOTOR OPERATOR, CONTROL WIRE TERMINA
- TS PIK:
- 107000868
MSRP $2.40Surplus $1.23 -
Contact Us For Quote
Eaton FD1010 Molded Case Breakers (MCCBs)
MSRP $283.50Surplus $45.93SKU: C15-16187 Brand: Eaton MPN: FD1010 UPC: 78667931255 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16187
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $283.50Surplus $45.93 -
Contact Us For Quote
Eaton FD1010LB15 Molded Case Breakers (MCCBs)
MSRP $600.00Surplus $216.00SKU: C15-11729 Brand: Eaton MPN: FD1010LB15 UPC: Shipping Weight: 1.50 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00 In. Shipping Width: 4.00 In. Product...- SKU:
- C15-11729
MSRP $600.00Surplus $216.00 -
Contact Us For Quote
Eaton FD1015 Molded Case Breakers (MCCBs) EA
MSRP $609.49Surplus $71.64Eaton FD1015 Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-9257 Brand: Eaton MPN: FD1015 UPC: Shipping Weight: 1.65 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00...- SKU:
- C15-9257
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 15 A, 35/10 kA Interrupt, 1-Pole, FD Frame, Load Side Terminal, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Interrupting Rating:
- 35 kA at 277 VAC, 10 kA at 125 VDC (UL), 35 kA at 220/240VAC, 10 kA at 125 VDC (IEC)
- Current Rating:
- 15 A
- Number of Poles:
- 1
- Frame Type:
- FD
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Installation/Operator:
- EatonCorp_00023_INST.pdf
- Catalog:
- EatonCorp_00274_V4T2_259_V4T2_260_V4T2_278_V4T2_279_V4T2_285_V4T2_293_CAT.pdf
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic, Molded Case
- Maximum DC Voltage Rating:
- 125 V
- CAD Drawings:
- EatonCorp_00499_1_CAD.pdf
- Maximum AC Voltage Rating:
- 277 V
- Data Sheet:
- EatonCorp_00484_1-12_DATA.pdf
- Approval:
- UL 489, CSA C22.2
MSRP $609.49Surplus $71.64 -
Contact Us For Quote
Eaton FD1020V Molded Case Breaker
MSRP $1,400.00Surplus $630.00SKU: U00-5844 Brand: Eaton MPN: FD1020V UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- U00-5844
MSRP $1,400.00Surplus $630.00 -
Contact Us For Quote
Eaton FD1020V Other Circuit Breakers EA
MSRP $1,400.00Surplus $200.22SKU: C15-9371 Brand: Eaton MPN: FD1020V UPC: 120785706 Shipping Weight: 1.80 lbs. Shipping Height: 2.00 In. Shipping Length: 10.00 In. Shipping Width: 6.00 In...- SKU:
- C15-9371
- Installation/Operator:
- Eaton_00583_INST.pdf
- Maximum AC Voltage Rating:
- 277 V
- Type:
- Molded Case, Thermal Magnetic, Non-Interchangeable
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 20 A, 35 kA, 1-Pole, FD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker with 50 Deg C calibration
- Interrupting Rating:
- 35 kA at 277 VAC, 10 kA at 125 VDC (UL, IEC)
- Current Rating:
- 20 A
- Catalog:
- Eaton_46579_V4T2_254-V4T2_290_CAT.pdf
- Voltage Rating:
- 277 VAC, 125 VDC (UL, IEC)
- Frame Type:
- FD
- Number of Poles:
- 1
- Series:
- C, FD
- Size:
- 1.38 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum DC Voltage Rating:
- 125 V
- Approval:
- UL 489, CSA C22.2
- Country of Origin:
- United States
MSRP $1,400.00Surplus $200.22 -
Eaton FD1025 Molded Case Breakers (MCCBs) FD 1P 25A 277V 50/60Hz 1Ph F Frame EA
MSRP $646.00Surplus $114.08Eaton FD1025 Molded Case Breakers (MCCBs) FD 1P 25A 277V 50/60Hz 1Ph F Frame EA​ ARCA SKU: C15-3322 Brand: Eaton MPN: FD1025 UPC: 786679312124 Shipping Weight: 1.65 lbs. Shipping...- SKU:
- C15-3322
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 25 A
- Frame:
- FD
- Interrupting Rating:
- 35 kA at 277 VAC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (UL)
- Interrupting Rating:
- 35 Kiloamp at 220/240Volt AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (IEC)
- Maximum AC Voltage:
- 277 V
- Maximum DC Voltage:
- 125 V
- Poles:
- 1
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 277 VAC 50/60 Hertz
- Volts:
- 125 VDC
- TS PIK:
- 21509020
- Number of Poles:
- 1
- Frame Type:
- FD
- Current Rating:
- 25 A
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Maximum DC Voltage Rating:
- 125 V
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Maximum AC Voltage Rating:
- 277 V
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Country of Origin:
- Dominican Republic
MSRP $646.00Surplus $114.08 -
Contact Us For Quote
Eaton FD1025L Molded Case Breakers (MCCBs) FD 1P 25A 277V 50/60Hz 1Ph F Frame
MSRP $579.00Surplus $223.92SKU: C15-3830 Brand: Eaton MPN: FD1025L UPC: 786679093313 Shipping Weight: 1.70 lbs. Shipping Height: 2.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3830
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 25 A
- Frame:
- FD
- Interrupting Rating:
- 35 kA at 277 V AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (UL)
- Interrupting Rating:
- 35 Kiloamp at 220/240Volt AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (IEC)
- Maximum AC Voltage:
- 277 V
- Maximum DC Voltage:
- 125 V
- Poles:
- 1
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Terminal Type:
- Line and Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 277 VAC 50/60 Hertz
- Volts:
- 125 VDC
- TS PIK:
- 115575854
- Current Rating:
- 25 A
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Maximum AC Voltage Rating:
- 277 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Voltage Rating:
- 277 V AC 50/60 Hertz, 125 V DC
- Number of Poles:
- 1
- Maximum DC Voltage Rating:
- 125 V
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Frame Type:
- FD
MSRP $579.00Surplus $223.92 -
Contact Us For Quote
Eaton FD1035 Molded Case Breakers (MCCBs) FD 1P 35A 277V 50/60Hz 1Ph F Frame
MSRP $577.00Surplus $295.26Eaton FD1035 Molded Case Breakers (MCCBs) FD 1P 35A 277V 50/60Hz 1Ph F Frame​ ARCA SKU: C15-3221 Brand: Eaton MPN: FD1035 UPC: 786679312568 Shipping Weight: 1.60 lbs. Shipping...- SKU:
- C15-3221
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 35 A
- Frame:
- FD
- Interrupting Rating:
- 35 kA at 277 V AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (UL)
- Interrupting Rating:
- 35 Kiloamp at 220/240Volt AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (IEC)
- Maximum AC Voltage:
- 277 V
- Maximum DC Voltage:
- 125 V
- Poles:
- 1
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 277 VAC 50/60 Hertz
- Volts:
- 125 VDC
- TS PIK:
- 21509060
- Frame Type:
- FD
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Current Rating:
- 35 A
- Number of Poles:
- 1
- Voltage Rating:
- 277 V AC 50/60 Hertz, 125 V DC
- Maximum DC Voltage Rating:
- 125 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Maximum AC Voltage Rating:
- 277 V
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $577.00Surplus $295.26 -
Contact Us For Quote
Eaton FD1040 Molded Case Breakers (MCCBs) FD 1P 40A 277V 50/60Hz 1Ph F Frame
MSRP $275.00Surplus $384.37SKU: C15-4720 Brand: Eaton MPN: FD1040 UPC: Shipping Weight: 1.65 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-4720
- TS PIK:
- 21509022
- Current Rating:
- 40 A
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Type:
- Fixed Thermal Magnetic, Molded Case
- Number of Poles:
- 1
- Maximum DC Voltage Rating:
- 125 V
- Terminal Type:
- Load
- Installation/Operator:
- Eaton_00091_INST.pdf
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Frame Type:
- FD
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Maximum AC Voltage Rating:
- 277 V
- Interrupting Rating:
- 35 kA at 277 VAC, 10 kA at 125 VDC (UL), 35 kA at 220/240VAC, 10 kA at 125 VDC (IEC)
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Country of Origin:
- Dominican Republic
MSRP $275.00Surplus $384.37 -
Eaton FD1040L Molded Case Breakers (MCCBs) EA
MSRP $611.59Surplus $53.44Eaton FD1040L Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-9295 Brand: Eaton MPN: FD1040L UPC: 00786679398326 Shipping Weight: 1.70 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-9295
- Frame Type:
- F Frame
- Voltage Rating:
- 277
- Current Rating:
- 40
- Number of Poles:
- 1
- Interrupting Rating:
- 35kA@347V
- Short Description:
- 3 Pole thermal magnetic molded case circuit breaker with a current rating of 40 As and a Vage rating of 600VAC, 250VDC.
- Country of Origin:
- Dominican Republic
MSRP $611.59Surplus $53.44 -
Contact Us For Quote
Eaton FD1050 Molded Case Breakers (MCCBs) FD 1P 50A 277V 50/60Hz 1Ph F Frame
MSRP $577.00Surplus $418.60SKU: C15-1948 Brand: Eaton MPN: FD1050 UPC: 786679312155 Shipping Weight: 1.65 lbs. Shipping Height: 2.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1948
- Series:
- C, FD
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 1.38 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 277 VAC at 50/60 Hz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 1
- Interrupting Rating:
- 35 kA at 277 VAC
- Interrupting Rating:
- 10 Kiloampere at 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 277
- Maximum DC Voltage Rating:
- 125
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 50 A, 35/10 kA, 1-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Installation/Operator:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00116_INST.pdf
- CAD Drawing:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_04182_1_CAD.pdf
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Current Rating:
- 50 A
- Number of Poles:
- 1
- Data Sheet:
- Eaton_07831_1-5_DATA.pdf
- Voltage Rating:
- 277 VAC
MSRP $577.00Surplus $418.60 -
Contact Us For Quote
Eaton FD1060 Molded Case Breakers (MCCBs)
MSRP $823.63Surplus $296.50SKU: C15-9906 Brand: Eaton MPN: FD1060 UPC: 78667931216 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-9906
- TS PIK:
- 21509024
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Size:
- 1.38 Inch W x 3.38 Inch D x 6 Inch H
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Current Rating:
- 60 A
- Voltage Rating:
- 277 VAC at 50/60 Hz, 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Approval:
- UL
- Data Sheet:
- Eaton_07831_1-5_DATA.pdf
- Maximum AC Voltage Rating:
- 277
- Type:
- Molded Case, Thermal Magnetic
- Number of Poles:
- 1
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 60 A, 35/10 kA, 1-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Frame Type:
- FD
- Interrupting Rating:
- 35 kA at 277 VAC, 10 kA at 125 VDC
- Maximum DC Voltage Rating:
- 125
- Series:
- C, FD
MSRP $823.63Surplus $296.50 -
Contact Us For Quote
Eaton FD1110 Molded Case Breakers (MCCBs) FD 1P 110A 277V 50/60Hz 1Ph F Frame
MSRP $1,650.00Surplus $687.86SKU: C15-3631 Brand: Eaton MPN: FD1110 UPC: 786679312599 Shipping Weight: 1.60 lbs. Shipping Height: 2.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3631
- Series:
- C
- Volts:
- 277 V
- Amps:
- 110 A
- Poles:
- 1
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $1,650.00Surplus $687.86 -
Eaton FD1150 Molded Case Breakers (MCCBs) FD 1P 150A 277V 50/60Hz 1Ph F Frame Series C
MSRP $1,460.00Surplus $125.15SKU: C15-2678 Brand: Eaton MPN: FD1150 UPC: 786679312612 Shipping Weight: 1.65 lbs. Shipping Height: 2.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2678
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 150 A
- Frame:
- FD
- Interrupting Rating:
- 35 kA at 277 VAC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (UL)
- Interrupting Rating:
- 35 Kiloamp at 220/240Volt AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (IEC)
- Maximum AC Voltage:
- 277 V
- Maximum DC Voltage:
- 125 V
- Poles:
- 1
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 277 VAC 50/60 Hertz
- Volts:
- 125 VDC
- TS PIK:
- 21509064
- Installation/Operator:
- Eaton_00091_INST.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Maximum DC Voltage Rating:
- 125 V
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Number of Poles:
- 1
- Maximum AC Voltage Rating:
- 277 V
- Frame Type:
- FD
- CAD Drawings:
- Eaton_41226_1_CAD.pdf
- Current Rating:
- 150 A
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAkER, F-FRAME, FD, COMPLETE BREAk
- Series:
- C
- Country of Origin:
- Dominican Republic
MSRP $1,460.00Surplus $125.15 -
Contact Us For Quote
Eaton FD2015 Molded Case Breakers (MCCBs) FD 2P 15A 600V 50/60Hz 2Ph F Frame
MSRP $1,537.00Surplus $542.64SKU: C15-3382 Brand: Eaton MPN: FD2015 UPC: 786679312209 Shipping Weight: 2.75 lbs. Shipping Height: 5.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-3382
- Series:
- C, FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 35 kA at 480 VAC
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 15 A, 35/10 kA, 2-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_6_7_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21585_1_CAD.pdf
- Number of Poles:
- 2
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Current Rating:
- 15 A
- Country of Origin:
- Dominican Republic
MSRP $1,537.00Surplus $542.64 -
Contact Us For Quote
Eaton FD2020 Molded Case Breakers (MCCBs) FD 2P 20A 600V 50/60Hz 2Ph F Frame
MSRP $1,594.00Surplus $542.64SKU: C15-3426 Brand: Eaton MPN: FD2020 UPC: 786679312216 Shipping Weight: 2.75 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-3426
- Series:
- C, FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 600 VAC at 50/60 Hz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 35 kA at 480 VAC
- Interrupting Rating:
- 10 kA at 250 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600
- Maximum DC Voltage Rating:
- 250
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 20 A, 35/10 kA, 2-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_6_7_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21585_1_CAD.pdf
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Current Rating:
- 20 A
- Number of Poles:
- 2
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Country of Origin:
- Dominican Republic
MSRP $1,594.00Surplus $542.64 -
Eaton FD2020L Molded Case Breakers (MCCBs) 2P
MSRP $1,509.43Surplus $302.21SKU: C15-6777 Brand: Eaton MPN: FD2020L UPC: 78667985063 Shipping Weight: 3.15 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In...- SKU:
- C15-6777
- TS PIK:
- 21011302
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Type:
- Fixed Thermal Magnetic, Molded Case
- Current Rating:
- 20 A
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Number of Poles:
- 2
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Line and Load
- Frame Type:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VDC, 18 kA at 600 VAC, 10 kA at 250 VDC (UL), 65 kA at 220/240 VAC, 35 kA at 380/415/440 VDC, 18 kA at 500 VAC, 10 kA at 250 VDC (IEC)
- Country of Origin:
- Dominican Republic
- Approval:
- UL 489, CSA C22.2
MSRP $1,509.43Surplus $302.21 -
Contact Us For Quote
Eaton FD2025 Molded Case Breakers (MCCBs) FD 2P 25A 600V 50/60Hz 2Ph F Frame EA
MSRP $1,502.04Surplus $208.32SKU: C15-3432 Brand: Eaton MPN: FD2025 UPC: 786679312223 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3432
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 25 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 21509030
- Number of Poles:
- 2
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Frame Type:
- FD
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Current Rating:
- 25 A
- Maximum AC Voltage Rating:
- 600 V
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $1,502.04Surplus $208.32 -
Eaton FD2035 Molded Case Breakers (MCCBs) 2P 35A
MSRP $1,502.04Surplus $397.80SKU: C15-4829 Brand: Eaton MPN: FD2035 UPC: 78667931224 Shipping Weight: 2.95 lbs. Shipping Height: 6.00 In. Shipping Length: 8.00 In. Shipping Width: 4.00 In...- SKU:
- C15-4829
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 35 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 113291104
- Maximum DC Voltage Rating:
- 250 V
- Frame Type:
- FD
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 35 A
- Installation/Operator:
- Eaton_00091_INST.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Number of Poles:
- 2
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Series:
- C
- Country of Origin:
- Dominican Republic
MSRP $1,502.04Surplus $397.80 -
Contact Us For Quote
Eaton FD2040L Molded Case Breakers (MCCBs) 2P
MSRP $1,509.43Surplus $669.46SKU: C15-6776 Brand: Eaton MPN: FD2040L UPC: 78667985066 Shipping Weight: 3.15 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 8.00 In...- SKU:
- C15-6776
- TS PIK:
- 21011304
MSRP $1,509.43Surplus $669.46 -
Contact Us For Quote
Eaton FD2045 Molded Case Breakers (MCCBs)
MSRP $1,335.00Surplus $360.45SKU: C15-16188 Brand: Eaton MPN: FD2045 UPC: 78667931263 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16188
- Type:
- Fixed Thermal Magnetic, Molded Case
- Frame Type:
- FD
- Current Rating:
- 45 A
- Number of Poles:
- 2
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 45 A, 600 VAC, 250 VDC, 65 kAIC AT 240 VAC, 35 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Approval:
- UL 489, CSA C22.2
- Terminal Type:
- Load
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum AC Voltage Rating:
- 600 V
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VDC, 18 kA at 600 VAC, 10 kA at 250 VDC (UL), 65 kA at 220/240 VAC, 35 kA at 380/415/440 VDC, 18 kA at 500 VAC, 10 kA at 250 VDC (IEC)
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
MSRP $1,335.00Surplus $360.45 -
Contact Us For Quote
Eaton FD2050L Molded Case Breakers (MCCBs) FD 2P 50A 600V 50/60Hz 2Ph F Frame
MSRP $1,697.00Surplus $551.70SKU: C15-3954 Brand: Eaton MPN: FD2050L UPC: 786679850671 Shipping Weight: 3.15 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 4.00 In...- SKU:
- C15-3954
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 50 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 V AC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Line and Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 128145122
- Voltage Rating:
- 600 V AC 50/60 Hertz, 250 V DC
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 50 A
- Number of Poles:
- 2
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Frame Type:
- FD
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
MSRP $1,697.00Surplus $551.70 -
Contact Us For Quote
Eaton FD2070 Molded Case Breakers (MCCBs)
MSRP $1,909.00Surplus $611.80SKU: C15-3115 Brand: Eaton MPN: FD2070 UPC: 786679312285 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3115
- TS PIK:
- 21509036
- Terminal Type:
- Load
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Fixed Thermal Magnetic, Molded Case
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VDC, 18 kA at 600 VAC, 10 kA at 250 VDC (UL), 65 kA at 220/240 VAC, 35 kA at 380/415/440 VDC, 18 kA at 500 VAC, 10 kA at 250 VDC (IEC)
- Frame Type:
- FD
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Number of Poles:
- 2
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 70 A, 600 VAC, 250 VDC, LOAD SIDE, 50/60 HZ
- Current Rating:
- 70 A
- Maximum AC Voltage Rating:
- 600 V
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Approval:
- UL 489, CSA C22.2
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Country of Origin:
- Dominican Republic
MSRP $1,909.00Surplus $611.80 -
Contact Us For Quote
Eaton FD2090 Molded Case Breakers (MCCBs) FD 2P 90A 600V 50/60Hz 2Ph F Frame
MSRP $1,839.00Surplus $644.00SKU: C15-1800 Brand: Eaton MPN: FD2090 UPC: 786679312292 Shipping Weight: 2.65 lbs. Shipping Height: 5.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-1800
- Frame Type:
- F
- Voltage Rating:
- 600 VAC
- Current Rating:
- 32 A
- Number of Poles:
- 2
- Interrupting Rating:
- 35 kA at 480 VAC,10 kA at 250 VDC
- Type:
- Molded Case
- Maximum AC Voltage Rating:
- 600
- Maximum DC Voltage Rating:
- 250
- Terminal Type:
- Standard Pressure Load Terminal
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 35/10 kA, 2-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_6_7_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Series:
- C, FD
- Approval:
- UL
MSRP $1,839.00Surplus $644.00 -
Eaton FD2100-MOD Molded Case Breakers (MCCBs) EA
MSRP $1,733.37Surplus $360.34SKU: C15-9313 Brand: Eaton MPN: FD2100-MOD UPC: Shipping Weight: 2.95 lbs. Shipping Height: 5.00 In. Shipping Length: 3.00 In. Shipping Width: 7.00 In. Product...- SKU:
- C15-9313
- Frame Type:
- F
- Voltage Rating:
- 00 VAC, 250 VDC
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Two-pole, 100 A, 600 VAC, 250 VDC, Load side, 50/60 Hz
- Country of Origin:
- Dominican Republic
MSRP $1,733.37Surplus $360.34 -
Eaton FD2100L Molded Case Breakers (MCCBs) 2P
MSRP $1,998.00Surplus $342.16SKU: C15-4732 Brand: Eaton MPN: FD2100L UPC: 78667985071 Shipping Weight: 3.15 lbs. Shipping Height: 4.00 In. Shipping Length: 5.00 In. Shipping Width: 8.00 In...- SKU:
- C15-4732
- TS PIK:
- 121473822
- Maximum AC Voltage Rating:
- 600
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
- Type:
- Molded Case, Thermal Magnetic
- Maximum DC Voltage Rating:
- 250
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 2
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Frame Type:
- FD
- Data Sheet:
- Eaton_07831_1-3_6_7_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 2-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Series:
- C, FD
- Interrupting Rating:
- 35 kA at 480 VAC, 10 kA at 250 VDC
- Installation/Operator:
- Eaton_00091_INST.pdf
- Terminal Type:
- Standard Pressure Line and Load Terminal
- Country of Origin:
- Dominican Republic
- Approval:
- UL
MSRP $1,998.00Surplus $342.16 -
Contact Us For Quote
Eaton FD2110 Molded Case Breakers (MCCBs) FD 2P 110A 600V 50/60Hz 2Ph F Frame Series C
MSRP $3,670.00Surplus $1,103.20SKU: C15-2728 Brand: Eaton MPN: FD2110 UPC: 786679004357 Shipping Weight: 2.95 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In...- SKU:
- C15-2728
- Series:
- C
- Volts:
- 600 V
- Amps:
- 110 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $3,670.00Surplus $1,103.20 -
Contact Us For Quote
Eaton FD2125 Molded Case Breakers (MCCBs) FD 2P 125A 600V 50/60Hz 2Ph F Frame
MSRP $3,670.00Surplus $1,103.20SKU: C15-2757 Brand: Eaton MPN: FD2125 UPC: 786679312315 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2757
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 125 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 21509039
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Frame Type:
- FD
- Number of Poles:
- 2
- Current Rating:
- 125 A
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAkER, F-FRAME, FD, COMPLETE BREAk
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Series:
- C
MSRP $3,670.00Surplus $1,103.20 -
Contact Us For Quote
Eaton FD2125L Molded Case Breakers (MCCBs) 2P
MSRP $3,882.91Surplus $787.66SKU: C15-6778 Brand: Eaton MPN: FD2125L UPC: 78667985072 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-6778
- TS PIK:
- 107762127
- Frame Type:
- FD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VDC, 18 kA at 600 VAC, 10 kA at 250 VDC (UL), 65 kA at 220/240 VAC, 35 kA at 380/415/440 VDC, 18 kA at 500 VAC, 10 kA at 250 VDC (IEC)
- Terminal Type:
- Line and Load
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Current Rating:
- 125 A
- Type:
- Fixed Thermal Magnetic, Molded Case
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Number of Poles:
- 2
- Maximum AC Voltage Rating:
- 600 V
- Country of Origin:
- Dominican Republic
- Approval:
- UL 489, CSA C22.2
MSRP $3,882.91Surplus $787.66 -
Contact Us For Quote
Eaton FD2150 Molded Case Breakers (MCCBs)
MSRP $5,238.62Surplus $1,990.68SKU: C15-9907 Brand: Eaton MPN: FD2150 UPC: 78667931232 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-9907
- TS PIK:
- 21509040
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Frame Type:
- FD
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic
- Approval:
- UL
- Series:
- C, FD
- Interrupting Rating:
- 35 kA at 480 VAC, 10 kA at 250 VDC
- Number of Poles:
- 2
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 35/10 kA, 2-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Maximum DC Voltage Rating:
- 250
- Current Rating:
- 150 A
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Data Sheet:
- Eaton_07831_1-3_6_7_DATA.pdf
- Maximum AC Voltage Rating:
- 600
- Terminal Type:
- Standard Pressure Load Terminal
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
MSRP $5,238.62Surplus $1,990.68 -
Contact Us For Quote
Eaton FD2150L Molded Case Breakers (MCCBs) FD 2P 150A 600V 50/60Hz 2Ph F Frame
MSRP $3,451.00Surplus $1,082.37SKU: C15-2946 Brand: Eaton MPN: FD2150L UPC: 786679850732 Shipping Weight: 2.80 lbs. Shipping Height: 3.00 In. Shipping Length: 7.00 In. Shipping Width: 3.00 In...- SKU:
- C15-2946
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 150 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 V AC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Line and Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 107007497
- Number of Poles:
- 2
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Current Rating:
- 150 A
- Voltage Rating:
- 600 V AC 50/60 Hertz, 250 V DC
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
MSRP $3,451.00Surplus $1,082.37 -
Contact Us For Quote
Eaton FD2175 Molded Case Breakers (MCCBs)
MSRP $1,485.00Surplus $400.95SKU: C15-16189 Brand: Eaton MPN: FD2175 UPC: 78667901527 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16189
- Terminal Type:
- Load
- Number of Poles:
- 2
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VDC, 18 kA at 600 VAC, 10 kA at 250 VDC (UL), 65 kA at 220/240 VAC, 35 kA at 380/415/440 VDC, 18 kA at 500 VAC, 10 kA at 250 VDC (IEC)
- Approval:
- UL 489, CSA C22.2
- Maximum DC Voltage Rating:
- 250 V
- Current Rating:
- 175 A
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum AC Voltage Rating:
- 600 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 175 A, 600 VAC, 250 VDC, 65 kAIC AT 240 VAC, 35 kAIC AT 480 VAC
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Frame Type:
- FD
- Type:
- Fixed Thermal Magnetic, Molded Case
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
MSRP $1,485.00Surplus $400.95 -
Contact Us For Quote
Eaton FD2200S18 Molded Case Breakers (MCCBs) FD 2P 200A 600V 50/60Hz 2Ph F Frame
MSRP $4,553.18Surplus $775.54SKU: C15-1809 Brand: Eaton MPN: FD2200S18 UPC: Shipping Weight: 2.85 lbs. Shipping Height: 3.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In. Product...- SKU:
- C15-1809
- Frame Type:
- F
- Voltage Rating:
- 600 V
- Current Rating:
- 200 A
- Number of Poles:
- 2
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Two-pole
MSRP $4,553.18Surplus $775.54 -
Eaton FD2225SK Molded Case Breakers (MCCBs) EA
MSRP $1,696.00Surplus $145.82SKU: C15-9674 Brand: Eaton MPN: FD2225SK UPC: Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 8.00 In. Product...- SKU:
- C15-9674
- Interrupting Rating:
- 18 kA at 600 VAC, 10 kA at 250 VDC (UL, IEC)
- Installation/Operator:
- Eaton_00583_INST.pdf
- Current Rating:
- 225 A
- Number of Poles:
- 2
- Catalog:
- Eaton_46579_V4T2_254-V4T2_290_CAT.pdf
- Type:
- Molded Case, Thermal Magnetic, Non-Interchangeable
- Maximum AC Voltage Rating:
- 600 V
- Frame Type:
- FD
- Voltage Rating:
- 600 VAC, 250 VDC (UL, IEC)
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 225 A, 35 kA, 2-Pole, Stainless Steel Terminal, FD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker with High Magnetic Molded Case Switch
- Series:
- C, FD
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Country of Origin:
- Canada
- Approval:
- UL 489, CSA C22.2
MSRP $1,696.00Surplus $145.82 -
Contact Us For Quote
Eaton FD3015H08 Molded Case Breakers (MCCBs) FD 3P 15A 600V 50/60Hz 3Ph F Frame
MSRP $2,049.00Surplus $698.60SKU: C15-3705 Brand: Eaton MPN: FD3015H08 UPC: 786679082751 Shipping Weight: 4.35 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3705
- Approval:
- CSA C22.2
- Amps:
- 15 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 V AC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 3
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 115574249
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Number of Poles:
- 3
- Voltage Rating:
- 600 V AC 50/60 Hertz, 250 V DC
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Frame Type:
- FD
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
- Current Rating:
- 15 A
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
MSRP $2,049.00Surplus $698.60 -
Contact Us For Quote
Eaton FD3020L Molded Case Breakers (MCCBs) FD 3P 20A 600V 50/60Hz 3Ph F Frame
MSRP $1,770.33Surplus $686.38SKU: C15-4972 Brand: Eaton MPN: FD3020L UPC: 78667930563 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-4972
- TS PIK:
- 21332216
MSRP $1,770.33Surplus $686.38 -
Contact Us For Quote
Eaton FD3025 Molded Case Breakers (MCCBs) FD 3P 25A 600V 50/60Hz 3Ph F Frame Thermal Magnetic
MSRP $1,761.89Surplus $798.00SKU: C15-4057 Brand: Eaton MPN: FD3025 UPC: 78667930564 Shipping Weight: 4.00 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 6.00 In...- SKU:
- C15-4057
- Frame Type:
- FD
- Voltage Rating:
- 600 VAC, 250 VDC
- Current Rating:
- 25 A
- Number of Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 10 kA at 250 VDC
- Type:
- Molded Case Thermal Magnetic
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Standard Pressure Load
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole, 25 A, 600 Vac, 250 Vdc, Load side, 50/60 Hz
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Installation/Operator:
- Eaton_07831_1-3_8_9_DATA.pdf
- Specification/Technical:
- Eaton_00091_INST.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Series:
- C
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Approval:
- UL 489, CSA C22.2
MSRP $1,761.89Surplus $798.00 -
Eaton FD3030 Molded Case Breakers (MCCBs)
MSRP $1,800.00Surplus $314.81SKU: C15-1811 Brand: Eaton MPN: FD3030 UPC: 786679305652 Shipping Weight: 4.05 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1811
- TS PIK:
- 21508833
- Series:
- C, FD
- Type:
- Molded Case, Fixed Thermal Magnetic
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Number of Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 30 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Frame Type:
- F
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Approval:
- UL 489, CSA C22.2
- Current Rating:
- 30 A
- Country of Origin:
- Dominican Republic
MSRP $1,800.00Surplus $314.81 -
Contact Us For Quote
Eaton FD3030BP10 Molded Case Breakers (MCCBs) EA
MSRP $2,266.73Surplus $703.34SKU: C15-9330 Brand: Eaton MPN: FD3030BP10 UPC: 78668502078 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-9330
- TS PIK:
- 121693906
MSRP $2,266.73Surplus $703.34 -
Contact Us For Quote
Eaton FD3035 Molded Case Breakers (MCCBs) FD 3P 35A 600V 50/60Hz 3Ph F Frame
MSRP $1,761.89Surplus $263.92SKU: C15-4973 Brand: Eaton MPN: FD3035 UPC: 78667930557 Shipping Weight: 4.50 lbs. Shipping Height: 6.00 In. Shipping Length: 4.13 In. Shipping Width: 3.38 In...- SKU:
- C15-4973
- Country of Origin:
- Dominican Republic
- Series:
- C, FD
- Current Rating:
- 35 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 35 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Frame Type:
- FD
- Installation/Operator:
- Eaton_00091_INST.pdf
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Type:
- Molded Case, Thermal Magnetic
- Terminal Type:
- Standard Pressure Load
- Number of Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 10 kA at 250 VDC
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Approval:
- UL 489, CSA C22.2
MSRP $1,761.89Surplus $263.92 -
Contact Us For Quote
Eaton FD3050 Molded Case Breakers (MCCBs) EA
MSRP $1,761.89Surplus $543.72SKU: C15-8978 Brand: Eaton MPN: FD3050 UPC: 78667930569 Shipping Weight: 4.00 lbs. Shipping Height: 4.00 In. Shipping Length: 5.00 In. Shipping Width: 6.00 In...- SKU:
- C15-8978
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Series:
- C
- Frame Type:
- FD
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC, 250 VDC
- Type:
- Molded Case, Thermal Magnetic
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Current Rating:
- 50 A
- Terminal Type:
- Standard Pressure Load
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 50 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Maximum AC Voltage Rating:
- 600 V
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 10 kA at 250 VDC
- Installation/Operator:
- Eaton_00091_INST.pdf
MSRP $1,761.89Surplus $543.72 -
Contact Us For Quote
Eaton FD3060B Molded Case Breakers (MCCBs) EA
MSRP $1,677.38Surplus $603.86SKU: C15-8985 Brand: Eaton MPN: FD3060B UPC: Shipping Weight: 4.00 lbs. Shipping Height: 6.00 In. Shipping Length: 5.00 In. Shipping Width: 4.00 In. Product...- SKU:
- C15-8985
MSRP $1,677.38Surplus $603.86 -
Contact Us For Quote
Eaton FD3070BP10 Molded Case Breakers (MCCBs) FD 3P 70A 600V 50/60Hz 3Ph F Frame
MSRP $1,758.00Surplus $790.00SKU: C15-2969 Brand: Eaton MPN: FD3070BP10 UPC: 786685020839 Shipping Weight: 4.05 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2969
- TS PIK:
- 121693911
MSRP $1,758.00Surplus $790.00 -
Eaton FD3080 Molded Case Breakers (MCCBs) FD 3P 80A 600V 50/60Hz 3Ph F Frame
MSRP $1,758.00Surplus $503.03SKU: C15-1813 Brand: Eaton MPN: FD3080 UPC: 786679305744 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1813
- Series:
- C, FD
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 80 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Installation/Operator:
- Leviton_00504_INST.pdf
- Current Rating:
- 80 A
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Type:
- Molded Case, Thermal Magnetic
- Country of Origin:
- Dominican Republic
MSRP $1,758.00Surplus $503.03 -
Contact Us For Quote
Eaton FD3090 Molded Case Breakers (MCCBs)
MSRP $1,978.43Surplus $764.46SKU: C15-4987 Brand: Eaton MPN: FD3090 UPC: 78667930575 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-4987
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Series:
- C, FD
- Type:
- Molded Case, Fixed Thermal Magnetic
- Frame Type:
- F
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Maximum AC Voltage Rating:
- 600 V
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 3
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Current Rating:
- 90 A
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Country of Origin:
- Dominican Republic
- TS PIK:
- 21260403
- Approval:
- UL 489, CSA C22.2
MSRP $1,978.43Surplus $764.46 -
Contact Us For Quote
Eaton FD3090L Molded Case Breakers (MCCBs) 3P 90A 50/60Hz 3Ph EA
MSRP $1,987.94Surplus $859.59SKU: U00-3196 Brand: Eaton MPN: FD3090L UPC: 78667915650 Shipping Weight: 4.70 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- U00-3196
- Maximum AC Voltage Rating:
- 600
- Terminal Type:
- Standard Pressure Line and Load Terminal
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Maximum DC Voltage Rating:
- 250
- Series:
- C, FD
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Interrupting Rating:
- 35 kA at 480 VAC, 10 kA at 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 35/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Installation/Operator:
- Eaton_00091_INST.pdf
- Frame Type:
- FD
- Current Rating:
- 90 A
- Size:
- 4.13 Inch W x 3.38 Inch D x 6 Inch H
- Type:
- Molded Case, Thermal Magnetic
MSRP $1,987.94Surplus $859.59 -
Contact Us For Quote
Eaton FD3090S22 Molded Case Breakers (MCCBs)
MSRP $3,680.00Surplus $993.60SKU: C15-16190 Brand: Eaton MPN: FD3090S22 UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16190
MSRP $3,680.00Surplus $993.60 -
Eaton FD3100 Molded Case Breakers (MCCBs) FD 3P 100A 600V 50/60Hz 3Ph F Frame EA
MSRP $1,900.00Surplus $364.90SKU: C15-2599 Brand: Eaton MPN: FD3100 UPC: 786685020860 Shipping Weight: 3.80 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 4.00 In...- SKU:
- C15-2599
- TS PIK:
- 121693914
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Current Rating:
- 100 A
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Series:
- C, FD
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Maximum DC Voltage Rating:
- 250 VDC
- Installation/Operator:
- Eaton_00091_INST.pdf
- Terminal Type:
- Load Side
- Type:
- Fixed Thermal, Fixed Magnetic, Molded Case
- Size:
- 3.38 Inch Length x 4.13 Inch Width x 4.13 Inch Height
- Frame Type:
- F
- Interrupting Rating:
- 65 kA at 240 VAC, 35 kA at 480 VAC
- Number of Poles:
- 3
- Maximum AC Voltage Rating:
- 600 VAC
- Country of Origin:
- Dominican Republic
- Approval:
- UL
MSRP $1,900.00Surplus $364.90 -
Contact Us For Quote
Eaton FD3100BP10 Molded Case Breakers (MCCBs)
MSRP $1,785.00Surplus $578.34SKU: C15-12020 Brand: Eaton MPN: FD3100BP10 UPC: Shipping Weight: 1.00 lbs. Shipping Height: 4.00 In. Shipping Length: 4.00 In. Shipping Width: 6.00 In. Product...- SKU:
- C15-12020
MSRP $1,785.00Surplus $578.34 -
Contact Us For Quote
Eaton FD3100K Molded Case Breakers (MCCBs) FD 3P 100A 600V 50/60Hz 3Ph F Frame
MSRP $1,283.00Surplus $840.00SKU: C15-2737 Brand: Eaton MPN: FD3100K UPC: 786679306192 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2737
- Series:
- C, FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 1087
- Size:
- 4.13 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 600 VAC at 50/60 Hz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 35 kA at 480 VAC
- Interrupting Rating:
- 10 kA at 250 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600
- Maximum DC Voltage Rating:
- 250
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 3-Pole, Load Side Terminal, FD Frame, Molded Case Switch
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Current Rating:
- 100 A
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Number of Poles:
- 3
MSRP $1,283.00Surplus $840.00 -
Contact Us For Quote
Eaton FD3100L Molded Case Breakers (MCCBs)
MSRP $1,987.94Surplus $604.80SKU: C15-2325 Brand: Eaton MPN: FD3100L UPC: 78667930577 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2325
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 kA at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Line and Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 21508845
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC, 250 VDC
- Current Rating:
- 100 A
- Country of Origin:
- Dominican Republic
MSRP $1,987.94Surplus $604.80 -
Eaton FD3125 Molded Case Breakers (MCCBs) FD 3P 125A 600V 50/60Hz 3Ph F Frame EA
MSRP $3,957.00Surplus $639.54SKU: C15-1440 Brand: Eaton MPN: FD3125 UPC: 786679305782 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1440
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 kA at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 21508846
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC
- Current Rating:
- 125 A
- Country of Origin:
- Dominican Republic
MSRP $3,957.00Surplus $639.54 -
Eaton FD3125J01 Molded Case Breakers (MCCBs) FD 3P 125A 600V 50/60Hz 3Ph F Frame EA
MSRP $5,344.82Surplus $446.06SKU: C15-4947 Brand: Eaton MPN: FD3125J01 UPC: 78211349100 Shipping Weight: 4.30 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-4947
- Series:
- C
- Volts:
- 600 V
- Amps:
- 125 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, FIXED THERMAL,
- Country of Origin:
- Dominican Republic
MSRP $5,344.82Surplus $446.06 -
Eaton FD3150K Molded Case Breakers (MCCBs)
MSRP $4,687.00Surplus $376.53SKU: C15-11304 Brand: Eaton MPN: FD3150K UPC: 78667930620 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-11304
- TS PIK:
- 21508887
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 35/10 kA, 3-Pole, Load Side Terminal, FD Frame, Molded Case Switch, Non-Interchangeable Trip Circuit Breaker
- Number of Poles:
- 3
- Series:
- C, FD
- Frame Type:
- FD
- Current Rating:
- 150 A
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Maximum AC Voltage Rating:
- 600
- Size:
- 4.13 Inch W x 3.38 Inch D x 6 Inch H
- Terminal Type:
- Standard Pressure Load Terminal
- Installation/Operator:
- Eaton_00091_INST.pdf
- Interrupting Rating:
- 35 kA at 480 VAC, 10 kA at 250 VDC
- Voltage Rating:
- 600 VAC at 50/60 Hz, 250 VDC
- Maximum DC Voltage Rating:
- 250
- Type:
- Molded Case, Thermal Magnetic
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Country of Origin:
- Dominican Republic
- Approval:
- UL 1087
MSRP $4,687.00Surplus $376.53 -
Contact Us For Quote
Eaton FD3150KL Molded Case Breakers (MCCBs) FD 3P 150A 600V 50/60Hz 3Ph F Frame
MSRP $3,550.00Surplus $1,282.21SKU: C15-3895 Brand: Eaton MPN: FD3150KL UPC: 786679450260 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3895
- Series:
- C
- Volts:
- 600 V
- Amps:
- 150 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C MOLDED CASE SWITCH, F-FRAME, FD, MOLDED CASE SWITCH, FIXED THERMA
MSRP $3,550.00Surplus $1,282.21 -
Contact Us For Quote
Eaton FD3175LA01S19 Molded Case Breakers (MCCBs) FD 3P 175A 600V 50/60Hz 3Ph F Frame
MSRP $375.00Surplus $123.53Eaton FD3175LA01S19 Molded Case Breakers (MCCBs) FD 3P 175A 600V 50/60Hz 3Ph F Frame​ ARCA SKU: C15-4369 Brand: Eaton MPN: FD3175LA01S19 UPC: Shipping Weight: 4.25 Shipping Height: 4.00...- SKU:
- C15-4369
- Frame Type:
- F
- Voltage Rating:
- 600 V
- Current Rating:
- 175 A
- Number of Poles:
- 3
- Short Description:
- FD 3P 175A 600V 50/60Hz 3Ph F Frame
MSRP $375.00Surplus $123.53 -
Contact Us For Quote
Eaton FD3200L Molded Case Breakers (MCCBs) FD 3P 200A 600V 50/60Hz 3Ph F Frame
MSRP $3,963.00Surplus $1,442.97SKU: C15-1799 Brand: Eaton MPN: FD3200L UPC: 786679015407 Shipping Weight: 5.00 lbs. Shipping Height: 5.00 In. Shipping Length: 7.50 In. Shipping Width: 5.00 In...- SKU:
- C15-1799
- Frame Type:
- F
- Voltage Rating:
- 600 VAC
- Current Rating:
- 32 A
- Number of Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC ,35 kA at 480 VAC ,18 kA at 600 VAC ,10 kA at 250 VDC
- Type:
- Thermal Magnetic
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Standard Pressure Line and Load
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 200 A, 35/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Series:
- C, FD
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
MSRP $3,963.00Surplus $1,442.97 -
Contact Us For Quote
Eaton FD3200S Molded Case Breakers (MCCBs)
MSRP $5,352.00Surplus $1,445.04SKU: C15-16191 Brand: Eaton MPN: FD3200S UPC: 62103707442 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16191
- Catalog:
- Eaton_46579_V4T2_254-V4T2_290_CAT.pdf
- Voltage Rating:
- 600 VAC, 250 VDC (UL, IEC)
- Interrupting Rating:
- 18 kA at 600 VAC, 10 kA at 250 VDC (UL, IEC)
- Installation/Operator:
- Eaton_00583_INST.pdf
- Maximum DC Voltage Rating:
- 250 V
- Type:
- Molded Case, Thermal Magnetic, Non-Interchangeable
- Maximum AC Voltage Rating:
- 600 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 200 A, 35 kA, 3-Pole, Stainless Steel Terminal, FD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker
- Frame Type:
- FD
- Series:
- C, FD
- Current Rating:
- 200 A
- Number of Poles:
- 3
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Approval:
- UL 489, CSA C22.2
MSRP $5,352.00Surplus $1,445.04 -
Eaton FD3225 Molded Case Breakers (MCCBs) FD 3P 225A 600V 50/60Hz 3Ph F Frame EA
MSRP $3,957.00Surplus $923.34SKU: C15-3102 Brand: Eaton MPN: FD3225 UPC: 786685020921 Shipping Weight: 4.10 lbs. Shipping Height: 6.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3102
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 225 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 3
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Specification/Technical:
- Eaton_61921_1_2_SPEC.pdf
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Frame Type:
- FD
- Short Description:
- SERIES C, F-FRAME MOLDED CASE CIRCUIT BREAKER, 10 BULK PACK, 225A, THREE-POLE, T
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 3
- Maximum AC Voltage Rating:
- 600 V
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 225 A
- TS PIK:
- 121693920
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Series:
- FD
- Country of Origin:
- Dominican Republic
MSRP $3,957.00Surplus $923.34 -
Contact Us For Quote
Eaton FD3225D19Z05 Molded Case Breakers (MCCBs) FD 3P 225A 600V 50/60Hz 3Ph F Frame
MSRP $3,957.00Surplus $797.79SKU: C15-1814 Brand: Eaton MPN: FD3225D19Z05 UPC: Shipping Weight: 4.05 lbs. Shipping Height: 3.00 In. Shipping Length: 6.00 In. Shipping Width: 4.00 In. Product...- SKU:
- C15-1814
- Frame Type:
- F
- Voltage Rating:
- 600 V
- Current Rating:
- 225 A
- Number of Poles:
- 3
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, FD, Complete breaker, Fixed thermal, Fixed magnetic trip type, Three-pole
MSRP $3,957.00Surplus $797.79 -
Contact Us For Quote
Eaton FD3225L Molded Case Breakers (MCCBs) FD 3P 225A 600V 50/60Hz 3Ph F Frame
MSRP $3,963.00Surplus $1,470.27SKU: C15-1688 Brand: Eaton MPN: FD3225L UPC: 786679015391 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1688
- Series:
- C, FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 4.13 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 600 VAC at 50/60 Hz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 35 kA at 480 VAC
- Interrupting Rating:
- 10 kA at 250 VDC
- Terminal Type:
- Standard Pressure Line and Load Terminal
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600
- Maximum DC Voltage Rating:
- 250
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 225 A, 35/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Current Rating:
- 225 A
MSRP $3,963.00Surplus $1,470.27 -
Contact Us For Quote
Eaton FD4175ELA03S21 Molded Case Breakers (MCCBs) FD 4P 175A 600V 50/60Hz 3Ph F Frame
MSRP $7,166.00Surplus $3,072.22SKU: C15-1934 Brand: Eaton MPN: FD4175ELA03S21 UPC: 786679138847 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 5.00 In. Shipping Width: 5.00...- SKU:
- C15-1934
- Series:
- C
- Volts:
- 600 V
- Amps:
- 175 A
- Poles:
- 4
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, FIXED THERMAL
- Frame Type:
- F
MSRP $7,166.00Surplus $3,072.22 -
Contact Us For Quote
Eaton FD4225L Molded Case Breakers (MCCBs)
MSRP $2,886.00Surplus $779.22SKU: C15-16192 Brand: Eaton MPN: FD4225L UPC: 78667901551 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16192
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FD, COMPLETE BREAK
MSRP $2,886.00Surplus $779.22 -
Contact Us For Quote
Eaton FDB2010 Molded Case Breakers (MCCBs) EA
MSRP $1,180.00Surplus $188.33SKU: C15-9651 Brand: Eaton MPN: FDB2010 UPC: 78667939942 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-9651
- TS PIK:
- 21510791
- Country of Origin:
- Dominican Republic
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREA
MSRP $1,180.00Surplus $188.33 -
Contact Us For Quote
Eaton FDB2015 Molded Case Breakers (MCCBs)
MSRP $770.00Surplus $207.90SKU: C15-16199 Brand: Eaton MPN: FDB2015 UPC: 78667931236 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16199
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 15A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $770.00Surplus $207.90 -
Eaton FDB2020 Molded Case Breakers (MCCBs) FDB 2P 20A 600V 50/60Hz 2Ph F Frame
MSRP $774.00Surplus $585.20SKU: C15-3988 Brand: Eaton MPN: FDB2020 UPC: 786679312377 Shipping Weight: 2.75 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-3988
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 20 A
- Frame:
- FD
- Interrupting Rating:
- 18 kA at 240 VAC
- Interrupting Rating:
- 14 Kiloamp at 480/600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 18 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 14 Kiloamp at 380/415/440/500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 21509804
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- Eaton_21587_1_CAD.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREA
- Frame Type:
- FD
- Country of Origin:
- United States
MSRP $774.00Surplus $585.20 -
Contact Us For Quote
Eaton FDB2025 Molded Case Breakers (MCCBs)
MSRP $760.00Surplus $205.20SKU: C15-16200 Brand: Eaton MPN: FDB2025 UPC: 78667931238 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16200
- Short Description:
- FDB BREAKER 2P 25A
MSRP $760.00Surplus $205.20 -
Contact Us For Quote
Eaton FDB2030 Molded Case Breakers (MCCBs)
MSRP $1,177.63Surplus $447.50SKU: C15-9908 Brand: Eaton MPN: FDB2030 UPC: 78667931239 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-9908
- TS PIK:
- 21509044
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 30A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $1,177.63Surplus $447.50 -
Contact Us For Quote
Eaton FDB2035 Molded Case Breakers (MCCBs)
MSRP $700.00Surplus $189.00SKU: C15-16201 Brand: Eaton MPN: FDB2035 UPC: 78667931240 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16201
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 35A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $700.00Surplus $189.00 -
Contact Us For Quote
Eaton FDB2040 Molded Case Breakers (MCCBs)
MSRP $880.00Surplus $585.20SKU: U00-8088 Brand: Eaton MPN: FDB2040 UPC: 78667931241 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- U00-8088
- Short Description:
- FDB BREAKER 2P 40A
MSRP $880.00Surplus $585.20 -
Contact Us For Quote
Eaton FDB2045 Molded Case Breakers (MCCBs)
MSRP $464.00Surplus $125.28SKU: C15-16202 Brand: Eaton MPN: FDB2045 UPC: 78667931249 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16202
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 45A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $464.00Surplus $125.28 -
Contact Us For Quote
Eaton FDB2050 Molded Case Breakers (MCCBs)
MSRP $1,580.00Surplus $426.60SKU: C15-16203 Brand: Eaton MPN: FDB2050 UPC: 78667931242 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16203
- Short Description:
- FDB BREAKER 2P 50A
MSRP $1,580.00Surplus $426.60 -
Contact Us For Quote
Eaton FDB2060 Molded Case Breakers (MCCBs)
MSRP $760.00Surplus $205.20SKU: C15-16204 Brand: Eaton MPN: FDB2060 UPC: 78667931243 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16204
- Short Description:
- FDB BREAKER 2P 60A
MSRP $760.00Surplus $205.20 -
Contact Us For Quote
Eaton FDB2060D01F01V4 Molded Case Breakers (MCCBs) FDB 2P 60A 600V 50/60Hz 2Ph F Frame Series C
MSRP $2,395.00Surplus $556.71SKU: C15-2558 Brand: Eaton MPN: FDB2060D01F01V4 UPC: Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-2558
- Frame Type:
- F
- Voltage Rating:
- 600 V
- Current Rating:
- 60 A
- Number of Poles:
- 2
- Interrupting Rating:
- 18 kA at 240 Vac, 14 kA at 480 Va
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, FDB, Complete breaker, Fixed thermal, fixed magnetic trip type, Two-pole, 60A, 600 Vac, 250 Vdc, 18 kA at 240 Vac, 14 kA at 480 Vac
MSRP $2,395.00Surplus $556.71 -
Contact Us For Quote
Eaton FDB2070 Molded Case Breakers (MCCBs)
MSRP $892.50Surplus $240.97SKU: C15-16205 Brand: Eaton MPN: FDB2070 UPC: 78667931244 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16205
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 70A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $892.50Surplus $240.97 -
Contact Us For Quote
Eaton FDB2080 Molded Case Breakers (MCCBs)
MSRP $892.50Surplus $240.97SKU: C15-16206 Brand: Eaton MPN: FDB2080 UPC: 78667903247 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16206
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 80A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $892.50Surplus $240.97 -
Contact Us For Quote
Eaton FDB2090 Molded Case Breakers (MCCBs)
MSRP $892.50Surplus $240.97SKU: C15-16207 Brand: Eaton MPN: FDB2090 UPC: 78667931245 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16207
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 90A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $892.50Surplus $240.97 -
Contact Us For Quote
Eaton FDB2110 Molded Case Breakers (MCCBs)
MSRP $3,951.00Surplus $1,066.77SKU: C15-16208 Brand: Eaton MPN: FDB2110 UPC: 78667939922 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16208
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 110A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
MSRP $3,951.00Surplus $1,066.77 -
Contact Us For Quote
Eaton FDB2125 Molded Case Breakers (MCCBs)
MSRP $1,218.00Surplus $328.86SKU: C15-16209 Brand: Eaton MPN: FDB2125 UPC: 78667931247 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16209
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Approval:
- UL 489, CSA C22.2
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Interrupting Rating:
- 18 kA at 240 V AC, 14 kA at 480/600 V AC, 10 kA at 250 V DC (UL), 18 kA at 220/240 V AC, 14 kA at 380/415/440/500 V AC, 10 kA at 250 V DC (IEC)
- Type:
- Fixed Thermal Magnetic, Molded Case
- Installation/Operator:
- Eaton_00091_INST.pdf
- Maximum DC Voltage Rating:
- 250 V
- Frame Type:
- FD
- Size:
- 2.75 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Current Rating:
- 125 A
- Terminal Type:
- Load
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, TWO-POLE, 125A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
- CAD Drawings:
- Eaton_21587_1_CAD.pdf
- Number of Poles:
- 2
- Maximum AC Voltage Rating:
- 600 V
MSRP $1,218.00Surplus $328.86 -
Contact Us For Quote
Eaton FDB2150 Molded Case Breakers (MCCBs) FDB 2P 150A 600V 50/60Hz 2Ph F Frame
MSRP $2,371.00Surplus $997.50SKU: C15-3162 Brand: Eaton MPN: FDB2150 UPC: 786679312483 Shipping Weight: 3.00 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In...- SKU:
- C15-3162
- Series:
- C
- Volts:
- 600 V
- Amps:
- 150 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREA
MSRP $2,371.00Surplus $997.50 -
Eaton FDB3020L Molded Case Breakers (MCCBs) 3P 20A
MSRP $1,155.58Surplus $207.98SKU: C15-6783 Brand: Eaton MPN: FDB3020L UPC: 78667930585 Shipping Weight: 4.60 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-6783
- TS PIK:
- 120033803
- Maximum AC Voltage Rating:
- 600 V
- Data Sheet:
- Eaton_07831_1-3_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Frame Type:
- FD
- Number of Poles:
- 3
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Interrupting Rating:
- 18 kA at 240 VAC, 14 kA at 480/600 VAC, 10 kA at 250 VDC
- Series:
- C, FDB
- Voltage Rating:
- 600 VAC, 250 VDC
- Type:
- Molded Case, Thermal Magnetic
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 20 A, 14/10 kA, 3-Pole, Line and Load Terminal, FD Frame, Thermal Magnetic, Molded Case, Non-Interchangeable Trip Circuit Breaker
- Terminal Type:
- Standard Pressure Line and Load
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Current Rating:
- 20 A
- Country of Origin:
- Dominican Republic
- Approval:
- UL 489, CSA C22.2
MSRP $1,155.58Surplus $207.98 -
Contact Us For Quote
Eaton FDB3025 Molded Case Breakers (MCCBs)
MSRP $820.80Surplus $221.62SKU: C15-16210 Brand: Eaton MPN: FDB3025 UPC: 78667930586 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16210
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Frame Type:
- FD
- Installation/Operator:
- Eaton_00091_INST.pdf
- Size:
- 4.13 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Interrupting Rating:
- 18 kA at 240 VAC, 14 kA at 480/600 VAC, 10 kA at 250 VDC (UL), 18 kA at 220/240 VAC, 14 kA at 380/415/440/500 VAC, 10 kA at 250 VDC (IEC)
- Type:
- Fixed Thermal Magnetic, Molded Case
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Current Rating:
- 25 A
- Number of Poles:
- 3
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREAKER, FIXED THERMAL, FIXED MAGNETIC TRIP TYPE, THREE-POLE, 25A, 600 VAC, 250 VDC, 18 kAIC AT 240 VAC, 14 kAIC AT 480 VAC, LOAD SIDE, 50/60 HZ
- Maximum AC Voltage Rating:
- 600 V
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Terminal Type:
- Load
- Approval:
- UL 489, CSA C22.2
MSRP $820.80Surplus $221.62 -
Contact Us For Quote
Eaton FDB3025L Molded Case Breakers (MCCBs) FDB 3P 25A 600V 50/60Hz 3Ph F Frame
MSRP $1,311.00Surplus $128.58SKU: C15-4746 Brand: Eaton MPN: FDB3025L UPC: Shipping Weight: 4.60 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-4746
- Series:
- C
- Volts:
- 600 V
- Amps:
- 25 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, FDB, COMPLETE BREA
- Country of Origin:
- Dominican Republic
MSRP $1,311.00Surplus $128.58
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
