Molded Case Breakers (MCCBs)
A molded case circuit breaker (MCCB) is a type of electrical breaker that is used to protect electrical systems from damage due to overloading, short-circuiting, or other electrical faults. MCCBs are commonly used in industrial and commercial electrical systems, and are designed to handle higher currents and voltage levels than residential miniature circuit breakers.
- Product
- Qty in Cart
- Price
-
Square D HDA36050 Molded Case Breakers (MCCBs)
MSRP $1,530.10Surplus $1,231.16SKU: C15-6576 Brand: Square D MPN: HDA36050 UPC: 78590153992 Shipping Weight: 5.40 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-6576
- TS PIK:
- 109594623
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 50 A
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 50 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_46397_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29577_1_CAD.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Prop 65 Warning:
- Yes
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Application:
- Distribution
- Trip Setting:
- 400 A (Hold), 850 A (Trip)
MSRP $1,530.10Surplus $1,231.16 -
Square D HDA36060 Molded Case Breakers (MCCBs)
MSRP $1,530.10Surplus $902.54SKU: C15-6368 Brand: Square D MPN: HDA36060 UPC: 78590141996 Shipping Weight: 5.56 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-6368
- TS PIK:
- 125439250
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46398_1-3_DATA.pdf
- Series:
- HD
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 60 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- CAD Drawings:
- SchneiderElectric_29578_1_CAD.pdf
- Number of Poles:
- 3
- Current Rating:
- 60 A
- Type:
- Thermal Magnetic, Current Limiting
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Trip Setting:
- 800 A (Hold), 1450 A (Trip)
- Application:
- Distribution
MSRP $1,530.10Surplus $902.54 -
Square D HDA36090 Molded Case Breakers (MCCBs)
MSRP $1,852.73Surplus $1,265.56SKU: C15-7143 Brand: Square D MPN: HDA36090 UPC: 78590142226 Shipping Weight: 5.50 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7143
- TS PIK:
- 122846954
- CAD Drawings:
- SchneiderElectric_29582_1_CAD.pdf
- Current Rating:
- 90 A
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_46404_1-3_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Application:
- Distribution
- Approval:
- UL, CSA, CE
- Trip Setting:
- 800 A (Hold), 1450 A (Trip)
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
MSRP $1,852.73Surplus $1,265.56 -
Square D HDA36030 Molded Case Breakers (MCCBs)
MSRP $1,530.10Surplus $1,231.16SKU: C15-6575 Brand: Square D MPN: HDA36030 UPC: 78590141993 Shipping Weight: 5.50 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-6575
- TS PIK:
- 109594619
- Type:
- Thermal Magnetic, Current Limiting
- CAD Drawings:
- SchneiderElectric_29573_1_CAD.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 30 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 30 A
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Number of Poles:
- 3
- Data Sheet:
- SchneiderElectric-SquareD_46393_1-3_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Trip Setting:
- 350 A (Hold), 750 A (Trip)
- Application:
- Distribution
- Approval:
- UL, CSA, CE
MSRP $1,530.10Surplus $1,231.16 -
Square D HDA36070 Molded Case Breakers (MCCBs)
MSRP $1,852.73Surplus $1,265.56SKU: C15-7147 Brand: Square D MPN: HDA36070 UPC: 78590141997 Shipping Weight: 5.45 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7147
- TS PIK:
- 126554038
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46402_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- SchneiderElectric_29579_1_CAD.pdf
- Current Rating:
- 70 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 70 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
- Application:
- Distribution
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Trip Setting:
- 800 A (Hold), 1450 A (Trip)
MSRP $1,852.73Surplus $1,265.56 -
Square D HDA36080 Molded Case Breakers (MCCBs)
MSRP $1,852.73Surplus $952.91SKU: C15-7146 Brand: Square D MPN: HDA36080 UPC: 78590150727 Shipping Weight: 5.55 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7146
- TS PIK:
- 122847403
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 80 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Current Rating:
- 80 A
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46403_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric_29581_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Prop 65 Warning:
- Yes
- Country of Origin:
- Dominican Republic
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Application:
- Distribution
- Trip Setting:
- 800 A (Hold), 1450 A (Trip)
MSRP $1,852.73Surplus $952.91 -
Square D HDA36150 Molded Case Breakers (MCCBs)
MSRP $3,716.35Surplus $1,779.75SKU: C15-7157 Brand: Square D MPN: HDA36150 UPC: 78590142000 Shipping Weight: 5.95 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7157
- TS PIK:
- 121894739
- Type:
- Thermal Magnetic, Current Limiting
- Data Sheet:
- SchneiderElectric-SquareD_46413_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- CAD Drawings:
- SchneiderElectric_29588_1_CAD.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 150 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Series:
- HD
- Prop 65 Warning:
- Yes
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
- Application:
- Distribution
- Trip Setting:
- 900 A (Hold), 1700 A (Trip)
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
MSRP $3,716.35Surplus $1,779.75 -
Contact Us For Quote
Square D HDL36020 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $758.61SKU: C15-10714 Brand: Square D MPN: HDL36020 UPC: 78590170669 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10714
- TS PIK:
- 120736906
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46446_1-3_DATA.pdf
- Series:
- HD
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 20 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Terminal Type:
- Line/Load Lug
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Type:
- Thermal Magnetic, Current Limiting
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 20 A
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Frame Type:
- H
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $758.61 -
Square D HDL36100 Molded Case Breakers (MCCBs)
MSRP $1,807.81Surplus $937.85Square D HDL36100 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-7153 Brand: Square D MPN: HDL36100 UPC: 78590183993 Shipping Weight: 4.25 lbs. Shipping Height: 6.00 In. Shipping...- SKU:
- C15-7153
- TS PIK:
- 127230779
- Number of Poles:
- 3
- Frame Type:
- H
- Current Rating:
- 100 A
- Data Sheet:
- SchneiderElectric-SquareD_46486_1-3_DATA.pdf
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Maximum AC Voltage Rating:
- 600 V
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Approval:
- UL, CSA, CE
- Country of Origin:
- Canada
MSRP $1,807.81Surplus $937.85 -
Contact Us For Quote
Square D HDL36150 Molded Case Breakers (MCCBs) HDL 3P 150A 600V 50/60Hz 3Ph H Frame
MSRP $3,751.74Surplus $1,867.70SKU: C15-2740 Brand: Square D MPN: HDL36150 UPC: 785901623212 Shipping Weight: 4.15 lbs. Shipping Height: 6.00 In. Shipping Length: 9.00 In. Shipping Width: 8.00 In...- SKU:
- C15-2740
- Series:
- HD
- Type:
- Thermal Magnetic
- Type:
- Current Limiting
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC
- Interrupting Rating:
- 20 kA at 250 Volt DC
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46501_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawing:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Manufacturer Warranty:
- SchneiderElectric-SquareD_00002_WARR.pdf
- Current Rating:
- 150 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Canada
MSRP $3,751.74Surplus $1,867.70 -
Square D HDA36015 Molded Case Breakers (MCCBs)
MSRP $1,530.10Surplus $1,231.16Square D HDA36015 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-6432 Brand: Square D MPN: HDA36015 UPC: 78590141910 Shipping Weight: 5.95 lbs. Shipping Height: 7.00 In. Shipping...- SKU:
- C15-6432
- TS PIK:
- 21032767
- Number of Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Series:
- HD
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 15 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Data Sheet:
- SchneiderElectric-SquareD_46390_1-3_DATA.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Current Rating:
- 15 A
- CAD Drawings:
- SchneiderElectric_29570_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Approval:
- UL, CSA, CE
- Trip Setting:
- 350 A (Hold), 750 A (Trip)
- Application:
- Distribution
MSRP $1,530.10Surplus $1,231.16 -
Square D HDA36020 Molded Case Breakers (MCCBs)
MSRP $1,530.10Surplus $902.54Square D HDA36020 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-6433 Brand: Square D MPN: HDA36020 UPC: 78590140524 Shipping Weight: 5.50 lbs. Shipping Height: 6.00 In. Shipping...- SKU:
- C15-6433
- TS PIK:
- 21032769
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 20 A
- Series:
- HD
- Data Sheet:
- SchneiderElectric-SquareD_46391_1-3_DATA.pdf
- Number of Poles:
- 3
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 20 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29571_1_CAD.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Application:
- Distribution
- Approval:
- UL, CSA, CE
- Trip Setting:
- 350 A (Hold), 750 A (Trip)
MSRP $1,530.10Surplus $902.54 -
Contact Us For Quote
Square D HDA36025 Molded Case Breakers (MCCBs)
MSRP $1,843.20Surplus $497.66SKU: C15-16415 Brand: Square D MPN: HDA36025 UPC: 78590142282 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16415
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 25 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Series:
- HD
- CAD Drawings:
- SchneiderElectric_29572_1_CAD.pdf
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Data Sheet:
- SchneiderElectric-SquareD_46392_1-3_DATA.pdf
- Trip Setting:
- 350 A (Hold), 750 A (Trip)
- Application:
- Distribution
- Number of Poles:
- 3
- Current Rating:
- 25 A
- Prop 65 Warning:
- Yes
MSRP $1,843.20Surplus $497.66 -
Contact Us For Quote
Square D HDA36035 Molded Case Breakers (MCCBs)
MSRP $1,361.44Surplus $367.59SKU: C15-18751 Brand: Square D MPN: HDA36035 UPC: 78590142223 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18751
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 35 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Current Rating:
- 35 A
- Number of Poles:
- 3
- Data Sheet:
- SchneiderElectric-SquareD_46394_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- CAD Drawings:
- SchneiderElectric_29574_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Trip Setting:
- 400 A (Hold), 850 A (Trip)
- Application:
- Distribution
MSRP $1,361.44Surplus $367.59 -
Square D HDA36040 Molded Case Breakers (MCCBs) HDA 3P 40A 600V 50/60Hz 3Ph H Frame
MSRP $1,530.10Surplus $1,295.96SKU: C15-2160 Brand: Square D MPN: HDA36040 UPC: 78590141994 Shipping Weight: 5.46 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-2160
- Series:
- HD
- Type:
- Vibrating Horn with Grille
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC
- Interrupting Rating:
- 20 Kiloamp at 250 Volt DC
- Enclosure:
- Class I Div 1 Group C D
- Enclosure:
- Class II Div 1 Group E F G
- Enclosure:
- Class III
- Application:
- Distribution
- Trip Setting:
- 400 A (Hold)
- Trip Setting:
- 850 Amp (Trip)
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 40 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Data Sheet:
- FederalSignal_00104_1_2_DATA.pdf
- Installation/Operator:
- FederalSignal_00041_INST.pdf
- Current Rating:
- 40 A
- CAD Drawings:
- SchneiderElectric_29575_1_CAD.pdf
- Voltage Rating:
- 600 VAC
- Number of Poles:
- 3
- Frame Type:
- H
- Prop 65 Warning:
- Yes
- Country of Origin:
- Canada
MSRP $1,530.10Surplus $1,295.96 -
Contact Us For Quote
Square D HDA36045 Molded Case Breakers (MCCBs)
MSRP $1,617.22Surplus $436.65SKU: C15-18752 Brand: Square D MPN: HDA36045 UPC: 78590142224 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-18752
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Current Rating:
- 45 A
- Data Sheet:
- SchneiderElectric-SquareD_46396_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Application:
- Distribution
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- CAD Drawings:
- SchneiderElectric_29576_1_CAD.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 45 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Trip Setting:
- 400 A (Hold), 850 A (Trip)
MSRP $1,617.22Surplus $436.65 -
Contact Us For Quote
Square D HDA36100 Molded Case Breakers (MCCBs) EA
MSRP $1,852.73Surplus $1,139.00SKU: C15-5195 Brand: Square D MPN: HDA36100 UPC: 785901419983 Shipping Weight: 5.55 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-5195
- Series:
- HD
- Type:
- Thermal Magnetic
- Type:
- Current Limiting
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC
- Interrupting Rating:
- 20 kA at 250 Volt DC
- Application:
- Distribution
- Trip Setting:
- 800 A (Hold)
- Trip Setting:
- 1700 Amp (Trip)
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46405_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawing:
- SchneiderElectric_29583_1_CAD.pdf
- Manufacturer Warranty:
- SchneiderElectric-SquareD_00002_WARR.pdf
- Current Rating:
- 100 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
MSRP $1,852.73Surplus $1,139.00 -
Contact Us For Quote
Square D HDA36100U31X Molded Case Breakers (MCCBs)
MSRP $1,965.72Surplus $530.74SKU: C15-16417 Brand: Square D MPN: HDA36100U31X UPC: 78590115442 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16417
- Prop 65 Warning:
- Yes
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Panelboard Molded Case Circuit Breaker
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Series:
- HD
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Application:
- Distribution
- Data Sheet:
- SchneiderElectric-SquareD_46407_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
- Used On:
- Class 611/612 I-Line Panelboard
- Number of Poles:
- 3
MSRP $1,965.72Surplus $530.74 -
Contact Us For Quote
Square D HDA36100U33X Molded Case Breakers (MCCBs)
MSRP $2,043.58Surplus $551.76SKU: C15-16418 Brand: Square D MPN: HDA36100U33X UPC: 78590140358 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16418
- Series:
- HD
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Ammeter, Micrologic 3.2 S, LSI, Current Limiting, Panelboard Molded Case Circuit Breaker
- Number of Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Current Rating:
- 100 A
- Data Sheet:
- SchneiderElectric-SquareD_46408_1-3_DATA.pdf
- Application:
- Distribution
- Type:
- Electronic, Standard, Micrologic 3.2 S, LSI, Current Limiting
- CAD Drawings:
- SchneiderElectric_29583_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Used On:
- Class 611/612 I-Line Panelboard
MSRP $2,043.58Surplus $551.76 -
Contact Us For Quote
Square D HDA36100U44X Molded Case Breakers (MCCBs)
MSRP $3,184.08Surplus $859.70SKU: C15-16419 Brand: Square D MPN: HDA36100U44X UPC: 78590113345 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16419
- Used On:
- Class 611/612 I-Line Panelboard
- Application:
- Distribution
- Data Sheet:
- SchneiderElectric-SquareD_46409_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric_29584_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Electronic, Ammeter, Micrologic 6.2 A, LSIG, Current Limiting
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 100 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Ammeter, Micrologic 6.2 A, LSIG, Current Limiting, Panelboard Molded Case Circuit Breaker
MSRP $3,184.08Surplus $859.70 -
Square D HDA36110 Molded Case Breakers (MCCBs)
MSRP $3,377.79Surplus $912.00SKU: C15-16420 Brand: Square D MPN: HDA36110 UPC: 78590142227 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16420
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 110 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Approval:
- UL, CSA, CE
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Trip Setting:
- 900 A (Hold), 1700 A (Trip)
- Type:
- Thermal Magnetic, Current Limiting
- Data Sheet:
- SchneiderElectric-SquareD_46410_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Application:
- Distribution
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Series:
- HD
- Prop 65 Warning:
- Yes
- Current Rating:
- 110 A
- CAD Drawings:
- SchneiderElectric_29585_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 3
- Country of Origin:
- Mexico
MSRP $3,377.79Surplus $912.00 -
Square D HDA36125 Molded Case Breakers (MCCBs)
MSRP $3,716.35Surplus $1,779.75SKU: C15-7149 Brand: Square D MPN: HDA36125 UPC: 78590141999 Shipping Weight: 5.95 lbs. Shipping Height: 6.00 In. Shipping Length: 15.00 In. Shipping Width: 9.00 In...- SKU:
- C15-7149
- TS PIK:
- 127231032
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load Terminal, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker
- Number of Poles:
- 3
- Current Rating:
- 125 A
- Series:
- HD
- Data Sheet:
- SchneiderElectric-SquareD_46411_1-3_DATA.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric_29586_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- Canada
- Approval:
- UL, CSA, CE
- Application:
- Distribution
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Trip Setting:
- 900 A (Hold), 1700 A (Trip)
MSRP $3,716.35Surplus $1,779.75 -
Contact Us For Quote
Square D HDA36125SA Molded Case Breakers (MCCBs)
MSRP $5,095.35Surplus $1,375.74SKU: C15-16421 Brand: Square D MPN: HDA36125SA UPC: 78590158004 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16421
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker with Shunt Trip
- Series:
- HD
- Number of Poles:
- 3
- Type:
- Thermal Magnetic, Current Limiting
- Approval:
- UL, CSA, CE
- Current Rating:
- 125 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Application:
- Distribution
- CAD Drawings:
- SchneiderElectric_29587_1_CAD.pdf
- Trip Setting:
- 900 A (Hold), 1700 A (Trip)
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46412_1-3_DATA.pdf
MSRP $5,095.35Surplus $1,375.74 -
Contact Us For Quote
Square D HDA36150SA Molded Case Breakers (MCCBs)
MSRP $3,478.12Surplus $939.09SKU: C15-16422 Brand: Square D MPN: HDA36150SA UPC: 78590132410 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16422
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_58_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Type:
- Thermal Magnetic, Current Limiting
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, ABC Phase, Line Lug Load, Thermal Magnetic, Current Limiting, Panelboard Molded Case Circuit Breaker with Shunt Trip
- Application:
- Distribution
- CAD Drawings:
- SchneiderElectric_29588_1_CAD.pdf
- Trip Setting:
- 900 A (Hold), 1700 A (Trip)
- Data Sheet:
- SchneiderElectric-SquareD_46414_1-3_DATA.pdf
- Used On:
- Class 611/612 I-Line Panelboard and Switchboard
- Series:
- HD
- Number of Poles:
- 3
- Current Rating:
- 150 A
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
MSRP $3,478.12Surplus $939.09 -
Contact Us For Quote
Square D HDA36150U31X Molded Case Breakers (MCCBs)
MSRP $2,830.14Surplus $764.14SKU: C15-16423 Brand: Square D MPN: HDA36150U31X UPC: 78590132440 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16423
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Line Lug Load, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Panelboard Molded Case Circuit Breaker
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 150 A
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46415_1-3_DATA.pdf
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA, CE
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_31_9_59_CAT.pdf
- Application:
- Distribution
- Used On:
- Class 611/612 I-Line Panelboard
- CAD Drawings:
- SchneiderElectric_29588_1_CAD.pdf
MSRP $2,830.14Surplus $764.14 -
Square D HDL36015 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $743.27SKU: C15-10713 Brand: Square D MPN: HDL36015 UPC: 78590157786 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10713
- TS PIK:
- 120730798
- Frame Type:
- H
- Prop 65 Warning:
- Yes
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 15 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Data Sheet:
- SchneiderElectric-SquareD_46443_1-3_DATA.pdf
- Current Rating:
- 15 A
- Number of Poles:
- 3
- Type:
- Thermal Magnetic, Current Limiting
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Maximum AC Voltage Rating:
- 600 V
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Terminal Type:
- Line/Load Lug
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Series:
- HD
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $743.27 -
Contact Us For Quote
Square D HDL36025 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $703.03SKU: C15-10715 Brand: Square D MPN: HDL36025 UPC: 78590157789 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10715
- TS PIK:
- 120730800
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46448_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Maximum AC Voltage Rating:
- 600 V
- Number of Poles:
- 3
- Frame Type:
- H
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Terminal Type:
- Line/Load Lug
- Type:
- Thermal Magnetic, Current Limiting
- Current Rating:
- 25 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 25 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Series:
- HD
- Prop 65 Warning:
- Yes
- Country of Origin:
- United States
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $703.03 -
Square D HDL36030 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $743.27SKU: C15-10716 Brand: Square D MPN: HDL36030 UPC: 78590170663 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10716
- TS PIK:
- 120736900
- Current Rating:
- 30 A
- Frame Type:
- H
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 30 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Type:
- Thermal Magnetic, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Number of Poles:
- 3
- Data Sheet:
- SchneiderElectric-SquareD_46450_1-3_DATA.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Terminal Type:
- Line/Load Lug
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $743.27 -
Square D HDL36035 Molded Case Breakers (MCCBs) HDL 3P 35A 600V 50/60Hz 3Ph H Frame
MSRP $1,481.09Surplus $1,124.43SKU: C15-2200 Brand: Square D MPN: HDL36035 UPC: 785901577911 Shipping Weight: 4.12 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-2200
- Series:
- HD
- Type:
- Positive Polarized
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Volts:
- 600 VAC 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 14 kA at 600 VAC
- Interrupting Rating:
- 20 Kiloamp at 250 Volt DC
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 35 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Data Sheet:
- EmersonElectric-Appleton_00126_3_4_DATA.pdf
- Installation/Operator:
- EmersonElectric-Appleton_00031_INST.pdf
- Manufacturer Warranty:
- EmersonElectric-Appleton_00002_WARR.pdf
- Voltage Rating:
- 600 VAC
- Number of Poles:
- 3
- Current Rating:
- 35 A
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Country of Origin:
- United States
MSRP $1,481.09Surplus $1,124.43 -
Square D HDL36040 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $703.03SKU: C15-10717 Brand: Square D MPN: HDL36040 UPC: 78590157792 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10717
- TS PIK:
- 120730803
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 40 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Series:
- HD
- Data Sheet:
- SchneiderElectric-SquareD_46455_1-3_DATA.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 40 A
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Type:
- Thermal Magnetic, Current Limiting
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Maximum AC Voltage Rating:
- 600 V
- Terminal Type:
- Line/Load Lug
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Frame Type:
- H
- Prop 65 Warning:
- Yes
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $703.03 -
Contact Us For Quote
Square D HDL36045 Molded Case Breakers (MCCBs)
MSRP $1,186.37Surplus $320.33SKU: C15-16428 Brand: Square D MPN: HDL36045 UPC: 78590145887 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16428
- Current Rating:
- 45 A
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 45 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Approval:
- UL, CSA, CE
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46458_1-3_DATA.pdf
- Terminal Type:
- Line/Load Lug
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Frame Type:
- H
MSRP $1,186.37Surplus $320.33 -
Contact Us For Quote
Square D HDL36050 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $1,013.90Square D HDL36050 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-6434 Brand: Square D MPN: HDL36050 UPC: 78590170670 Shipping Weight: 4.10 lbs. Shipping Height: 6.00 In. Shipping...- SKU:
- C15-6434
- TS PIK:
- 21033022
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Frame Type:
- H
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 3
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 50 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Series:
- HD
- Data Sheet:
- SchneiderElectric-SquareD_46459_1-3_DATA.pdf
- Current Rating:
- 50 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Terminal Type:
- Line/Load Lug
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA, CE
MSRP $1,481.09Surplus $1,013.90 -
Square D HDL36060 Molded Case Breakers (MCCBs)
MSRP $1,481.09Surplus $743.27SKU: C15-6435 Brand: Square D MPN: HDL36060 UPC: 78590157795 Shipping Weight: 4.10 lbs. Shipping Height: 6.00 In. Shipping Length: 9.00 In. Shipping Width: 8.00 In...- SKU:
- C15-6435
- TS PIK:
- 21033018
- Maximum DC Voltage Rating:
- 250 V
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46464_1-3_DATA.pdf
- Terminal Type:
- Line/Load Lug
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 60 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Frame Type:
- H
- Current Rating:
- 60 A
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Number of Poles:
- 3
- Prop 65 Warning:
- Yes
- Approval:
- UL, CSA, CE
- Country of Origin:
- Mexico
MSRP $1,481.09Surplus $743.27 -
Contact Us For Quote
Square D HDL36060SA Molded Case Breakers (MCCBs)
MSRP $3,702.74Surplus $999.74SKU: C15-16429 Brand: Square D MPN: HDL36060SA UPC: 78590159097 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16429
- Prop 65 Warning:
- Yes
- Current Rating:
- 60 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46470_1-3_DATA.pdf
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 60 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Approval:
- UL, CSA, CE
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Frame Type:
- H
MSRP $3,702.74Surplus $999.74 -
Contact Us For Quote
Square D HDL36060U31X Molded Case Breakers (MCCBs)
MSRP $1,293.24Surplus $349.17SKU: C15-18762 Brand: Square D MPN: HDL36060U31X UPC: 78590123047 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-18762
- Terminal Type:
- Line/Load Lug
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Frame Type:
- H
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 3
- Data Sheet:
- SchneiderElectric-SquareD_46472_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 60 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Molded Case Circuit Breaker
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Series:
- HD
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 60 A
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
MSRP $1,293.24Surplus $349.17 -
Square D HDL36070 Molded Case Breakers (MCCBs)
MSRP $1,807.81Surplus $961.54SKU: C15-10718 Brand: Square D MPN: HDL36070 UPC: 78590183985 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10718
- TS PIK:
- 120732133
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 70 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Current Rating:
- 70 A
- Number of Poles:
- 3
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46476_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Maximum AC Voltage Rating:
- 600 V
- Terminal Type:
- Line/Load Lug
- Maximum DC Voltage Rating:
- 250 V
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Prop 65 Warning:
- Yes
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Frame Type:
- H
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,807.81Surplus $961.54 -
Contact Us For Quote
Square D HDL36070SA Molded Case Breakers (MCCBs)
MSRP $4,278.57Surplus $1,155.21SKU: C15-16430 Brand: Square D MPN: HDL36070SA UPC: 78590147486 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16430
- Type:
- Thermal Magnetic, Current Limiting
- Frame Type:
- H
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Number of Poles:
- 3
- Approval:
- UL, CSA, CE
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Series:
- HD
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Data Sheet:
- SchneiderElectric-SquareD_46479_1-3_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Line/Load Lug
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 70 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 70 A
MSRP $4,278.57Surplus $1,155.21 -
Square D HDL36080 Molded Case Breakers (MCCBs)
MSRP $1,807.81Surplus $961.54SKU: C15-10719 Brand: Square D MPN: HDL36080 UPC: 78590162316 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10719
- TS PIK:
- 120731003
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Frame Type:
- H
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 80 A
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46480_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum DC Voltage Rating:
- 250 V
- Series:
- HD
- Number of Poles:
- 3
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 80 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,807.81Surplus $961.54 -
Contact Us For Quote
Square D HDL36080C Molded Case Breakers (MCCBs)
MSRP $3,501.26Surplus $945.34SKU: C15-16431 Brand: Square D MPN: HDL36080C UPC: 78590168253 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16431
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Series:
- HD
- Number of Poles:
- 3
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
- Terminal Type:
- Line/Load Lug
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46481_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Current Rating:
- 80 A
- Type:
- Thermal Magnetic, Current Limiting
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 80 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
MSRP $3,501.26Surplus $945.34 -
Contact Us For Quote
Square D HDL36080SA Molded Case Breakers (MCCBs)
MSRP $4,278.57Surplus $1,155.21SKU: C15-16432 Brand: Square D MPN: HDL36080SA UPC: 78590193066 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16432
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46482_1-3_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 80 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Current Rating:
- 80 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Approval:
- UL, CSA, CE
- Type:
- Thermal Magnetic, Current Limiting
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Series:
- HD
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Maximum DC Voltage Rating:
- 250 V
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
MSRP $4,278.57Surplus $1,155.21 -
Square D HDL36090 Molded Case Breakers (MCCBs)
MSRP $1,807.81Surplus $893.46SKU: C15-10720 Brand: Square D MPN: HDL36090 UPC: 78590195591 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10720
- TS PIK:
- 120732531
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Prop 65 Warning:
- Yes
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Frame Type:
- H
- Data Sheet:
- SchneiderElectric-SquareD_46483_1-3_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 90 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, 80% Continuous Current, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Current Rating:
- 90 A
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Line/Load Lug
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Number of Poles:
- 3
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $1,807.81Surplus $893.46 -
Contact Us For Quote
Square D HDL36100SA Molded Case Breakers (MCCBs)
MSRP $4,195.53Surplus $1,132.79SKU: C15-16433 Brand: Square D MPN: HDL36100SA UPC: 78590152557 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16433
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Prop 65 Warning:
- Yes
- Data Sheet:
- SchneiderElectric-SquareD_46491_1-3_DATA.pdf
- Maximum AC Voltage Rating:
- 600 V
- Number of Poles:
- 3
- Current Rating:
- 100 A
- Maximum DC Voltage Rating:
- 250 V
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Series:
- HD
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Frame Type:
- H
- Approval:
- UL, CSA, CE
MSRP $4,195.53Surplus $1,132.79 -
Square D HDL36100U31X Molded Case Breakers (MCCBs)
MSRP $1,683.76Surplus $454.61SKU: C15-16434 Brand: Square D MPN: HDL36100U31X UPC: 78590154832 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16434
- Current Rating:
- 100 A
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Approval:
- UL, CSA, CE
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Data Sheet:
- SchneiderElectric-SquareD_46492_1-3_DATA.pdf
- Series:
- HD
- Number of Poles:
- 3
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 100 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Molded Case Circuit Breaker
- Country of Origin:
- Mexico
MSRP $1,683.76Surplus $454.61 -
Square D HDL36110 Molded Case Breakers (MCCBs)
MSRP $2,017.45Surplus $1,341.60SKU: C15-10721 Brand: Square D MPN: HDL36110 UPC: 78590162319 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10721
- TS PIK:
- 120736809
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Prop 65 Warning:
- Yes
- Current Rating:
- 110 A
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Data Sheet:
- SchneiderElectric-SquareD_46495_1-3_DATA.pdf
- Number of Poles:
- 3
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Maximum DC Voltage Rating:
- 250 V
- Approval:
- UL, CSA, CE
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Series:
- HD
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 110 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Country of Origin:
- Mexico
MSRP $2,017.45Surplus $1,341.60 -
Contact Us For Quote
Square D HDL36110SA Molded Case Breakers (MCCBs)
MSRP $4,024.00Surplus $1,086.48SKU: C15-16437 Brand: Square D MPN: HDL36110SA UPC: 78590191124 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16437
- Maximum DC Voltage Rating:
- 250 V
- Data Sheet:
- SchneiderElectric-SquareD_46497_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Maximum AC Voltage Rating:
- 600 V
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Approval:
- UL, CSA, CE
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Type:
- Thermal Magnetic, Current Limiting
- Terminal Type:
- Line/Load Lug
- Number of Poles:
- 3
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Frame Type:
- H
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 110 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Series:
- HD
- Current Rating:
- 110 A
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
MSRP $4,024.00Surplus $1,086.48 -
Square D HDL36125 Molded Case Breakers (MCCBs)
MSRP $3,539.38Surplus $1,585.22SKU: C15-10722 Brand: Square D MPN: HDL36125 UPC: 78590195584 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-10722
- TS PIK:
- 120737055
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug Terminal, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker
- Frame Type:
- H
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Number of Poles:
- 3
- Current Rating:
- 125 A
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Series:
- HD
- Terminal Type:
- Line/Load Lug
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 600 V
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46498_1-3_DATA.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Country of Origin:
- Mexico
- Approval:
- UL, CSA, CE
MSRP $3,539.38Surplus $1,585.22 -
Contact Us For Quote
Square D HDL36125AA Molded Case Breakers (MCCBs)
MSRP $2,924.07Surplus $789.50SKU: C15-16438 Brand: Square D MPN: HDL36125AA UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In. Product...- SKU:
- C15-16438
- Number of Poles:
- 3
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Data Sheet:
- SchneiderElectric_18375_1-3_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 1NO-1NC 24 V Auxiliary Switch
- Current Rating:
- 125 A
- Frame Type:
- H
- Terminal Type:
- Line/Load Lug
- Maximum DC Voltage Rating:
- 250 V
- Maximum AC Voltage Rating:
- 600 V
- CAD Drawings:
- SchneiderElectric_29592_1_CAD.pdf
- Approval:
- UL, CSA, CE
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Series:
- HD
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
MSRP $2,924.07Surplus $789.50 -
Contact Us For Quote
Square D HDL36125AASA Molded Case Breakers (MCCBs)
MSRP $3,242.62Surplus $875.51SKU: C15-16439 Brand: Square D MPN: HDL36125AASA UPC: 60648628215 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16439
- Approval:
- UL, CSA, CE
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Frame Type:
- H
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 1NO-1NC Auxiliary Switch/Shunt Trip
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 125 A
- Number of Poles:
- 3
- Series:
- HD
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Terminal Type:
- Line/Load Lug
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Maximum AC Voltage Rating:
- 600 V
- Type:
- Thermal Magnetic, Current Limiting
- Data Sheet:
- SchneiderElectric-SquareD_42404_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Maximum DC Voltage Rating:
- 250 V
MSRP $3,242.62Surplus $875.51 -
Contact Us For Quote
Square D HDL36125SA Molded Case Breakers (MCCBs)
MSRP $6,803.78Surplus $1,837.02SKU: C15-16440 Brand: Square D MPN: HDL36125SA UPC: 78590156848 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16440
- Series:
- HD
- Prop 65 Warning:
- Yes
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 125 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Type:
- Thermal Magnetic, Current Limiting
- Frame Type:
- H
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Terminal Type:
- Line/Load Lug
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Maximum AC Voltage Rating:
- 600 V
- Maximum DC Voltage Rating:
- 250 V
- Current Rating:
- 125 A
- Number of Poles:
- 3
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46500_1-3_DATA.pdf
- Approval:
- UL, CSA, CE
MSRP $6,803.78Surplus $1,837.02 -
Contact Us For Quote
Square D HDL36150CU31X Molded Case Breakers (MCCBs)
MSRP $3,999.50Surplus $1,079.86SKU: C15-16441 Brand: Square D MPN: HDL36150CU31X UPC: 78590167200 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-16441
- Number of Poles:
- 3
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Molded Case Circuit Breaker
- Series:
- HD
- Data Sheet:
- SchneiderElectric-SquareD_46504_1-3_DATA.pdf
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Approval:
- UL, CSA, CE
- Maximum DC Voltage Rating:
- 250 V
- Terminal Type:
- Line/Load Lug
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Current Rating:
- 150 A
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
MSRP $3,999.50Surplus $1,079.86 -
Contact Us For Quote
Square D HDL36150SA Molded Case Breakers (MCCBs)
MSRP $6,803.78Surplus $1,837.02SKU: C15-16442 Brand: Square D MPN: HDL36150SA UPC: 78590158188 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-16442
- Current Rating:
- 150 A
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Thermal Magnetic, Current Limiting, Molded Case Circuit Breaker with 110/130 VAC Shunt Trip
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33_7_34_CAT.pdf
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Data Sheet:
- SchneiderElectric-SquareD_46507_1-3_DATA.pdf
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Series:
- HD
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Type:
- Thermal Magnetic, Current Limiting
- Prop 65 Warning:
- Yes
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Number of Poles:
- 3
- Terminal Type:
- Line/Load Lug
- Maximum DC Voltage Rating:
- 250 V
- Approval:
- UL, CSA, CE
- Frame Type:
- H
- Maximum AC Voltage Rating:
- 600 V
MSRP $6,803.78Surplus $1,837.02 -
Contact Us For Quote
Square D HDL36150U31X Molded Case Breakers (MCCBs)
MSRP $2,495.75Surplus $2,525.21SKU: U00-8165 Brand: Square D MPN: HDL36150U31X UPC: 78590154867 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- U00-8165
- Series:
- HD
- Number of Poles:
- 3
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Prop 65 Warning:
- Yes
- Terminal Type:
- Line/Load Lug
- Maximum AC Voltage Rating:
- 600 V
- Type:
- Electronic, Standard, Micrologic 3.2, LI, Current Limiting
- Data Sheet:
- SchneiderElectric-SquareD_46510_1-3_DATA.pdf
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Electronic, Standard, Micrologic 3.2, LI, Current Limiting, Molded Case Circuit Breaker
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Current Rating:
- 150 A
- Approval:
- UL, CSA, CE
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Frame Type:
- H
MSRP $2,495.75Surplus $2,525.21 -
Contact Us For Quote
Square D HDL36150U33X Molded Case Breakers (MCCBs)
MSRP $4,017.20Surplus $1,084.64SKU: C15-18764 Brand: Square D MPN: HDL36150U33X UPC: 78590156410 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- C15-18764
- Short Description:
- 600 VAC 50/60 Hz, 250 VDC, 150 A, 14 kA, 3-Pole, H-Frame, Unit Mount, Line/Load Lug, Electronic, Standard, Micrologic 3.2 S, LSI, Current Limiting, Molded Case Circuit Breaker
- Prop 65 Warning:
- Yes
- Voltage Rating:
- 600 VAC 50/60 Hertz, 250 VDC
- Installation/Operator:
- SchneiderElectric-Telemecanique_00047_INST.pdf
- Frame Type:
- H
- Series:
- HD
- Maximum AC Voltage Rating:
- 600 V
- Catalog:
- SchneiderElectric-SquareD_32357_7_6_7_31_7_33-7_35_CAT.pdf
- Terminal Type:
- Line/Load Lug
- Number of Poles:
- 3
- Maximum DC Voltage Rating:
- 250 V
- Data Sheet:
- SchneiderElectric-SquareD_46512_1-3_DATA.pdf
- Interrupting Rating:
- 14 kA at 600 VAC, 20 kA at 250 VDC
- Current Rating:
- 150 A
- Type:
- Electronic, Standard, Micrologic 3.2 S, LSI, Current Limiting
- Size:
- 4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height
- CAD Drawings:
- SchneiderElectric-SquareD_74672_1_CAD.pdf
- Approval:
- UL, CSA, CE
MSRP $4,017.20Surplus $1,084.64
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
