Fuses
A fuse is a safety device that is used to protect electrical circuits from overloading and short-circuits. It works by breaking the flow of electrical current in the event of an overload or short-circuit. This helps to prevent damage to electrical equipment, minimize the risk of electrical fires, and protect people from electric shock.
- Product
- Qty in Cart
- Price
-
Contact Us For Quote
Bussmann JM60600-1CR Fuse Blocks and Holders EA
MSRP $1,329.07Surplus $664.53SKU: F16-5537 Brand: Bussmann MPN: JM60600-1CR UPC: 05171239109 Shipping Weight: 4.10 lbs. Shipping Height: 6.00 In. Shipping Length: 10.00 In. Shipping Width: 7.00...- SKU:
- F16-5537
- TS PIK:
- 124861616
- Short Description:
- 600 V, 450 to 600 A, Thermoplastic, 1-Pole, Spring Reinforced, Box Lug with Slot Screw Terminal, Panel Mount, Class J, Barrier, Modular Fuse Block
- Fuse Type:
- Class J
- Series:
- JM
- Type:
- Barrier
- Terminal Type:
- Tin-Plated Copper Brass Box Lug/Slot Screw
- Catalog:
- Eaton-Bussmann_00349_8_31_8_32_CAT.pdf
- Data Sheet:
- Eaton-Bussmann_00152_1-12_DATA.pdf
- CAD Drawings:
- Eaton-Bussmann_00789_1_2_CAD.pdf
- Number of Poles:
- 1
- Fuse Current Rating:
- 450 to 600 A
- Fuse Voltage Rating:
- 600 V
- Material:
- Thermoplastic (Base)
- Clip Type:
- Spring Reinforced
- Wire Size:
- (2) 4 AWG to 500 KCMIL (Solid/Stranded)
- Approval:
- UL, CSA, CE
MSRP $1,329.07Surplus $664.53 -
Bussmann LPN-RK-45SP Fuses EA
MSRP $36.00Surplus $14.02Bussmann LPN-RK-45SP Fuses EA​ ARCA SKU: F16-2707 Brand: Bussmann MPN: LPN-RK-45SP UPC: 3005171253 Shipping Weight: 0.15 lbs. Shipping Height: 1.00 In. Shipping Length: 3.00...- SKU:
- F16-2707
- Series:
- LPN-RK
- Type:
- Class RK1
- Approval:
- UL
- Volts:
- 250 VAC
- Amps:
- 32 A
- Interrupting Rating:
- 300 kA
- Terminal Type:
- Ferrule
- Length:
- 3
- Diameter:
- 0.81
- Characteristics:
- Time Delay
- Short Description:
- 0.81" x 3", 250 VAC, 125 VDC, 45 A, 300/100 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK1, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating
- Catalog:
- Eaton-Bussmann_00349_1_24_1_25_CAT.pdf
- Data Sheet:
- Eaton-Bussmann_00161_1-4_DATA.pdf
- Current Rating:
- 45 A
- Voltage Rating:
- 250 VAC, 125 VDC
- Country of Origin:
- Mexico
MSRP $36.00Surplus $14.02 -
Bussmann LPN-RK-5SP Fuses EA
MSRP $35.00Surplus $10.37Bussmann LPN-RK-5SP Fuses EA​ ARCA SKU: F16-2684 Brand: Bussmann MPN: LPN-RK-5SP UPC: 05171253823 Shipping Weight: 0.05 lbs. Shipping Height: 1.00 In. Shipping Length: 2...- SKU:
- F16-2684
- Series:
- LPN-RK
- Type:
- Class RK1
- Approval:
- UL
- Approval:
- CSA C22.2
- Approval:
- CE
- Volts:
- 250 VAC
- Volts:
- 125 VDC
- Amps:
- 32 A
- Interrupting Rating:
- 300 kA (AC)
- Interrupting Rating:
- 100 kA (DC)
- Terminal Type:
- Ferrule x Ferrule with Grooved Ring
- Length:
- 2
- Diameter:
- 0.56
- Characteristics:
- 8 Second Time Delay (500 Percent Rated Current)
- Characteristics:
- Current Limiting
- Characteristics:
- Non-Indicating
- Characteristics:
- Dual Element
- Short Description:
- 0.56" x 2", 250 VAC, 125 VDC, 5 A, 300/100 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK1, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating
- Catalog:
- Eaton-Bussmann_00349_1_24_1_25_CAT.pdf
- Data Sheet:
- Eaton-Bussmann_00161_1-4_DATA.pdf
- Current Rating:
- 5 A
- Voltage Rating:
- 250 VAC, 125 VDC
- Interrupt Rating:
- 300/100 kA
- Country of Origin:
- Mexico
MSRP $35.00Surplus $10.37 -
Contact Us For Quote
Bussmann NO.2642 Fuse Reducers and Clips
MSRP $424.87Surplus $107.72Bussmann NO.2642 Fuse Reducers and Clips​ ARCA SKU: F16-5160 Brand: Bussmann MPN: NO.2642 UPC: 05171233106 Shipping Weight: 0.25 lbs. Shipping Height: 1.00 In. Shipping...- SKU:
- F16-5160
MSRP $424.87Surplus $107.72 -
Contact Us For Quote
Bussmann S-1 Fuses EA
MSRP $30.00Surplus $14.25Bussmann S-1 Fuses EA​ ARCA SKU: F16-2657 Brand: Bussmann MPN: S-1 UPC: Shipping Weight: 0.05 lbs. Shipping Height: 1.00 In. Shipping Length: 3.00 In. Shipping...- SKU:
- F16-2657
- Approval:
- UL 248-11
- Approval:
- CSA 1423-01
- Approval:
- CE
- Base Type:
- Rejection
- Characteristics:
- Dual Element Time Delay
- Amps:
- 1 A
- Interrupting Rating:
- 10 Kiloamp (Symmetrical)
- Type:
- Type S
- Volts:
- 125 VAC
- Short Description:
- 125 VAC, 1 A, 10 kA Interrupt Rating, Rejection Base, Type S, Dual Element Time Delay, Plug Fuse (4 per Box)
- Series:
- S
- Data Sheet:
- Eaton-Bussmann_00761_1_2_DATA.pdf
MSRP $30.00Surplus $14.25 -
Bussmann TPA-50 Distribution Fuses
MSRP $58.60Surplus $31.56SKU: F16-6962 Brand: Bussmann MPN: TPA-50 UPC: 5171237042 Shipping Weight: 0.05 lbs. Shipping Height: 1.00 In. Shipping Length: 2.00 In. Shipping Width: 1.00 In...- SKU:
- F16-6962
- TS PIK:
- 121479018
- Short Description:
- 0.58" x 1.5", 170 VDC, 50 A, 100 kA, Ferrule Terminal, Telecommunication, Current Limiting, Indicating, DC Power Distribution Fuse
- Series:
- TPA
- Type:
- Telecommunication, Current Limiting, Indicating
- Current Rating:
- 50 A
- Interrupting Rating:
- 100 kA
- Approval:
- UL, CSA 1422-30, CE
- Terminal Type:
- Ferrule
- Length:
- 1.5
- Diameter:
- 0.58
- Voltage Rating:
- 170 VDC
- Catalog:
- Eaton-Bussmann_00930_14_5_CAT.pdf
- Data Sheet:
- Eaton-Bussmann_00769_1_2_DATA.pdf
MSRP $58.60Surplus $31.56 -
Contact Us For Quote
Eaton 15RBA2-125E Fuse Accessories
MSRP $587.00Surplus $200.02SKU: F16-6791 Brand: Eaton MPN: 15RBA2-125E UPC: 78667023005 Shipping Weight: 1.15 lbs. Shipping Height: 3.00 In. Shipping Length: 11.00 In. Shipping Width: 3.00 In...- SKU:
- F16-6791
- TS PIK:
- 110570125
MSRP $587.00Surplus $200.02 -
Eaton 4000358C10B Fuse Accessories EA
MSRP $150.00Surplus $24.64Eaton 4000358C10B Fuse Accessories EA​ ARCA SKU: F16-2910 Brand: Eaton MPN: 4000358C10B UPC: Shipping Weight: 0.05 lbs. Shipping Height: 7.00 In. Shipping Length: 6.00...- SKU:
- F16-2910
MSRP $150.00Surplus $24.64 -
Eaton CA132015EN Fuses 38kV
MSRP $400.00Surplus $120.00Eaton CA132015EN Fuses 38kV​ ARCA SKU: F16-1628 Brand: Eaton MPN: CA132015EN UPC: Shipping Weight: 1.55 lbs. Shipping Height: 4.00 In. Shipping Length: 16.00 In. Shipping...- SKU:
- F16-1628
- UOM:
- EA
- Volts:
- 38 kV
- Box Quantity:
- 1
MSRP $400.00Surplus $120.00 -
Contact Us For Quote
Ferraz Shawmut 30323R Fuse Blocks and Holders EA
MSRP $45.95Surplus $30.26Ferraz Shawmut 30323R Fuse Blocks and Holders EA​ ARCA SKU: F16-2322 Brand: Ferraz Shawmut MPN: 30323R UPC: 78200166356 Shipping Weight: 0.30 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- F16-2322
- Series:
- 303
- Type:
- Open Style
- Approval:
- UL 4248
- Approval:
- CSA
- Amps:
- 32 A
- Poles:
- 3
- Terminal Type:
- Pressure Plate with Double Quick-Connect
- Wire Size:
- 14 to 10 AWG (Copper)
- Body Material:
- Glass Filled Polycarbonate
- Fuse Type:
- Class CC
- Fuse Current Rating:
- 30 A
- Fuse Voltage Rating:
- 600 VAC 50/60 Hertz
- Fuse Voltage Rating:
- 600 Volt DC
- Clip Type:
- Tin Plated Copper Alloy
- Short Description:
- 600 VAC/VDC, 30 A, 14 to 10 AWG Copper, 3-Pole, Glass Filled Polycarbonate, Tin Plated Copper Alloy Clip, Pressure Plate with Double Quick-Connect Terminal, Class CC, Open Style
- Catalog:
- Mersen_00180_PF25_PF27_CAT.pdf
- Data Sheet:
- Mersen_00039_1_2_DATA.pdf
- Number of Poles:
- 3
MSRP $45.95Surplus $30.26 -
Ferraz Shawmut A4BY5000 Fuses
MSRP $12,177.26Surplus $4,133.45SKU: F16-4697 Brand: Ferraz Shawmut MPN: A4BY5000 UPC: 78200193931 Shipping Weight: 29.75 lbs. Shipping Height: 8.00 In. Shipping Length: 14.00 In. Shipping Width: 8...- SKU:
- F16-4697
- TS PIK:
- 529721
- Short Description:
- L TD FUSE 600V 5000A A4BY
- Current Rating:
- 5000 A
MSRP $12,177.26Surplus $4,133.45 -
Ferraz Shawmut A4J200 Fuses 600V EA
MSRP $278.90Surplus $105.42SKU: F16-3464 Brand: Ferraz Shawmut MPN: A4J200 UPC: 78200196037 Shipping Weight: 0.80 lbs. Shipping Height: 2.00 In. Shipping Length: 6.00 In. Shipping Width: 2.00...- SKU:
- F16-3464
- Short Description:
- 1.62" x 5.75", 600 VAC/300 VDC, 200 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)
- Type:
- Class J
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- CAD Drawings:
- Mersen_00352_1_CAD.pdf
- Series:
- A4J
- Current Rating:
- 200 A
- Catalog:
- Mersen_00086_193_CAT.pdf
- Characteristics:
- Fast Acting
- Data Sheet:
- Mersen_00056_PF22_PF23_DATA.pdf
- Terminal Type:
- Blade
- TS PIK:
- 530036
- Diameter:
- 1-5/8
- Length:
- 5-3/4
- Voltage Rating:
- 600 VAC, 300 VDC
- Approval:
- UL 248/248-8, CSA C22.2
- Country of Origin:
- United States
MSRP $278.90Surplus $105.42 -
Contact Us For Quote
Ferraz Shawmut A50P600-4TA Fuses
MSRP $996.67Surplus $447.04SKU: F16-6529 Brand: Ferraz Shawmut MPN: A50P600-4TA UPC: 78200114068 Shipping Weight: 1.15 lbs. Shipping Height: 2.50 In. Shipping Length: 4.50 In. Shipping Width: 2...- SKU:
- F16-6529
- Short Description:
- 14068-FUSE,FORM 101
MSRP $996.67Surplus $447.04 -
Ferraz Shawmut A6D400R Fuses 600V EA
MSRP $631.11Surplus $267.09SKU: F16-3488 Brand: Ferraz Shawmut MPN: A6D400R UPC: 78200199225 Shipping Weight: 3.40 lbs. Shipping Height: 12.00 In. Shipping Length: 12.00 In. Shipping Width: 2...- SKU:
- F16-3488
- Type:
- Class RK1
- Series:
- A6D-R
- Data Sheet:
- Mersen_00050_PF8_PF9_DATA.pdf
- Voltage Rating:
- 600 VAC/DC
- Short Description:
- 2.56" x 11.63", 600 VAC/VDC, 400 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (1 per Pack)
- Current Rating:
- 400 A
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Terminal Type:
- Blade
- Characteristics:
- Time Delay
- CAD Drawings:
- Mersen_00217_1_CAD.pdf
- Catalog:
- Mersen_00086_189_CAT.pdf
- Interrupt Rating:
- 200/100 kA
- TS PIK:
- 110477906
- Approval:
- UL 248/248-12, CSA C22.2
- Diameter:
- 2-9/16
- Length:
- 11-5/8
MSRP $631.11Surplus $267.09 -
Contact Us For Quote
Ferraz Shawmut A6K600R Fuse Accessories
MSRP $1,788.73Surplus $764.83SKU: F16-4679 Brand: Ferraz Shawmut MPN: A6K600R UPC: 78200191593 Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping Length: 0.00 In. Shipping Width: 0.00...- SKU:
- F16-4679
- TS PIK:
- 110477425
- Series:
- A6K-R
- Approval:
- UL 248/248-12, CSA C22.2
- Terminal Type:
- Blade
- Current Rating:
- 600 A
- Length:
- 13-3/8
- Short Description:
- 3.12" x 13.38", 600 VAC/300 VDC, 600 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Highly Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)
- Catalog:
- Mersen_00086_190_CAT.pdf
- Data Sheet:
- Mersen_00051_PF10_PF11_DATA.pdf
- Voltage Rating:
- 600 VAC, 300 VDC
- Type:
- Class RK1
- Characteristics:
- Fast Acting
- CAD Drawings:
- Mersen_00129_1_CAD.pdf
- Interrupting Rating:
- 200 kA (AC), 20 kA (DC)
MSRP $1,788.73Surplus $764.83 -
Contact Us For Quote
Ferraz Shawmut A6K60R Fuse Accessories 600V
MSRP $175.07Surplus $74.86Ferraz Shawmut A6K60R Fuse Accessories 600V​ ARCA SKU: F16-3796 Brand: Ferraz Shawmut MPN: A6K60R UPC: Shipping Weight: 0.00 lbs. Shipping Height: 0.00 In. Shipping...- SKU:
- F16-3796
- Short Description:
- 1.06" x 5.5", 600 VAC/300 VDC, 60 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Highly Current Limiting, Fast Acting, Low Vage UL Power Fuse (10 per Pack)
- Characteristics:
- Fast Acting
- Type:
- Class RK1
- Voltage Rating:
- 600 VAC, 300 VDC
- Series:
- A6K-R
- CAD Drawings:
- Mersen_00358_1_CAD.pdf
- Diameter:
- 1-1/16
- Approval:
- UL 248/248-12, CSA C22.2
- Catalog:
- Mersen_00086_190_CAT.pdf
- Terminal Type:
- Ferrule
- Data Sheet:
- Mersen_00051_PF10_PF11_DATA.pdf
- Interrupting Rating:
- 200 kA (AC), 20 kA (DC)
- Length:
- 5-1/2
- Current Rating:
- 60 A
MSRP $175.07Surplus $74.86 -
Ferraz Shawmut A6T90 Fuses EA
MSRP $151.87Surplus $55.52SKU: F16-3502 Brand: Ferraz Shawmut MPN: A6T90 UPC: 78200189142 Shipping Weight: 0.50 lbs. Shipping Height: 1.00 In. Shipping Length: 5.00 In. Shipping Width: 3.00 In...- SKU:
- F16-3502
- Short Description:
- 0.82" x 2.95", 600 VAC/300 VDC, 90 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (5 per Pack)
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Terminal Type:
- Blade
- Series:
- A6T
- Type:
- Class T
- CAD Drawings:
- Mersen_00359_1_CAD.pdf
- Data Sheet:
- Mersen_00052_PF32_PF33_DATA.pdf
- Current Rating:
- 90 A
- Characteristics:
- Fast Acting
- Catalog:
- Mersen_00086_195_CAT.pdf
- TS PIK:
- 110477063
- Length:
- 2.95
- Voltage Rating:
- 600 VAC, 300 VDC
- Diameter:
- 0.82
- Approval:
- UL 248/248-15, CSA C22.2
MSRP $151.87Surplus $55.52 -
Ferraz Shawmut A70QS125-4 Fuses EA
MSRP $178.00Surplus $61.23Ferraz Shawmut A70QS125-4 Fuses EA​ ARCA SKU: F16-2685 Brand: Ferraz Shawmut MPN: A70QS125-4 UPC: 782001948689 Shipping Weight: 0.40 lbs. Shipping Height: 2.00 In. Shipping...- SKU:
- F16-2685
- Approval:
- UL
- Approval:
- CSA
- Characteristics:
- High Speed
- Amps:
- 125 A
- Diameter:
- 1.22
- Interrupting Rating:
- 200 kA (AC)
- Interrupting Rating:
- 100 Kiloamp (DC)
- Length:
- 4.38
- Terminal Type:
- Blade
- Type:
- Round
- Type:
- Semiconductor
- Volts:
- 700 VAC/DC
- Short Description:
- 1.22" x 4.38", 700 VAC/VDC, 125 A, 200 kA AC/100 kA DC Interrupt Rating, GMG Body, Tin Plated Brass Blade Terminal, Bolted Mount, High Speed, Round, Form 101, Semiconductor Protection Fuse
- Series:
- A70QS
- Data Sheet:
- Mersen_00015_HS16_HS17_DATA.pdf
- CAD Drawing:
- Mersen_00227_1_CAD.pdf
- Current Rating:
- 125 A
- CAD Drawings:
- Mersen_00227_1_CAD.pdf
- Catalog:
- Mersen_00697_39_CAT.pdf
- Voltage Rating:
- 700 VAC/DC
MSRP $178.00Surplus $61.23 -
Ferraz Shawmut AJT110 Fuses
MSRP $404.43Surplus $109.79SKU: F16-3974 Brand: Ferraz Shawmut MPN: AJT110 UPC: 78200196263 Shipping Weight: 0.80 lbs. Shipping Height: 1.00 In. Shipping Length: 6.00 In. Shipping Width: 1.00...- SKU:
- F16-3974
- Short Description:
- 1.62" x 5.75", 600 VAC 50/60 Hz/500 VDC, 110 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (1 per Pack)
- CAD Drawings:
- Mersen_00352_1_CAD.pdf
- Current Rating:
- 110 A
- Series:
- AJT
- Catalog:
- Mersen_00086_192_CAT.pdf
- Characteristics:
- Time Delay
- Data Sheet:
- Mersen_00063_1_2_DATA.pdf
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Terminal Type:
- Blade
- Type:
- Class J
- TS PIK:
- 110477768
- Diameter:
- 1-5/8
- Voltage Rating:
- 600 VAC, 500 VDC
- Length:
- 5-3/4
- Approval:
- UL 248/248-8, CSA C22.2
- Country of Origin:
- United States
MSRP $404.43Surplus $109.79 -
Ferraz Shawmut AJT50 Fuses
MSRP $88.49Surplus $16.67SKU: F16-3979 Brand: Ferraz Shawmut MPN: AJT50 UPC: 30782001962365 Shipping Weight: 0.15 lbs. Shipping Height: 3.00 In. Shipping Length: 1.00 In. Shipping Width: 2.00...- SKU:
- F16-3979
- TS PIK:
- 110477755
- Short Description:
- 1.06" x 2.38", 600 VAC 50/60 Hz/500 VDC, 50 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)
- Series:
- AJT
- Data Sheet:
- Mersen_00063_1_2_DATA.pdf
- Catalog:
- Mersen_00086_192_CAT.pdf
- Type:
- Class J
- Interrupting Rating:
- 200 kA (AC), 100 kA (DC)
- Characteristics:
- Time Delay, Current Limiting
- Terminal Type:
- Ferrule
- CAD Drawings:
- Mersen_00369_1_CAD.pdf
- Current Rating:
- 50 A
- Voltage Rating:
- 600 VAC 50/60 Hertz, 400 VDC
- Length:
- 2.38
- Diameter:
- 1.063
- Approval:
- UL 248/248-8, CSA C22.2
- Country of Origin:
- United States
MSRP $88.49Surplus $16.67
Disclaimer: ARCA Supply is not an authorized distributor, reseller or representative of any manufacturer, brand or product listed. All product names, trademarks, brands and logos are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder. All items sold by ARCA Supply are covered under ARCA Supply's warranty and not the manufacturer warranty.
