Cutler Hammer
Cutler-Hammer HFD3020L Molded Case Breakers (MCCBs) EA
- MPN:
- HFD3020L
- UPC:
- 78667917507
- SKU:
- C15-6794
Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: C15-6794
Brand: Cutler-Hammer
MPN: HFD3020L
UPC: 78667917507
Shipping Weight: 4.20 lbs.
Shipping Height: 4.00 In.
Shipping Length: 7.00 In.
Shipping Width: 5.00 In.
Product Notes:
Long Description: Cutler-Hammer HFD3020L Molded Case Breakers (MCCBs) EA
Specifications
Type: |
Molded Case, Thermal Magnetic |
Series: |
C, HFD |
Catalog: |
|
Installation/Operator: |
|
Terminal Type: |
Standard Pressure Line and Load |
CAD Drawings: |
|
Approval: |
UL 489, CSA C22.2 |
Number of Poles: |
3 |
Size: |
4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height |
Interrupting Rating: |
100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VDC, 22 kA at 250 VDC |
Voltage Rating: |
600 VAC, 250 VDC |
Current Rating: |
20 A |
Maximum DC Voltage Rating: |
250 V |
Frame Type: |
FD |
Maximum AC Voltage Rating: |
600 V |
