Molded Case Breakers (MCCBs)
A molded case circuit breaker (MCCB) is a type of electrical breaker that is used to protect electrical systems from damage due to overloading, short-circuiting, or other electrical faults. MCCBs are commonly used in industrial and commercial electrical systems, and are designed to handle higher currents and voltage levels than residential miniature circuit breakers.
- Product
- Qty in Cart
- Price
-
Eaton LGE3630NN Molded Case Breakers (MCCBs) LGE 3P 630A 480V 50/60Hz 3Ph L Frame EA
MSRP $4,550.00Surplus $672.55SKU: C15-1829 Brand: Eaton MPN: LGE3630NN UPC: 782116336142 Shipping Weight: 13.40 lbs. Shipping Height: 5.00 In. Shipping Length: 13.00 In. Shipping Width: 6.00 In...- SKU:
- C15-1829
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Amps:
- 630 A
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 415/480 Volt AC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Maximum AC Voltage:
- 600 V
- Poles:
- 3
- Size:
- 5.48 Inch Width x 4.09 Inch Depth x 10.13 Inch Height
- Terminal Type:
- LG Frame
- Volts:
- 600 VAC
- Specification/Technical:
- Eaton_62118_1_2_SPEC.pdf
- Installation/Operator:
- Eaton_00239_INST.pdf
- TS PIK:
- 120602127
- Maximum AC Voltage Rating:
- 600 V
- Type:
- LG Frame
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_186_V4T2_189_V4T2_196_V4T2_199_V4T2_201_CAT.pdf
- Voltage Rating:
- 600 VAC
- Current Rating:
- 630 A
- Number of Poles:
- 3
- Short Description:
- EATON MOLDED CASE CIRCUIT BREAkER ACCESSORY FRAME, FRAME ONLY, 630 A, 65 kAIC AT
- Series:
- L
- Country of Origin:
- United States
MSRP $4,550.00Surplus $672.55 -
Eaton GHB3040 Molded Case Breakers (MCCBs) GHB 3P 40A 480V 50/60Hz 3Ph G Frame EA
MSRP $860.00Surplus $266.95SKU: C15-2804 Brand: Eaton MPN: GHB3040 UPC: 78667991128 Shipping Weight: 1.75 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 4.00 In...- SKU:
- C15-2804
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- CSA C22.2
- Approval:
- UL 489
- Size:
- 3 Inch Width x 2.63 Inch Depth x 4 Inch Height
- Volts:
- 277/480 VAC 50/60 Hertz
- Volts:
- 125/250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 14 kA at 277 Volt AC/480 Star/250 Volt DC
- Terminal Type:
- Aluminum Pressure Line and Load
- Frame Type:
- GHB
- Maximum AC Voltage Rating:
- 480 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 277/480 VAC 50/60 Hz, 125 VDC, 40 A, 14 kA, 3-Pole, Steel Pressure Screw Line and Load Terminal, GHB Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_259_V4T2_260_CAT.pdf
- Installation/Operator:
- Eaton_00166_INST.pdf
- TS PIK:
- 21517405
- Current Rating:
- 40 A
- Number of Poles:
- 3
- Voltage Rating:
- 277/480 VAC 50/60 Hertz, 125/250 VDC
- Country of Origin:
- United States
MSRP $860.00Surplus $266.95 -
Contact Us For Quote
Eaton JGE3100FAG Molded Case Breakers (MCCBs) JGE 3P 100A 600V 50/60Hz 3Ph J Frame EA
MSRP $3,915.00Surplus $903.74SKU: C15-3944 Brand: Eaton MPN: JGE3100FAG UPC: 782113962511 Shipping Weight: 6.05 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3944
- Series:
- G
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Size:
- 3.57 Inch Width x 4.13 Inch Depth x 7 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 25 kA at 415 Volt AC
- Interrupting Rating:
- 25 kA at 480 Volt AC
- Interrupting Rating:
- 18 kA at 600 Volt AC
- Terminal Type:
- Line and Load Terminal
- Frame Type:
- JG
- Maximum AC Voltage Rating:
- 600 VAC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 25 kA, 3-Pole, Line/Load Terminal, JGE Frame, Fixed Thermal, Adjustable Magnetic
- Catalog:
- Eaton_46579_V4T2_167-V4T2_183_CAT.pdf
- Installation/Operator:
- Eaton_00372_INST.pdf
- CAD Drawing:
- Eaton_32657_1_2_CAD.pdf
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC
- Current Rating:
- 100 A
- CAD Drawings:
- Eaton_32657_1_2_CAD.pdf
MSRP $3,915.00Surplus $903.74 -
Eaton FD3150 Molded Case Breakers (MCCBs) FD 3P 150A 600V 50/60Hz 3Ph F Frame EA
MSRP $6,620.00Surplus $1,085.38SKU: C15-3022 Brand: Eaton MPN: FD3150 UPC: 786679305799 Shipping Weight: 4.35 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3022
- Series:
- FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- CSA C22.2
- Approval:
- UL 489
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC
- Interrupting Rating:
- 18 kA at 600 Volt AC
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 21508847
- Current Rating:
- 150 A
- Voltage Rating:
- 600 VAC, 250 VDC (UL, IEC)
- Number of Poles:
- 3
- Country of Origin:
- Dominican Republic
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
MSRP $6,620.00Surplus $1,085.38 -
Contact Us For Quote
Square D QGA222002 Molded Case Breakers (MCCBs) EA
MSRP $1,593.00Surplus $1,117.20SKU: C15-7202 Brand: Square D MPN: QGA222002 UPC: 78590129911 Shipping Weight: 3.95 lbs. Shipping Height: 4.00 In. Shipping Length: 9.00 In. Shipping Width: 4.00 In...- SKU:
- C15-7202
- Data Sheet:
- SchneiderElectric_15735_1_2_DATA.pdf
- Number of Poles:
- 2
- Interrupting Rating:
- 65 kA at 240 VAC
- CAD Drawings:
- SchneiderElectric_30258_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_02030_INST.pdf
- Type:
- Thermal Magnetic
- Series:
- QG
- Current Rating:
- 200 A
- Voltage Rating:
- 240 VAC 50/60 Hertz
- Catalog:
- SchneiderElectric-SquareD_32357_9_57_CAT.pdf
- Short Description:
- 240 VAC 50/60 Hz, 200 A, 65 kA, 2-Pole, Q-Frame, AC Phase, Line Lug Load Terminal, Thermal Magnetic, Panelboard Molded Case Circuit Breaker
- Application:
- Power Distribution
- Trip Setting:
- 1200 to 2400 A
- Approval:
- UL, CSA
- Used On:
- I-Line Panelboard and Switchboard
- Prop 65 Warning:
- Yes
MSRP $1,593.00Surplus $1,117.20 -
Eaton FD3175 Molded Case Breakers (MCCBs)
MSRP $4,452.25Surplus $846.42SKU: C15-1689 Brand: Eaton MPN: FD3175 UPC: 78667901538 Shipping Weight: 4.05 lbs. Shipping Height: 6.00 In. Shipping Length: 4.00 In. Shipping Width: 3.00 In...- SKU:
- C15-1689
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 kA at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 175 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 110190786
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Current Rating:
- 175 A
- Voltage Rating:
- 600 VAC
- Country of Origin:
- Dominican Republic
MSRP $4,452.25Surplus $846.42 -
Contact Us For Quote
Eaton FD3070 Molded Case Breakers (MCCBs) FD 3P 70A 600V 50/60Hz 3Ph F Frame EA Thermal Magnetic
MSRP $2,498.00Surplus $840.00SKU: C15-2322 Brand: Eaton MPN: FD3070 UPC: 786679305720 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-2322
- Series:
- C, FD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 kA at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 70 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- Current Rating:
- 70 A
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Voltage Rating:
- 600 VAC, 250 VDC
- Country of Origin:
- Dominican Republic
MSRP $2,498.00Surplus $840.00 -
Eaton FD3100 Molded Case Breakers (MCCBs) FD 3P 100A 600V 50/60Hz 3Ph F Frame EA Thermal Magnetic
MSRP $1,978.43Surplus $402.01SKU: C15-1686 Brand: Eaton MPN: FD3100 UPC: 786679305768 Shipping Weight: 4.40 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1686
- Series:
- C
- Type:
- Fixed Thermal
- Type:
- Fixed Magnetic
- Type:
- Molded Case
- Approval:
- UL
- Size:
- 3.38 Inch Length x 4.13 Inch Width x 4.13 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC
- Terminal Type:
- Load Side
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 600 VAC
- Maximum DC Voltage Rating:
- 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 21508844
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Voltage Rating:
- 600 VAC
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Country of Origin:
- Dominican Republic
MSRP $1,978.43Surplus $402.01 -
Contact Us For Quote
Square D QGA32175 Molded Case Breakers (MCCBs)
MSRP $2,835.00Surplus $1,584.03SKU: C15-7207 Brand: Square D MPN: QGA32175 UPC: 78590170561 Shipping Weight: 6.70 lbs. Shipping Height: 6.00 In. Shipping Length: 13.00 In. Shipping Width: 8.00 In...- SKU:
- C15-7207
- TS PIK:
- 121894791
- Voltage Rating:
- 240 VAC 50/60 Hertz
- Interrupting Rating:
- 65 kA at 240 VAC
- Short Description:
- 240 VAC 50/60 Hz, 175 A, 65 kA, 3-Pole, Q-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Panelboard Molded Case Circuit Breaker
- Series:
- QG
- Data Sheet:
- SchneiderElectric_15747_1_2_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_9_57_CAT.pdf
- Current Rating:
- 175 A
- Number of Poles:
- 3
- Installation/Operator:
- SchneiderElectric-SquareD_02030_INST.pdf
- Type:
- Thermal Magnetic
- CAD Drawings:
- SchneiderElectric_30259_1_CAD.pdf
- Trip Setting:
- 1200 to 2400 A
- Application:
- Power Distribution
- Approval:
- UL, CSA
- Prop 65 Warning:
- Yes
- Used On:
- I-Line Panelboard and Switchboard
MSRP $2,835.00Surplus $1,584.03 -
Eaton FD3020 Molded Case Breakers (MCCBs)
MSRP $1,761.89Surplus $269.70Eaton FD3020 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-2142 Brand: Eaton MPN: FD3020 UPC: 786679305621 Shipping Weight: 5.00 lbs. Shipping Height: 6.00 In. Shipping...- SKU:
- C15-2142
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 kA at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 kA at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 20 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21586_1_CAD.pdf
- TS PIK:
- 21508830
- Current Rating:
- 20 A
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Voltage Rating:
- 600 VAC
- Number of Poles:
- 3
- Country of Origin:
- Dominican Republic
MSRP $1,761.89Surplus $269.70 -
Contact Us For Quote
Eaton GD3020 Molded Case Breakers (MCCBs) GD 3P 20A 480V 50/60Hz 3Ph G Frame
MSRP $1,200.00Surplus $490.00Eaton GD3020 Molded Case Breakers (MCCBs) GD 3P 20A 480V 50/60Hz 3Ph G Frame​ ARCA SKU: C15-2933 Brand: Eaton MPN: GD3020 UPC: 786679231029 Shipping Weight: 1.70 Shipping Height: 3.00 In...- SKU:
- C15-2933
- Series:
- GD
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 3 Inch Width x 2.81 Inch Depth x 4.88 Inch Height
- Volts:
- 480 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 22 kA at 480 Volt AC
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Steel Pressure Line and Load
- Frame Type:
- G
- Maximum AC Voltage Rating:
- 480 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 480 VAC 50/60 Hz, 250 VDC, 20 A, 22/10 kA, 3-Pole, Standard Pressure Load Terminal, G Frame, Molded Case, Thermal Magnetic
- Catalog:
- Eaton_03771_V4T2_225-V4T2_227_V4T2_229_CAT.pdf
- Installation/Operator:
- Eaton_00165_INST.pdf
- Voltage Rating:
- 480 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 20 A
- Number of Poles:
- 3
MSRP $1,200.00Surplus $490.00 -
Contact Us For Quote
ED2100 2P 100A
MSRP $674.97Surplus $587.86SKU: C15-3746 Brand: MPN: ED2100 UPC: Shipping Weight: 2.95 lbs. Shipping Height: 4.00 In. Shipping Length: 7.00 In. Shipping Width: 6.00 In. Product...- SKU:
- C15-3746
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 240 VAC at 50/60 Hz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 10 kA at 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 240
- Maximum DC Voltage Rating:
- 125
- Short Description:
- 240 VAC 50/60 Hz, 125 VDC, 100 A, 65/10 kA, 2-Pole, Standard Pressure Load Terminal, ED Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Current Rating:
- 100 A
- Voltage Rating:
- 240 VAC at 50/60 Hz, 125 VDC
- Number of Poles:
- 2
- Country of Origin:
- Dominican Republic
MSRP $674.97Surplus $587.86 -
Contact Us For Quote
Square D QGA32225 Molded Case Breakers (MCCBs)
MSRP $2,835.00Surplus $1,584.03SKU: C15-7208 Brand: Square D MPN: QGA32225 UPC: 78590178979 Shipping Weight: 6.95 lbs. Shipping Height: 6.00 In. Shipping Length: 13.00 In. Shipping Width: 8.00 In...- SKU:
- C15-7208
- TS PIK:
- 121894795
- Voltage Rating:
- 240 VAC 50/60 Hertz
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_9_57_CAT.pdf
- Series:
- QG
- CAD Drawings:
- SchneiderElectric_30259_1_CAD.pdf
- Type:
- Thermal Magnetic
- Interrupting Rating:
- 65 kA at 240 VAC
- Data Sheet:
- SchneiderElectric_15750_1_2_DATA.pdf
- Short Description:
- 240 VAC 50/60 Hz, 225 A, 65 kA, 3-Pole, Q-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Panelboard Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-SquareD_02030_INST.pdf
- Current Rating:
- 225 A
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Used On:
- I-Line Panelboard and Switchboard
- Application:
- Power Distribution
- Approval:
- UL, CSA
- Trip Setting:
- 1200 to 2400 A
MSRP $2,835.00Surplus $1,584.03 -
Eaton FD3040 Molded Case Breakers (MCCBs) 3P 40A
MSRP $1,761.89Surplus $277.08SKU: C15-1808 Brand: Eaton MPN: FD3040 UPC: 78667930567 Shipping Weight: 4.50 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1808
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 40 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- CAD Drawing:
- Eaton_21588_1_CAD.pdf
- TS PIK:
- 21508835
- Data Sheet:
- Eaton_07831_1-3_8_9_DATA.pdf
- Voltage Rating:
- 600 VAC
- Current Rating:
- 40 A
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Number of Poles:
- 3
- Country of Origin:
- Dominican Republic
MSRP $1,761.89Surplus $277.08 -
Eaton ED2175 Molded Case Breakers (MCCBs) ED 2P 175A 240V 50/60Hz 2Ph F Frame
MSRP $639.00Surplus $587.86SKU: C15-3447 Brand: Eaton MPN: ED2175 UPC: 786679456286 Shipping Weight: 3.00 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-3447
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 2.75 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 240 VAC at 50/60 Hz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 10 kA at 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 240
- Maximum DC Voltage Rating:
- 125
- Short Description:
- 240 VAC 50/60 Hz, 125 VDC, 175 A, 65/10 kA, 2-Pole, Standard Pressure Load Terminal, ED Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_07831_1-3_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Voltage Rating:
- 240 VAC at 50/60 Hz, 125 VDC
- Number of Poles:
- 2
- Current Rating:
- 175 A
- Country of Origin:
- Dominican Republic
MSRP $639.00Surplus $587.86 -
Contact Us For Quote
Eaton ED3125 Molded Case Breakers (MCCBs) ED 3P 125A 240V 50/60Hz 3Ph F Frame EA
MSRP $1,696.00Surplus $419.26SKU: C15-1857 Brand: Eaton MPN: ED3125 UPC: 786679455326 Shipping Weight: 4.25 lbs. Shipping Height: 5.00 In. Shipping Length: 8.00 In. Shipping Width: 5.00 In...- SKU:
- C15-1857
- Series:
- C, ED
- Type:
- Molded Case
- Type:
- Fixed Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 240 VAC at 50/60 Hertz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 10 kA at 125 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 240 V
- Maximum DC Voltage Rating:
- 125 V
- Short Description:
- 240 VAC 50/60 Hz, 125 VDC, 125 A, 65/10 kA, 3-Pole, Standard Pressure Load Terminal, ED Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Current Rating:
- 125 A
- Voltage Rating:
- 240 VAC, 125 VDC
- Number of Poles:
- 3
MSRP $1,696.00Surplus $419.26 -
Eaton FD2060L Molded Case Breakers (MCCBs) 2P
MSRP $1,662.00Surplus $121.00SKU: C15-2870 Brand: Eaton MPN: FD2060L UPC: 78667985068 Shipping Weight: 3.15 lbs. Shipping Height: 4.00 In. Shipping Length: 8.00 In. Shipping Width: 6.00 In...- SKU:
- C15-2870
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 60 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 35 Kiloamp at 380/415/440 Volt DC
- Interrupting Rating:
- 18 Kiloamp at 500 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 600 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Line and Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 107007492
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Number of Poles:
- 2
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Current Rating:
- 60 A
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- Eaton_21585_1_CAD.pdf
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAkER, F-FRAME, FD, COMPLETE BREAk
- Series:
- C
- Country of Origin:
- Dominican Republic
MSRP $1,662.00Surplus $121.00 -
Eaton JGE3150FAG Molded Case Breakers (MCCBs) JGE 3P 150A 600V 50/60Hz 3Ph J Frame
MSRP $3,915.00Surplus $1,368.59SKU: C15-4126 Brand: Eaton MPN: JGE3150FAG UPC: 782113526713 Shipping Weight: 5.30 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In...- SKU:
- C15-4126
- Series:
- G
- Type:
- Fixed Thermal
- Type:
- Adjustable Magnetic
- Approval:
- IEC
- Approval:
- CE
- Approval:
- UL
- Approval:
- CSA
- Size:
- 9.5 Inch Length x 5 Inch Width x 6.5 Inch Height
- Volts:
- 600 VAC 50/60 Hertz
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 25 kA at 480 Volt AC
- Interrupting Rating:
- 18 kA at 600 Volt AC
- Terminal Type:
- Line and Load
- Frame Type:
- JG
- Maximum AC Voltage Rating:
- 600
- Short Description:
- 600 VAC 50/60 Hz, 150 A, 25 kA, 3-Pole, Line/Load Terminal, JG Frame, Fixed Thermal, Adjustable Magnetic
- Catalog:
- Eaton_46579_V4T2_167-V4T2_183_CAT.pdf
- Installation/Operator:
- Eaton_00372_INST.pdf
- CAD Drawing:
- Eaton_32657_1_2_CAD.pdf
- Current Rating:
- 150 A
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_32657_1_2_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz
- Country of Origin:
- Dominican Republic
MSRP $3,915.00Surplus $1,368.59 -
FD3060 3P 60A
MSRP $1,761.89Surplus $416.51SKU: C15-1807 Brand: Eaton MPN: FD3060 UPC: 78667930569 Shipping Weight: 4.50 lbs. Shipping Height: 6.00 In. Shipping Length: 4.13 In. Shipping Width: 3.38 In...- SKU:
- C15-1807
- Series:
- C
- Type:
- Miniature
- Type:
- Standard
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 600 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 18 Kiloamp at 600 Volt AC at 50/60 Hertz
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 60 A, 35/10 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- SchneiderElectric_21404_1_2_DATA.pdf
- Installation/Operator:
- SchneiderElectric-SquareD_02166_INST.pdf
- Manufacturer Warranty:
- SchneiderElectric-SquareD_00002_WARR.pdf
- Voltage Rating:
- 600 VAC
- Current Rating:
- 60 A
- Number of Poles:
- 3
- CAD Drawings:
- Eaton_21586_1_CAD.pdf
- Country of Origin:
- Dominican Republic
MSRP $1,761.89Surplus $416.51 -
Contact Us For Quote
Eaton ED2030 Molded Case Breakers (MCCBs) ED 2P 30A 240V 50/60Hz 2Ph F Frame
MSRP $504.83Surplus $560.00Eaton ED2030 Molded Case Breakers (MCCBs) ED 2P 30A 240V 50/60Hz 2Ph F Frame​ ARCA SKU: C15-2818 Brand: Eaton MPN: ED2030 UPC: 782116348985 Shipping Weight: 2.95 lbs. Shipping...- SKU:
- C15-2818
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 30 A
- Frame:
- FD
- Interrupting Rating:
- 65 kA at 240 VAC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (UL)
- Interrupting Rating:
- 65 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 125 Volt DC (IEC)
- Maximum AC Voltage:
- 240 V
- Maximum DC Voltage:
- 125 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 240 VAC 50/60 Hertz
- Volts:
- 125 VDC
- TS PIK:
- 120758514
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Voltage Rating:
- 240 VAC
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Current Rating:
- 30 A
- Maximum DC Voltage Rating:
- 125 V
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAkER, F-FRAME, ED, COMPLETE BREAk
- Maximum AC Voltage Rating:
- 240 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Number of Poles:
- 2
- Frame Type:
- FD
MSRP $504.83Surplus $560.00
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
