Square D
Square D HGL26020 Molded Case Breakers (MCCBs)
- MPN:
- HGL26020
- UPC:
- 78590143376
- SKU:
- U00-8185
Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: U00-8185
Brand: Square D
MPN: HGL26020
UPC: 78590143376
Shipping Weight: 0.00 lbs.
Shipping Height: 0.00 In.
Shipping Length: 0.00 In.
Shipping Width: 0.00 In.
Product Notes:
Long Description: Square D HGL26020 Molded Case Breakers (MCCBs)
Specifications
Current Rating: |
20 A |
Voltage Rating: |
600 VAC 50/60 Hertz, 250 VDC |
Size: |
4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height |
Frame Type: |
H |
Interrupting Rating: |
18 kA at 600 VAC, 20 kA at 250 VDC |
Maximum AC Voltage Rating: |
600 V |
Number of Poles: |
2 |
Installation/Operator: |
|
Approval: |
UL, CSA, CE |
Series: |
HG |
Type: |
Thermal Magnetic, Current Limiting |
CAD Drawings: |
|
Terminal Type: |
Line/Load Lug |
Maximum DC Voltage Rating: |
250 V |
Data Sheet: |
|
Catalog: |
