Eaton BQ2252120 Miniature Circuit Breakers (MCBs) BQ 2P 20A/25A 240V 50/60Hz 1Ph

SKU:

C15-1146

Series:

BQ

Volts:

240 V

Amps:

20 A/25 A

Poles:

2

Frequency Rating:

50/60 Hz

Short Description:

EATON BR THERMAL MAGNETIC CIRCUIT BREAKER,TYPE BQ 1-INCH CTL PLUG-ON CIRCUIT BRE

Country of Origin:

Dominican Republic

Number of Poles:

2

Type:

Thermal Magnetic

Current Rating:

20 A

Voltage Rating:

120/240 VAC

Interrupting Rating:

10 kA

Eaton BR225 Miniature Circuit Breakers (MCBs)

SKU:

C15-1225

Approval:

UL 489

Amps:

25 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

2

Size:

1.9 Inch Length x 2 Inch Width x 2.5 Inch Height

Terminal Type:

Thermal Magnetic

Type:

Common Trip

Used On:

BR Load Center

Volts:

120/240 VAC

Gauge:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 25 A, 10 kA, 2-Pole, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic, Circuit Breaker

Series:

BR

Specification/Technical:

Eaton_36608_1_SPEC.pdf

TS PIK:

21493857

Current Rating:

25 A

Number of Poles:

2

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Square D QOB3100 Miniature Circuit Breakers (MCBs) 3P 100A 240V

SKU:

C15-6600

TS PIK:

118952291

Installation/Operator:

SchneiderElectric-SquareD_02166_INST.pdf

Number of Poles:

3

Interrupting Rating:

10 kA at 120/240 VAC, 5 kA at 48 VDC

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 100 A, 10 kA, 3-Pole, Q-Frame, Bolt-On Mount, Box Lug Terminal, Miniature, Standard, Panelboard Circuit Breaker

Catalog:

SchneiderElectric-SquareD_32357_9_16_CAT.pdf

Voltage Rating:

120/240 VAC

Current Rating:

100 A

Series:

QOB

Data Sheet:

SchneiderElectric_21360_1_2_DATA.pdf

Type:

Miniature, Standard

Used On:

NQ Panelboard

Country of Origin:

United States

Approval:

UL, CSA

Installation:

Bolt-On

Eaton BAB2090 Miniature Circuit Breakers (MCBs) 2P 90A 240V EA

SKU:

C15-1070

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

10 kA at 120/240 VAC

Interrupting Rating:

5 kA at 24 to 48/62.5/80 Volt DC

Terminal Type:

Extended Tang Line

Terminal Type:

Box Lug Load

Wire Size:

8 to 1/0 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 90 A, 10 kA, 2-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_11_V4T1_12_V4T1_46_CAT.pdf

TS PIK:

21508699

Current Rating:

90 A

Number of Poles:

2

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton BRN115DF Miniature Circuit Breakers (MCBs)

SKU:

C15-1447

Type:

Dual Function

Type:

Pigtail Neutral

Approval:

UL

Size:

2.9 Inch Width x 2.9 Inch Depth x 0.9 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Load Center

Interrupting Rating:

10 kA

Application:

BR Load Center

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Poles:

1

Short Description:

120 VAC, 15 A, 1-Pole, 10 kA, Plug-On Mount, Dual Function, Pigtail

Catalog:

Eaton_00001_V1T1_50_V1T1_85_CAT.pdf

Current Rating:

15 A

Voltage Rating:

120 VAC

TS PIK:

127538895

Mounting:

Plug-On

Number of Poles:

1

Series:

BR

Country of Origin:

Dominican Republic

Eaton BRP120A1CS Miniature Circuit Breakers (MCBs)

SKU:

C15-2539

Approval:

UL

Amps:

20 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

3 Inch Width x 2.5 Inch Depth x 1 Inch Height

Type:

All-In-One

Used On:

BR Load Center

Volts:

120 VAC

Short Description:

120 V, 20 A, 10 kA Interrupt, 1-Pole, Plug-On Neutral, All-In-One, Type BR, Arc/Ground Fault Circuit Breaker

Specification/Technical:

EatonCorp_00337_1_2_SPEC.pdf

Current Rating:

20 A

Voltage Rating:

120 VAC

Number of Poles:

1

Series:

BR

TS PIK:

127754105

Country of Origin:

Dominican Republic

Eaton GHB1030 Molded Case Breakers (MCCBs) 1P 30A EA

SKU:

C15-3698

Series:

C

Type:

Fixed Thermal Magnetic

Type:

Molded Case

Approval:

UL 489

Approval:

CSA C22.2

Size:

1 Inch Width x 2.81 Inch Depth x 4.88 Inch Height

Volts:

277 VAC 50/60 Hertz

Volts:

125 VDC

Amps:

32 A

Poles:

1

Interrupting Rating:

65 kA at 120/240 VAC

Interrupting Rating:

14 kA at 125 Volt DC

Terminal Type:

Steel Pressure Line and Load

Frame Type:

GHB

Maximum AC Voltage Rating:

277 V

Maximum DC Voltage Rating:

125 V

Short Description:

277/480 VAC 50/60 Hz, 125 VDC, 30 A, 14 kA, 1-Pole, Steel Pressure Screw Line and Load Terminal, GHB Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_259_V4T2_260_CAT.pdf

Installation/Operator:

Eaton_00166_INST.pdf

TS PIK:

113893861

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Current Rating:

30 A

Number of Poles:

1

Country of Origin:

United States

Eaton PDG23M0100TFFL Molded Case Breakers (MCCBs)

SKU:

U00-8437

TS PIK:

127789136

Short Description:

PDG2_3P_100A_25kA/600V_FXFXTMTU

Cutler-Hammer HMCPE100R3C Motor Circuit Protector (MCPs) HMCP 3P 100A 480V NULL EA

SKU:

M01-2354

Approval:

UL 489

Approval:

CSA C22.2

Approval:

CE

Amps:

100 A

Frame:

EG

Maximum AC Voltage:

347 V

Maximum DC Voltage:

250 V

Motor FLA:

23 to 87 A

Poles:

3

Size:

2.99 Inch Width x 3 Inch Depth x 5.5 Inch Height

Starter Size:

NEMA 3

Terminal Type:

Non-Aluminum Line and Load Terminal

Trip Setting:

300 to 1100 A

Type:

Molded Case

Type:

Magnetic

Volts:

600 Star/347 VAC

Volts:

250 VDC

Short Description:

480 VAC, 600 Star/347 VAC, 250 VDC, 100 A, 300 to 1100 A Trip, 23 to 87 A FLA, 3-Pole, NEMA 3, Non-Aluminum Line and Load Terminal, EG Frame, Magnetic, Molded Case, Motor Circuit Protector

Series:

G, HMCPE

Specification/Technical:

Eaton_14476_1_2_SPEC.pdf

TS PIK:

115786307

Maximum AC Voltage Rating:

347 V

Frame Type:

EG

Maximum DC Voltage Rating:

250 V

Current Rating:

100 A

Catalog:

Eaton_27487_V4T2_225_CAT.pdf

Voltage Rating:

600 Star/347 VAC, 250 VDC

Number of Poles:

3

Country of Origin:

Dominican Republic

Eaton BAB1040 Miniature Circuit Breakers (MCBs) 1P 40A 120V EA

SKU:

C15-1026

Series:

BAB

Type:

Thermal Magnetic

Type:

Non-Interchangeable Trip

Type:

Miniature

Approval:

UL 489

Approval:

CSA

Size:

1.2 Inch Width x 3.6 Inch Depth x 4.8 Inch Height

Volts:

120/240 VAC

Volts:

24/48/62.5 VDC

Amps:

32 A

Poles:

1

Mounting:

Bolt-On

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48 Volt DC

Terminal Type:

Steel Box Lug Standard Load

Wire Size:

14 to 4 AWG Copper/Aluminum (Standard Load)

Short Description:

120/240 VAC, 40 A, 10 kA, 1-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_11_V4T1_12_V4T1_46_CAT.pdf

Number of Poles:

1

Current Rating:

40 A

Voltage Rating:

120/240 VAC

TS PIK:

21508671

Country of Origin:

Dominican Republic

Eaton BRCAF120QN Miniature Circuit Breakers (MCBs) BR 1P 20A 240V 50/60Hz 1Ph EA

SKU:

C15-1289

Series:

BR

Type:

Threaded Hub

Size:

1 Inch W x 3 Inch D x 5 Inch H

Amps:

32 A

Used On:

Type BR Loadcenter

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Poles:

1

Short Description:

20 A, 10 kA, 1-Pole, Quick Connect Neutral, Combination

Catalog:

Eaton_36650_V1T1_57_CAT.pdf

Current Rating:

20 A

Number of Poles:

1

Mounting:

Plug-On

Country of Origin:

Dominican Republic

Eaton JT410033 Trip Units JT 4P 100A 600V 50/60Hz

SKU:

A13-1084

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY TRIP UNIT, TRIP UNIT, 100 A, FOUR-PO

Country of Origin:

United States

Eaton QL2HT Circuit Breaker Accessories 2P 225A EA

SKU:

C15-2010

Accessory Type:

Handle Accessories

Breaker Type:

BR

Poles:

2

Type:

Handle Tie

Short Description:

2-Pole, BR Breaker, Circuit Breaker Handle Tie

TS PIK:

124125316

Country of Origin:

Dominican Republic

Square D EJB14020 Miniature Circuit Breakers (MCBs)

SKU:

C15-6417

TS PIK:

21032707

Voltage Rating:

277 VAC

Number of Poles:

1

Interrupting Rating:

65 kA at 480 Star/277 VAC

Catalog:

SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf

Short Description:

277 VAC, 20 A, 65 kA, 1-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_45697_1_2_DATA.pdf

Type:

Thermal Magnetic, Branch, Miniature

Used On:

NF Merchandised Panelboard

Current Rating:

20 A

Installation/Operator:

SchneiderElectric-SquareD_01117_INST.pdf

Series:

EJB

Country of Origin:

Mexico

Application:

Lighting

Installation:

Bolt-On

Approval:

UL (Canada and US)

Trip Setting:

270 A (Hold), 875 A (Trip)

Square D FH36020 Molded Case Breakers (MCCBs)

SKU:

C15-7189

Interrupting Rating:

18 kA at 600 VAC

Installation/Operator:

SchneiderElectric-SquareD_00076_INST.pdf

Number of Poles:

3

Catalog:

SchneiderElectric_00256_11_9_CAT.pdf

Current Rating:

20 A

Short Description:

240/480/600 VAC, 250 VDC, 20 A, 65/25/18/10 kA, 3-Pole, F-Frame, I-Line Mount, Thermal Magnetic, Molded Case Circuit Breaker

Series:

650, FH

Voltage Rating:

600 VAC, 250 VDC

Type:

Molded Case, Thermal Magnetic, Main

Data Sheet:

SchneiderElectric-SquareD_04551_1_2_DATA.pdf

Application:

Construction

Installation:

Plug-On

Used On:

I-Line Panelboard and Switchboard

Approval:

UL 489, CSA, IEC, Federal Specification W-C-375B/GEN

Trip Setting:

275 A Hold, 600 A Trip

Eaton AFGFTESTER Circuit Breaker Accessories EA

SKU:

C15-5034

UOM:

EA

Box Quantity:

1

Eaton BRML Circuit Breaker Accessories

SKU:

C15-2036

Constructional Feature:

0

Type:

Mechanical Interlock

Used On:

BR Series 2/3/4-Pole Circuit Breaker

Short Description:

Mechanical Interlock for 2/3/4-Pole Circuit Breaker

Specification/Technical:

Eaton_37766_1_SPEC.pdf

TS PIK:

116170144

Catalog:

Eaton_36650_V1T1_86_CAT.pdf

Country of Origin:

Dominican Republic

Eaton GFEP220 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-3892

Approval:

UL 489

Amps:

20 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

2

Terminal Trip Sensitivity:

30 MilliA

Type:

Common Trip

Used On:

Load Center

Volts:

120/240 VAC

Gauge:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 20 A, 10 kA, 30 mA Trip Level, 2-Pole, Plug-On Mount, Common Trip, Equipment Protector, Ground Fault Circuit Breaker

Series:

GFEP

Specification/Technical:

Eaton_39355_1_2_SPEC.pdf

TS PIK:

21494115

Number of Poles:

2

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

Current Rating:

20 A

Catalog:

Eaton_36601_V1T1_82_V1T1_85_V1T1_92_V1T1_93_CAT.pdf

Country of Origin:

Dominican Republic

Trip Sensitivity:

30 MilliA

GENERAL ELECTRIC THQLRK Circuit Breaker Accessories EA

SKU:

C15-5939

Short Description:

Retainer Kit for PowerMark Plus THQL Circuit Breaker

Used On:

THQL 225 A PowerMark Gold Main Breaker Load Center

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00008_INST.pdf

Type:

Retainer Kit

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00022_1_28_CAT.pdf

Siemens SC3 Miniature Circuit Breakers (MCBs) EA

SKU:

E30-8873

Short Description:

0.468" x 0.587" x 0.615", 0.03 to 0.125" Thick, Top In-Line Cable Tie Slot, 45 Lb Load Rated, Black, Nylon 6/6, Directional Angled Teeth Built-In, Thin Metal Edge, Wire Management Clip (500 per Bag)

Type:

Directional Angled Teeth Built-In, Thin Metal Edge

Series:

NWC

CAD Drawings:

ECMIndustries-IlscoCorp_04802_1_CAD.pdf

Catalog:

ECMIndustries-IlscoCorp_02049_459_CAT.pdf

Country of Origin:

Mexico

Square D EDB34040 Miniature Circuit Breakers (MCBs) EDB 3P 40A 277V 50/60Hz 3Ph EA

SKU:

C15-3583

Series:

EDB

Type:

Thermal Magnetic

Type:

Branch

Type:

Miniature

Approval:

UL (Canada and US)

Volts:

480 Star/277 VAC

Amps:

32 A

Used On:

NF Merchandised Panelboard

Poles:

3

Interrupting Rating:

18 kA at 480 Star/277 VAC

Application:

Lighting

Installation:

Bolt-On

Trip Setting:

630 A (Hold)

Trip Setting:

1800 Amp (Trip)

Short Description:

480 Star/277 VAC, 40 A, 18 kA, 3-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature

Catalog:

SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_45612_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_01117_INST.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

113878627

Number of Poles:

3

Voltage Rating:

480 Star/277 VAC

Current Rating:

40 A

Country of Origin:

United States

Eaton BABRSP1020 Miniature Circuit Breakers (MCBs) BAB 1P 20A 240V 50/60Hz 1Ph EA Remote Operation

SKU:

C15-1116

Series:

BABRSP

Type:

Branch

Approval:

UL 489

Approval:

CSA 22.2

Volts:

120 VAC at 50/60 Hz

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA

Application:

Lighting Control

Application:

Energy Management

Installation:

Bolt-On

Short Description:

120 VAC 50/60 Hz, 20 A, 10 kA, 1-Pole, Bolt-On

Catalog:

Eaton_03771_V4T1_30_V4T1_31_CAT.pdf

TS PIK:

119703660

Current Rating:

20 A

Voltage Rating:

120 VAC

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton EGH1020FFB Molded Case Breakers (MCCBs) EGH 1P 20A 240V 50/60Hz 1Ph EG Frame

SKU:

C15-4210

Series:

G

Type:

Molded Case

Type:

Fixed Thermal Fixed Magnetic

Approval:

UL

Approval:

CSA

Approval:

CE

Size:

1 Inch W x 2.99 Inch D x 5.5 Inch H

Volts:

480 VAC

Amps:

32 A

Poles:

1

Interrupting Rating:

65 kA at 480 VAC

Terminal Type:

Standard Pressure Line and Load Terminal

Terminal Type:

Bolt-On

Frame Type:

EG

Maximum AC Voltage Rating:

480

Short Description:

480 VAC, 20 A, 65 kA, 1-Pole, Bolt-On Terminal, EG Frame, Fixed Thermal, Fixed Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_142-V4T2_144_V4T2_153_V4T2_161_CAT.pdf

Voltage Rating:

480 VAC

Current Rating:

20 A

Number of Poles:

1

Square D HOM215 Miniature Circuit Breakers (MCBs) 2P 15A 120V

SKU:

C15-1599

Type:

Thermal Magnetic

Approval:

UL

Size:

2 Inch Width x 2.98 Inch Depth x 3.13 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

Load Center

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

ClA

Wire Size:

(1) 14 to 8 AWG (Copper/Aluminum)

Wire Size:

(2) 14 to 10 AWG (Copper)

Short Description:

120/240 VAC, 15 A, 10 kA, 2-Pole, Clamp Terminal, Plug-In Mount, Standard, Common Trip

Catalog:

SchneiderElectric-SquareD_03264_1_19_CAT.pdf

Data Sheet:

SchneiderElectric_15634_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02030_INST.pdf

CAD Drawing:

SchneiderElectric_30258_1_CAD.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

111081973

Voltage Rating:

120/240 VAC

Current Rating:

15 A

Number of Poles:

2

Series:

HOM

Country of Origin:

Mexico

Square D QOU115 Miniature Circuit Breakers (MCBs)

SKU:

C15-4929

Series:

QOU

Type:

Miniature

Type:

Standard

Approval:

UL

Approval:

CSA

Size:

0.75 Inch Width x 2.95 Inch Depth x 4.05 Inch Height

Volts:

120/240 VAC 50/60 Hertz

Volts:

48 VDC

Amps:

32 A

Used On:

OEM

Poles:

1

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Slotted Box Lug Line/Load

Wire Size:

14 to 2 AWG (Copper/Aluminum)

Short Description:

120/240 VAC 50/60 Hz, 48 VDC, 15 A, 10 kA Interrupt, 1-Pole, 14 to 2 AWG Copper/Aluminum, Unit Mount, Slotted Box Lug Line/Load Terminal, Standard

Catalog:

SchneiderElectric-SquareD_32357_7_19_7_21_CAT.pdf

Data Sheet:

SchneiderElectric_21454_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02170_INST.pdf

CAD Drawing:

SchneiderElectric_30265_1_CAD.pdf

Manufacturer Warranty:

SchneiderElectric-SquareD_00002_WARR.pdf

TS PIK:

113285771

Voltage Rating:

120/240 VAC

CAD Drawings:

SchneiderElectric_30265_1_CAD.pdf

Number of Poles:

1

Current Rating:

15 A

Country of Origin:

Mexico

SRPE60A60 Rating Plug SRPE 60A

SKU:

A13-1204

Maximum Breaker Current Rating:

60 A

Frame Type:

SE150

Short Description:

60 A, 60 A Maximum Breaker Current, 178 to 777 A Trip, 2 or 3-Pole, SE150 Frame, Interchangeable, Adjustable Instantaneous/Electronic Trip, Circuit Breaker Rating Plug

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_172_6_207_CAT.pdf

Specification/Technical:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00802_1_SPEC.pdf

Approval:

UL

Country of Origin:

United States

Eaton AN19BN0C5E020 Other Circuit Breakers

SKU:

C15-11265

TS PIK:

123893694

Eaton FAZ-C6/3-NA Din Rail Mounted Circuit Breakers EA

SKU:

C15-9280

TS PIK:

124501546

Interrupting Rating:

10 kA

Voltage Rating:

277/480 VAC

Wire Size:

18 to 4/18 to 8 AWG

Catalog:

Eaton_03771_V4T1_47-V4T1_72_CAT.pdf

Data Sheet:

Eaton_54022_1-5_DATA.pdf

Current Rating:

6 A

Number of Poles:

3

Size:

2.09 Inch Width x 2.36 Inch Depth x 4.13 Inch Height

Terminal Type:

Screw

Series:

FAZ

Type:

Thermal Magnetic

Mounting:

DIN Rail

Short Description:

277/480 VAC 50/60 Hz, 6 A, 3-Pole, 10/14 kA, 5 to 10 x Rated Current, Screw Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic, Miniature Circuit Breaker

Curve Type:

C

Approval:

UL 489, CSA C22.2

Country of Origin:

Germany

Trip Setting:

5 to 10 x Rated Current

Eaton HFD1015L Molded Case Breakers (MCCBs) 1P 15A

SKU:

C15-5517

TS PIK:

21331548

Current Rating:

15 A

Voltage Rating:

277 VAC 50/60 Hertz, 125 VDC

Frame Type:

FD

Catalog:

EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf

Number of Poles:

1

Type:

Fixed Thermal Magnetic, Molded Case

Data Sheet:

Eaton_07831_1-12_DATA.pdf

Interrupting Rating:

65 kA at 277 VAC, 10 kA at 125 VDC (UL), 65 kA at 220/240 VAC, 10 kA at 125 VDC (IEC)

Maximum DC Voltage Rating:

125 V

Maximum AC Voltage Rating:

277 V

CAD Drawings:

Eaton_41228_1_CAD.pdf

Installation/Operator:

Eaton_00091_INST.pdf

Size:

1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height

Terminal Type:

Line and Load

Country of Origin:

Dominican Republic

Approval:

UL 489, CSA C22.2

Eaton HFD3125 Molded Case Breakers (MCCBs) HFD 3P 125A 600V 50/60Hz 3Ph F Frame EA

SKU:

C15-1866

Series:

C

Type:

Fixed Thermal

Type:

Adjustable Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Size:

4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height

Volts:

600 VAC at 50/60 Hertz

Volts:

250 VDC

Amps:

32 A

Poles:

3

Interrupting Rating:

100 kA at 240 VAC

Interrupting Rating:

65 Kiloamp at 480 Volt AC at 50/60 Hertz

Interrupting Rating:

25 Kiloamp at 600 Volt DC

Interrupting Rating:

22 Kiloamp at 250 Volt DC

Terminal Type:

Standard Pressure Load

Frame Type:

FD

Maximum AC Voltage Rating:

600 V

Maximum DC Voltage Rating:

250 V

Short Description:

600 VAC 50/60 Hz, 250 VDC, 125 A, 65/22 kA, 3-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Installation/Operator:

Eaton_00372_INST.pdf

CAD Drawing:

Eaton_32657_1_2_CAD.pdf

TS PIK:

21506286

Number of Poles:

3

Data Sheet:

Eaton_32336_1-12_DATA.pdf

Voltage Rating:

480/600 VAC, 250 VDC

CAD Drawings:

Eaton_21588_1_CAD.pdf

Current Rating:

125 A

Country of Origin:

United States

Eaton QCR2030 Miniature Circuit Breakers (MCBs) QCR 2P 30A 240V 50/60Hz 1Ph EA

SKU:

C15-3919

Series:

QC

Type:

Branch

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

DIN Rail

Mounting:

Cable-In

Mounting:

Cable-Out

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

3000 A at 24 to 48 VDC

Interrupting Rating:

2000 A at 62.5 VDC

Terminal Type:

Box Lug

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 30 A, 10 kA, 2-Pole, Box Lug Terminal, Cable-In/Out, 35 MM DIN Rail Rear Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_23_V4T1_24_CAT.pdf

TS PIK:

106998243

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

30 A

Country of Origin:

Dominican Republic

Siemens B230 Miniature Circuit Breakers (MCBs) B 2P 30A 240V EA

SKU:

C15-2271

Type:

Molded Case

Type:

Branch

Type:

BL

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Interrupting Rating:

10 kA

Application:

Electrical Distribution

Installation:

Bolt-On

Short Description:

120/240 VAC 50/60 Hz, 30 A, 10 kA, 2-Pole, BL Frame, Bolt-On, Molded Case, Thermal and Fixed Magnetic Trip, Common Trip

Catalog:

SiemensAG_01502_5_8_5_19_10_14_CAT.pdf

Data Sheet:

SiemensAG_01508_1_DATA.pdf

Current Rating:

30 A

Voltage Rating:

120/240 VAC

Number of Poles:

2

Mounting:

Bolt-On

Series:

B

Country of Origin:

Mexico

Eaton CL120 Miniature Circuit Breakers (MCBs) 1P 20A EA

SKU:

C15-1591

Type:

Front Mount

Approval:

UL 489

Volts:

120/240 V

Amps:

32 A

Poles:

1

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 V, 20 A, 10 kA, 1-Pole, 14 to 4 AWG Copper/Aluminum, Thermal Magnetic, Type CL

Catalog:

Eaton_00001_V1T1_104_CAT.pdf

TS PIK:

119604531

Voltage Rating:

120/240 VAC

Current Rating:

20 A

Number of Poles:

1

Series:

CL

Country of Origin:

United States

Size:

8.45 Inch Length x 3.5 Inch Width x 1.5 Inch Height

Installation/Operator:

KleinTools_00228_INST.pdf

Square D EDB14030 Miniature Circuit Breakers (MCBs)

SKU:

C15-6356

TS PIK:

110613263

Type:

Thermal Magnetic, Branch, Miniature

Current Rating:

30 A

Used On:

NF Merchandised Panelboard

Catalog:

SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_01117_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_45551_1_2_DATA.pdf

Series:

EDB

Short Description:

277 VAC, 30 A, 18 kA, 1-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker

Interrupting Rating:

18 kA at 480 Star/277 VAC

Voltage Rating:

277 VAC

Number of Poles:

1

Country of Origin:

Mexico

Approval:

UL (Canada and US), IEC

Application:

Lighting

Installation:

Bolt-On

Trip Setting:

270 A (Hold), 875 A (Trip)

Challenger A1515 Miniature Circuit Breakers (MCBs) 1P 15/15A 50/60Hz 1Ph EA

SKU:

C15-8208

Number of Poles:

1

Eaton CHFCAF115CS Miniature Circuit Breakers (MCBs) CHF 1P 15A 120V 50/60Hz 1Ph

SKU:

C15-2535

Series:

CH

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON CH AFCI CIRCUIT BREAKER

Type:

Arc Fault

Number of Poles:

1

Current Rating:

15 A

Country of Origin:

Dominican Republic

Eaton CSR2100N Main Breakers CSR 2P 100A 240V 50/60Hz 1Ph EA

SKU:

C15-1977

Series:

CSR

Type:

Common Trip

Volts:

120/240 VAC

Amps:

32 A

Used On:

CH Series Load Center

Poles:

2

Interrupting Rating:

25 kA

Terminal Type:

Load Lug

Wire Size:

2 AWG to 300 KCMIL (Copper/Aluminum)

Specification/Technical:

EatonCorp_00204_1_2_SPEC.pdf

Current Rating:

100 A

Number of Poles:

2

Frame Type:

CH

Voltage Rating:

120/240 V

Short Description:

Type CSR Standard Circuit Breaker,Standard circuit breaker,100 A,25 kAIC,Two-pole,120/240 V,CH,#2 - 300 kcmil,Q1,CSR,Type CH loadcenters

Country of Origin:

Dominican Republic

Eaton FAZ-D40/2 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-5259

Series:

FAZ

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 1077

Approval:

UL (Canada and US)

Approval:

CSA C22.2

Approval:

CE

Size:

1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height

Volts:

277/480 VAC

Amps:

32 A

Poles:

2

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Screw

Wire Size:

18 to 4/18 to 8 AWG

Trip Setting:

10 to 20 x Rated Current

Short Description:

277/480 VAC 50/60 Hz, 40 A, 2-Pole, 10 kA, 10 to 20 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, D-Curve, Current Limiting, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_74-V4T1_92_CAT.pdf

Data Sheet:

Eaton_54188_1-9_DATA.pdf

Voltage Rating:

277/480 VAC

Current Rating:

40 A

Number of Poles:

2

Curve Type:

D

Country of Origin:

Germany

Eaton JHMVD12B Circuit Breaker Accessories Vari-Depth Handle Mechanism J Frame EA

SKU:

C15-1502

Approval:

UL

Approval:

CSA

Enclosure:

NEMA 1/12

Switch Type:

Molded Case

Breaker Type:

F Frame

Handle Type:

Black Universal Rotary

Handle Included:

Yes

Shaft Length:

12

Handle Mounting Location:

Left

Short Description:

12" Shaft, F Frame, Molded Case Switch, Black Universal Rotary

Catalog:

Eaton_41386_153_CAT.pdf

TS PIK:

115793073

Country of Origin:

Dominican Republic

GENERAL ELECTRIC SELA36AT0100 Molded Case Breakers (MCCBs)

SKU:

C15-6874

TS PIK:

125878947

Voltage Rating:

600 VAC

Short Description:

600 VAC, 100 A Sensor, 65 kA Interrupt, 3-Pole, 12 to 3/0 AWG Aluminum/Copper, SE150 Frame, Digital, Solid State Electronic/Interchangeable Trip, RMS Trip Unit, LSI Trip Function, Standard Continuous Load, Molded Case Circuit Breaker

Series:

SEL

Frame Type:

E

Number of Poles:

3

Size:

4.12 Inch Width x 3.38 Inch Depth x 6.31 Inch Height

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC (UL), 100 kA at 220 to 240 VAC, 20 kA at 380 to 415 VAC, 8 kA at 500 VAC, 3 kA at 690 VAC (IEC)

Maximum AC Voltage Rating:

600 V

Type:

Molded Case, Electronic Solid State Trip, Current Limiting

Current Rating:

100 A

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01751_1_CAD.pdf

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_5_6_6_6_172_CAT.pdf

Approval:

UL, CSA

Murray MP1515N Miniature Circuit Breakers (MCBs) 1P 15/15A 50/60Hz 1Ph EA

SKU:

C15-6297

Data Sheet:

SiemensAG_01518_1_DATA.pdf

Used On:

Loadcenter

Terminal Type:

Load Lug

Wire Size:

14 to 8 AWG (Copper), 12 to 8 AWG (Aluminum)

Current Rating:

15 A

Mounting:

Plug-On

Short Description:

120 V, 15/15 A, 10 kA, 1-Pole, Load Lug Terminal, MH-T Frame, Thermal Magnetic, Low Vage, Miniature, Circuit Breaker

Type:

Duplex

Number of Poles:

1

Voltage Rating:

120 VAC

Interrupting Rating:

10 kA

Country of Origin:

Mexico

Square D QO130GFI Miniature Circuit Breakers (MCBs) 30A 120V

SKU:

C15-6581

TS PIK:

118952369

Series:

QO-GFI

Short Description:

120 VAC 50/60 Hz, 30 A, 10 kA Interrupt, 1-Pole, Plug-In Mount, 1-Panel Space, Pressure Plate Terminal, 6 mA Class A Ground Fault, Pigtail, Miniature Circuit Breaker

Current Rating:

30 A

Installation/Operator:

SchneiderElectric-SquareD_00193_INST.pdf

Type:

Thermal Magnetic, Equipment Protector

Interrupting Rating:

10 kA

Number of Poles:

1

Data Sheet:

SchneiderElectric-SquareD_14869_1_2_DATA.pdf

Terminal Type:

Pressure Plate

Size:

0.75 Inch W x 2.91 Inch D x 4.12 Inch H

Catalog:

SchneiderElectric-SquareD_03264_1_5_CAT.pdf

Voltage Rating:

120 VAC at 50/60 Hz (UL/CSA)

Wire Size:

12 to 8 AWG (Aluminum), 14 to 8 AWG (Copper)

Mounting:

Plug-On

Used On:

QO Loadcenter, NQOD Panelboard, OEM Interior/Speed-D Switchboard Distribution Panel

Country of Origin:

Mexico

Trip Sensitivity:

6 MilliA

Approval:

UL, CSA

Eaton CH120AF Miniature Circuit Breakers (MCBs) EA

SKU:

C15-1374

Approval:

UL

Construction Feature:

Arc Fault Circuit Interrupter

Amps:

20 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

4 Inch Length x 0.75 Inch Width x 3.5 Inch Height

Terminal Type:

Clip (Line)

Type:

Thermal Magnetic

Used On:

Load Center

Volts:

120/240 VAC

Short Description:

120/240 VAC, 20 A, 10 kA, 1-Pole, Clip Line Terminal, Plug-On Mount, Thermal Magnetic, Branch Feeder, Arc Fault Circuit Breaker

Series:

CH

TS PIK:

119471855

Wire Size:

14 to 8 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

Current Rating:

20 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Application:

HACR

Eaton QBHW2060H Molded Case Breakers (MCCBs) EA

SKU:

C15-9649

TS PIK:

21505489

Catalog:

Eaton_03771_V4T1_12_CAT.pdf

Number of Poles:

2

Series:

QBHW

Current Rating:

60 A

Voltage Rating:

240 VAC

Type:

Thermal Magnetic

Short Description:

240 VAC, 60 A, 22 kA, 2-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature, Circuit Breaker

Terminal Type:

Extended Tang Line Terminal, Box Lug Load Terminal

Interrupting Rating:

22000 A at 240 VAC

Mounting:

Bolt-On

Wire Size:

8 to 1/0 AWG (Aluminum/Copper, Load)

Approval:

UL 489, CSA

Country of Origin:

United States

Eaton QCF2050 Miniature Circuit Breakers (MCBs) QCF 2P 50A 120V 50/60Hz 1Ph EA

SKU:

C15-1663

Series:

QCF

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Cable-In/Cable-Out

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

3000 A at 24 to 48 Volt DC

Interrupting Rating:

3800 A at 62.5 Volt DC

Terminal Type:

Box Lug

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 50 A, 10 kA, 2-Pole, Box Lug Terminal, Cable-In/Out Front Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_23_V4T1_25_CAT.pdf

Voltage Rating:

120/240 VAC

Current Rating:

50 A

Number of Poles:

2

TS PIK:

106998233

Country of Origin:

Dominican Republic

Abb SU201M-K3 Miniature Circuit Breakers (MCBs) 1P 3A 277V 50/60Hz

SKU:

C15-3392

Approval:

UL 489

Approval:

CSA C22.2

Approval:

CE

Amps:

3 A

Interrupting Rating:

10 kA

Mounting:

DIN Rail

Poles:

1

Size:

69 Millimeter Length x 17.5 Millimeter Width x 111 Millimeter Height

Terminal Type:

Failsafe Bi-Directional Cylinder Lift Double ClA Screw

Type:

Current Limiting

Used On:

Motor

Volts:

480 Star/277 VAC 50/60 Hertz

Volts:

48/96 VDC

Gauge:

18 to 4 AWG (Conductor)

Gauge:

18 to 8 AWG (Busbar)

Short Description:

69 MM x 17.5 MM x 111

Voltage Rating:

480 Star/277 VAC 50/60 Hertz, 48/96 VDC

Current Rating:

3 A

Number of Poles:

1

Catalog:

ABBInstallationProducts_00808_4_6_CAT.pdf

Data Sheet:

ABBInstallationProducts_00911_1-7_10_DATA.pdf

Installation/Operator:

ABBInstallationProducts_00074_INST.pdf

Wire Size:

18 to 4 AWG (Conductor), 18 to 8 AWG (Busbar)

Country of Origin:

Italy

Eaton BQ240250 Miniature Circuit Breakers (MCBs) BQ 2P 40A/50A 120V 50/60Hz 1Ph EA

SKU:

C15-1157

Series:

BQ

Type:

Thermal Magnetic

Type:

Common Trip

Type:

Quadplex

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Loadcenter

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 40/50 A, 10 kA, 2-Pole Outer/2-Pole Center, Plug-On Mount, BQ Breaker, Independent Trip, Quadplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_83_V1T1_87_CAT.pdf

TS PIK:

21493966

Number of Poles:

2

Current Rating:

40/50 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton BR3HT Circuit Breaker Accessories

SKU:

C15-2012

Breaker Type:

BR

Poles:

1

Short Description:

1-Pole, BR Breaker, Circuit Breaker Handle Tie

Series:

BR

Specification/Technical:

Eaton_36194_1_SPEC.pdf

TS PIK:

123342677

Country of Origin:

Dominican Republic

Eaton BRP115DF Miniature Circuit Breakers (MCBs)

SKU:

C15-2236

Type:

Dual Function

Type:

Plug-On Neutral

Approval:

UL

Size:

2.9 Inch Width x 2.9 Inch Depth x 0.9 Inch Height

Volts:

120 VAC

Amps:

32 A

Interrupting Rating:

10 kA

Application:

BR Load Center

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Poles:

1

Short Description:

120 VAC, 15 A, 1-Pole, 10 kA, Plug-On Neutral, Dual Function

Catalog:

Eaton_00001_V1T1_50_V1T1_85_CAT.pdf

Voltage Rating:

120 VAC

Current Rating:

15 A

TS PIK:

127539055

Mounting:

Plug-On

Number of Poles:

1

Series:

BR

Country of Origin:

United States

Eaton CHFGFT120 Miniature Circuit Breakers (MCBs) CHF 1P 20A 120V 50/60Hz 1Ph EA

SKU:

C15-1445

Series:

CH

Type:

Thermal Magnetic

Size:

3.5 Inch Length x 1 Inch Width x 3 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Clip (Line)

Wire Size:

14 to 6 AWG (Copper/Aluminum)

Trip Sensitivity:

5 MilliA

Short Description:

120 VAC, 20 A, 10 kA, 5 mA Trip Level, 1-Pole, Plug-On Mount, Thermal Magnetic

Catalog:

Eaton_00069_33_CAT.pdf

TS PIK:

126205839

Current Rating:

20 A

Voltage Rating:

120 VAC

Number of Poles:

1

Country of Origin:

United States

Eaton CHL125N Miniature Circuit Breakers (MCBs) 3P 125A 240V EA

SKU:

L19-1786

Series:

CH

Type:

Main Lug

Used On:

Type CH Loadcenter

Conductor Size:

10 to 1/0 AWG

Short Description:

125 A, #10-1/0, NEMA 3R

Catalog:

Eaton_36601_V1T1_2_V1T1_11_V1T1_21_CAT.pdf

TS PIK:

111009780

Number of Poles:

1

Country of Origin:

United States

Eaton EGH1100FFB Molded Case Breakers (MCCBs) EGH 1P 100A 240V 50/60Hz 1Ph EG Frame

SKU:

C15-2091

Series:

G

Volts:

240 V

Amps:

100 A

Poles:

1

Frequency Rating:

50/60 Hz

Frame:

EG

Short Description:

EGH BOLT ON 1P 100A BRANCH BREAKER FOR PRL3E

Current Rating:

100 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton HMCP100R3CH09 Motor Circuit Protector (MCPs)

SKU:

C15-11301

TS PIK:

110190698

Short Description:

SERIES C, F-FRAME MOTOR CIRCUIT PROTECTOR 3P 100A CB Molded Case Circuit Breakers

Number of Poles:

3

Current Rating:

100 A

Frame Type:

F

Voltage Rating:

600 VAC

Eaton HMCPS150U4C Motor Circuit Protector (MCPs)

SKU:

C15-9266

Short Description:

150 A, 3-Pole, 750 to 2500 A, Trip Setting, Motor Circuit Protector

Current Rating:

150 A

Terminal Type:

Non-Aluminum

Data Sheet:

Eaton_00054_1-9_DATA.pdf

Catalog:

Eaton_21665_V4T2_362_V4T2_363_V4T2_368_CAT.pdf

Installation/Operator:

Eaton_00176_INST.pdf

Country of Origin:

Dominican Republic

Trip Setting:

750 to 2500 A

Eaton LT3500FA Trip Units

SKU:

A13-1049

TS PIK:

120602137

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY TRIP UNIT, TRIP UNIT, 500 A, THREE-POLE, FIXED THERMAL, ADJUSTABLE MAGNETIC, LT, FRAME LG, SERIES G

GE TEDST12 Shunt Trips EA

SKU:

A13-1320

Type:

Remote

Used On:

Circuit Breaker

Short Description:

120/240 VAC, 125 VDC, Remote Control

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01912_6_71_CAT.pdf

Square D QO1HPL Circuit Breaker Accessories EA

SKU:

C15-6532

Type:

Padlockable

Short Description:

2/3-Pole, On/Off Locking, Loose Handle Padlock Attachment for QO/Q1 Series Circuit Breaker

Installation/Operator:

SchneiderElectric-SquareD_00884_INST.pdf

Used On:

QO/Q1 Series Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_14908_1_DATA.pdf

Catalog:

SchneiderElectric-SquareD_03264_1_8_CAT.pdf

Locking Provision:

On/Off

Crouse-Hinds BRCAF120 Miniature Circuit Breakers (MCBs) BR 1P 20A 50/60Hz 1Ph EA

SKU:

C15-5384

TS PIK:

124548669

Short Description:

120 V, 20 A, 10 kA, 1-Pole, Plug-On Mount, Combination, Arc Fault Circuit Breaker

Series:

BR

Voltage Rating:

120 V

Mounting:

Plug-On

Type:

Combination

Current Rating:

20 A

Size:

6 Inch Length x 3.5 Inch Width x 1.25 Inch Height

Interrupting Rating:

10 kA

Catalog:

Eaton_36650_V1T1_76_V1T1_79_CAT.pdf

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Used On:

Loadcenter

Number of Poles:

1

Country of Origin:

Dominican Republic

Approval:

UL 1699

Poles:

1

Eaton BR350 Miniature Circuit Breakers (MCBs)

SKU:

C15-11092

TS PIK:

21493898

Series:

BR

Voltage Rating:

240 VAC

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Catalog:

Eaton_36620_V1T1_85_CAT.pdf

Type:

Thermal Magnetic, Common Trip

Short Description:

240 VAC, 50 A, 10 kA, 3-Pole, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic, Circuit Breaker

Current Rating:

50 A

Mounting:

Plug-On

Used On:

BR Series Load Center

Number of Poles:

3

Approval:

UL 489

Country of Origin:

Dominican Republic

Eaton FAZ-D10/3 Miniature Circuit Breakers (MCBs) FAZ 3P 10A 277V 50/60Hz 3Ph EA

SKU:

C15-3506

Series:

FAZ

Approval:

UL 1077

Approval:

CSA C22.2

Size:

2.07 Inch L

Volts:

400 V

Amps:

32 A

Poles:

3

Mounting:

DIN Rail

Terminal Type:

Screw

Trip Setting:

10 to 20 x Rated Current (Magnetic)

Short Description:

480 VAC Star/277 VAC, 96 VDC, 10 A, 15 kA, 10 to 20 x Rated Current, 3-Pole, Screw Terminal, DIN Rail Mount

Catalog:

Eaton_03771_V4T1_74_V4T1_75_V4T1_78_V4T1_85_V4T1_86_V4T1_88_V4T1_92_CAT.pdf

Data Sheet:

Eaton_40766_1-9_DATA.pdf

Installation/Operator:

Eaton_00479_INST.pdf

TS PIK:

124503353

Number of Poles:

3

Current Rating:

10 A

Voltage Rating:

400 VAC

Curve Type:

D

Country of Origin:

Germany

Eaton FD1020 Molded Case Breakers (MCCBs) GHB 2P 40A 480V 50/60Hz 3Ph G Frame EA

SKU:

C15-1804

Frame Type:

F

Voltage Rating:

277 VAC

Current Rating:

32 A

Number of Poles:

1

Interrupting Rating:

35 kA at 277 VAC,10 kA at 125 VDC

Type:

Current Limiting

Maximum AC Voltage Rating:

277

Maximum DC Voltage Rating:

125

Terminal Type:

Standard Pressure Load Terminal

Size:

1.38 Inch W x 3.38 Inch D x 6 Inch H

Short Description:

277 VAC 50/60 Hz, 125 VDC, 20 A, 35/10 kA, 1-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Data Sheet:

Eaton_07831_1-5_DATA.pdf

Installation/Operator:

Eaton_00091_INST.pdf

CAD Drawings:

Eaton_41226_1_CAD.pdf

Series:

C

Approval:

UL

Country of Origin:

United States

Eaton KD3350W Molded Case Breakers (MCCBs) KD 3P 350A 600V 50/60Hz 3Ph K Frame EA

SKU:

C15-3948

Series:

C

Volts:

600 V

Amps:

350 A

Poles:

3

Frequency Rating:

50/60 Hz

Frame:

K

Short Description:

EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, K-FRAME, KD, COMPLETE BREAK

TS PIK:

115573590

Country of Origin:

Dominican Republic

Eaton QCF2010T Miniature Circuit Breakers (MCBs) QCF 2P 10A 240V 50/60Hz 1Ph

SKU:

C15-1998

Series:

Quicklag

Volts:

240 V

Amps:

10 A

Poles:

2

Frequency Rating:

50/60 Hz

Short Description:

QCF BKR 2P 10A W/ RING LUG TERM.

Country of Origin:

Dominican Republic

Eaton BR2100 Miniature Circuit Breakers (MCBs)

SKU:

C15-1215

Series:

BR

Type:

Thermal Magnetic

Type:

Common Trip

Approval:

UL 489

Approval:

CSA

Size:

1.9 Inch Length x 2 Inch Width x 2.4 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Load Center

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Lug

Wire Size:

4 to 1/0 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 100 A, 10 kA, 2-Pole, Lug Screw Terminal, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_56_V1T1_84_CAT.pdf

TS PIK:

21493865

Number of Poles:

2

Current Rating:

100 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton DNPL154015 Miniature Circuit Breakers (MCBs) BRD 2P 15A/40A 240V 50/60Hz 3Ph

SKU:

C15-2964

Series:

DNPL

Type:

Quadplex

Type:

Independent Trip

Approval:

UL

Approval:

CSA

Volts:

Centre (120/240 VAC)

Volts:

Outer Left/Right (120 VAC)

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC Center, 120 VAC Outer Left/Right, 40/15 A, (2) 1-Pole, (1) 2-Pole, 10 kA, Plug-In Mount, Quadplex, Independent Trip

Catalog:

Eaton_00069_16_18_CAT.pdf

Number of Poles:

2

Current Rating:

40/15A

Voltage Rating:

120/240 VAC

Country of Origin:

United States

Eaton EHD2020 Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame

SKU:

C15-1882

Series:

C, EHD

Type:

Duplex with LED Indicator Light

Approval:

UL

Size:

2.75 Inch W x 3.38 Inch D x 6 Inch H

Volts:

480 VAC at 50/60 Hz

Volts:

250 VDC

Amps:

32 A

Poles:

2

Interrupting Rating:

14 kA at 480 VAC

Interrupting Rating:

10 Kiloampere at 250 VDC

Terminal Type:

Standard Pressure Load Terminal

Frame Type:

F

Maximum AC Voltage Rating:

480

Maximum DC Voltage Rating:

250

Short Description:

480 VAC 50/60 Hz, 250 VDC, 20 A, 14/10 kA, 2-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Data Sheet:

LegrandNorthAmerica-Pass&Seymour_03871_1-4_DATA.pdf

Installation/Operator:

LegrandNorthAmerica-Pass&Seymour_00236_INST.pdf

Number of Poles:

2

Current Rating:

20 A

Voltage Rating:

480 VAC at 50/60 Hz, 250 VDC

Country of Origin:

Dominican Republic

Eaton GCWTK Circuit Breaker Accessories Control Wire Terminal Kit J-K Frame 12PK

SKU:

C15-2296

Type:

Control Wire Tab/Terminal

Used On:

PDG1X3TA125/PDG1X3T125 C Series J/K Frame Power Defense Molded Case Circuit Breaker

Specification/Technical:

Eaton_12459_1_2_SPEC.pdf

TS PIK:

117049645

Catalog:

Eaton_03771_V4T2_25_V4T2_128_V4T2_416_CAT.pdf

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY TERMINAL KIT, CONTROL WIRE TERMINAL

Country of Origin:

Dominican Republic

Eaton GDINBP10 DIN Rail and Accessories Din Rail Attachment

SKU:

C26-1182

Type:

DIN Rail Kit

Used On:

Circuit Breaker

Short Description:

2" x 0.5" x 2", 3-Pole

Siemens QA115AFC Molded Case Breakers (MCCBs) QA 1P 15A 120V EA

SKU:

C15-4212

Type:

Combination Arc-Fault

Approval:

UL 1699

Size:

1 Inch Width x 6 Inch Depth x 3 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Load Center

Mounting:

Plug-On

Interrupting Rating:

10 kA

Application:

120 V Fluorescent Lighting

Wire Size:

14 to 8 AWG (Copper)

Wire Size:

12 to 8 AWG (Aluminum)

Poles:

1

Short Description:

120 VAC, 15 A, 10 kA, 1-Pole, Plug-In Mount, QAF2 Frame, Combination AFCI

Catalog:

SiemensAG_00562_1_40_CAT.pdf

Data Sheet:

SiemensAG_07079_1_DATA.pdf

TS PIK:

111034706

Voltage Rating:

120 VAC

Current Rating:

15 A

Country of Origin:

Philippines

Square D QOB115GFI Miniature Circuit Breakers (MCBs) 15A 120V

SKU:

C15-6384

TS PIK:

124023841

Size:

0.75 Inch W x 2.91 Inch D x 4.12 Inch H

Voltage Rating:

120 VAC at 50/60 Hz (UL/CSA)

Used On:

NQOD Panelboard/Interior

Terminal Type:

Pressure Plate

Installation/Operator:

SchneiderElectric-SquareD_00193_INST.pdf

Current Rating:

15 A

Series:

QOB-GFI

Short Description:

120 VAC 50/60 Hz, 15 A, 10 kA Interrupt, 1-Pole, Bolt-On Mount, 1-Panel Space, Pressure Plate Terminal, Pigtail, 6 mA Class A Ground Fault, Miniature Circuit Breaker

Interrupting Rating:

10 kA

Number of Poles:

1

Data Sheet:

SchneiderElectric-SquareD_15104_1_2_DATA.pdf

Type:

Thermal Magnetic, Equipment Protector

Catalog:

SchneiderElectric-SquareD_03283_9_14_CAT.pdf

Wire Size:

14 to 8 AWG (Aluminum/Copper)

Mounting:

Bolt-On

Prop 65 Warning:

Yes

Country of Origin:

United States

Approval:

UL, CSA

Trip Sensitivity:

6 MilliA

Square D QOU230VH Miniature Circuit Breakers (MCBs) EA

SKU:

C15-5292

Approval:

UL

Approval:

CSA

Amps:

30 A

Interrupting Rating:

22 kA

Mounting:

DIN Rail

Poles:

2

Size:

1.5 Inch Width x 2.95 Inch Depth x 4.05 Inch Height

Terminal Type:

Slotted Box Lug Line/Load

Type:

Miniature

Type:

Standard

Used On:

OEM

Volts:

120/240 VAC 50/60 Hertz

Gauge:

14 to 2 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 30 A, 22 kA Interrupt, 2-Pole, 14 to 2 AWG Copper/Aluminum, Unit Mount, Slotted Box Lug Line/Load, Standard, Miniature Circuit Breaker

Series:

QOU

Data Sheet:

SchneiderElectric_21578_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02171_INST.pdf

CAD Drawing:

SchneiderElectric_30267_1_CAD.pdf

Catalog:

SchneiderElectric-SquareD_32357_7_19_7_21_CAT.pdf

CAD Drawings:

SchneiderElectric_30267_1_CAD.pdf

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

30 A

Wire Size:

14 to 2 AWG (Copper/Aluminum)

Country of Origin:

United States

Eaton BAB2020H Miniature Circuit Breakers (MCBs) BAB 2P 20A 240V 50/60Hz 1Ph EA

SKU:

C15-1042

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

240 VAC

Amps:

32 A

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48/62.5/80 VDC

Terminal Type:

Extended Tang Line Terminal

Terminal Type:

Box Lug Load Terminal

Wire Size:

14 to 4 AWG Aluminum/Copper (Load)

Short Description:

240 VAC, 20 A, 10 kA, 2-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_3_V4T1_11_V4T1_12_CAT.pdf

TS PIK:

21508681

Current Rating:

20 A

Voltage Rating:

240 VAC

Number of Poles:

2

Country of Origin:

Dominican Republic

Eaton GHB3100 Molded Case Breakers (MCCBs) GHB 3P 100A 240V 50/60Hz 3Ph G Frame EA

SKU:

C15-3398

Series:

C

Type:

Molded Case

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Size:

3.8 Inch Width x 6.6 Inch Depth x 4 Inch Height

Volts:

277/480 VAC at 50/60 Hertz

Volts:

125/250 VDC

Amps:

32 A

Poles:

3

Interrupting Rating:

14 kA at 480 VAC Star/277 VAC/125/250 VDC

Terminal Type:

Aluminum Pressure Line and Load

Frame Type:

GHB

Maximum AC Voltage Rating:

480 V

Maximum DC Voltage Rating:

250 V

Short Description:

277/480 VAC 50/60 Hz, 125 VDC, 100 A, 14 kA, 3-Pole, Steel Pressure Screw Line and Load Terminal, GHB Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_259_V4T2_260_CAT.pdf

Installation/Operator:

Eaton_00166_INST.pdf

TS PIK:

21517410

Current Rating:

100 A

Number of Poles:

3

Voltage Rating:

277/480 VAC, 125/250 VDC

Country of Origin:

Dominican Republic

Eaton MHMVD Circuit Breaker Accessories Vari-Depth Mechanism M Frame

SKU:

C15-4787

Frame:

M

Short Description:

VARI-DEPTH ROTARY MECH 10 MM (MDL)

Country of Origin:

United States​

GENERAL ELECTRIC FBN36TE015RV Molded Case Breakers (MCCBs) 15A

SKU:

C15-6864

TS PIK:

115927047

Maximum AC Voltage Rating:

480 V

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00018_INST.pdf

Interrupting Rating:

65 kA at 480 VAC, 150 kA at 240 VAC

Current Rating:

15 A

Terminal Type:

Line and Load Lug

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01746_1_CAD.pdf

Number of Poles:

3

Type:

Thermal Magnetic

Frame Type:

FB100

Voltage Rating:

240/480 VAC

Short Description:

600 VAC Star/347 VAC, 15 A, 65 kA Interrupt, 3-Pole, 14 to 10 AWG Aluminum/Copper Load Lug Terminal, FB100-Frame, Fixed Thermal Magnetic, Molded Case Circuit Breaker with A-Series AD Plus Lighting Panel

Approval:

UL

Country of Origin:

United States

GENERAL ELECTRIC THQP240 Miniature Circuit Breakers (MCBs) 2P 40A 120V EA

SKU:

C15-2427

Type:

Thermal Magnetic

Approval:

UL

Size:

1/2 Inch Width

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Plug-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120/240 VAC, 40 A, 10 kA Interrupt, 2-Pole, 8 to 4 AWG Aluminum/Copper Load Lug Terminal, 1/2" Plug-In Mount, Q-Line Frame, Non-Interchangeable/Internal Common Trip, Compact, Fixed Thermal Magnetic

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_1_6_1_7_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00024_INST.pdf

CAD Drawing:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01810_1_CAD.pdf

TS PIK:

112127466

Current Rating:

40 A

Voltage Rating:

120/240 VAC

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01810_1_CAD.pdf

Number of Poles:

2

Mounting:

Plug-On

Series:

THQP

Country of Origin:

United States

Square D QO1PA Circuit Breaker Accessories Padlock 1P

SKU:

C15-3806

Series:

QO

Type:

Padlockable

Used On:

QO Series Circuit Breaker

Poles:

1

Locking Provision:

On/Off

Short Description:

1-Pole, On/Off Locking

Catalog:

SchneiderElectric-SquareD_03264_1_8_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_14910_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00204_INST.pdf

Country of Origin:

Mexico

ABB AE30-30-11-81 Other Circuit Breakers

SKU:

C15-11371

Eaton BRDC215220 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-11217

Eaton BRH120 Miniature Circuit Breakers (MCBs) NULL EA

SKU:

C15-1300

Series:

BR

Type:

Barrier

Type:

Splicer

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

22 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 20 A, 22 kA, 1-Pole, Plug-On Mount, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_84_CAT.pdf

Data Sheet:

Eaton-Bussmann_00521_1-4_DATA.pdf

TS PIK:

21494020

Current Rating:

20 A

Number of Poles:

1

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton CHH2100H2X Molded Case Breakers (MCCBs) CHH 2P 100A 240V 50/60Hz 1Ph

SKU:

C15-1694

Series:

CHH

Volts:

120/240 VAC

Amps:

32 A

Used On:

1MP/1MM/3MM Series 200 A Modular Meter Stack

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

25 kA

Short Description:

120/240 VAC, 100 A, 25 kA, 2-Pole, Bolt-On Mount, Main Tenant

Catalog:

Eaton_00062_14_CAT.pdf

Installation/Operator:

Eaton_00008_INST.pdf

Manufacturer Warranty:

Eaton_00009_WARR.pdf

Number of Poles:

2

Current Rating:

100 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton FAZ-C10/1-RT-SP Din Rail Mounted Circuit Breakers

SKU:

C15-4211

Series:

FAZ

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Size:

0.7 Inch Width x 2.36 Inch Depth x 4.13 Inch Height

Volts:

277/480 VAC

Amps:

32 A

Poles:

1

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Screw

Wire Size:

18 to 4/18 to 8 AWG

Trip Setting:

5 to 10 x Rated Current

Short Description:

277/480 VAC 50/60 Hz, 10 A, 1-Pole, 10/14 kA, 5 to 10 x Rated Current, Ring Tongue Terminal, DIN Rail Mount, Single Packaging, C-Curve, Current Limiting, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_47-V4T1_72_CAT.pdf

TS PIK:

115465385

Voltage Rating:

277/480 VAC

Number of Poles:

1

Current Rating:

10 A

Curve Type:

C

Country of Origin:

Germany

Eaton FAZ-C2/1-NA-DC-SP Miniature Circuit Breakers (MCBs) FAZ 1P 2A 120/240V 50/60Hz 1Ph EA

SKU:

C15-5050

Series:

FAZ

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Size:

0.7 Inch Width x 2.36 Inch Depth x 4.13 Inch Height

Volts:

277/480 VAC

Volts:

125 VDC per Pole

Amps:

32 A

Poles:

1

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Screw

Wire Size:

18 to 4/18 to 8 AWG

Trip Setting:

5 to 10 x Rated Current

Short Description:

277/480 VAC 50/60 Hz, 125 VDC per Pole, 2 A, 1-Pole, 10 kA, 5 to 10 x Rated Current, Screw Terminal, DIN Rail Mount, Single Packaging, C-Curve, Current Limiting, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_47-V4T1_72_CAT.pdf

Number of Poles:

1

Voltage Rating:

277/480 VAC

Current Rating:

2 A

Curve Type:

C

Country of Origin:

Germany

Eaton FAZ-C2/3-NA Din Rail Mounted Circuit Breakers

SKU:

C15-3100

Series:

FAZ

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Approval:

CCC

Size:

2.09 Inch Width x 3.15 Inch Height

Volts:

277/480 VAC at 50/60 Hertz

Volts:

96 VDC

Amps:

32 A

Poles:

3

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Interrupting Rating:

10 kA at 96 Volt DC (UL

Terminal Type:

Screw

Trip Setting:

5 to 10 x Rated Current

Short Description:

277/480 VAC 50/60 Hz, 2 A, 3-Pole, 10/14 kA, 5 to 10 x Rated Current, Screw Terminal, DIN Rail Mount, Standard Packaging, C-Curve, Current Limiting, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_47-V4T1_72_CAT.pdf

Data Sheet:

Eaton_56870_1-5_DATA.pdf

Number of Poles:

3

Voltage Rating:

270/480 VAC

Current Rating:

2 A

Curve Type:

C

TS PIK:

124501542

Country of Origin:

Germany

Eaton FAZ-D25/2-NA Miniature Circuit Breakers (MCBs) EA

SKU:

C15-9039

Catalog:

Eaton_03771_V4T1_47-V4T1_72_CAT.pdf

Terminal Type:

Screw

Data Sheet:

Eaton_54141_1-5_DATA.pdf

Wire Size:

18 to 4/18 to 8 AWG

Size:

1.39 Inch Width x 2.36 Inch Depth x 4.13 Inch Height

Voltage Rating:

277/480 VAC

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Series:

FAZ

Short Description:

277/480 VAC 50/60 Hz, 25 A, 2-Pole, 10/14 kA, 10 to 20 x Rated Current, Screw Terminal, DIN Rail Mount, Standard Packaging, D-Curve, Current Limiting, Thermal Magnetic, Miniature Circuit Breaker

Number of Poles:

2

Type:

Thermal Magnetic

Current Rating:

25 A

Curve Type:

D

Approval:

UL 489, CSA C22.2

Country of Origin:

Germany

Trip Setting:

10 to 20 x Rated Current

Eaton FDE310021W Molded Case Breakers (MCCBs) FDE 3P 100A 600V 50/60Hz 3Ph F Frame EA

SKU:

C15-4983

Frame Type:

FD

Installation/Operator:

Eaton_00064_INST.pdf

Maximum AC Voltage Rating:

600 V

Current Rating:

100 A

Data Sheet:

Eaton_07831_1-12_DATA.pdf

Terminal Type:

Load

Size:

4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height

Type:

Fixed Thermal Magnetic, Molded Case

Number of Poles:

3

Catalog:

EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf

Interrupting Rating:

65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC (UL)

Voltage Rating:

480/600 VAC 50/60 Hertz, 250 VDC

Maximum DC Voltage Rating:

250 V

Country of Origin:

Dominican Republic

Eaton GHB3040 Molded Case Breakers (MCCBs) GHB 3P 40A 480V 50/60Hz 3Ph G Frame EA

SKU:

C15-2804

Series:

C

Type:

Molded Case

Type:

Thermal Magnetic

Approval:

CSA C22.2

Approval:

UL 489

Size:

3 Inch Width x 2.63 Inch Depth x 4 Inch Height

Volts:

277/480 VAC 50/60 Hertz

Volts:

125/250 VDC

Amps:

32 A

Poles:

3

Interrupting Rating:

65 kA at 240 VAC

Interrupting Rating:

14 kA at 277 Volt AC/480 Star/250 Volt DC

Terminal Type:

Aluminum Pressure Line and Load

Frame Type:

GHB

Maximum AC Voltage Rating:

480 V

Maximum DC Voltage Rating:

250 V

Short Description:

277/480 VAC 50/60 Hz, 125 VDC, 40 A, 14 kA, 3-Pole, Steel Pressure Screw Line and Load Terminal, GHB Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_259_V4T2_260_CAT.pdf

Installation/Operator:

Eaton_00166_INST.pdf

TS PIK:

21517405

Current Rating:

40 A

Number of Poles:

3

Voltage Rating:

277/480 VAC 50/60 Hertz, 125/250 VDC

Country of Origin:

United States

Eaton GPLKOFF Circuit Breaker Accessories Handle Lock EA

SKU:

C15-4768

Locking Provision:

0

Poles:

0

Used On:

G Frame Molded Case Circuit Breaker

Short Description:

OFF Locking Provision, Padlockable, Circuit Breaker Handle Lock

TS PIK:

116622486

Type:

Padlockable, Hasp, Snap-On

Eaton HFD1025 Molded Case Breakers (MCCBs)

SKU:

C15-9771

TS PIK:

106999149

Eaton QC1020 Miniature Circuit Breakers (MCBs) 1P 20A 240V EA

SKU:

C15-1641

Series:

QC

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

1

Mounting:

Cable-In/Cable-Out

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 Amp at 24 to 48 Volt DC

Interrupting Rating:

3800 Amp at 62.5 Volt DC

Terminal Type:

Ring

Wire Size:

14 to 10 AWG Copper/Aluminum (Load)

Short Description:

120/240 VAC, 20 A, 10 kA, 1-Pole, Steel Ring Line/Load Terminal, Cable-In/Out Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_19_V4T1_20_V4T1_46_CAT.pdf

TS PIK:

21508934

Number of Poles:

1

Voltage Rating:

120/240 VAC

Current Rating:

20 A

Country of Origin:

Dominican Republic

Eaton QCDINADAPT DIN Rail and Accessories 6PK

SKU:

C26-1443

Accessory Type:

Mounting Accessories

Type:

DIN Rail Adapter

Used On:

Quicklag Type C Miniature Circuit Breaker

Short Description:

DIN Rail Adapter, Circuit Breaker Mounting Plate

Specification/Technical:

Eaton_09710_1_SPEC.pdf

TS PIK:

107001610

Catalog:

Eaton_03771_V4T1_44_CAT.pdf

GE TQD22125WL Molded Case Breakers (MCCBs)

SKU:

C15-5945

Frame Type:

TQD

Voltage Rating:

240 V

Current Rating:

125 A

Short Description:

240 VAC, 125 A, 10 kA Interrupt, 2-Pole, Aluminum/Copper Line/Load Lug Terminal, Q-Line Frame, Non-Interchangeable/Internal Common Trip, Fixed Thermal Magnetic, Cable-In Cable-Out, Molded Case Circuit Breaker

Number of Poles:

2

Maximum AC Voltage Rating:

240 V

Type:

Molded Case, Fixed Thermal Magnetic, Internal Common Trip

Size:

2-3/4 Inch W x 2-5/8 Inch D x 6-9/16 Inch H

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Copper/Aluminum Line and Load Lug

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_4_6_5_6_8_6_42_CAT.pdf

Series:

Series TQD

Approval:

UL

GENERAL ELECTRIC THHQB1115 Miniature Circuit Breakers (MCBs) EA
