Square D
Square D HLL36090 Molded Case Breakers (MCCBs)
- MPN:
- HLL36090
- UPC:
- 78590168319
- SKU:
- U00-8203
Product Conditions
Surplus
Parts from another distributor or wholesaler that were only removed from the original packaging for inspection and pictures. These parts have never been energized, installed, or modified in any way.
Used
Parts that show any sign of being energized, installed, assembled with other parts, or functional wear or corrosion. These parts are sold as-is and returns may not be accepted.
Repackaged
Parts from another distributor or wholesaler that are missing the original packaging. These parts have never been energized, installed, or modified in any way and will ship in an ARCA box.
Description
SKU: U00-8203
Brand: Square D
MPN: HLL36090
UPC: 78590168319
Shipping Weight: 0.00 lbs.
Shipping Height: 0.00 In.
Shipping Length: 0.00 In.
Shipping Width: 0.00 In.
Product Notes:
Long Description: Square D HLL36090 Molded Case Breakers (MCCBs)
Specifications
Current Rating: |
90 A |
Maximum DC Voltage Rating: |
250 V |
Voltage Rating: |
600 VAC 50/60 Hertz, 250 VDC |
Interrupting Rating: |
50 kA at 600 VAC, 20 kA at 250 VDC |
CAD Drawings: |
|
Approval: |
UL, CSA, CE |
Terminal Type: |
Line/Load Lug |
Size: |
4.09 Inch Width x 3.39 Inch Depth x 6.42 Inch Height |
Number of Poles: |
3 |
Series: |
HL |
Data Sheet: |
|
Maximum AC Voltage Rating: |
600 V |
Installation/Operator: |
|
Type: |
Thermal Magnetic, Current Limiting |
Frame Type: |
H |
Catalog: |
