Din Rail Mounted Circuit Breakers
A DIN rail mounted circuit breaker is a type of circuit breaker that is designed to be mounted on a standardized DIN rail, which is a common mounting platform used in electrical control panels and cabinets. The DIN rail provides a convenient and standardized method of mounting and organizing circuit breakers, and is widely used in industrial and commercial applications.
- Product
- Qty in Cart
- Price
-
Eaton QC1020 Miniature Circuit Breakers (MCBs) 1P 20A 240V EA
MSRP $119.00Surplus $19.64Eaton QC1020 Miniature Circuit Breakers (MCBs) 1P 20A 240V EA​ ARCA SKU: C15-1641 Brand: Eaton MPN: QC1020 UPC: 78667930888 Shipping Weight: 0.30 lbs. Shipping Height: 4.00 In...- SKU:
- C15-1641
- Series:
- QC
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA
- Volts:
- 120/240 VAC
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- Cable-In/Cable-Out
- Interrupting Rating:
- 10000 A at 120/240 VAC
- Interrupting Rating:
- 5000 Amp at 24 to 48 Volt DC
- Interrupting Rating:
- 3800 Amp at 62.5 Volt DC
- Terminal Type:
- Ring
- Wire Size:
- 14 to 10 AWG Copper/Aluminum (Load)
- Short Description:
- 120/240 VAC, 20 A, 10 kA, 1-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature
- Catalog:
- Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf
- TS PIK:
- 21508934
- Number of Poles:
- 1
- Voltage Rating:
- 120/240 VAC
- Current Rating:
- 20 A
- Country of Origin:
- Dominican Republic
MSRP $119.00Surplus $19.64 -
Eaton FAZ-C20/1-NA-SP Din Rail Mounted Circuit Breakers 1P 20A 277V EA
MSRP $229.83Surplus $24.57Eaton FAZ-C20/1-NA-SP Din Rail Mounted Circuit Breakers 1P 20A 277V EA​ ARCA SKU: C15-3822 Brand: Eaton MPN: FAZ-C20/1-NA-SP UPC: 4015081636365 Shipping Weight: 0.30 lbs. Shipping...- SKU:
- C15-3822
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 0.7 Inch Width x 3.15 Inch Height
- Volts:
- 277 VAC 50/60 Hertz
- Volts:
- 48 VDC (UL/CSA)
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 48 Volt DC (UL
- Interrupting Rating:
- 14 kA (UL
- Terminal Type:
- Screw
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole, 10/14 kA, 5 to 10 x Rated Current, Screw Terminal, DIN Rail Mount, Single Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- TS PIK:
- 124653168
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Voltage Rating:
- 277/480 VAC
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $229.83Surplus $24.57 -
Eaton FAZ-D20/3-NA Miniature Circuit Breakers (MCBs) 3P 20A 480V EA
MSRP $635.62Surplus $152.11Eaton FAZ-D20/3-NA Miniature Circuit Breakers (MCBs) 3P 20A 480V EA​ ARCA SKU: C15-2766 Brand: Eaton MPN: FAZ-D20/3-NA UPC: 4015081021475 Shipping Weight: 0.90 lbs. Shipping...- SKU:
- C15-2766
- Series:
- FAZ
- Type:
- Non-Fusible
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 2.09 Inch Width x 3.15 Inch Height
- Volts:
- 277/480 VAC at 50/60 Hertz
- Volts:
- 96 VDC
- Amps:
- 32 A
- Poles:
- 3
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 Kiloamp at 96 Volt DC (UL
- Interrupting Rating:
- 14 Kiloamp (UL
- Terminal Type:
- Screw
- Trip Setting:
- 10 to 20 x Rated Current
- Short Description:
- 277/480 VAC, 96 VDC, 20 A, 10 kA, 10 to 20 x Rated Current, 3-Pole, Screw Terminal, DIN Rail Mount, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47_V4T1_48_V4T1_53_V4T1_66-V4T1_68_V4T1_70_V4T1_72_CAT.pdf
- CAD Drawing:
- Eaton_41246_1_CAD.pdf
- TS PIK:
- 124501573
- Wire Size:
- 18 to 6 AWG (1-Wire), 18 to 10 AWG (2-Wire)
- Data Sheet:
- Eaton_40775_1-5_DATA.pdf
- Current Rating:
- 20 A
- Voltage Rating:
- 270/480 VAC
- Used On:
- Motor, Transformer, Other High Inductive System
- Number of Poles:
- 3
- Curve Type:
- D
- Country of Origin:
- Germany
MSRP $635.62Surplus $152.11 -
Eaton QCR2020HT Miniature Circuit Breakers (MCBs) QCR 2P 20A 240V 50/60Hz 1Ph
MSRP $585.36Surplus $325.34Eaton QCR2020HT Miniature Circuit Breakers (MCBs) QCR 2P 20A 240V 50/60Hz 1Ph​ ARCA SKU: C15-3429 Brand: Eaton MPN: QCR2020HT UPC: 782114225851 Shipping Weight: 0.50 lbs. Shipping...- SKU:
- C15-3429
- Type:
- Thermal Magnetic
- Approval:
- UL
- Approval:
- CSA
- Size:
- 5.75 Inch Length x 2 Inch Width x 3.5 Inch Height
- Volts:
- 240 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail Rear
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Ring/Spade Lug
- Short Description:
- 240 VAC, 20 A, 2-Pole, 10 kA, Ring/Spade Lug Terminal, DIN Rail Rear Mount, Cable-In/Cable-Out, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_23_V4T1_24_CAT.pdf
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Voltage Rating:
- 240 VAC
- Country of Origin:
- Dominican Republic
MSRP $585.36Surplus $325.34 -
Eaton QCR1020 Miniature Circuit Breakers (MCBs) 1P 20A EA
MSRP $108.90Surplus $34.51Eaton QCR1020 Miniature Circuit Breakers (MCBs) 1P 20A EA​ ARCA SKU: C15-1629 Brand: Eaton MPN: QCR1020 UPC: 10786679144067 Shipping Weight: 0.30 lbs. Shipping Height: 2.00 In...- SKU:
- C15-1629
- Series:
- QC
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA
- Volts:
- 120/240 VAC
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Mounting:
- Cable-In
- Mounting:
- Cable-Out
- Interrupting Rating:
- 10000 A at 120/240 VAC
- Interrupting Rating:
- 3000 Ampere at 24 to 48 VDC
- Interrupting Rating:
- 2000 Ampere at 62.5 VDC
- Terminal Type:
- Box Lug
- Wire Size:
- 14 to 4 AWG (Aluminum/Copper)
- Short Description:
- 120/240 VAC, 20 A, 10 kA, 1-Pole, Box Lug Terminal, Cable-In/Out, 35 MM DIN Rail Rear Mount, Thermal Magnetic, Miniature
- Catalog:
- Eaton_03771_V4T1_23_V4T1_24_CAT.pdf
- TS PIK:
- 110575155
- Voltage Rating:
- 120/240 VAC
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Country of Origin:
- Dominican Republic
MSRP $108.90Surplus $34.51 -
Eaton FAZ-C20/1-NA-L Miniature Circuit Breakers (MCBs) FAZ 1P 20A 120/240V 50/60Hz 1Ph EA
MSRP $85.39Surplus $16.91Eaton FAZ-C20/1-NA-L Miniature Circuit Breakers (MCBs) FAZ 1P 20A 120/240V 50/60Hz 1Ph EA​ ARCA SKU: C15-5055 Brand: Eaton MPN: FAZ-C20/1-NA-L UPC: 9008790868788 Shipping Weight: 0.35 lbs...- SKU:
- C15-5055
- Short Description:
- FAZ-NA UL 489 MCB 240VAC 1P 20A C CURVE
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Mounting:
- DIN Rail
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $85.39Surplus $16.91 -
Eaton FAZ-C20/1N Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph
MSRP $225.98Surplus $18.46Eaton FAZ-C20/1N Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph​ ARCA SKU: C15-2845 Brand: Eaton MPN: FAZ-C20/1N UPC: 015082786759 Shipping Weight: 0.45 Shipping Height: 2...- SKU:
- C15-2845
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 1+N
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole+ Neutral, 10 kA, 5 to 10 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_53889_1-9_DATA.pdf
- Voltage Rating:
- 270/480 VAC
- Number of Poles:
- 1+Neutral
- Current Rating:
- 20 A
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $225.98Surplus $18.46 -
Eaton FAZ-C20/3-NA Din Rail Mounted Circuit Breakers EA
MSRP $869.87Surplus $138.77Eaton FAZ-C20/3-NA Din Rail Mounted Circuit Breakers EA​ ARCA SKU: C15-5048 Brand: Eaton MPN: FAZ-C20/3-NA UPC: 4015081021277 Shipping Weight: 0.85 lbs. Shipping Height: 3.00 In...- SKU:
- C15-5048
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 2.09 Inch Width x 3.15 Inch Height
- Volts:
- 277/480 VAC at 50/60 Hertz
- Volts:
- 96 VDC
- Amps:
- 32 A
- Poles:
- 3
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 96 Volt DC (UL
- Interrupting Rating:
- 14 kA (UL
- Terminal Type:
- Screw
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 3-Pole, 10/14 kA, 5 to 10 x Rated Current, Screw Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- Data Sheet:
- Eaton_56871_1-5_DATA.pdf
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Number of Poles:
- 3
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $869.87Surplus $138.77 -
Eaton QCGFEP1020 Miniature Circuit Breakers (MCBs) QCGF 1P 20A 240V 50/60Hz 1Ph
MSRP $1,252.40Surplus $320.18Eaton QCGFEP1020 Miniature Circuit Breakers (MCBs) QCGF 1P 20A 240V 50/60Hz 1Ph​ ARCA SKU: C15-1618 Brand: Eaton MPN: QCGFEP1020 UPC: 786679146552 Shipping Weight: 0.50 Shipping Height: 2...- SKU:
- C15-1618
- Type:
- Front Mount
- Approval:
- UL
- Approval:
- CSA
- Size:
- 3.3 Inch Width x 5.2 Inch Depth x 1.3 Inch Height
- Volts:
- 120 VAC
- Amps:
- 32 A
- Poles:
- 1
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Cable-In/Cable-Out
- Trip Sensitivity:
- 30 MilliA
- Short Description:
- 120 VAC, 20 A, 1-Pole, 10 kA, Non-Interchangeable Trip, Cable-In/Cable-Out, Equipment Protector, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_28_CAT.pdf
- Manufacturer Warranty:
- Eaton_00013_WARR.pdf
- Current Rating:
- 20 A
- Number of Poles:
- 1
- Voltage Rating:
- 120 VAC
- Country of Origin:
- Dominican Republic
MSRP $1,252.40Surplus $320.18 -
Eaton FAZ-B20/1-NA Din Rail Mounted Circuit Breakers FAZ 1P 20A 277V 50/60Hz 1Ph EA
MSRP $197.39Surplus $17.21Eaton FAZ-B20/1-NA Din Rail Mounted Circuit Breakers FAZ 1P 20A 277V 50/60Hz 1Ph EA​ ARCA SKU: C15-4200 Brand: Eaton MPN: FAZ-B20/1-NA UPC: 015081296365 Shipping Weight: 0.30 lbs. Shipping...- SKU:
- C15-4200
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 0.7 Inch Width x 3.15 Inch Height
- Volts:
- 277 VAC at 50/60 Hertz
- Volts:
- 48 VDC (UL/CSA)
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 48 Volt DC (UL
- Interrupting Rating:
- 14 kA (UL
- Terminal Type:
- Screw
- Trip Setting:
- 3 to 5 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole, 10/14 kA, 3 to 5 x Rated Current, Screw Terminal, DIN Rail Mount, Standard Packaging, B-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- Data Sheet:
- Eaton_56859_1-3_DATA.pdf
- TS PIK:
- 124610178
- Current Rating:
- 20 A
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 1
- Curve Type:
- B
- Country of Origin:
- Germany
MSRP $197.39Surplus $17.21 -
Eaton FAZ-D20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph
MSRP $496.87Surplus $49.88Eaton FAZ-D20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph​ ARCA SKU: C15-4055 Brand: Eaton MPN: FAZ-D20/3 UPC: 015082788975 Shipping Weight: 0.85 Shipping Height: 2.00...- SKU:
- C15-4055
- Series:
- FAZ
- Approval:
- UL 1077
- Approval:
- CSA C22.2
- Size:
- 2.07 Inch L
- Amps:
- 32 A
- Poles:
- 3
- Mounting:
- DIN Rail
- Terminal Type:
- Screw
- Trip Setting:
- 10 to 20 x Rated Current (Magnetic)
- Short Description:
- 480 VAC Star/277 VAC, 96 VDC, 20 A, 15 kA, 10 to 20 x Rated Current, 3-Pole, Screw Terminal, DIN Rail Mount
- Catalog:
- Eaton_03771_V4T1_74_V4T1_75_V4T1_78_V4T1_85_V4T1_86_V4T1_88_V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_40774_1-9_DATA.pdf
- Installation/Operator:
- Eaton_00479_INST.pdf
- Number of Poles:
- 3
- Current Rating:
- 20 A
- Curve Type:
- D
- Country of Origin:
- Germany
MSRP $496.87Surplus $49.88 -
Crouse-Hinds QC1020D Miniature Circuit Breakers (MCBs) QC 1P 20A 50/60Hz 1Ph EA
MSRP $150.89Surplus $34.01Crouse-Hinds QC1020D Miniature Circuit Breakers (MCBs) QC 1P 20A 50/60Hz 1Ph EA​ ARCA SKU: C15-5587 Brand: Crouse-Hinds MPN: QC1020D UPC: 786679153215 Shipping Weight: 0.25 lbs. Shipping...- SKU:
- C15-5587
- TS PIK:
- 21505552
- Short Description:
- EATON QUICKLAG TYPE QC INDUSTRIAL THERMAL-MAGNETIC CIRCUIT BREAKER,INDUSTRIAL CI
- Country of Origin:
- Dominican Republic
- Series:
- QA
- Interrupting Rating:
- 10 kA
- Current Rating:
- 20 A
- Number of Poles:
- 1
- Voltage Rating:
- 120/240 VAC
- Type:
- Thermal Magnetic
MSRP $150.89Surplus $34.01 -
Crouse-Hinds QC2020 Miniature Circuit Breakers (MCBs) QC 2P 20A 50/60Hz 3Ph EA
MSRP $344.41Surplus $50.16Crouse-Hinds QC2020 Miniature Circuit Breakers (MCBs) QC 2P 20A 50/60Hz 3Ph EA​ ARCA SKU: C15-5539 Brand: Crouse-Hinds MPN: QC2020 UPC: 786679309377 Shipping Weight: 0.60 lbs. Shipping...- SKU:
- C15-5539
- TS PIK:
- 21508957
- Voltage Rating:
- 120/240 VAC
- Terminal Type:
- Ring
- Series:
- QC
- Short Description:
- 120/240 VAC, 20 A, 10 kA, 2-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature, Circuit Breaker
- Mounting:
- Cable-In, Cable Out
- Number of Poles:
- 2
- Current Rating:
- 20 A
- Wire Size:
- 14 to 10 AWG Aluminum/Copper (Load)
- Catalog:
- Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf
- Interrupting Rating:
- 10000 A at 120/240 VAC, 5000 A at 24 to 48/62.5/80 VDC
- Type:
- Thermal Magnetic
- Country of Origin:
- Dominican Republic
- Approval:
- UL 489, CSA
MSRP $344.41Surplus $50.16 -
Cutler-Hammer QCGF1020 Din Rail Mounted Circuit Breakers EA
MSRP $367.69Surplus $54.70Cutler-Hammer QCGF1020 Din Rail Mounted Circuit Breakers EA​ ARCA SKU: C15-11196 Brand: Cutler-Hammer MPN: QCGF1020 UPC: 78667914605 Shipping Weight: 0.55 lbs. Shipping Height: 2.00...- SKU:
- C15-11196
- TS PIK:
- 106998265
- Country of Origin:
- Dominican Republic
- Short Description:
- 120 VAC, 20 A, 10 kA, 5 mA Trip Level, 1-Pole, Aluminum Lug Line Terminal, Cable-In/Out Mount, Thermal Magnetic, Circuit Protector, Ground Fault Circuit Breaker
- Voltage Rating:
- 120 VAC
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Approval:
- UL 489, CSA
- Terminal Type:
- Aluminum Lug Line Terminal
- Wire Size:
- 14 to 4 AWG Aluminum/Copper (Load)
- Mounting:
- Cable In/Cable Out
- Catalog:
- Eaton_00073_V9T1_23_CAT.pdf
- Interrupting Rating:
- 10 kA
- Type:
- Thermal Magnetic, Circuit Protector
- Trip Sensitivity:
- 5 MilliA
MSRP $367.69Surplus $54.70 -
Eaton FAZ-B20/1-RT Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph EA
MSRP $251.84Surplus $42.64Eaton FAZ-B20/1-RT Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph EA​ ARCA SKU: C15-4132 Brand: Eaton MPN: FAZ-B20/1-RT UPC: 015081296938 Shipping Weight: 0.55 lbs. Shipping...- SKU:
- C15-4132
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 4.13 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 3 to 5 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole, 10/14 kA, 3 to 5 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Standard Packaging, B-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- Data Sheet:
- Eaton_53644_1_2_DATA.pdf
- TS PIK:
- 124493258
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Curve Type:
- B
- Country of Origin:
- Germany
MSRP $251.84Surplus $42.64 -
Eaton FAZ-C20/1-RT-SP Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph EA
MSRP $197.39Surplus $28.29Eaton FAZ-C20/1-RT-SP Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph EA​ ARCA SKU: C15-3569 Brand: Eaton MPN: FAZ-C20/1-RT-SP UPC: 015081637205 Shipping Weight: 0.30 lbs...- SKU:
- C15-3569
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 4.13 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Ring Tongue
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole, 10/14 kA, 5 to 10 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Single Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- TS PIK:
- 124825476
- Current Rating:
- 20 A
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 1
- Country of Origin:
- Germany
MSRP $197.39Surplus $28.29 -
Eaton FAZ-C20/1-SP Din Rail Mounted Circuit Breakers
MSRP $158.21Surplus $30.11Eaton FAZ-C20/1-SP Din Rail Mounted Circuit Breakers​ ARCA SKU: C15-3173 Brand: Eaton MPN: FAZ-C20/1-SP UPC: 15081637645 Shipping Weight: 0.25 lbs. Shipping Height: 1.00 In...- SKU:
- C15-3173
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 0.7 Inch Width x 3.15 Inch Height
- Volts:
- 277 VAC at 50/60 Hertz
- Volts:
- 48 VDC (UL/CSA)
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 48 Volt DC (UL
- Interrupting Rating:
- CSA)
- Terminal Type:
- Screw
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC, 48 VDC, 20 A, 15 kA Interrupt Rating, 5 to 10 x Rated Current, 1-Pole, Screw Terminal, DIN Rail Mount, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74_V4T1_75_V4T1_77_V4T1_85_V4T1_86_V4T1_88_V4T1_92_CAT.pdf
- TS PIK:
- 124653295
- Current Rating:
- 20 A
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 1
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $158.21Surplus $30.11 -
Eaton FAZ-C20/2-RT Din Rail Mounted Circuit Breakers
MSRP $428.41Surplus $33.28Eaton FAZ-C20/2-RT Din Rail Mounted Circuit Breakers​ ARCA SKU: C15-5201 Brand: Eaton MPN: FAZ-C20/2-RT UPC: 4015081020874 Shipping Weight: 0.55 lbs. Shipping Height: 2.00 In...- SKU:
- C15-5201
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 1.39 Inch Width x 2.36 Inch Depth x 4.13 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 2-Pole, 10/14 kA, 5 to 10 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47-V4T1_72_CAT.pdf
- Data Sheet:
- Eaton_53895_1-5_DATA.pdf
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $428.41Surplus $33.28 -
Eaton FAZ-C20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 400V 50/60Hz 3Ph EA
MSRP $496.87Surplus $87.99Eaton FAZ-C20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 400V 50/60Hz 3Ph EA​ ARCA SKU: C15-3984 Brand: Eaton MPN: FAZ-C20/3 UPC: 015082788746 Shipping Weight: 0.75 lbs. Shipping...- SKU:
- C15-3984
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 2.09 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 3
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 5 to 10 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 3-Pole, 10 kA, 5 to 10 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_53896_1-9_DATA.pdf
- TS PIK:
- 127691537
- Number of Poles:
- 3
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Curve Type:
- C
- Country of Origin:
- Germany
MSRP $496.87Surplus $87.99 -
Eaton FAZ-D20/1-NA-SP Miniature Circuit Breakers (MCBs) 1P 20A 277V EA
MSRP $200.11Surplus $34.33Eaton FAZ-D20/1-NA-SP Miniature Circuit Breakers (MCBs) 1P 20A 277V EA​ ARCA SKU: C15-2631 Brand: Eaton MPN: FAZ-D20/1-NA-SP UPC: 015081636734 Shipping Weight: 0.30 lbs. Shipping...- SKU:
- C15-2631
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 0.7 Inch Width x 3.15 Inch Height
- Volts:
- 277 VAC at 50/60 Hertz
- Volts:
- 48 VDC (UL/CSA)
- Amps:
- 32 A
- Poles:
- 1
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 48 Volt DC (UL
- Interrupting Rating:
- 14 kA (UL
- Terminal Type:
- Screw
- Trip Setting:
- 10 to 20 x Rated Current
- Short Description:
- 277 VAC, 48 VDC, 20 A, 10 kA Interrupt Rating, 10 to 20 x Rated Current, 1-Pole, Screw Terminal, DIN Rail Mount, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47_V4T1_48_V4T1_53_V4T1_66-V4T1_68_V4T1_70_V4T1_72_CAT.pdf
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Number of Poles:
- 1
- Curve Type:
- D
- Country of Origin:
- Germany
MSRP $200.11Surplus $34.33 -
Eaton FAZ-D20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph EA
MSRP $353.94Surplus $27.38Eaton FAZ-D20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph EA​ ARCA SKU: C15-3511 Brand: Eaton MPN: FAZ-D20/2 UPC: 015082787848 Shipping Weight: 0.55 lbs. Shipping...- SKU:
- C15-3511
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Line/Load
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 10 to 20 x Rated Current
- Short Description:
- 480 VAC Star/277 VAC, 96 VDC, 20 A, 15 kA, 10 to 20 x Rated Current, 2-Pole, Screw Terminal, DIN Rail Mount, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74_V4T1_75_V4T1_78_V4T1_85_V4T1_86_V4T1_88_V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_40772_1-9_DATA.pdf
- Installation/Operator:
- Eaton_00479_INST.pdf
- Voltage Rating:
- 277/480 V
- Current Rating:
- 20 A
- Number of Poles:
- 2
- TS PIK:
- 124503273
- Country of Origin:
- Germany
MSRP $353.94Surplus $27.38 -
Eaton FAZ-D20/2-NA Miniature Circuit Breakers (MCBs) FAZ 2P 20A 277V 50/60Hz EA
MSRP $427.00Surplus $41.55Eaton FAZ-D20/2-NA Miniature Circuit Breakers (MCBs) FAZ 2P 20A 277V 50/60Hz EA​ ARCA SKU: C15-3855 Brand: Eaton MPN: FAZ-D20/2-NA UPC: 015081020670 Shipping Weight: 0.60 lbs. Shipping...- SKU:
- C15-3855
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CCC
- Size:
- 1.4 Inch Width x 3.15 Inch Height
- Volts:
- 277/480 VAC at 50/60 Hertz
- Volts:
- 96 VDC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Interrupting Rating:
- 10 kA at 96 Volt DC (UL
- Interrupting Rating:
- 14 kA (UL
- Terminal Type:
- Screw
- Trip Setting:
- 10 to 20 x Rated Current
- Short Description:
- 277/480 VAC, 96 VDC, 20 A, 10 kA, 10 to 20 x Rated Current, 2-Pole, Screw Terminal, DIN Rail Mount, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_47_V4T1_48_V4T1_53_V4T1_66-V4T1_68_V4T1_70_V4T1_72_CAT.pdf
- Data Sheet:
- Eaton_40773_1-5_DATA.pdf
- Installation/Operator:
- Eaton_00480_INST.pdf
- TS PIK:
- 124501493
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 2
- Current Rating:
- 20 A
- Curve Type:
- D
- Country of Origin:
- Germany
MSRP $427.00Surplus $41.55 -
Eaton FAZ-K20/1 Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph
MSRP $174.25Surplus $21.52Eaton FAZ-K20/1 Miniature Circuit Breakers (MCBs) FAZ 1P 20A 277V 50/60Hz 1Ph​ ARCA SKU: C15-3184 Brand: Eaton MPN: FAZ-K20/1 UPC: 015082786001 Shipping Weight: 0.30 Shipping Height: 1.00...- SKU:
- C15-3184
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 20 A
- Interrupting Rating:
- 10 kA
- Mounting:
- DIN Rail
- Poles:
- 1
- Size:
- 0.7 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Terminal Type:
- Screw
- Trip Setting:
- 8 to 12 x Rated Current
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Volts:
- 277/480 VAC
- Gauge:
- 18 to 4/18 to 8 AWG
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 1-Pole, 10 kA, 8 to 12 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, K-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- Data Sheet:
- Eaton_54283_1-8_DATA.pdf
- Voltage Rating:
- 277/480 VAC
- Number of Poles:
- 1
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Wire Size:
- 18 to 4/18 to 8 AWG
- Current Rating:
- 20 A
- Curve Type:
- K
- Country of Origin:
- Germany
MSRP $174.25Surplus $21.52 -
Eaton FAZ-Z20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph
MSRP $394.78Surplus $70.76Eaton FAZ-Z20/2 Miniature Circuit Breakers (MCBs) FAZ 2P 20A 120/240V 50/60Hz 1Ph​ ARCA SKU: C15-3198 Brand: Eaton MPN: FAZ-Z20/2 UPC: 015082788265 Shipping Weight: 0.55 Shipping Height: 2...- SKU:
- C15-3198
- Series:
- FAZ
- Type:
- Current Limiting
- Type:
- Thermal Magnetic
- Approval:
- UL 1077
- Approval:
- UL (Canada and US)
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Volts:
- 277/480 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Screw
- Wire Size:
- 18 to 4/18 to 8 AWG
- Trip Setting:
- 2 to 3 x Rated Current
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 2-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Data Sheet:
- Eaton_54401_1-9_DATA.pdf
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Voltage Rating:
- 277/480 VAC
- Curve Type:
- Z
- Country of Origin:
- Germany
MSRP $394.78Surplus $70.76 -
Eaton FAZ-Z20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph
MSRP $626.20Surplus $110.40Eaton FAZ-Z20/3 Miniature Circuit Breakers (MCBs) FAZ 3P 20A 277V 50/60Hz 3Ph​ ARCA SKU: C15-2694 Brand: Eaton MPN: FAZ-Z20/3 UPC: 015082789286 Shipping Weight: 0.75 lbs. Shipping...- SKU:
- C15-2694
- TS PIK:
- 124503387
- Number of Poles:
- 3
- Mounting:
- DIN Rail
- Terminal Type:
- Screw
- Size:
- 2.09 Inch Width x 2.36 Inch Depth x 3.15 Inch Height
- Voltage Rating:
- 277/480 VAC
- Current Rating:
- 20 A
- Interrupting Rating:
- 10 kA
- Type:
- Thermal Magnetic
- Data Sheet:
- Eaton_54402_1-9_DATA.pdf
- Wire Size:
- 18 to 4/18 to 8 AWG
- Catalog:
- Eaton_03771_V4T1_74-V4T1_92_CAT.pdf
- Short Description:
- 277/480 VAC 50/60 Hz, 20 A, 3-Pole, 10 kA, 2 to 3 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, Z-Curve, Current Limiting, Thermal Magnetic, Supplementary Protector
- Series:
- FAZ
- Curve Type:
- Z
- Approval:
- UL 1077, UL (Canada and US), CSA C22.2, CE
- Country of Origin:
- Germany
- Trip Setting:
- 2 to 3 x Rated Current
MSRP $626.20Surplus $110.40 -
Eaton QC2020 Din Rail Mounted Circuit Breakers 2P 20A EA
MSRP $344.41Surplus $63.33Eaton QC2020 Din Rail Mounted Circuit Breakers 2P 20A EA​ ARCA SKU: C15-1656 Brand: Eaton MPN: QC2020 UPC: 78667930937 Shipping Weight: 0.65 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-1656
- Series:
- QC
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA
- Volts:
- 120/240 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- DIN Rail
- Mounting:
- Cable Out
- Interrupting Rating:
- 10000 A at 120/240 VAC
- Interrupting Rating:
- 5000 A at 24 to 48/62.5/80 VDC
- Terminal Type:
- Screw
- Wire Size:
- 14 to 10 AWG Aluminum/Copper (Load)
- Short Description:
- 120/240 VAC, 20 A, 10 kA, 2-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature
- Catalog:
- Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Voltage Rating:
- 120/240 VAC
- TS PIK:
- 21508957
- Country of Origin:
- Dominican Republic
MSRP $344.41Surplus $63.33 -
Eaton QC2020H Miniature Circuit Breakers (MCBs) QC 2P 20A 240V 50/60Hz 1Ph EA
MSRP $570.38Surplus $147.18Eaton QC2020H Miniature Circuit Breakers (MCBs) QC 2P 20A 240V 50/60Hz 1Ph EA​ ARCA SKU: C15-3543 Brand: Eaton MPN: QC2020H UPC: 786679309384 Shipping Weight: 0.70 lbs. Shipping...- SKU:
- C15-3543
- Series:
- QC
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA
- Volts:
- 240 VAC
- Amps:
- 32 A
- Poles:
- 2
- Mounting:
- Cable-In
- Mounting:
- Cable Out
- Interrupting Rating:
- 10000 A
- Terminal Type:
- Ring
- Wire Size:
- 14 to 10 AWG Aluminum/Copper (Load)
- Short Description:
- 240 VAC, 20 A, 10 kA, 2-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature
- Catalog:
- Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf
- TS PIK:
- 21508958
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Voltage Rating:
- 240 VAC
- Country of Origin:
- Dominican Republic
MSRP $570.38Surplus $147.18 -
Eaton QCF2020 Din Rail Mounted Circuit Breakers EA
MSRP $225.55Surplus $49.24Eaton QCF2020 Din Rail Mounted Circuit Breakers EA​ ARCA SKU: C15-9240 Brand: Eaton MPN: QCF2020 UPC: 10786679143305 Shipping Weight: 0.55 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-9240
- Terminal Type:
- Lug
- Catalog:
- Eaton_03771_V4T1_23_V4T1_25_CAT.pdf
- Type:
- Thermal Magnetic
- Interrupting Rating:
- 10000 A at 120/240 VAC, 3000 A at 24 to 48 VDC, 3800 A at 62.5 VDC
- Wire Size:
- 14 to 4 AWG (Copper/Aluminum)
- Series:
- QCF
- TS PIK:
- 106998227
- Short Description:
- 120/240 VAC, 20 A, 10 kA, 2-Pole, Box Lug Terminal, Cable-In/Out Front Mount, Thermal Magnetic, Miniature, Circuit Breaker
- Voltage Rating:
- 120/240 VAC
- Current Rating:
- 20 A
- Mounting:
- DIN Rail
- Number of Poles:
- 2
- Approval:
- UL 489, CSA
- Country of Origin:
- Dominican Republic
MSRP $225.55Surplus $49.24 -
Eaton QCHW1020V Din Rail Mounted Circuit Breakers EA
MSRP $424.60Surplus $88.53Eaton QCHW1020V Din Rail Mounted Circuit Breakers EA​ ARCA SKU: C15-9469 Brand: Eaton MPN: QCHW1020V UPC: Shipping Weight: 0.30 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- C15-9469
- TS PIK:
- 120660536
- Short Description:
- EATON QUICKLAG TYPE QCHW INDUSTRIAL THERMAL-MAGNETIC CIRCUIT BREAKER,INDUSTRIAL
- Number of Poles:
- 1
- Current Rating:
- 20 A
- Mounting:
- DIN Rail
- Country of Origin:
- Dominican Republic
MSRP $424.60Surplus $88.53 -
Eaton QCR2020HTS Din Rail Mounted Circuit Breakers EA
MSRP $1,619.95Surplus $213.91SKU: C15-9710 Brand: Eaton MPN: QCR2020HTS UPC: 107821142206 Shipping Weight: 0.80 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-9710
- TS PIK:
- 115463415
- Number of Poles:
- 2
- Current Rating:
- 20 A
- Mounting:
- DIN Rail
- Country of Origin:
- Dominican Republic
MSRP $1,619.95Surplus $213.91 -
Eaton QCR3020HT Din Rail Mounted Circuit Breakers
MSRP $1,112.02Surplus $145.43SKU: C15-11123 Brand: Eaton MPN: QCR3020HT UPC: 78211422569 Shipping Weight: 0.75 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00 In. Shipping Width: 4.00 In...- SKU:
- C15-11123
- TS PIK:
- 115463469
- Country of Origin:
- Dominican Republic
- Voltage Rating:
- 240 VAC
- Series:
- QCR
- Short Description:
- is a 3-pole, 20A thermal-magnetic miniature circuit breaker from the Quicklag QCR series, designed for DIN rail mounting in industrial applications.​
- Number of Poles:
- 3
- Current Rating:
- 20 A
- Type:
- Thermal-Magnetic
- Interrupting Rating:
- 10 kA
- Poles:
- 3
MSRP $1,112.02Surplus $145.43 -
Eaton WMZT1C20 Miniature Circuit Breakers (MCBs) EA
MSRP $114.84Surplus $41.87Eaton WMZT1C20 Miniature Circuit Breakers (MCBs) EA​ ARCA SKU: C15-9291 Brand: Eaton MPN: WMZT1C20 UPC: Shipping Weight: 0.35 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- C15-9291
- Mounting:
- DIN Rail
- Number of Poles:
- 1
- Voltage Rating:
- 277/480 VAC 50/60 Hertz, 48 VDC
- Short Description:
- UL 489 WMZT DIN RAIL MINIATURE CIRCUIT BREAKER
- Terminal Type:
- Standard Box
- Current Rating:
- 20 A
- Interrupting Rating:
- 10 kA (UL/CSA), 15 kA (IEC)
- CAD Drawings:
- Eaton_41269_1_CAD.pdf
- Catalog:
- Eaton_32246_V9T1_3_V9T1_25_V9T1_26_CAT.pdf
- Type:
- Thermal Magnetic, C Protection Curve, Miniature
- Size:
- 3 Inch Width x 0.697 Inch Depth x 4.134 Inch Height
- Approval:
- UL 489, CSA 22.2, CE
- Country of Origin:
- Mexico
MSRP $114.84Surplus $41.87 -
GENERAL ELECTRIC THQC32020WL Din Rail Mounted Circuit Breakers 3P 20A 240V
MSRP $535.33Surplus $31.02GENERAL ELECTRIC THQC32020WL Din Rail Mounted Circuit Breakers 3P 20A 240V​ ARCA SKU: C15-3501 Brand: GENERAL ELECTRIC MPN: THQC32020WL UPC: 78316401270 Shipping Weight: 1.35 lbs. Shipping...- SKU:
- C15-3501
- Type:
- Thermal Magnetic
- Type:
- Compact
- Approval:
- UL
- Volts:
- 120/240 VAC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 10 kA
- Terminal Type:
- Lug
- Frame Type:
- Q-Line
- Maximum AC Voltage Rating:
- 240 V
- Short Description:
- 240 VAC, 20 A, 10 kA Interrupt, 3-Pole, 14 to 8 AWG Copper/12 to 8 AWG Aluminum Line/Load Lug Terminal, 35 MM DIN Rail Mount, Q-Line Frame, Non-Interchangeable/Internal Common Trip, Compact, Fixed Thermal Magnetic, Cable-In Cable-Out
- Catalog:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_40_CAT.pdf
- CAD Drawing:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_01788_1_CAD.pdf
- TS PIK:
- 112124801
- CAD Drawings:
- ABBElectrificationProducts-ABBGEIndustrialSolutions_01788_1_CAD.pdf
- Voltage Rating:
- 120/240 VAC
- Current Rating:
- 20 A
- Number of Poles:
- 3
- Mounting:
- DIN Rail
- Country of Origin:
- United States
MSRP $535.33Surplus $31.02 -
Square D BGA36020 Din Rail Mounted Circuit Breakers
MSRP $1,930.32Surplus $1,023.11SKU: C15-10652 Brand: Square D MPN: BGA36020 UPC: 60648115367 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10652
- TS PIK:
- 127013715
- Country of Origin:
- United States
- Prop 65 Warning:
- Yes
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 20 A, 18 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- BG
- Type:
- Thermal Magnetic
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Terminal Type:
- I-Line Connection Line Lug Load
- Interrupting Rating:
- 18 kA at 600 Star/347 V, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_35049_1-4_DATA.pdf
- Number of Poles:
- 3
- CAD Drawings:
- SchneiderElectric-SquareD_73602_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Approval:
- UL, CSA, CE
- Current Rating:
- 20 A
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Frame Type:
- B
- Maximum AC Voltage Rating:
- 347 V
- Maximum DC Voltage Rating:
- 250 V
MSRP $1,930.32Surplus $1,023.11 -
Square D BJA36020 Din Rail Mounted Circuit Breakers
MSRP $2,450.34Surplus $1,230.63SKU: C15-10666 Brand: Square D MPN: BJA36020 UPC: 60648115424 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10666
- TS PIK:
- 127013736
- Terminal Type:
- I-Line Connection Line Lug Load
- Number of Poles:
- 3
- Short Description:
- 600 Star/347 VAC 50/60 Hz, 250 VDC, 20 A, 25 kA, 3-Pole, B-Frame, ABC Phase, I-Line Connection Line Lug Load Terminal, Thermal Magnetic, Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-SquareD_00008_INST.pdf
- Series:
- BJ
- Current Rating:
- 20 A
- Approval:
- UL, CSA, CE
- Data Sheet:
- SchneiderElectric-SquareD_35194_1-4_DATA.pdf
- Type:
- Thermal Magnetic
- CAD Drawings:
- SchneiderElectric-SquareD_73669_1_CAD.pdf
- Size:
- 3.19 Inch Width x 3.5 Inch Depth x 5.39 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_7_32_CAT.pdf
- Interrupting Rating:
- 25 kA at 600 Star/347 V, 50 kA at 250 VDC
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 Star/347 VAC 50/60 Hertz, 250 VDC
- Country of Origin:
- United States
- Maximum AC Voltage Rating:
- 347 V
- Maximum DC Voltage Rating:
- 250 V
- Frame Type:
- B
MSRP $2,450.34Surplus $1,230.63
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
