Ferraz Shawmut R262 Fuse Reducers and Clips

SKU:

F16-3595

Fuse Type:

Class R

Catalog:

MERSENE00136_J3.pdf

Series:

R

Short Description:

60 A at 250 V Fuse, 200 A at 250 V Clip, 200 kA, Class R, Rejection, Fuse Reducer

Type:

Rejection

Approval:

UL, CSA

Country of Origin:

United States

Ferraz Shawmut TRS5R Fuse Accessories 600V EA

SKU:

F16-3633

Short Description:

0.81" x 5", 600 VAC 50/60 Hz/600 VDC, 5 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

Current Rating:

5 A

Type:

Class RK5

CAD Drawings:

Mersen_00104_1_CAD.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Series:

TRS-R

Terminal Type:

Ferrule

Catalog:

Mersen_00086_191_CAT.pdf

Diameter:

13/16

Length:

5

Voltage Rating:

600 VAC/DC

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Characteristics:

Time Delay

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A2D35R Fuses EA

SKU:

F16-3694

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_189_CAT.pdf

Short Description:

0.81" x 3", 250 VAC/VDC, 35 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (10 per Pack)

Series:

A2D-R

Current Rating:

35 A

CAD Drawings:

Mersen_00173_1_CAD.pdf

Characteristics:

Time Delay

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Terminal Type:

Ferrule

Type:

Class RK1

Voltage Rating:

250 VAC/DC

Diameter:

13/16

Length:

3

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQR4/10 Fuses EA

SKU:

F16-3565

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 4/10 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

0.4 A

Series:

ATQR

Type:

Class CC Rejection

Terminal Type:

Ferrule

Characteristics:

Time Delay

CAD Drawings:

Mersen_00232_1_CAD.pdf

Catalog:

Mersen_00086_194_CAT.pdf

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

TS PIK:

110477270

Diameter:

0.41

Voltage Rating:

600 VAC

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A4J25 Fuses EA

SKU:

F16-3466

Terminal Type:

Ferrule

Type:

Class J

Current Rating:

25 A

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

CAD Drawings:

Mersen_00197_1_CAD.pdf

Catalog:

Mersen_00086_193_CAT.pdf

Characteristics:

Fast Acting

Series:

A4J

Short Description:

0.81" x 2.25", 600 VAC/300 VDC, 25 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (10 per Pack)

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

530021

Length:

2-1/4

Diameter:

13/16

Voltage Rating:

600 VAC, 300 VDC

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A6T225 Fuses

SKU:

F16-3799

Current Rating:

225 A

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Series:

A6T

Terminal Type:

Blade

Characteristics:

Fast Acting

Type:

Class T

CAD Drawings:

Mersen_00220_1_CAD.pdf

Short Description:

1.62" x 3.62", 600 VAC/300 VDC, 225 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_195_CAT.pdf

TS PIK:

110477070

Diameter:

1.62

Voltage Rating:

600 VAC, 300 VDC

Length:

3.62

Approval:

UL 248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATDR4-1/2 Fuses EA

SKU:

F16-3826

Current Rating:

4.5 A

Series:

ATDR

Data Sheet:

Mersen_00064_1_2_DATA.pdf

Catalog:

Mersen_00086_194_CAT.pdf

Terminal Type:

Ferrule

Characteristics:

Time Delay

Type:

Class CC Rejection

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00134_1_CAD.pdf

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 4-1/2 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse

TS PIK:

110864123

Diameter:

0.41

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

Mexico

Ferraz Shawmut ATDR20 Fuses

SKU:

F16-3529

Type:

Class CC Rejection

Characteristics:

Time Delay

Series:

ATDR

Terminal Type:

Ferrule

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 20 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class CC, Low Vage, Current Limiting, Time Delay Fuse

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00134_1_CAD.pdf

Current Rating:

20 A

Catalog:

Mersen_00180_PF24_PF25_CAT.pdf

TS PIK:

110477347

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Length:

1.5

Diameter:

0.41

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut ATDR5 Fuses

SKU:

F16-3534

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 5 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class CC, Low Vage, Current Limiting, Time Delay Fuse

Current Rating:

5 A

Catalog:

Mersen_00180_PF24_PF25_CAT.pdf

CAD Drawings:

Mersen_00134_1_CAD.pdf

Type:

Class CC Rejection

Series:

ATDR

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Time Delay

Terminal Type:

Ferrule

TS PIK:

110477105

Length:

1.5

Diameter:

0.41

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut ATQR3 Fuses

SKU:

F16-3562

Catalog:

Mersen_00180_PF26_PF27_CAT.pdf

Series:

ATQR

CAD Drawings:

Mersen_00232_1_CAD.pdf

Type:

Class CC Rejection

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 50/60 Hz, 3 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class CC, Low Vage, Current Limiting, Time Delay Fuse

Characteristics:

Time Delay

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

3 A

Voltage Rating:

600 VAC

Length:

1.5

Diameter:

0.41

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A2D45R Fuses EA

SKU:

F16-3697

CAD Drawings:

Mersen_00173_1_CAD.pdf

Short Description:

0.81" x 3", 250 VAC/VDC, 45 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (10 per Pack)

Current Rating:

45 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Series:

A2D-R

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Characteristics:

Time Delay

Terminal Type:

Ferrule

Catalog:

Mersen_00086_189_CAT.pdf

Type:

Class RK1

TS PIK:

110477831

Voltage Rating:

250 VAC/DC

Length:

3

Diameter:

0.81

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TR250R Fuses EA

SKU:

F16-3603

Short Description:

2.06" x 8.63", 250 VAC 50/60 Hz/250 VDC, 250 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Type:

Class RK5

Terminal Type:

Blade

CAD Drawings:

Mersen_00257_1_CAD.pdf

Current Rating:

250 A

Characteristics:

Current Limiting, Time Delay

Catalog:

Mersen_00086_191_CAT.pdf

TS PIK:

528372

Diameter:

2.06

Voltage Rating:

250 VAC 50/60 Hertz, 250 VDC

Length:

8.63

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A3T500 Fuses EA

SKU:

F16-3458

Type:

Class T

Short Description:

1.62" x 3.06", 300 VAC/160 VDC, 500 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Characteristics:

Fast Acting

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Series:

A3T

Terminal Type:

Blade

Catalog:

Mersen_00086_195_CAT.pdf

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

CAD Drawings:

Mersen_00342_1_CAD.pdf

Current Rating:

500 A

TS PIK:

110477043

Length:

3.06

Voltage Rating:

300 VAC, 160 VDC

Diameter:

1.62

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQ12 Fuses

SKU:

F16-2365

Catalog:

Mersen_00086_198_CAT.pdf

Short Description:

0.41" x 1.5", 500 VAC, 12 A, 10 kA Interrupt Rating, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Midget Fuse

CAD Drawings:

Mersen_00136_1_CAD.pdf

Interrupting Rating:

10 kA

Current Rating:

12 A

Terminal Type:

Ferrule

Characteristics:

Time Delay

Data Sheet:

Mersen_00180_MF2_DATA.pdf

Series:

ATQ

Voltage Rating:

500 VAC 50/60 Hertz

Interrupt Rating:

10 kA

Diameter:

0.41

Length:

1.5

Approval:

UL 248-14, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut AJT10 Fuses EA

SKU:

F16-3973

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class J

Characteristics:

Time Delay, Current Limiting

Current Rating:

10 A

Short Description:

0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 10 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (5 per Pack)

Series:

AJT

Catalog:

Mersen_00086_192_CAT.pdf

CAD Drawings:

Mersen_00175_1_CAD.pdf

Data Sheet:

Mersen_00063_1_2_DATA.pdf

TS PIK:

110477773

Length:

2.25

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Diameter:

0.813

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQR3/16 Fuses

SKU:

F16-3849

Characteristics:

Time Delay

Terminal Type:

Ferrule

Current Rating:

0.1875 A

Series:

ATQR

Catalog:

Mersen_00086_194_CAT.pdf

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 3/16 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Type:

Class CC Rejection

Interrupting Rating:

200 kA (AC)/100 kA (DC)

CAD Drawings:

Mersen_00232_1_CAD.pdf

TS PIK:

115439329

Diameter:

0.41

Voltage Rating:

600 VAC, 300 VDC

Length:

1.5

Approval:

UL 248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATQR5 Fuses

SKU:

F16-3566

Characteristics:

Time Delay

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class CC Rejection

Catalog:

Mersen_00086_194_CAT.pdf

Current Rating:

5 A

CAD Drawings:

Mersen_00232_1_CAD.pdf

Series:

ATQR

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 5 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Terminal Type:

Ferrule

TS PIK:

110477296

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Diameter:

0.41

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

Mexico

Ferraz Shawmut AJT8 Fuses EA

SKU:

F16-3981

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00175_1_CAD.pdf

Short Description:

0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 8 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)

Series:

AJT

Terminal Type:

Ferrule

Characteristics:

Time Delay, Current Limiting

Catalog:

Mersen_00086_192_CAT.pdf

Current Rating:

8 A

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Type:

Class J

TS PIK:

110477788

Diameter:

0.813

Voltage Rating:

600 VAC 50/60 Hertz, 500 VDC

Length:

2.25

Approval:

UL 248/248-8, CSA C22.2

Ferraz Shawmut 266 Fuse Accessories Red EA

SKU:

O28-4416

Type:

Hinged

Short Description:

Hinged Ceiling Plate, Steel

Catalog:

GENRIHE00001_25.pdf

Size:

1-1/2 Inch CWT

Material:

Steel

Ferraz Shawmut ATQR10 Fuses

SKU:

F16-3557

Current Rating:

10 A

Type:

Class CC Rejection

Terminal Type:

Ferrule

Series:

ATQR

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00180_PF26_PF27_CAT.pdf

Characteristics:

Time Delay

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 50/60 Hz, 10 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class CC, Low Vage, Current Limiting, Time Delay Fuse

CAD Drawings:

Mersen_00232_1_CAD.pdf

TS PIK:

110477304

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC, 300 VDC

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATQR1 Fuses

SKU:

E30-7853

Series:

ATQR

Catalog:

Mersen_00086_194_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Time Delay

Current Rating:

1 A

CAD Drawings:

Mersen_00232_1_CAD.pdf

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 1 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Type:

Class CC Rejection

Terminal Type:

Ferrule

TS PIK:

110477275

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut A3T80 Fuses

SKU:

F16-3725

Type:

Class T

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Short Description:

0.81" x 2.16", 300 VAC/160 VDC, 80 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (5 per Pack)

Current Rating:

80 A

Series:

A3T

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Catalog:

Mersen_00086_195_CAT.pdf

Characteristics:

Fast Acting

Terminal Type:

Blade

CAD Drawings:

Mersen_00337_1_CAD.pdf

TS PIK:

110477029

Voltage Rating:

300 VAC, 160 VDC

Diameter:

0.81

Length:

2.16

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATQR1/10 Fuses

SKU:

F16-2097

Current Rating:

0.1 A

Terminal Type:

Ferrule

Characteristics:

Time Delay

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 1/10 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Type:

Class CC Rejection

Catalog:

Mersen_00086_194_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00232_1_CAD.pdf

Series:

ATQR

Voltage Rating:

600 VAC, 300 VDC

Diameter:

0.41

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut AJT15 Fuses

SKU:

F16-3513

Characteristics:

Time Delay, Current Limiting

Series:

AJT

CAD Drawings:

Mersen_00175_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00180_PF1_PF2_CAT.pdf

Current Rating:

15 A

Short Description:

0.81" x 2.25", 600 VAC, 500 VDC, 50/60 Hz, 15 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class J, Low Vage, Time Delay Fuse

Type:

Class J

Terminal Type:

Ferrule

TS PIK:

110477760

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Length:

2.25

Diameter:

0.813

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A6T175 Fuses

SKU:

F16-3494

Series:

A6T

Current Rating:

175 A

CAD Drawings:

Mersen_00130_1_CAD.pdf

Catalog:

Mersen_00086_195_CAT.pdf

Terminal Type:

Blade

Type:

Class T

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Fast Acting

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Short Description:

1.07" x 3.26", 600 VAC/300 VDC, 175 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Voltage Rating:

600 VAC, 300 VDC

Length:

3.26

Diameter:

1.07

Approval:

UL 248/248-15, CSA C22.2

Ferraz Shawmut A4J6 Fuses

SKU:

F16-3475

Series:

A4J

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

6 A

Short Description:

0.81" x 2.25", 600 VAC/300 VDC, 6 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (10 per Pack)

Characteristics:

Fast Acting

CAD Drawings:

Mersen_00197_1_CAD.pdf

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

Type:

Class J

Terminal Type:

Ferrule

Catalog:

Mersen_00086_193_CAT.pdf

TS PIK:

530017

Length:

2-1/4

Voltage Rating:

600 VAC, 300 VDC

Diameter:

13/16

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TR6R Fuses EA

SKU:

F16-4150

Characteristics:

Time Delay

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Type:

Class RK5

Short Description:

0.56" x 2", 250 VAC 50/60 Hz/160 VDC, 6 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

Current Rating:

6 A

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Catalog:

Mersen_00086_191_CAT.pdf

CAD Drawings:

Mersen_00099_1_CAD.pdf

Series:

TR-R

Terminal Type:

Ferrule

TS PIK:

528344

Voltage Rating:

250 VAC, 160 VDC

Diameter:

9/16

Length:

2

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A2D70R Fuses EA

SKU:

F16-3701

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Series:

A2D-R

Current Rating:

70 A

Terminal Type:

Blade

Catalog:

Mersen_00086_189_CAT.pdf

Short Description:

1.06" x 5.88", 250 VAC/VDC, 70 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (5 per Pack)

CAD Drawings:

Mersen_00173_1_CAD.pdf

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class RK1

TS PIK:

110477834

Diameter:

1-1/16

Length:

5-7/8

Voltage Rating:

250 VAC/DC

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQR30 Fuses

SKU:

F16-3563

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 30 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Current Rating:

30 A

Catalog:

Mersen_00086_194_CAT.pdf

CAD Drawings:

Mersen_00232_1_CAD.pdf

Terminal Type:

Ferrule

Series:

ATQR

Characteristics:

Time Delay

Type:

Class CC Rejection

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

115439335

Diameter:

0.41

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut TR200R Fuses

SKU:

F16-4871

TS PIK:

528370

Current Rating:

200 A

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Short Description:

1.56" x 7.13", 250 VAC 50/60 Hz, 250 VDC, 200 A, 200 kA AC/20 kA DC Interrupt Rating, Fiberglass Body, Tin Plated Copper Blade Terminal, Class RK5, Clip Mount, Time Delay, Low Vage, UL Power Fuse

CAD Drawings:

Mersen_00291_1_CAD.pdf

Characteristics:

Time Delay, Low Vage

Terminal Type:

Blade

Series:

TR-R

Type:

Class RK5

Diameter:

1.56

Length:

7.13

Voltage Rating:

250 VAC 50/60 Hertz, 250 VDC

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATDR9 Fuses EA

SKU:

F16-3536

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 9 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse

Catalog:

Mersen_00086_194_CAT.pdf

Characteristics:

Time Delay

CAD Drawings:

Mersen_00134_1_CAD.pdf

Type:

Class CC Rejection

Data Sheet:

Mersen_00064_1_2_DATA.pdf

Terminal Type:

Ferrule

Series:

ATDR

Current Rating:

9 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

115439321

Diameter:

0.41

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

Mexico

Ferraz Shawmut ATDR1 Fuses

SKU:

F16-3525

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 1 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse

Type:

Class CC Rejection

Series:

ATDR

Data Sheet:

Mersen_00064_1_2_DATA.pdf

Characteristics:

Time Delay

CAD Drawings:

Mersen_00134_1_CAD.pdf

Catalog:

Mersen_00086_194_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Ferrule

Current Rating:

1 A

TS PIK:

110477099

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut ATQ1/8 Fuses EA

SKU:

F16-3837

Terminal Type:

Ferrule

CAD Drawings:

Mersen_00136_1_CAD.pdf

Data Sheet:

Mersen_00067_MF2_DATA.pdf

Interrupting Rating:

10 kA

Characteristics:

12 Sec Time Delay (at 200 Percent Rated Load)

Catalog:

Mersen_00086_198_CAT.pdf

Short Description:

0.41" x 1.5", 500 VAC, 1/8 A, 10 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Midget Fuse

Series:

ATQ

Current Rating:

0.125 A

TS PIK:

110477158

Voltage Rating:

500 VAC

Diameter:

0.41

Length:

1.5

Approval:

UL 248-14, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut R266 Fuse Reducers and Clips

SKU:

F16-5189

Short Description:

60 A at 600 V Fuse, 200 A at 600 V Clip, 200 kA, Class R, Rejection, Fuse Reducer

Approval:

UL, CSA

Series:

R

Fuse Type:

Class R

Type:

Rejection

Catalog:

MERSENE00136_J3.pdf

Country of Origin:

Mexico

Ferraz Shawmut TR1-8/10R Fuse Accessories

SKU:

F16-4992

Series:

TR-R

Short Description:

0.56" x 2", 250 VAC 50/60 Hz/250 VDC, 1-8/10 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

CAD Drawings:

Mersen_00099_1_CAD.pdf

Current Rating:

1-8/10 A

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Catalog:

Mersen_00086_191_CAT.pdf

Type:

Class RK5

Terminal Type:

Ferrule

Characteristics:

Time Delay

Length:

2

Voltage Rating:

250 VAC/DC

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Diameter:

9/16

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A2D10R Fuses EA

SKU:

F16-3687

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Catalog:

Mersen_00086_189_CAT.pdf

Short Description:

0.56" x 2", 250 VAC/VDC, 10 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (10 per Pack)

Current Rating:

10 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Ferrule

Characteristics:

Time Delay

Type:

Class RK1

CAD Drawings:

Mersen_00173_1_CAD.pdf

Series:

A2D-R

TS PIK:

110477822

Diameter:

9/16

Length:

2

Voltage Rating:

250 VAC/DC

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A4BY800 Fuses

SKU:

F16-4677

TS PIK:

529734

Series:

A4BY

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

800 A

Terminal Type:

Blade

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

CAD Drawings:

Mersen_00124_1_CAD.pdf

Catalog:

Mersen_00086_188_CAT.pdf

Type:

Class L

Short Description:

2.5" x 8.63", 600 VAC/300 VDC, 800 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Voltage Rating:

600 VAC, 300 VDC

Diameter:

2-1/2

Length:

8-5/8

Approval:

UL 248/248-10, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A4BY1500 Fuses 600V EA

SKU:

F16-4848

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_188_CAT.pdf

Series:

A4BY

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

CAD Drawings:

Mersen_00195_1_CAD.pdf

Type:

Class L

Terminal Type:

Blade

Current Rating:

1500 A

Characteristics:

Time Delay

Short Description:

3" x 10.75", 600 VAC/300 VDC, 1500 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

TS PIK:

529737

Length:

10-3/4

Voltage Rating:

600 VAC, 300 VDC

Diameter:

3

Approval:

UL 248/248-10, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A2D6R Fuses EA

SKU:

F16-3700

Series:

A2D-R

Short Description:

0.56" x 2", 250 VAC/VDC, 6 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

CAD Drawings:

Mersen_00173_1_CAD.pdf

Terminal Type:

Ferrule

Catalog:

Mersen_00086_189_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class RK1

Current Rating:

6 A

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Characteristics:

Time Delay

TS PIK:

110477817

Length:

2

Diameter:

9/16

Voltage Rating:

250 VAC/DC

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATQR1-4/10 Fuses EA

SKU:

F16-3961

Series:

ATQR

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 1-4/10 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Current Rating:

1.4 A

Catalog:

Mersen_00086_194_CAT.pdf

Type:

Class CC Rejection

CAD Drawings:

Mersen_00232_1_CAD.pdf

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

Terminal Type:

Ferrule

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

110477278

Length:

1.5

Diameter:

0.41

Voltage Rating:

600 VAC

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A4J300 Fuses

SKU:

F16-3469

Short Description:

2.12" x 7.13", 600 VAC/300 VDC, 300 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Type:

Class J

Current Rating:

300 A

Catalog:

Mersen_00086_193_CAT.pdf

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

Terminal Type:

Blade

Characteristics:

Fast Acting

CAD Drawings:

Mersen_00196_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Series:

A4J

Length:

7-1/8

Approval:

UL 248/248-8, CSA C22.2

Diameter:

2-1/8

Voltage Rating:

600 VAC, 300 VDC

Ferraz Shawmut TRS350R Fuses

SKU:

F16-3629

TS PIK:

528434

Short Description:

2.56" x 11.63", 600 VAC 50/60 Hz/600 VDC, 350 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)

Catalog:

Mersen_00086_191_CAT.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00293_1_CAD.pdf

Type:

Class RK5

Current Rating:

350 A

Series:

TRS-R

Terminal Type:

Blade

Length:

11-5/8

Voltage Rating:

600 VAC/DC

Diameter:

2-9/16

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATQ1-1/8 Fuses EA

SKU:

F16-3839

Short Description:

500V 1-1/8A TD MIDGET FUSE

Current Rating:

1.125 A

TS PIK:

110477175

Country of Origin:

United States

Ferraz Shawmut ATQR12 Fuses

SKU:

E30-7854

Terminal Type:

Ferrule

Current Rating:

12 A

Catalog:

Mersen_00086_194_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Short Description:

0.41" x 1.5", 600 VAC 50/60 Hz, 300 VDC, 12 A, 200 kA Interrupt Rating, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Class CC Rejection, Control Transformer Fuse

Characteristics:

Time Delay

Type:

Class CC Rejection

Data Sheet:

Mersen_00180_PF26_PF27_DATA.pdf

CAD Drawings:

Mersen_00232_1_CAD.pdf

Series:

ATQR

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200 kA

Length:

1.5

Diameter:

0.41

TS PIK:

110477271

Approval:

UL 248/248-4, CSA C22.2

Ferraz Shawmut A2D125R Fuse Accessories EA

SKU:

F16-3688

Type:

Class RK1

Current Rating:

125 A

Catalog:

Mersen_00086_189_CAT.pdf

Short Description:

1.56" x 7.13", 250 VAC/VDC, 125 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (1 per Pack)

Terminal Type:

Blade

CAD Drawings:

Mersen_00173_1_CAD.pdf

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Series:

A2D-R

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Diameter:

1.56

Characteristics:

Time Delay

Approval:

UL 248/248-12, CSA C22.2

Voltage Rating:

250 VAC/DC

Length:

7.13

Country of Origin:

Mexico

Ferraz Shawmut TR6/10R Fuse Accessories

SKU:

F16-3923

Type:

Class RK5

CAD Drawings:

Mersen_00099_1_CAD.pdf

Series:

TR-R

Current Rating:

6/10 A

Catalog:

Mersen_00086_191_CAT.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Short Description:

0.56" x 2", 250 VAC 50/60 Hz/250 VDC, 6/10 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

Terminal Type:

Ferrule

Length:

2

Approval:

UL 248-12, CSA C22.2

Diameter:

9/16

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Voltage Rating:

250 VAC/DC

Characteristics:

Time Delay

Country of Origin:

United States

Ferraz Shawmut A4J100 Fuses 600V EA

SKU:

F16-3460

TS PIK:

530031

Short Description:

1.06" x 4.63", 600 VAC/300 VDC, 100 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (5 per Pack)

Series:

A4J

Type:

Class J

CAD Drawings:

Mersen_00199_1_CAD.pdf

Catalog:

Mersen_00086_193_CAT.pdf

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

100 A

Characteristics:

Fast Acting

Terminal Type:

Blade

Voltage Rating:

600 VAC, 300 VDC

Length:

4-4/8

Diameter:

1-1/8

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut AJT17-1/2 Fuses EA

SKU:

F16-3515

Type:

Class J

Current Rating:

17.5 A

Characteristics:

Time Delay, Current Limiting

Catalog:

Mersen_00086_192_CAT.pdf

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Series:

AJT

CAD Drawings:

Mersen_00175_1_CAD.pdf

Terminal Type:

Ferrule

Short Description:

0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 17-1/2 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator

TS PIK:

110477790

Diameter:

0.813

Length:

2.25

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Approval:

UL 248/248-8, CSA C22.2

Ferraz Shawmut A3T225 Fuses EA

SKU:

F16-3456

Short Description:

1.33" x 2.75", 300 VAC/160 VDC, 225 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Type:

Class T

Series:

A3T

Catalog:

Mersen_00086_195_CAT.pdf

Current Rating:

225 A

Characteristics:

Fast Acting

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Terminal Type:

Blade

CAD Drawings:

Mersen_00340_1_CAD.pdf

TS PIK:

110477037

Voltage Rating:

300 VAC, 160 VDC

Diameter:

1.33

Length:

2.75

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A3T1200 Fuses

SKU:

E30-11641

Short Description:

2.52" x 4", 300 VAC/160 VDC, 1200 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Type:

Class T

Catalog:

Mersen_00086_195_CAT.pdf

CAD Drawings:

Mersen_00338_1_CAD.pdf

Series:

A3T

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Characteristics:

Fast Acting

Terminal Type:

Blade

Current Rating:

1200 A

Interrupting Rating:

200 kA (AC), 50 kA (DC)

TS PIK:

110477047

Diameter:

2.52

Length:

4

Voltage Rating:

300 VAC, 160 VDC

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A4BY2500 Fuses

SKU:

F16-4674

TS PIK:

529741

Short Description:

4.5" x 10.75", 600 VAC/300 VDC, 2500 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

Current Rating:

2500 A

Type:

Class L

Characteristics:

Time Delay

CAD Drawings:

Mersen_00350_1_CAD.pdf

Series:

A4BY

Terminal Type:

Blade

Catalog:

Mersen_00086_188_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Voltage Rating:

600 VAC, 300 VDC

Diameter:

4-1/2

Length:

10-3/4

Approval:

UL E2137/238, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TRS500R Fuse Accessories

SKU:

F16-3632

Series:

TRS-R

CAD Drawings:

Mersen_00177_1_CAD.pdf

Current Rating:

500 A

Catalog:

Mersen_00086_191_CAT.pdf

Short Description:

3.12" x 13.38", 600 VAC 50/60 Hz/600 VDC, 500 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)

Terminal Type:

Blade

Type:

Class RK5

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Voltage Rating:

600 VAC/DC

Length:

13-3/8

Approval:

UL 248-12, CSA C22.2

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Diameter:

3-1/8

Characteristics:

Time Delay

Country of Origin:

United States

Ferraz Shawmut AJT9 Fuses EA

SKU:

F16-3524

Catalog:

Mersen_00086_192_CAT.pdf

Series:

AJT

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Type:

Class J

Short Description:

0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 9 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)

Current Rating:

9 A

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00175_1_CAD.pdf

Terminal Type:

Ferrule

TS PIK:

110477780

Diameter:

13/16

Voltage Rating:

600 VAC, 500 VDC

Length:

2-1/4

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A6T50 Fuses

SKU:

F16-5072

Type:

Class T

Series:

A6T

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Short Description:

0.81" x 1.57", 600 VAC/300 VDC, 50 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Copper Ferrule Terminal, Clip Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (10 per Pack)

Catalog:

Mersen_00086_195_CAT.pdf

Current Rating:

50 A

CAD Drawings:

Mersen_00221_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Fast Acting

Terminal Type:

Ferrule

TS PIK:

110477058

Diameter:

0.81

Voltage Rating:

600 VAC, 300 VDC

Length:

1.57

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut 212 Fuse Reducers and Clips EA

SKU:

F16-3644

Type:

Deep Bell

Short Description:

Deep Bell Escutcheon, Chrome Plated

Catalog:

GENRIHE00001_23.pdf

Material:

Steel

Size:

1-1/4 Inch Outer Diameter x 1-3/8 Inch Height

Country of Origin:

Mexico

Approval:

UL

Standard Package:

50 per Case

Prop 65 Warning:

Yes

Ferraz Shawmut ATQ1-6/10 Fuses

SKU:

F16-3840

Series:

ATQ

Interrupting Rating:

10 kA

Catalog:

Mersen_00086_198_CAT.pdf

Data Sheet:

Mersen_00067_MF2_DATA.pdf

Short Description:

0.41" x 1.5", 500 VAC, 1-6/10 A, 10 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Midget Fuse

CAD Drawings:

Mersen_00136_1_CAD.pdf

Characteristics:

12 Second Time Delay (200 Percent Rated Load)

Terminal Type:

Ferrule

Current Rating:

1.6 A

TS PIK:

110477178

Voltage Rating:

500 VAC

Length:

1.5

Diameter:

0.41

Approval:

UL 248-14, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATDR2 Fuses

SKU:

F16-3528

Series:

ATDR

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 2 A, 200 kA Interrupt Rating, GMG Body/Insulating, Tin Plated Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class CC, Low Vage, Current Limiting, Time Delay Fuse

Terminal Type:

Ferrule

Characteristics:

Time Delay

CAD Drawings:

Mersen_00134_1_CAD.pdf

Catalog:

Mersen_00180_PF24_PF25_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

2 A

Type:

Class CC Rejection

TS PIK:

110477101

Length:

1.5

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Diameter:

0.41

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut A4J175 Fuses 600V EA

SKU:

F16-3463

Current Rating:

175 A

Short Description:

1.62" x 5.75", 600 VAC/300 VDC, 175 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Series:

A4J

Catalog:

Mersen_00086_193_CAT.pdf

Type:

Class J

CAD Drawings:

Mersen_00352_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

Characteristics:

Fast Acting

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

TS PIK:

530035

Voltage Rating:

600 VAC, 300 VDC

Length:

5-3/4

Diameter:

1-5/8

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATDR2-1/2 Fuses 600V EA

SKU:

F16-3530

Series:

ATDR

Type:

Class CC Rejection

Current Rating:

2.5 A

Catalog:

Mersen_00086_194_CAT.pdf

Terminal Type:

Ferrule

Data Sheet:

Mersen_00064_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00134_1_CAD.pdf

Characteristics:

Time Delay

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 2-1/2 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse

TS PIK:

110477102

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC 50/60 Hertz, 300 VDC

Approval:

UL 248/248-4, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut ATQR4-1/2 Fuses EA

SKU:

F16-3850

Current Rating:

4.5 A

Type:

Class CC Rejection

Series:

ATQR

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 4-1/2 A, 200 kA/100 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Control Transformer Fuse

Catalog:

Mersen_00086_194_CAT.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Time Delay

CAD Drawings:

Mersen_00232_1_CAD.pdf

Terminal Type:

Ferrule

Data Sheet:

Mersen_00068_PF26_PF27_DATA.pdf

TS PIK:

110477295

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC, 300 VDC

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut AJT80 Fuses

SKU:

F16-5091

Series:

AJT

Catalog:

Mersen_00086_192_CAT.pdf

Characteristics:

Time Delay, Current Limiting

Current Rating:

80 A

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

CAD Drawings:

Mersen_00366_1_CAD.pdf

Type:

Class J

TS PIK:

110477770

Diameter:

1.063

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Length:

4.63

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut AJT250 Fuses EA

SKU:

F16-3975

Short Description:

2.12" x 7.13", 600 VAC 50/60 Hz/500 VDC, 250 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Blade Terminal, Clip/Bolted Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (1 per Pack)

CAD Drawings:

Mersen_00368_1_CAD.pdf

Type:

Class J

Current Rating:

250 A

Catalog:

Mersen_00086_192_CAT.pdf

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

Series:

AJT

Length:

7-1/8

Voltage Rating:

600 VAC, 500 VDC

Diameter:

2-1/8

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A2D3R Fuses

SKU:

F16-3450

Current Rating:

3 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class RK1

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

CAD Drawings:

Mersen_00173_1_CAD.pdf

Series:

A2D-R

Characteristics:

Time Delay

Catalog:

Mersen_00086_189_CAT.pdf

Short Description:

0.56" x 2", 250 VAC/VDC, 3 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

Terminal Type:

Ferrule

TS PIK:

110477810

Voltage Rating:

250 VAC/DC

Length:

2

Diameter:

9/16

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut AJT40 Fuses

SKU:

F16-3520

Short Description:

1.06" x 2.38", 600 VAC 50/60 Hz/500 VDC, 40 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_192_CAT.pdf

Type:

Class J

Current Rating:

40 A

Terminal Type:

Ferrule

CAD Drawings:

Mersen_00369_1_CAD.pdf

Series:

AJT

Characteristics:

Time Delay, Current Limiting

Data Sheet:

Mersen_00063_1_2_DATA.pdf

TS PIK:

110477753

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Length:

2.38

Diameter:

1.063

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATMR30 Fuses EA

SKU:

F16-3548

Series:

ATMR

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Current Rating:

30 A

Characteristics:

Fast Acting

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Ferrule

Type:

Class CC Rejection

Catalog:

Mersen_00086_194_CAT.pdf

Short Description:

0.41" x 1.5", 600 VAC/VDC, 30 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting, Power Fuse

TS PIK:

110477223

Voltage Rating:

600 VAC/DC

Length:

1.5

Diameter:

0.41

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut TR90R Fuses

SKU:

F16-3613

Type:

Class RK5

Series:

TR-R

Short Description:

0.06" x 5.88", 250 VAC/VDC, 50/60 Hz, 90 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Vage, Current Limiting, Time Delay Fuse

Catalog:

Mersen_00180_PF12_PF13_CAT.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Characteristics:

Time Delay

CAD Drawings:

Mersen_00290_1_CAD.pdf

Current Rating:

90 A

Terminal Type:

Blade

TS PIK:

528364

Length:

5-7/8

Voltage Rating:

250 VAC/DC

Diameter:

1-1/16

Approval:

UL 248-12, CSA C22.2, CE

Country of Origin:

United States

Ferraz Shawmut A4BY4000 Fuses

SKU:

F16-4675

TS PIK:

529744

Short Description:

5.75" x 10.75", 600 VAC/300 VDC, 4000 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Catalog:

Mersen_00086_188_CAT.pdf

Current Rating:

4000 A

Series:

A4BY

Characteristics:

Time Delay

CAD Drawings:

Mersen_00351_1_CAD.pdf

Terminal Type:

Blade

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

Type:

Class L

Diameter:

5-3/4

Voltage Rating:

600 VAC, 300 VDC

Length:

10-3/4

Approval:

UL, CSA

Country of Origin:

Mexico

Ferraz Shawmut A2D25R Fuses 250V EA

SKU:

F16-3693

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Current Rating:

25 A

CAD Drawings:

Mersen_00173_1_CAD.pdf

Short Description:

0.56" x 2", 250 VAC/VDC, 25 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (10 per Pack)

Type:

Class RK1

Series:

A2D-R

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_189_CAT.pdf

Characteristics:

Time Delay

Terminal Type:

Ferrule

TS PIK:

110477827

Voltage Rating:

250 VAC/DC

Diameter:

9/16

Length:

2

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A4J225 Fuses EA

SKU:

F16-3465

Series:

A4J

Type:

Class J

Short Description:

2.12" x 7.13", 600 VAC/300 VDC, 225 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Current Rating:

225 A

CAD Drawings:

Mersen_00352_1_CAD.pdf

Catalog:

Mersen_00086_193_CAT.pdf

Characteristics:

Fast Acting

Terminal Type:

Blade

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

530037

Diameter:

2.12

Voltage Rating:

600 VAC, 300 VDC

Length:

7.13

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQ14 Fuses EA

SKU:

E30-7851

Terminal Type:

Ferrule

Current Rating:

14 A

Catalog:

Mersen_00086_198_CAT.pdf

Data Sheet:

Mersen_00180_MF2_DATA.pdf

Short Description:

0.41" x 1.5", 500 VAC, 14 A, 10 kA Interrupt Rating, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Midget Fuse

CAD Drawings:

Mersen_00136_1_CAD.pdf

Interrupting Rating:

10 kA

Series:

ATQ

Characteristics:

12 Sec Time Delay (at 200 Percent Rated Load)

TS PIK:

110477162

Voltage Rating:

500 VAC

Diameter:

0.41

Length:

1.5

Approval:

UL 248-14, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TR70R Fuse Accessories EA

SKU:

F16-3989

Current Rating:

70 A

CAD Drawings:

Mersen_00290_1_CAD.pdf

Terminal Type:

Blade

Type:

Class RK5

Series:

TR-R

Catalog:

Mersen_00180_PF12_PF13_CAT.pdf

Short Description:

0.06" x 5.88", 250 VAC/VDC, 50/60 Hz, 70 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Vage, Current Limiting, Time Delay Fuse

Approval:

UL 248-12, CSA C22.2

Characteristics:

Time Delay, Dual Element

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Length:

5-7/8

Voltage Rating:

250 VAC/DC

Diameter:

1-1/16

Country of Origin:

United States

Ferraz Shawmut ATDR12 Fuses

SKU:

F16-3527

Short Description:

0.41" x 1.5", 600 VAC, 300 VDC, 12 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Time Delay, Power Fuse

Series:

ATDR

Current Rating:

12 A

Terminal Type:

Ferrule

Characteristics:

Time Delay

CAD Drawings:

Mersen_00134_1_CAD.pdf

Data Sheet:

Mersen_00064_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_194_CAT.pdf

Type:

Class CC Rejection

TS PIK:

110477110

Voltage Rating:

600 VAC, 300 VDC

Length:

1.5

Diameter:

0.41

Approval:

UL 248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A2D175R Fuses

SKU:

F16-3446

Short Description:

1.56" x 7.13", 250 VAC/VDC, 175 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (1 per Pack)

CAD Drawings:

Mersen_00173_1_CAD.pdf

Series:

A2D-R

Catalog:

Mersen_00086_189_CAT.pdf

Current Rating:

175 A

Characteristics:

Time Delay

Type:

Class RK1

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

TS PIK:

110477841

Voltage Rating:

250 VAC/DC

Length:

7.13

Diameter:

1.56

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut 162 Fuse Reducers and Clips EA

SKU:

C26-11208

Short Description:

Chrome Plated, 1-Hole, Escutcheon Extension for CHATEAU 1-Handle Tub and Shower Valve

Type:

Circular

Catalog:

GENRIHE00001_23.pdf

Size:

3/4 Inch IPS

Material:

Steel

Series:

100

Body Material:

Zinc

Prop 65 Warning:

Yes

Country of Origin:

United States

Ferraz Shawmut TR4/10R Fuse Accessories

SKU:

F16-3920

Series:

TR-R

Terminal Type:

Ferrule

Short Description:

0.56" x 2", 250 VAC 50/60 Hz/250 VDC, 4/10 A, 200 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (10 per Pack)

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Catalog:

Mersen_00086_191_CAT.pdf

Type:

Class RK5

Current Rating:

4/10 A

CAD Drawings:

Mersen_00099_1_CAD.pdf

Voltage Rating:

250 VAC/VDC

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Diameter:

9/16

Characteristics:

Time Delay

Approval:

UL 248-12, CSA C22.2

Length:

2

Country of Origin:

United States

Ferraz Shawmut A3T50 Fuses

SKU:

F16-3724

Catalog:

Mersen_00086_195_CAT.pdf

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Characteristics:

Fast Acting

CAD Drawings:

Mersen_00341_1_CAD.pdf

Short Description:

0.56" x 0.88", 300 VAC/160 VDC, 50 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Ferrule Terminal, Clip Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (10 per Pack)

Series:

A3T

Terminal Type:

Ferrule

Current Rating:

50 A

Type:

Class T

Interrupting Rating:

200 kA (AC), 50 kA (DC)

TS PIK:

110477026

Diameter:

0.56

Voltage Rating:

300 VAC, 160 VDC

Length:

0.88

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATMR15 Fuses EA

SKU:

F16-3544

Short Description:

0.41" x 1.5", 600 VAC/VDC, 15 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting, Power Fuse

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class CC Rejection

Terminal Type:

Ferrule

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Catalog:

Mersen_00086_194_CAT.pdf

Characteristics:

Fast Acting

Series:

ATMR

Current Rating:

15 A

TS PIK:

110477220

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC/DC

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut AJT110 Fuses

SKU:

F16-3974

Short Description:

1.62" x 5.75", 600 VAC 50/60 Hz/500 VDC, 110 A, 200 kA AC/100 kA DC Interrupt, Fiberglass Body, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (1 per Pack)

CAD Drawings:

Mersen_00352_1_CAD.pdf

Current Rating:

110 A

Series:

AJT

Catalog:

Mersen_00086_192_CAT.pdf

Characteristics:

Time Delay

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

Type:

Class J

TS PIK:

110477768

Diameter:

1-5/8

Voltage Rating:

600 VAC, 500 VDC

Length:

5-3/4

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A4J90 Fuses

SKU:

F16-3734

Type:

Class J

Short Description:

1.06" x 4.63", 600 VAC/300 VDC, 90 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (5 per Pack)

CAD Drawings:

Mersen_00199_1_CAD.pdf

Catalog:

Mersen_00086_193_CAT.pdf

Series:

A4J

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Fast Acting

Current Rating:

90 A

Terminal Type:

Blade

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

TS PIK:

530030

Length:

4.63

Voltage Rating:

600 VAC, 300 VDC

Diameter:

1.06

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATQ1-1/4 Fuses EA

SKU:

F16-3838

Interrupting Rating:

10 kA

Catalog:

Mersen_00086_198_CAT.pdf

Data Sheet:

Mersen_00067_MF2_DATA.pdf

CAD Drawings:

Mersen_00136_1_CAD.pdf

Series:

ATQ

Current Rating:

1.25 A

Terminal Type:

Ferrule

Characteristics:

12 Second Time Delay (200 Percent Rated Load)

Short Description:

0.41" x 1.5", 500 VAC, 1-1/4 A, 10 kA Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Time Delay, Midget Fuse

TS PIK:

110477176

Length:

1.5

Diameter:

0.41

Voltage Rating:

500 VAC

Approval:

UL 248-14, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A2D450R Fuses EA

SKU:

F16-3696

Short Description:

3.12" x 10.38", 250 VAC/VDC, 450 A, 200 kA AC/100 kA DC Interrupt, Polyester Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK1, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Indicator (1 per Pack)

Current Rating:

450 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class RK1

Terminal Type:

Blade

Series:

A2D-R

Catalog:

Mersen_00086_189_CAT.pdf

Data Sheet:

Mersen_00050_PF8_PF9_DATA.pdf

Characteristics:

Time Delay

CAD Drawings:

Mersen_00173_1_CAD.pdf

Length:

10-3/8

Voltage Rating:

250 VAC/VDC

Diameter:

2-9/16

Approval:

UL 248/248-12, CSA C22.2

Ferraz Shawmut A3T350 Fuses EA

SKU:

F16-3721

Series:

A3T

Type:

Class T

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Current Rating:

350 A

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

CAD Drawings:

Mersen_00340_1_CAD.pdf

Terminal Type:

Blade

Characteristics:

Fast Acting

Short Description:

1.33" x 2.75", 300 VAC/160 VDC, 350 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Catalog:

Mersen_00086_195_CAT.pdf

TS PIK:

110477040

Diameter:

1.33

Voltage Rating:

300 VAC, 160 VDC

Length:

2.75

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TR1/10R Fuse Accessories

SKU:

E30-7870

Short Description:

9/16" x 2", 250 VAC 50/60 Hz, 250 VDC, 1/10 A, 200 kA AC/20 kA DC Interrupt Rating, PolyTube Body, Copper Ferrule Terminal, Clip Mount, Time Delay, Class RK5, Low Vage Power Fuse

Series:

TR-R

Type:

Class RK5

Current Rating:

1/10 A

Catalog:

Mersen_00086_191_CAT.pdf

Terminal Type:

Ferrule

CAD Drawings:

Mersen_00099_1_CAD.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Length:

2

Diameter:

0.56

Characteristics:

Time Delay

Voltage Rating:

250 VAC 50/60 Hertz, 250 VDC

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut ATMR25 Fuses 600V EA

SKU:

F16-3834

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Short Description:

0.41" x 1.5", 600 VAC/VDC, 25 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting, Power Fuse

Catalog:

Mersen_00086_194_CAT.pdf

Current Rating:

25 A

Series:

ATMR

Terminal Type:

Ferrule

Characteristics:

Fast Acting

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class CC Rejection

TS PIK:

110477222

Diameter:

0.41

Voltage Rating:

600 VAC/DC

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A4J350 Fuses EA

SKU:

F16-3471

Current Rating:

350 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Series:

A4J

Short Description:

2.12" x 7.13", 600 VAC/300 VDC, 350 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Brass Alloy Blade Terminal, Clip Mount, Class J, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Data Sheet:

Mersen_00056_PF22_PF23_DATA.pdf

Catalog:

Mersen_00086_193_CAT.pdf

Characteristics:

Fast Acting

CAD Drawings:

Mersen_00196_1_CAD.pdf

Terminal Type:

Blade

Type:

Class J

TS PIK:

530040

Length:

7-1/8

Diameter:

2-1/8

Voltage Rating:

600 VAC, 300 VDC

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut AJT100 Fuses

SKU:

F16-3511

Type:

Class J

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Current Rating:

100 A

Data Sheet:

Mersen_00063_1_2_DATA.pdf

CAD Drawings:

Mersen_00366_1_CAD.pdf

Terminal Type:

Blade

Characteristics:

Time Delay, Current Limiting

Series:

AJT

Catalog:

Mersen_00086_192_CAT.pdf

TS PIK:

110477761

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Diameter:

1.063

Length:

4.63

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut A3T200 Fuses EA

SKU:

F16-3455

Series:

A3T

Type:

Class T

Short Description:

1.06" x 2.44", 300 VAC/160 VDC, 200 A, 200 kA AC/50 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

CAD Drawings:

Mersen_00339_1_CAD.pdf

Terminal Type:

Blade

Catalog:

Mersen_00086_195_CAT.pdf

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Current Rating:

200 A

Characteristics:

Fast Acting

TS PIK:

110477036

Voltage Rating:

300 VAC, 160 VDC

Length:

2.44

Diameter:

1.06

Approval:

UL 248/248-15, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut TRS75R Fuses

SKU:

F16-3635

Short Description:

1.31" x 7.88", 600 VAC 50/60 Hz/600 VDC, 75 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (5 per Pack)

Series:

TRS-R

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

Type:

Class RK5

Characteristics:

Time Delay

Catalog:

Mersen_00086_191_CAT.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Current Rating:

75 A

CAD Drawings:

Mersen_00258_1_CAD.pdf

TS PIK:

528422

Diameter:

1.31

Length:

7.88

Voltage Rating:

600 VAC 50/60 Hertz, 600 VDC

Approval:

UL 248/248-12, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut ATMR2 Fuses

SKU:

F16-3545

Current Rating:

2 A

Type:

Class CC Rejection

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Series:

ATMR

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Characteristics:

Fast Acting

Terminal Type:

Ferrule

Catalog:

Mersen_00086_194_CAT.pdf

Short Description:

0.41" x 1.5", 600 VAC/VDC, 2 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting, Power Fuse

TS PIK:

110477184

Voltage Rating:

600 VAC/DC

Diameter:

0.41

Length:

1.5

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Ferraz Shawmut A50P100-4 Fuses

SKU:

F16-3735

TS PIK:

529949

Short Description:

1" x 3.63", 500 VAC, 450 VDC, 100 A, 35 kA AC Interrupt, GMG Body, Tin Plated Brass Blade Terminal, Bolted Mount, Round, Current Limiting, High Speed, Very Fast Acting, Semiconductor Protection Fuse

Current Rating:

100 A

Series:

A50P

Length:

3.63

Characteristics:

Very Fast Acting, High Speed

Interrupting Rating:

35 kA (AC)

Terminal Type:

Blade

Voltage Rating:

500 VAC, 450 VDC

Type:

Round, Semiconductor

Data Sheet:

Mersen_00057_HS8_HS9_DATA.pdf

CAD Drawings:

Mersen_00206_1_CAD.pdf

Diameter:

1

Approval:

UL

Country of Origin:

Mexico

Ferraz Shawmut AB4Y300 Fuses

SKU:

F16-5057

Ferraz Shawmut A4BY3500 Fuses

SKU:

F16-4695

TS PIK:

529743

Short Description:

5.75" x 10.75", 600 VAC/300 VDC, 3500 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

Current Rating:

3500 A

CAD Drawings:

Mersen_00351_1_CAD.pdf

Series:

A4BY

Type:

Class L

Terminal Type:

Blade

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_188_CAT.pdf

Characteristics:

Time Delay

Voltage Rating:

600 VAC, 300 VDC

Length:

10-3/4

Diameter:

5-3/4

Approval:

UL 248/248-10, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut OT100 Fuses
