Molded Case Breakers (MCCBs)
A molded case circuit breaker (MCCB) is a type of electrical breaker that is used to protect electrical systems from damage due to overloading, short-circuiting, or other electrical faults. MCCBs are commonly used in industrial and commercial electrical systems, and are designed to handle higher currents and voltage levels than residential miniature circuit breakers.
- Product
- Qty in Cart
- Price
-
Eaton EGS3070FFG Molded Case Breakers (MCCBs) EGS 3P 70A 480V 50/60Hz 3Ph EG Frame
MSRP $1,614.00Surplus $584.47SKU: C15-2777 Brand: Eaton MPN: EGS3070FFG UPC: 782114877197 Shipping Weight: 2.50 lbs. Shipping Height: 5.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-2777
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CE
- Amps:
- 70 A
- Frame:
- EG
- Interrupting Rating:
- 22 kA at 600 Star/347 VAC
- Interrupting Rating:
- 35 Kiloamp at 480 Volt AC
- Interrupting Rating:
- 40 Kiloamp at 415 Volt AC
- Interrupting Rating:
- 85 Kiloamp at 240 Volt AC
- Maximum AC Voltage:
- 480 V
- Poles:
- 3
- Size:
- 3 Inch Width x 2.99 Inch Depth x 5.5 Inch Height
- Terminal Type:
- Standard Line and Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 240/415/480/600 Star/347 VAC 50/60 Hz
- TS PIK:
- 116533589
- Short Description:
- EATON SERIES G MOLDED CASE CIRCUIT BREAkER, EG-FRAME, EG, FIXED THERMAL, FIXED M
- Voltage Rating:
- 240/415/480/600 Star/347 VAC 50/60 Hz
- Frame Type:
- EG
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_142-V4T2_166_CAT.pdf
- Current Rating:
- 70 A
- Data Sheet:
- Eaton_21533_1-12_DATA.pdf
- Maximum AC Voltage Rating:
- 480 V
- Number of Poles:
- 3
MSRP $1,614.00Surplus $584.47 -
Contact Us For Quote
Eaton EGS3080FFG Molded Case Breakers (MCCBs) EGS 3P 80A 480V 50/60Hz 3Ph EG Frame
MSRP $1,162.00Surplus $431.10SKU: C15-3498 Brand: Eaton MPN: EGS3080FFG UPC: 782114877203 Shipping Weight: 2.70 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 4.00 In...- SKU:
- C15-3498
- Series:
- G, EGS
- Type:
- Molded Case
- Type:
- Fixed Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Approval:
- CE
- Size:
- 3 Inch Width x 2.29 Inch Depth x 5.5 Inch Height
- Volts:
- 600/347 VAC at 50/60 Hertz
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 5 kA at 240 V AC
- Interrupting Rating:
- 40 kA at 415 Volt AC
- Interrupting Rating:
- 35 kA at 480 Volt AC
- Interrupting Rating:
- 22 kA at 600 Volt AC Star/347 Volt AC
- Terminal Type:
- Standard Pressure Line and Load
- Frame Type:
- EG
- Maximum AC Voltage Rating:
- 600 V
- Short Description:
- 415/480 VAC 50/60 Hz, 80 A, 40/35 kA, 3-Pole, Line/Load Terminal, EG Frame, Fixed Thermal Magnetic
- Catalog:
- Eaton_46579_V4T2_142-V4T2_161_CAT.pdf
- Installation/Operator:
- Eaton_00042_INST.pdf
- Number of Poles:
- 3
- Current Rating:
- 80 A
- Voltage Rating:
- 600/347 V AC
MSRP $1,162.00Surplus $431.10 -
Contact Us For Quote
Eaton EGS3090FFB Molded Case Breakers (MCCBs) EGS 3P 90A 480V 50/60Hz 3Ph EG Frame
MSRP $1,614.00Surplus $484.43SKU: C15-3466 Brand: Eaton MPN: EGS3090FFB UPC: 786685382210 Shipping Weight: 2.35 lbs. Shipping Height: 4.00 In. Shipping Length: 6.00 In. Shipping Width: 3.00 In...- SKU:
- C15-3466
- Series:
- G
- Volts:
- 480 V
- Amps:
- 90 A
- Poles:
- 3
- Frequency Rating:
- 50/60 Hz
- Frame:
- EG
- Short Description:
- EATON SERIES G MOLDED CASE CIRCUIT BREAKER, EG-FRAME, EG, COMPLETE BREAKER, FIXE
MSRP $1,614.00Surplus $484.43 -
Eaton EGS3100FFB Molded Case Breakers (MCCBs) EGS 3P 100A 480V 50/60Hz 3Ph EG Frame
MSRP $1,192.14Surplus $740.42SKU: C15-4072 Brand: Eaton MPN: EGS3100FFB UPC: 786685382227 Shipping Weight: 2.55 lbs. Shipping Height: 5.00 In. Shipping Length: 6.50 In. Shipping Width: 4.00 In...- SKU:
- C15-4072
- Series:
- G
- Type:
- Molded Case
- Type:
- Fixed Thermal Fixed Magnetic
- Approval:
- UL
- Approval:
- CSA
- Approval:
- CE
- Size:
- 3 Inch W x 2.99 Inch D x 5.5 Inch H
- Volts:
- 480 VAC
- Amps:
- 32 A
- Poles:
- 3
- Interrupting Rating:
- 35 kA at 480 VAC
- Terminal Type:
- Standard Pressure Line and Load Terminal
- Terminal Type:
- Bolt-On
- Frame Type:
- EG
- Maximum AC Voltage Rating:
- 480
- Short Description:
- 480 VAC, 100 A, 35 kA, 3-Pole, Bolt-On Terminal, EG Frame, Fixed Thermal, Fixed Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_142-V4T2_144_V4T2_153_V4T2_154_V4T2_160_CAT.pdf
- Current Rating:
- 100 A
- Voltage Rating:
- 480 VAC
- Number of Poles:
- 3
- Country of Origin:
- Dominican Republic
MSRP $1,192.14Surplus $740.42 -
Eaton EGS3100FFG Molded Case Breakers (MCCBs) EA
MSRP $1,568.00Surplus $287.78SKU: C15-9718 Brand: Eaton MPN: EGS3100FFG UPC: Shipping Weight: 2.75 lbs. Shipping Height: 5.00 In. Shipping Length: 7.00 In. Shipping Width: 4.00 In. Product...- SKU:
- C15-9718
- TS PIK:
- 116533592
- Short Description:
- 415/480 VAC 50/60 Hz, 100 A, 40/35 kA, 3-Pole, Line/Load Terminal, EG Frame, Fixed Thermal Magnetic, Molded Case Circuit Breaker
- Series:
- G, EGS
- Maximum AC Voltage Rating:
- 600 V
- Current Rating:
- 100 A
- Voltage Rating:
- 600/347 VAC
- Size:
- 3 Inch Width x 2.29 Inch Depth x 5.5 Inch Height
- Interrupting Rating:
- 5 kA at 240 VAC, 40 kA at 415 VAC, 35 kA at 480 VAC, 22 kA at 600 VAC Star/347 VAC
- Frame Type:
- EG
- Terminal Type:
- Standard Pressure Line and Load
- Catalog:
- Eaton_46579_V4T2_142-V4T2_161_CAT.pdf
- Number of Poles:
- 3
- Installation/Operator:
- Eaton_00042_INST.pdf
- Type:
- Molded Case, Fixed Thermal Magnetic
- Country of Origin:
- Dominican Republic
MSRP $1,568.00Surplus $287.78 -
Eaton EHD1015 Molded Case Breakers (MCCBs) EHD 1P 15A 480V 50/60Hz 1Ph F Frame
MSRP $251.40Surplus $220.78Eaton EHD1015 Molded Case Breakers (MCCBs) EHD 1P 15A 480V 50/60Hz 1Ph F Frame​ ARCA SKU: C15-4147 Brand: Eaton MPN: EHD1015 UPC: 786679317310 Shipping Weight: 1.60 Shipping Height: 3.00...- SKU:
- C15-4147
- Series:
- C, EHD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 1.38 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 277 VAC at 50/60 Hz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 1
- Interrupting Rating:
- 14 kA at 277 VAC
- Interrupting Rating:
- 10 kA at 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 277
- Maximum DC Voltage Rating:
- 125
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 15 A, 14/10 kA, 1-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Voltage Rating:
- 277 VAC at 50/60 Hz, 125 VDC
- Number of Poles:
- 1
- Current Rating:
- 15 A
- Country of Origin:
- Dominican Republic
MSRP $251.40Surplus $220.78 -
Contact Us For Quote
Eaton EHD1015L Molded Case Breakers (MCCBs) 1P 15A
MSRP $253.51Surplus $116.90Eaton EHD1015L Molded Case Breakers (MCCBs) 1P 15A​ ARCA SKU: C15-4975 Brand: Eaton MPN: EHD1015L UPC: 78667915660 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- C15-4975
MSRP $253.51Surplus $116.90 -
Eaton EHD1020V Molded Case Breakers (MCCBs) EA
MSRP $340.00Surplus $36.89Eaton EHD1020V Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-9707 Brand: Eaton MPN: EHD1020V UPC: 78667907781 Shipping Weight: 1.65 lbs. Shipping Height: 7.00 In. Shipping...- SKU:
- C15-9707
- TS PIK:
- 115512937
- Terminal Type:
- Steel Standard Pressure Load
- Size:
- 1.38 Inch Width x 3.88 Inch Depth x 6 Inch Height
- Frame Type:
- FD
- Current Rating:
- 20 A
- Interrupting Rating:
- 4 kA at 277 VAC, 10 kA at 125 VDC (UL), 14 kA at 380/415 VAC, 10 kA at 125 VDC (IEC)
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Voltage Rating:
- 277 VAC 50/60 Hertz, 125 VDC
- Type:
- Fixed Thermal Magnetic, Molded Case
- Number of Poles:
- 1
- Maximum DC Voltage Rating:
- 125 V
- CAD Drawings:
- Eaton_57534_1_CAD.pdf
- Maximum AC Voltage Rating:
- 277 V
- Installation/Operator:
- Eaton_00091_INST.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Country of Origin:
- Dominican Republic
MSRP $340.00Surplus $36.89 -
Eaton EHD1030 Molded Case Breakers (MCCBs) EHD 1P 30A 480V 50/60Hz 1Ph F Frame
MSRP $308.00Surplus $132.24Eaton EHD1030 Molded Case Breakers (MCCBs) EHD 1P 30A 480V 50/60Hz 1Ph F Frame​ ARCA SKU: C15-2673 Brand: Eaton MPN: EHD1030 UPC: 786679317341 Shipping Weight: 1.65 Shipping Height: 2.00...- SKU:
- C15-2673
- Series:
- C, EHD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 1.38 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 277 VAC
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 1
- Interrupting Rating:
- 14 kA at 277 VAC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- FD
- Maximum AC Voltage Rating (V):
- 277
- Maximum DC Voltage Rating (V):
- 125
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 30 A, 14/10 kA, 1-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Voltage Rating:
- 277 VAC, 125 VDC
- Current Rating:
- 30 A
- Number of Poles:
- 1
- Country of Origin:
- Dominican Republic
MSRP $308.00Surplus $132.24 -
Contact Us For Quote
Eaton EHD1050 Molded Case Breakers (MCCBs) EA
MSRP $251.40Surplus $207.48Eaton EHD1050 Molded Case Breakers (MCCBs) EA​ ARCA SKU: C15-5245 Brand: Eaton MPN: EHD1050 UPC: 786679317365 Shipping Weight: 1.70 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- C15-5245
- Series:
- C, EHD
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL
- Size:
- 1.38 Inch W x 3.38 Inch D x 6 Inch H
- Volts:
- 277 VAC at 50/60 Hz
- Volts:
- 125 VDC
- Amps:
- 32 A
- Poles:
- 1
- Interrupting Rating:
- 14 kA at 277 VAC
- Interrupting Rating:
- 10 kA at 125 VDC
- Terminal Type:
- Standard Pressure Load Terminal
- Frame Type:
- F
- Maximum AC Voltage Rating:
- 277
- Maximum DC Voltage Rating:
- 125
- Short Description:
- 277 VAC 50/60 Hz, 125 VDC, 50 A, 14/10 kA, 1-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Voltage Rating:
- 277 VAC at 50/60 Hz, 125 VDC
- Current Rating:
- 50 A
- Number of Poles:
- 1
- Country of Origin:
- Dominican Republic
MSRP $251.40Surplus $207.48 -
Eaton EHD1100 Molded Case Breakers (MCCBs) 1P 100A
MSRP $461.59Surplus $112.67Eaton EHD1100 Molded Case Breakers (MCCBs) 1P 100A​ ARCA SKU: C15-3151 Brand: Eaton MPN: EHD1100 UPC: 78667931739 Shipping Weight: 2.00 lbs. Shipping Height: 3.00 In. Shipping...- SKU:
- C15-3151
- Series:
- C
- Volts:
- 480 V
- Amps:
- 100 A
- Poles:
- 1
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, EHD, COMPLETE BREA
- TS PIK:
- 21509160
- Country of Origin:
- Dominican Republic
MSRP $461.59Surplus $112.67 -
Eaton EHD2015 Molded Case Breakers (MCCBs)
MSRP $990.00Surplus $52.21Eaton EHD2015 Molded Case Breakers (MCCBs)​ ARCA SKU: C15-3877 Brand: Eaton MPN: EHD2015 UPC: 786679317419 Shipping Weight: 2.90 lbs. Shipping Height: 4.00 In. Shipping...- SKU:
- C15-3877
- Series:
- C
- Type:
- Molded Case
- Type:
- Thermal Magnetic
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Volts:
- 480 VAC at 50/60 Hertz
- Volts:
- 250 VDC
- Amps:
- 32 A
- Poles:
- 2
- Interrupting Rating:
- 14 kA at 480 VAC
- Interrupting Rating:
- 10 kA at 250 Volt DC
- Terminal Type:
- Standard Pressure Load
- Frame Type:
- FD
- Maximum AC Voltage Rating:
- 480 V
- Maximum DC Voltage Rating:
- 250 V
- Short Description:
- 480 VAC 50/60 Hz, 250 VDC, 15 A, 14/10 kA, 2-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case
- Catalog:
- Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf
- Data Sheet:
- Eaton_40755_1-4_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Current Rating:
- 15 A
- Voltage Rating:
- 480 VAC, 250 VDC
- Number of Poles:
- 2
- TS PIK:
- 21509162
- Country of Origin:
- Dominican Republic
MSRP $990.00Surplus $52.21 -
Contact Us For Quote
Eaton EHD2015VWD01 Molded Case Breakers (MCCBs) EHD 2P 15A 480V 50/60Hz 2Ph F Frame
MSRP $809.00Surplus $176.90Eaton EHD2015VWD01 Molded Case Breakers (MCCBs) EHD 2P 15A 480V 50/60Hz 2Ph F Frame​ ARCA SKU: C15-1956 Brand: Eaton MPN: EHD2015VWD01 UPC: 786679040935 Shipping Weight: 3.00 Shipping...- SKU:
- C15-1956
- Series:
- C
- Volts:
- 480 V
- Amps:
- 15 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- Series C complete molded case circuit breaker, F-frame, EHD, Fixed thermal, fixed magnetic trip, Two-pole, 15A, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Without terminals, line and load end caps, Imperial, 50°C, 50/60 Hz
- Frame Type:
- F
- Number of Poles:
- 2
- Voltage Rating:
- 480 VAC
- Current Rating:
- 15 A
- Country of Origin:
- Dominican Republic
MSRP $809.00Surplus $176.90 -
Contact Us For Quote
Eaton EHD2020B06 Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame A1L1RPK1A Bell Alarm
MSRP $1,275.00Surplus $426.19SKU: C15-1681 Brand: Eaton MPN: EHD2020B06 UPC: 786679051115 Shipping Weight: 3.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-1681
- Series:
- C
- Volts:
- 480 V
- Amps:
- 20 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- General Accessories:
- A1L1RPK1A Bell Alarm
- Short Description:
- Series C complete molded case circuit breaker, F-frame, EHD, Complete breaker, Fixed thermal, fixed magnetic trip, Two-pole, 20A, 18 kAIC at 240 Vac, 14 kAIC at 480 Vac, Load side, 1mk-1bk rear with right pigtail, 50/60 Hz
- Frame Type:
- F
- Number of Poles:
- 2
- Voltage Rating:
- 480 VAC
- Current Rating:
- 20 A
- Interrupting Rating:
- 18 kA
MSRP $1,275.00Surplus $426.19 -
Contact Us For Quote
Eaton EHD2020C05 Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame AAL1RPK
MSRP $665.00Surplus $146.35Eaton EHD2020C05 Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame AAL1RPK​ ARCA SKU: C15-1957 Brand: Eaton MPN: EHD2020C05 UPC: Shipping Weight: 3.05 Shipping Height: 5.00...- SKU:
- C15-1957
- Frame Type:
- F
- Voltage Rating:
- 480 V
- Current Rating:
- 20 A
- Number of Poles:
- 2
- Interrupting Rating:
- 50A, 18 kA at 240 Vac, 14 kA at 480 Vac
- Short Description:
- Eaton Series C complete molded case circuit breaker, F-frame, EHD, Fixed thermal, fixed magnetic trip, Two-pole, 50A, 18 kA at 240 Vac, 14 kA at 480 Vac, Load side
- Series:
- C
MSRP $665.00Surplus $146.35 -
Eaton EHD2020L Molded Case Breakers (MCCBs) EA
MSRP $1,020.60Surplus $267.98SKU: C15-11035 Brand: Eaton MPN: EHD2020L UPC: Shipping Weight: 2.65 lbs. Shipping Height: 3.00 In. Shipping Length: 7.00 In. Shipping Width: 5.00 In. Product...- SKU:
- C15-11035
- TS PIK:
- 21510801
- Frame Type:
- FD
- Voltage Rating:
- 480 VAC, 250 VDC (UL, IEC)
- Current Rating:
- 20 A
- Number of Poles:
- 2
- CAD Drawings:
- Eaton_21583_1_CAD.pdf
- Terminal Type:
- Standard Pressure Line and Load Terminal
- Installation/Operator:
- Eaton_00091_INST.pdf
- Series:
- C, EHD
- Maximum DC Voltage Rating:
- 250 V
- Type:
- Molded Case, Thermal Magnetic, Non-Interchangeable
- Catalog:
- Eaton_46579_V4T2_254-V4T2_290_CAT.pdf
- Short Description:
- 480 VAC 50/60 Hz, 250 VDC, 20 A, 14 kA, 2-Pole, Line/Load Terminal, EHD Frame, Non-Interchangeable Trip Thermal Magnetic, Molded Case Circuit Breaker
- Maximum AC Voltage Rating:
- 480 V
- Interrupting Rating:
- 14 kA at 480 VAC, 10 kA at 250 VDC (UL, IEC)
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
MSRP $1,020.60Surplus $267.98 -
Eaton EHD2020V Molded Case Breakers (MCCBs) EA
MSRP $749.97Surplus $204.26SKU: C15-9246 Brand: Eaton MPN: EHD2020V UPC: Shipping Weight: 3.00 lbs. Shipping Height: 6.00 In. Shipping Length: 8.00 In. Shipping Width: 4.00 In. Product...- SKU:
- C15-9246
- Country of Origin:
- Dominican Republic
MSRP $749.97Surplus $204.26 -
Contact Us For Quote
Eaton EHD2020VL Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame
MSRP $671.00Surplus $261.36SKU: C15-2341 Brand: Eaton MPN: EHD2020VL UPC: 782114210406 Shipping Weight: 3.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-2341
- Series:
- C
- Volts:
- 480 V
- Amps:
- 20 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, EHD, COMPLETE BREA
MSRP $671.00Surplus $261.36 -
Eaton EHD2025 Molded Case Breakers (MCCBs) EHD 2P 25A 480V 50/60Hz 2Ph F Frame Thermal Magnetic
MSRP $760.00Surplus $115.30Eaton EHD2025 Molded Case Breakers (MCCBs) EHD 2P 25A 480V 50/60Hz 2Ph F Frame Thermal Magnetic​ ARCA SKU: C15-3996 Brand: Eaton MPN: EHD2025 UPC: 786679317433 Shipping Weight: 2.75 lbs...- SKU:
- C15-3996
- Approval:
- UL 489
- Approval:
- CSA C22.2
- Amps:
- 25 A
- Frame:
- FD
- Interrupting Rating:
- 18 kA at 240 VAC
- Interrupting Rating:
- 14 Kiloamp at 480 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (UL)
- Interrupting Rating:
- 18 Kiloamp at 220/240 Volt AC
- Interrupting Rating:
- 14 Kiloamp at 440 Volt AC
- Interrupting Rating:
- 10 Kiloamp at 250 Volt DC (IEC)
- Maximum AC Voltage:
- 480 V
- Maximum DC Voltage:
- 250 V
- Poles:
- 2
- Size:
- 2.75 Inch Width x 3.38 Inch Depth x 6 Inch Height
- Terminal Type:
- Load
- Type:
- Fixed Thermal Magnetic
- Type:
- Molded Case
- Volts:
- 480 VAC 50/60 Hertz
- Volts:
- 250 VDC
- TS PIK:
- 21527130
- Frame Type:
- FD
- Voltage Rating:
- 480 VAC 50/60 Hertz, 250 VDC
- Maximum DC Voltage Rating:
- 250 V
- CAD Drawings:
- Eaton_21583_1_CAD.pdf
- Catalog:
- EatonCorp-CutlerHammer_00123_V4T2_254-V4T2_290_CAT.pdf
- Current Rating:
- 25 A
- Number of Poles:
- 2
- Maximum AC Voltage Rating:
- 480 V
- Data Sheet:
- Eaton_07831_1-12_DATA.pdf
- Installation/Operator:
- Eaton_00091_INST.pdf
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, EHD, COMPLETE BREA
- Series:
- C
- Country of Origin:
- Dominican Republic
MSRP $760.00Surplus $115.30 -
Contact Us For Quote
Eaton EHD2030B06 Molded Case Breakers (MCCBs) EHD 2P 30A 480V 50/60Hz 2Ph F Frame A1L1RPK1A Bell Alarm
MSRP $1,291.00Surplus $407.89SKU: C15-1730 Brand: Eaton MPN: EHD2030B06 UPC: 786679040980 Shipping Weight: 3.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00 In...- SKU:
- C15-1730
- Series:
- C
- Volts:
- 480 V
- Amps:
- 30 A
- Poles:
- 2
- Frequency Rating:
- 50/60 Hz
- Frame:
- F
- General Accessories:
- A1L1RPK1A Bell Alarm
- Short Description:
- EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, F-FRAME, EHD, COMPLETE BREA
MSRP $1,291.00Surplus $407.89
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
