Square D EDB14030 Miniature Circuit Breakers (MCBs)

SKU:

C15-6356

TS PIK:

110613263

Type:

Thermal Magnetic, Branch, Miniature

Current Rating:

30 A

Used On:

NF Merchandised Panelboard

Catalog:

SchneiderElectric-SquareD_32357_9_31-9_33_CAT.pdf

Installation/Operator:

SchneiderElectric-SquareD_01117_INST.pdf

Data Sheet:

SchneiderElectric-SquareD_45551_1_2_DATA.pdf

Series:

EDB

Short Description:

277 VAC, 30 A, 18 kA, 1-Pole, E-Frame, Bolt-On Mount, Aluminum Lug Terminal, Thermal Magnetic, Branch, Miniature, Panelboard Circuit Breaker

Interrupting Rating:

18 kA at 480 Star/277 VAC

Voltage Rating:

277 VAC

Number of Poles:

1

Country of Origin:

Mexico

Approval:

UL (Canada and US), IEC

Application:

Lighting

Installation:

Bolt-On

Trip Setting:

270 A (Hold), 875 A (Trip)

Sti Guardmaster 44507-0110 Switch Accessories EA

SKU:

S21-2098

Bussmann AGC-2 Fuses 2A 125V 5PK

SKU:

F16-1537

TS PIK:

21366615

Short Description:

1-1/4 to 2" IPS, 6 AWG to 250 KCMIL, Clear Coated Aluminum Alloy, Ground ClA

Series:

AGC

CAD Drawings:

ECMIndustries-IlscoCorp_00203_1_CAD.pdf

Catalog:

ECMIndustries-IlscoCorp_00001_208_357_CAT.pdf

Challenger A1515 Miniature Circuit Breakers (MCBs) 1P 15/15A 50/60Hz 1Ph EA

SKU:

C15-8208

Number of Poles:

1

Eaton 4000353C12B Fuses

SKU:

F16-6902

Country of Origin:

Mexico

Eaton ARP00006CH2 Meter and Meter Socket Accessories EA

SKU:

C26-2187

Hub Size:

2 Inch

Type:

Meter Socket Entry

Short Description:

2" Hub, Meter Socket Hub Cover Plate

Specification/Technical:

Eaton_37470_1_SPEC.pdf

TS PIK:

106967243

Catalog:

Eaton_32249_V1T4_30-V1T4_32_V1T4_58_CAT.pdf

Country of Origin:

Mexico

Eaton CHFCAF115CS Miniature Circuit Breakers (MCBs) CHF 1P 15A 120V 50/60Hz 1Ph

SKU:

C15-2535

Series:

CH

Volts:

120 V

Amps:

15 A

Poles:

1

Frequency Rating:

50/60 Hz

Short Description:

EATON CH AFCI CIRCUIT BREAKER

Type:

Arc Fault

Number of Poles:

1

Current Rating:

15 A

Country of Origin:

Dominican Republic

Eaton CLNSURGECS Surge Protection Devices (SPDs) EA

SKU:

U23-2313

TS PIK:

128502886

Eaton CSR2100N Main Breakers CSR 2P 100A 240V 50/60Hz 1Ph EA

SKU:

C15-1977

Series:

CSR

Type:

Common Trip

Volts:

120/240 VAC

Amps:

32 A

Used On:

CH Series Load Center

Poles:

2

Interrupting Rating:

25 kA

Terminal Type:

Load Lug

Wire Size:

2 AWG to 300 KCMIL (Copper/Aluminum)

Specification/Technical:

EatonCorp_00204_1_2_SPEC.pdf

Current Rating:

100 A

Number of Poles:

2

Frame Type:

CH

Voltage Rating:

120/240 V

Short Description:

Type CSR Standard Circuit Breaker,Standard circuit breaker,100 A,25 kAIC,Two-pole,120/240 V,CH,#2 - 300 kcmil,Q1,CSR,Type CH loadcenters

Country of Origin:

Dominican Republic

Eaton FAZ-D40/2 Miniature Circuit Breakers (MCBs) EA

SKU:

C15-5259

Series:

FAZ

Type:

Current Limiting

Type:

Thermal Magnetic

Approval:

UL 1077

Approval:

UL (Canada and US)

Approval:

CSA C22.2

Approval:

CE

Size:

1.4 Inch Width x 2.36 Inch Depth x 3.15 Inch Height

Volts:

277/480 VAC

Amps:

32 A

Poles:

2

Mounting:

DIN Rail

Interrupting Rating:

10 kA

Terminal Type:

Screw

Wire Size:

18 to 4/18 to 8 AWG

Trip Setting:

10 to 20 x Rated Current

Short Description:

277/480 VAC 50/60 Hz, 40 A, 2-Pole, 10 kA, 10 to 20 x Rated Current, Line/Load Terminal, DIN Rail Mount, Standard Packaging, D-Curve, Current Limiting, Thermal Magnetic

Catalog:

Eaton_03771_V4T1_74-V4T1_92_CAT.pdf

Data Sheet:

Eaton_54188_1-9_DATA.pdf

Voltage Rating:

277/480 VAC

Current Rating:

40 A

Number of Poles:

2

Curve Type:

D

Country of Origin:

Germany

Eaton JHMVD12B Circuit Breaker Accessories Vari-Depth Handle Mechanism J Frame EA

SKU:

C15-1502

Approval:

UL

Approval:

CSA

Enclosure:

NEMA 1/12

Switch Type:

Molded Case

Breaker Type:

F Frame

Handle Type:

Black Universal Rotary

Handle Included:

Yes

Shaft Length:

12

Handle Mounting Location:

Left

Short Description:

12" Shaft, F Frame, Molded Case Switch, Black Universal Rotary

Catalog:

Eaton_41386_153_CAT.pdf

TS PIK:

115793073

Country of Origin:

Dominican Republic

Eaton UHS2710Z0017 Surge Protection Devices (SPD) Accessories Arrester

SKU:

U23-1527

Country of Origin:

United States

Short Description:

is a surge protection device accessory designed for enhanced electrical safety. It provides reliable protection against voltage surges, ensuring optimal performance and durability in various electronic systems.

Ferraz Shawmut A6T125 Fuses EA

SKU:

F16-4863

TS PIK:

110477066

Short Description:

1.07" x 3.26", 600 VAC/300 VDC, 125 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Copper Blade Terminal, Bolted Mount, Class T, Current Limiting, Fast Acting, Low Vage UL Power Fuse (1 per Pack)

Type:

Class T

Series:

A6T

Catalog:

Mersen_00086_195_CAT.pdf

CAD Drawings:

Mersen_00130_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Data Sheet:

Mersen_00052_PF32_PF33_DATA.pdf

Current Rating:

125 A

Terminal Type:

Blade

Characteristics:

Fast Acting

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/100 kA

Approval:

UL 248/248-15, CSA C22.2

Length:

3.26

Diameter:

1.07

Ferraz Shawmut ATMR3 Fuses

SKU:

F16-1479

Series:

ATMR

Type:

Class CC Rejection

Approval:

UL 248/248-4

Approval:

CSA C22.2

Volts:

600 VAC/DC

Amps:

32 A

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

100 kA (DC)

Terminal Type:

Ferrule

Length:

1.5

Diameter:

0.41

Characteristics:

Fast Acting

Short Description:

0.41" x 1.5", 600 VAC/VDC, 3 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting

Catalog:

Mersen_00086_194_CAT.pdf

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Current Rating:

3 A

Voltage Rating:

600 VAC/DC

Country of Origin:

United States

Ferraz Shawmut TR15R Fuses

SKU:

F16-2483

Series:

TR-R

Type:

Class RK5

Approval:

UL 248-12

Volts:

250 VAC 50/60 Hertz

Amps:

32 A

Interrupting Rating:

200 kA

Terminal Type:

Ferrule

Length:

2

Diameter:

0.56

Characteristics:

Time Delay

Short Description:

0.56" x 2", 250 VAC, 160 VDC, 50/60 Hz, 15 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Copper Connection/Terminal, Ferrule Terminal, Clip Mount, Class RK5, Low Voltage, Current Limiting

Catalog:

Mersen_00180_PF12_PF13_CAT.pdf

CAD Drawing:

Mersen_00099_1_CAD.pdf

CAD Drawings:

Mersen_00099_1_CAD.pdf

Current Rating:

15 A

Voltage Rating:

250 VAC 50/60 Hertz, 160 VDC

Country of Origin:

United States

GE THN3361R Safety Switches THN 3P 30A 600V 50/60Hz 3Ph Non Fusible 3Wire Nema 3R Heavy Duty

SKU:

S21-1542

Type:

Heavy Duty

Approval:

UL

Approval:

CSA

Approval:

NEMA KS1

Size:

13.1 Inch

Current Rating:

30 A

Poles:

3

Enclosure:

NEMA 3R

AC Voltage Rating:

600 V

Short Description:

240/480/600 VAC, 250 VDC, 30 A, 3-Pole, 3-Wire, NEMA 3R, Class H/K/J/R, Non-Fusible, Heavy Duty, Outdoor

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00004_8_1_8_3_CAT.pdf

CAD Drawing:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00492_1_CAD.pdf

TS PIK:

112124717

Number of Poles:

3

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00492_1_CAD.pdf

Number of Wires:

3

Fuse Provision:

Non-Fusible

Country of Origin:

United States

GENERAL ELECTRIC SELA36AT0100 Molded Case Breakers (MCCBs)

SKU:

C15-6874

TS PIK:

125878947

Voltage Rating:

600 VAC

Short Description:

600 VAC, 100 A Sensor, 65 kA Interrupt, 3-Pole, 12 to 3/0 AWG Aluminum/Copper, SE150 Frame, Digital, Solid State Electronic/Interchangeable Trip, RMS Trip Unit, LSI Trip Function, Standard Continuous Load, Molded Case Circuit Breaker

Series:

SEL

Frame Type:

E

Number of Poles:

3

Size:

4.12 Inch Width x 3.38 Inch Depth x 6.31 Inch Height

Interrupting Rating:

100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC (UL), 100 kA at 220 to 240 VAC, 20 kA at 380 to 415 VAC, 8 kA at 500 VAC, 3 kA at 690 VAC (IEC)

Maximum AC Voltage Rating:

600 V

Type:

Molded Case, Electronic Solid State Trip, Current Limiting

Current Rating:

100 A

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01751_1_CAD.pdf

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_6_5_6_6_6_172_CAT.pdf

Approval:

UL, CSA

Mersen A4BY1200 Fuses

SKU:

F16-4671

TS PIK:

529736

Series:

A4BY

Current Rating:

1200 A

Short Description:

2.5" x 10.75", 600 VAC/300 VDC, 1200 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Type:

Class L

Catalog:

Mersen_00086_188_CAT.pdf

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

CAD Drawings:

Mersen_00195_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Terminal Type:

Blade

Characteristics:

Time Delay

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/100 kA

Diameter:

2-1/2

Approval:

UL 248/248-10, CSA C22.2

Length:

10-3/4

Country of Origin:

Mexico

Mersen R622 Fuse Reducers and Clips 200A EA

SKU:

F16-3598

Type:

Rejection

Short Description:

200 A at 250/600 V Fuse, 600 A at 250/600 V Clip, 200 kA, Class R, Rejection, Fuse Reducer

Fuse Type:

Class R

Catalog:

Mersen_00041_J4_CAT.pdf

Approval:

UL, CSA

Country of Origin:

United States

Murray MP1515N Miniature Circuit Breakers (MCBs) 1P 15/15A 50/60Hz 1Ph EA

SKU:

C15-6297

Data Sheet:

SiemensAG_01518_1_DATA.pdf

Used On:

Loadcenter

Terminal Type:

Load Lug

Wire Size:

14 to 8 AWG (Copper), 12 to 8 AWG (Aluminum)

Current Rating:

15 A

Mounting:

Plug-On

Short Description:

120 V, 15/15 A, 10 kA, 1-Pole, Load Lug Terminal, MH-T Frame, Thermal Magnetic, Low Vage, Miniature, Circuit Breaker

Type:

Duplex

Number of Poles:

1

Voltage Rating:

120 VAC

Interrupting Rating:

10 kA

Country of Origin:

Mexico

Square D QO130GFI Miniature Circuit Breakers (MCBs) 30A 120V

SKU:

C15-6581

TS PIK:

118952369

Series:

QO-GFI

Short Description:

120 VAC 50/60 Hz, 30 A, 10 kA Interrupt, 1-Pole, Plug-In Mount, 1-Panel Space, Pressure Plate Terminal, 6 mA Class A Ground Fault, Pigtail, Miniature Circuit Breaker

Current Rating:

30 A

Installation/Operator:

SchneiderElectric-SquareD_00193_INST.pdf

Type:

Thermal Magnetic, Equipment Protector

Interrupting Rating:

10 kA

Number of Poles:

1

Data Sheet:

SchneiderElectric-SquareD_14869_1_2_DATA.pdf

Terminal Type:

Pressure Plate

Size:

0.75 Inch W x 2.91 Inch D x 4.12 Inch H

Catalog:

SchneiderElectric-SquareD_03264_1_5_CAT.pdf

Voltage Rating:

120 VAC at 50/60 Hz (UL/CSA)

Wire Size:

12 to 8 AWG (Aluminum), 14 to 8 AWG (Copper)

Mounting:

Plug-On

Used On:

QO Loadcenter, NQOD Panelboard, OEM Interior/Speed-D Switchboard Distribution Panel

Country of Origin:

Mexico

Trip Sensitivity:

6 MilliA

Approval:

UL, CSA

Sylvania FEXT56 Fuse Accessories EA

SKU:

F16-2251

UOM:

EA

Box Quantity:

1

Bwf EX-5V Power Outlet Panels EA

SKU:

L19-3898

Short Description:

4-9/16" x 2", 1/2" Hub, 18.3 Cu Inch, Gray, Die-Cast Metal, Round, Weatherproof Outlet Box Extension (18 per Case)

Catalog:

TeddicoElectricalProducts_00002_5_6_CAT.pdf

Material:

Die-Cast Metal

Eaton CH120AF Miniature Circuit Breakers (MCBs) EA

SKU:

C15-1374

Approval:

UL

Construction Feature:

Arc Fault Circuit Interrupter

Amps:

20 A

Interrupting Rating:

10 kA

Mounting:

Plug-On

Poles:

1

Size:

4 Inch Length x 0.75 Inch Width x 3.5 Inch Height

Terminal Type:

Clip (Line)

Type:

Thermal Magnetic

Used On:

Load Center

Volts:

120/240 VAC

Short Description:

120/240 VAC, 20 A, 10 kA, 1-Pole, Clip Line Terminal, Plug-On Mount, Thermal Magnetic, Branch Feeder, Arc Fault Circuit Breaker

Series:

CH

TS PIK:

119471855

Wire Size:

14 to 8 AWG (Copper/Aluminum)

Voltage Rating:

120/240 VAC

Current Rating:

20 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Application:

HACR

Eaton DG323URB General Duty Safety Switches

SKU:

S21-1082

Type:

General Duty

AC Voltage Rating:

240 V

Current Rating:

100 A

Number of Poles:

3

Number of Wires:

3

Fuse Provision:

Non-Fusible

Enclosure:

NEMA 3R

Power Rating:

15 HP at 240 VAC 1-Phase, 30 HP at 240 VAC 3-Phase

Neutral Type:

None

Size:

9.13 Inch W x 7.38 Inch D x 18.81 Inch H

Enclosure Material:

Painted Steel

Short Description:

240 VAC, 100 A, 30 HP, 3-Pole, 3-Wire, NEMA 3R, Painted Galvanized Steel, Non-Fusible, General Duty, Single Throw Safety Switch

Catalog:

Eaton_00003_V2T1_2_V2T1_3_V2T1_11_V2T1_25_V2T1_26_V2T1_28_CAT.pdf

Specification/Technical:

Eaton_38401_1_2_SPEC.pdf

TS PIK:

111010601

Series:

DG

Country of Origin:

United States

Approval:

UL 98

Finish:

Painted Galvanized

Eaton QBHW2060H Molded Case Breakers (MCCBs) EA

SKU:

C15-9649

TS PIK:

21505489

Catalog:

Eaton_03771_V4T1_12_CAT.pdf

Number of Poles:

2

Series:

QBHW

Current Rating:

60 A

Voltage Rating:

240 VAC

Type:

Thermal Magnetic

Short Description:

240 VAC, 60 A, 22 kA, 2-Pole, Extended Tang Line/Steel Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature, Circuit Breaker

Terminal Type:

Extended Tang Line Terminal, Box Lug Load Terminal

Interrupting Rating:

22000 A at 240 VAC

Mounting:

Bolt-On

Wire Size:

8 to 1/0 AWG (Aluminum/Copper, Load)

Approval:

UL 489, CSA

Country of Origin:

United States

Eaton QCF2050 Miniature Circuit Breakers (MCBs) QCF 2P 50A 120V 50/60Hz 1Ph EA

SKU:

C15-1663

Series:

QCF

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Mounting:

Cable-In/Cable-Out

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

3000 A at 24 to 48 Volt DC

Interrupting Rating:

3800 A at 62.5 Volt DC

Terminal Type:

Box Lug

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 50 A, 10 kA, 2-Pole, Box Lug Terminal, Cable-In/Out Front Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_23_V4T1_25_CAT.pdf

Voltage Rating:

120/240 VAC

Current Rating:

50 A

Number of Poles:

2

TS PIK:

106998233

Country of Origin:

Dominican Republic

Eaton TDL Meter and Meter Socket Accessories EA

SKU:

L19-1281

Used On:

CH Series Load Center

Load Center Current Rating:

100 to 225 Amp

Number Of Load Center Circuits:

12 to 42

Short Description:

12 to 42-Circuit

Catalog:

Eaton_36601_V1T1_20_V1T1_22_V1T1_66_V1T1_67_CAT.pdf

TS PIK:

111009806

Ferraz Shawmut R266 Fuse Reducers and Clips

SKU:

F16-5189

Short Description:

60 A at 600 V Fuse, 200 A at 600 V Clip, 200 kA, Class R, Rejection, Fuse Reducer

Approval:

UL, CSA

Series:

R

Fuse Type:

Class R

Type:

Rejection

Catalog:

MERSENE00136_J3.pdf

Country of Origin:

Mexico

GE TH3362 Safety Switches TH 3P 60A 600V 50/60Hz 3Ph Fusible 3Wire NEMA 1 Heavy Duty

SKU:

S21-1541

Type:

Heavy Duty

Approval:

UL

Approval:

CSA

Approval:

NEMA KS1

Size:

21.3 Inch

Current Rating:

60 A

Poles:

3

Enclosure:

NEMA 1

AC Voltage Rating:

600 V

Short Description:

480/600 VAC, 125/250 VDC, 60 A, 3-Pole, 3-Wire, NEMA 1, Class H/K/J/R, Fusible, Heavy Duty, Indoor

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00004_8_1_8_3_CAT.pdf

TS PIK:

554898

Number of Poles:

3

Number of Wires:

3

Series:

TH

Country of Origin:

United States

Mean Well WDR-120-24 Other Power Supplies EA

SKU:

U23-2338

Mersen A4BQ1200 Fuse Accessories

SKU:

F16-4662

TS PIK:

21406884

Type:

Class L

Data Sheet:

Mersen_00019_PF1_PF2_DATA.pdf

CAD Drawings:

Mersen_00192_1_CAD.pdf

Short Description:

2.5" x 10.75", 600 VAC/500 VDC, 1200 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Rejection, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Current Rating:

1200 A

Series:

A4BQ

Terminal Type:

Blade

Catalog:

Mersen_00086_188_CAT.pdf

Approval:

UL 248/248-10, CSA C22.2

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Time Delay

Voltage Rating:

600 VAC, 500 VDC

Length:

10-3/4

Diameter:

2-1/2

Country of Origin:

Mexico

Mulberry 30485 Switch Accessories Wallplate

SKU:

S21-1678

Abb SU201M-K3 Miniature Circuit Breakers (MCBs) 1P 3A 277V 50/60Hz

SKU:

C15-3392

Approval:

UL 489

Approval:

CSA C22.2

Approval:

CE

Amps:

3 A

Interrupting Rating:

10 kA

Mounting:

DIN Rail

Poles:

1

Size:

69 Millimeter Length x 17.5 Millimeter Width x 111 Millimeter Height

Terminal Type:

Failsafe Bi-Directional Cylinder Lift Double ClA Screw

Type:

Current Limiting

Used On:

Motor

Volts:

480 Star/277 VAC 50/60 Hertz

Volts:

48/96 VDC

Gauge:

18 to 4 AWG (Conductor)

Gauge:

18 to 8 AWG (Busbar)

Short Description:

69 MM x 17.5 MM x 111

Voltage Rating:

480 Star/277 VAC 50/60 Hertz, 48/96 VDC

Current Rating:

3 A

Number of Poles:

1

Catalog:

ABBInstallationProducts_00808_4_6_CAT.pdf

Data Sheet:

ABBInstallationProducts_00911_1-7_10_DATA.pdf

Installation/Operator:

ABBInstallationProducts_00074_INST.pdf

Wire Size:

18 to 4 AWG (Conductor), 18 to 8 AWG (Busbar)

Country of Origin:

Italy

Bussmann NON-15 Fuses 15A 250V 10BOX

SKU:

F16-1185

Series:

NON

Type:

Class K5/H

Approval:

UL 248

Approval:

CSA

Approval:

CE

Volts:

250 VAC

Volts:

125 VDC

Amps:

32 A

Interrupting Rating:

50 kA (AC/DC)

Terminal Type:

Ferrule

Length:

2

Diameter:

0.56

Characteristics:

1-Time

Characteristics:

Non-Current Limiting

Characteristics:

Non-Indicating

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 15 A, 50 kA Interrupt Rating, Ferrule Terminal, Class K5/H, 1-Time, Non-Current Limiting

Catalog:

Eaton-Bussmann_00349_1_21_CAT.pdf

Data Sheet:

Eaton-Bussmann_00320_1_2_DATA.pdf

TS PIK:

124377

Current Rating:

15 A

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

50 kA

Country of Origin:

Mexico

Eaton BQ240250 Miniature Circuit Breakers (MCBs) BQ 2P 40A/50A 120V 50/60Hz 1Ph EA

SKU:

C15-1157

Series:

BQ

Type:

Thermal Magnetic

Type:

Common Trip

Type:

Quadplex

Approval:

UL 489

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Loadcenter

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Aluminum/Copper)

Short Description:

120/240 VAC, 40/50 A, 10 kA, 2-Pole Outer/2-Pole Center, Plug-On Mount, BQ Breaker, Independent Trip, Quadplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_83_V1T1_87_CAT.pdf

TS PIK:

21493966

Number of Poles:

2

Current Rating:

40/50 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton BR3HT Circuit Breaker Accessories

SKU:

C15-2012

Breaker Type:

BR

Poles:

1

Short Description:

1-Pole, BR Breaker, Circuit Breaker Handle Tie

Series:

BR

Specification/Technical:

Eaton_36194_1_SPEC.pdf

TS PIK:

123342677

Country of Origin:

Dominican Republic

Eaton BRP115DF Miniature Circuit Breakers (MCBs)

SKU:

C15-2236

Type:

Dual Function

Type:

Plug-On Neutral

Approval:

UL

Size:

2.9 Inch Width x 2.9 Inch Depth x 0.9 Inch Height

Volts:

120 VAC

Amps:

32 A

Interrupting Rating:

10 kA

Application:

BR Load Center

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Poles:

1

Short Description:

120 VAC, 15 A, 1-Pole, 10 kA, Plug-On Neutral, Dual Function

Catalog:

Eaton_00001_V1T1_50_V1T1_85_CAT.pdf

Voltage Rating:

120 VAC

Current Rating:

15 A

TS PIK:

127539055

Mounting:

Plug-On

Number of Poles:

1

Series:

BR

Country of Origin:

United States

Eaton BRP30B100 Loadcenters and Panelboards BR 1P 100A 240V 50/60Hz 1Ph 3Wire 60Cir 30Sp EA NEMA 1

SKU:

L19-1808

Type:

Main Breaker

Approval:

UL 50/67

Size:

14.3 Inch Width x 3.8 Inch Depth x 29.13 Inch Height

Volts:

120/240 VAC

Amps:

100 A

Interrupting Rating:

10 kA

Enclosure:

NEMA 1

Enclosure:

Indoor

Cover Type:

Flush/Surface

Neutral Type:

Insulated/Bondable Split

Circuit Configuration:

1-Phase 3-Wire

Bus Material:

Tin Plated Aluminum

Maximum Number of Circuits:

60

Enclosure Size Designation:

X5

Maximum Number of Spaces:

(30) 1-Pole 1

Feed Location:

Top/Bottom

Main Wire Size:

4 to 1/0 AWG Copper/Aluminum

Main Breaker Type:

BR

Breaker Mounting:

Plug-On

Catalog:

Eaton_00071_V1T1_46-V1T1_78_CAT.pdf

Installation/Operator:

Eaton_00231_INST.pdf

TS PIK:

127538983

Voltage Rating:

120/240 VAC

Current Rating:

100 A

Short Description:

120/240 VAC, 1-Phase, 100 A, 25 kA Interrupt, 60-Circuit, 30-Space, 1-Pole, 3-Wire, 6 to 1/0 AWG Copper/Aluminum, Aluminum Bus, NEMA 1, Insulated/Bondable Spilt Neutral, Indoor, Plug-On, Main Circuit Breaker Load Center with Cover

Enclosure Type:

NEMA 1, Indoor

Country of Origin:

United States

Eaton CHFGFT120 Miniature Circuit Breakers (MCBs) CHF 1P 20A 120V 50/60Hz 1Ph EA

SKU:

C15-1445

Series:

CH

Type:

Thermal Magnetic

Size:

3.5 Inch Length x 1 Inch Width x 3 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Clip (Line)

Wire Size:

14 to 6 AWG (Copper/Aluminum)

Trip Sensitivity:

5 MilliA

Short Description:

120 VAC, 20 A, 10 kA, 5 mA Trip Level, 1-Pole, Plug-On Mount, Thermal Magnetic

Catalog:

Eaton_00069_33_CAT.pdf

TS PIK:

126205839

Current Rating:

20 A

Voltage Rating:

120 VAC

Number of Poles:

1

Country of Origin:

United States

Eaton CHL125N Miniature Circuit Breakers (MCBs) 3P 125A 240V EA

SKU:

L19-1786

Series:

CH

Type:

Main Lug

Used On:

Type CH Loadcenter

Conductor Size:

10 to 1/0 AWG

Short Description:

125 A, #10-1/0, NEMA 3R

Catalog:

Eaton_36601_V1T1_2_V1T1_11_V1T1_21_CAT.pdf

TS PIK:

111009780

Number of Poles:

1

Country of Origin:

United States

Eaton DH365UGK Safety Switches EA

SKU:

S21-1591

Series:

DH

Type:

Heavy Duty

Approval:

UL 98

Size:

23 Inch Width x 12.63 Inch Depth x 45.19 Inch Height

Current Rating:

400 A

Poles:

3

Finish:

Painted

Enclosure:

NEMA 1

Number of Wires:

3

Power Rating:

125 HP at 240 VAC 3-Phase

Neutral Type:

None

AC Voltage Rating:

480 V

Enclosure Material:

Steel

Fuse Provision:

Non-Fusible

DC Voltage Rating:

250 V

Short Description:

480 to 600 VAC, 250 VDC, 400 A, 350 HP, 3-Pole, 3-Wire, NEMA 1, Painted Steel, Non-Fusible, Heavy Duty

Catalog:

Eaton_00003_V2T1_2_V2T1_4_V2T1_11_CAT.pdf

TS PIK:

111011577

Number of Poles:

3

Country of Origin:

United States

Eaton EGH1100FFB Molded Case Breakers (MCCBs) EGH 1P 100A 240V 50/60Hz 1Ph EG Frame

SKU:

C15-2091

Series:

G

Volts:

240 V

Amps:

100 A

Poles:

1

Frequency Rating:

50/60 Hz

Frame:

EG

Short Description:

EGH BOLT ON 1P 100A BRANCH BREAKER FOR PRL3E

Current Rating:

100 A

Number of Poles:

1

Country of Origin:

Dominican Republic

Eaton HMCP100R3CH09 Motor Circuit Protector (MCPs)

SKU:

C15-11301

TS PIK:

110190698

Short Description:

SERIES C, F-FRAME MOTOR CIRCUIT PROTECTOR 3P 100A CB Molded Case Circuit Breakers

Number of Poles:

3

Current Rating:

100 A

Frame Type:

F

Voltage Rating:

600 VAC

Eaton HMCPS150U4C Motor Circuit Protector (MCPs)

SKU:

C15-9266

Short Description:

150 A, 3-Pole, 750 to 2500 A, Trip Setting, Motor Circuit Protector

Current Rating:

150 A

Terminal Type:

Non-Aluminum

Data Sheet:

Eaton_00054_1-9_DATA.pdf

Catalog:

Eaton_21665_V4T2_362_V4T2_363_V4T2_368_CAT.pdf

Installation/Operator:

Eaton_00176_INST.pdf

Country of Origin:

Dominican Republic

Trip Setting:

750 to 2500 A

Eaton LT3500FA Trip Units

SKU:

A13-1049

TS PIK:

120602137

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY TRIP UNIT, TRIP UNIT, 500 A, THREE-POLE, FIXED THERMAL, ADJUSTABLE MAGNETIC, LT, FRAME LG, SERIES G

GE TEDST12 Shunt Trips EA

SKU:

A13-1320

Type:

Remote

Used On:

Circuit Breaker

Short Description:

120/240 VAC, 125 VDC, Remote Control

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01912_6_71_CAT.pdf

Gould TR125R Fuses

SKU:

F16-3600

Current Rating:

125 A

Type:

Class RK5

Catalog:

Mersen_00180_PF12_PF13_CAT.pdf

Series:

TR-R

CAD Drawings:

Mersen_00291_1_CAD.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Short Description:

1.56" x 7.13", 250 VAC/VDC, 50/60 Hz, 125 A, 200 kA Interrupt Rating, Poly Tube Body/Insulating, Tin Plated Copper Connection/Terminal, Blade Terminal, Clip Mount, Class RK5, Low Vage, Current Limiting, Time Delay Fuse

Characteristics:

Time Delay

Terminal Type:

Blade

TS PIK:

528367

Length:

7-1/8

Voltage Rating:

250 VAC/DC

Approval:

UL 248-12, CSA C22.2

Diameter:

1-9/16

Country of Origin:

United States

Siemens ECGK Meter and Meter Socket Accessories EA

SKU:

L19-2209

Used On:

P1/P2/P3 Panelboard

Standard Package:

1

Conductor Material:

Copper

Short Description:

(6) 14 to 1/0 AWG, (15) 14 to 6 AWG, Copper Conductor, 42-Circuit, 44-Connection

Catalog:

SiemensAG_00565_11_3_11_20_11_22_11_55_11_67_CAT.pdf

Data Sheet:

SiemensAG_05755_1_DATA.pdf

Installation/Operator:

SiemensAG_00272_INST.pdf

Square D QO1HPL Circuit Breaker Accessories EA

SKU:

C15-6532

Type:

Padlockable

Short Description:

2/3-Pole, On/Off Locking, Loose Handle Padlock Attachment for QO/Q1 Series Circuit Breaker

Installation/Operator:

SchneiderElectric-SquareD_00884_INST.pdf

Used On:

QO/Q1 Series Circuit Breaker

Data Sheet:

SchneiderElectric-SquareD_14908_1_DATA.pdf

Catalog:

SchneiderElectric-SquareD_03264_1_8_CAT.pdf

Locking Provision:

On/Off

Westinghouse WHUN361 Heavy Duty Safety Switches EA

SKU:

S21-2531

Type:

Heavy Duty

AC Voltage Rating:

600 V

Current Rating:

30 A

Number of Poles:

3

Series:

WH

Carlon E97SSRB Power Outlet Panels

SKU:

L19-3934

Short Description:

5.69" Diameter, 1-1/4" NPS Receptacle, Brown High Impact Resistant Thermoplastic, Round, Floor Box Cover

Catalog:

ABB-Carlon_03571_42_127_CAT.pdf

CAD Drawings:

ABB-Carlon_04085_1_CAD.pdf

Material:

Thermoplastic

Type:

Round

Cooper FL1A10 Fuses EA

SKU:

F16-2795

Short Description:

FUSE LK CPS PSD CUTOUT 010A

UOM:

EA

Type:

MEDIUM VOLTAGE FUSE LINK

Box Quantity:

1

Country of Origin:

United States

Crouse-Hinds BRCAF120 Miniature Circuit Breakers (MCBs) BR 1P 20A 50/60Hz 1Ph EA

SKU:

C15-5384

TS PIK:

124548669

Short Description:

120 V, 20 A, 10 kA, 1-Pole, Plug-On Mount, Combination, Arc Fault Circuit Breaker

Series:

BR

Voltage Rating:

120 V

Mounting:

Plug-On

Type:

Combination

Current Rating:

20 A

Size:

6 Inch Length x 3.5 Inch Width x 1.25 Inch Height

Interrupting Rating:

10 kA

Catalog:

Eaton_36650_V1T1_76_V1T1_79_CAT.pdf

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Used On:

Loadcenter

Number of Poles:

1

Country of Origin:

Dominican Republic

Approval:

UL 1699

Poles:

1

Eaton BR350 Miniature Circuit Breakers (MCBs)

SKU:

C15-11092

TS PIK:

21493898

Series:

BR

Voltage Rating:

240 VAC

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Catalog:

Eaton_36620_V1T1_85_CAT.pdf

Type:

Thermal Magnetic, Common Trip

Short Description:

240 VAC, 50 A, 10 kA, 3-Pole, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic, Circuit Breaker

Current Rating:

50 A

Mounting:

Plug-On

Used On:

BR Series Load Center

Number of Poles:

3

Approval:

UL 489

Country of Origin:

Dominican Republic

Eaton DH030NK Switch Accessories EA

SKU:

L19-1652

Amps:

30 to 60 A

Volts:

600 VAC/DC (Heavy Duty)

Type:

Groundable

Used On:

Heavy Duty Safety Switch

Gauge:

0

Short Description:

30 to 60 A, (4) 14 to 2 AWG, Neutral Kit for Heavy Duty Safety Switch

Specification/Technical:

Eaton_38419_1_SPEC.pdf

TS PIK:

111013018

Catalog:

Eaton_00003_V2T1_13_V2T1_19_CAT.pdf

Switch Current Rating:

30 to 60 A

Switch Voltage Rating:

600 VAC/DC (Heavy Duty)

Country of Origin:

United States

Eaton FAZ-D10/3 Miniature Circuit Breakers (MCBs) FAZ 3P 10A 277V 50/60Hz 3Ph EA

SKU:

C15-3506

Series:

FAZ

Approval:

UL 1077

Approval:

CSA C22.2

Size:

2.07 Inch L

Volts:

400 V

Amps:

32 A

Poles:

3

Mounting:

DIN Rail

Terminal Type:

Screw

Trip Setting:

10 to 20 x Rated Current (Magnetic)

Short Description:

480 VAC Star/277 VAC, 96 VDC, 10 A, 15 kA, 10 to 20 x Rated Current, 3-Pole, Screw Terminal, DIN Rail Mount

Catalog:

Eaton_03771_V4T1_74_V4T1_75_V4T1_78_V4T1_85_V4T1_86_V4T1_88_V4T1_92_CAT.pdf

Data Sheet:

Eaton_40766_1-9_DATA.pdf

Installation/Operator:

Eaton_00479_INST.pdf

TS PIK:

124503353

Number of Poles:

3

Current Rating:

10 A

Voltage Rating:

400 VAC

Curve Type:

D

Country of Origin:

Germany

Eaton FD1020 Molded Case Breakers (MCCBs) GHB 2P 40A 480V 50/60Hz 3Ph G Frame EA

SKU:

C15-1804

Frame Type:

F

Voltage Rating:

277 VAC

Current Rating:

32 A

Number of Poles:

1

Interrupting Rating:

35 kA at 277 VAC,10 kA at 125 VDC

Type:

Current Limiting

Maximum AC Voltage Rating:

277

Maximum DC Voltage Rating:

125

Terminal Type:

Standard Pressure Load Terminal

Size:

1.38 Inch W x 3.38 Inch D x 6 Inch H

Short Description:

277 VAC 50/60 Hz, 125 VDC, 20 A, 35/10 kA, 1-Pole, Standard Pressure Load Terminal, FD Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Data Sheet:

Eaton_07831_1-5_DATA.pdf

Installation/Operator:

Eaton_00091_INST.pdf

CAD Drawings:

Eaton_41226_1_CAD.pdf

Series:

C

Approval:

UL

Country of Origin:

United States

Eaton KD3350W Molded Case Breakers (MCCBs) KD 3P 350A 600V 50/60Hz 3Ph K Frame EA

SKU:

C15-3948

Series:

C

Volts:

600 V

Amps:

350 A

Poles:

3

Frequency Rating:

50/60 Hz

Frame:

K

Short Description:

EATON SERIES C COMPLETE MOLDED CASE CIRCUIT BREAKER, K-FRAME, KD, COMPLETE BREAK

TS PIK:

115573590

Country of Origin:

Dominican Republic

Eaton QCF2010T Miniature Circuit Breakers (MCBs) QCF 2P 10A 240V 50/60Hz 1Ph

SKU:

C15-1998

Series:

Quicklag

Volts:

240 V

Amps:

10 A

Poles:

2

Frequency Rating:

50/60 Hz

Short Description:

QCF BKR 2P 10A W/ RING LUG TERM.

Country of Origin:

Dominican Republic

Ferraz Shawmut A4BY1600 Fuse Accessories

SKU:

F16-4691

TS PIK:

529738

Type:

Class L

Short Description:

3" x 10.75", 600 VAC/300 VDC, 1600 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

CAD Drawings:

Mersen_00195_1_CAD.pdf

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

Series:

A4BY

Catalog:

Mersen_00086_188_CAT.pdf

Terminal Type:

Blade

Current Rating:

1600 A

Length:

10-3/4

Approval:

UL E2137/238, CSA C22.2

Characteristics:

4-Second Time Delay

Diameter:

3

Voltage Rating:

600 VAC, 300 VDC

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Country of Origin:

Mexico

Ferraz Shawmut A4BY600 Fuse Accessories

SKU:

F16-4715

CAD Drawings:

Mersen_00124_1_CAD.pdf

Terminal Type:

Blade

Catalog:

Mersen_00086_188_CAT.pdf

Current Rating:

600 A

Series:

A4BY

Short Description:

2" x 8.63", 600 VAC/300 VDC, 600 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Silver Plated Copper Blade Terminal, Bolted Mount, Class L, Current Limiting, 4 Sec Time Delay, Low Vage UL Power Fuse (1 per Pack)

Type:

Class L

Data Sheet:

Mersen_00019_PF4_PF5_DATA.pdf

Length:

8-5/8

Voltage Rating:

600 VAC, 300 VDC

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Approval:

UL 248/248-10, CSA C22.2

Diameter:

2

Country of Origin:

Mexico

Ferraz Shawmut AJT25 Fuses

SKU:

F16-3518

TS PIK:

110477758

Series:

AJT

Catalog:

Mersen_00086_192_CAT.pdf

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Short Description:

0.81" x 2.25", 600 VAC 50/60 Hz/500 VDC, 25 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)

CAD Drawings:

Mersen_00175_1_CAD.pdf

Terminal Type:

Ferrule

Characteristics:

Time Delay, Current Limiting

Current Rating:

25 A

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Type:

Class J

Length:

2.25

Diameter:

0.813

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut AJT40 Fuses

SKU:

F16-3520

Short Description:

1.06" x 2.38", 600 VAC 50/60 Hz/500 VDC, 40 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class J, Current Limiting, Time Delay, Low Vage UL Power Fuse with SmartSpot Visual Blown Indicator (10 per Pack)

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Catalog:

Mersen_00086_192_CAT.pdf

Type:

Class J

Current Rating:

40 A

Terminal Type:

Ferrule

CAD Drawings:

Mersen_00369_1_CAD.pdf

Series:

AJT

Characteristics:

Time Delay, Current Limiting

Data Sheet:

Mersen_00063_1_2_DATA.pdf

TS PIK:

110477753

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Length:

2.38

Diameter:

1.063

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut AJT70 Fuses EA

SKU:

F16-3523

Characteristics:

Time Delay, Current Limiting

Series:

AJT

Current Rating:

70 A

CAD Drawings:

Mersen_00366_1_CAD.pdf

Catalog:

Mersen_00086_192_CAT.pdf

Terminal Type:

Blade

Type:

Class J

Data Sheet:

Mersen_00063_1_2_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

TS PIK:

110477769

Diameter:

1.063

Length:

4.63

Voltage Rating:

600 VAC 50/60 Hertz, 400 VDC

Approval:

UL 248/248-8, CSA C22.2

Country of Origin:

United States

Ferraz Shawmut TRS350R Fuses

SKU:

F16-3629

TS PIK:

528434

Short Description:

2.56" x 11.63", 600 VAC 50/60 Hz/600 VDC, 350 A, 200 kA AC/100 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class RK5, Rejection, Current Limiting, Time Delay, Low Vage UL Power Fuse (1 per Pack)

Catalog:

Mersen_00086_191_CAT.pdf

Data Sheet:

Mersen_00090_PF12_PF13_DATA.pdf

Characteristics:

Time Delay

Interrupting Rating:

200 kA (AC), 100 kA (DC)

CAD Drawings:

Mersen_00293_1_CAD.pdf

Type:

Class RK5

Current Rating:

350 A

Series:

TRS-R

Terminal Type:

Blade

Length:

11-5/8

Voltage Rating:

600 VAC/DC

Diameter:

2-9/16

Approval:

UL 248-12, CSA C22.2

Country of Origin:

United States

Gould OTS20 Fuses

SKU:

F16-3586

Type:

Class K5

Short Description:

13/16" x 5", 600 VAC, 300 VDC, 20 A, 50 kA AC/20 kA DC Interrupt Rating, Paper Body, Copper Ferrule Terminal, Clip Mount, Fast Acting, One Time, Class K5, Low Vage Power Fuse

Current Rating:

20 A

Series:

OTS

CAD Drawings:

Mersen_00254_1_CAD.pdf

Catalog:

Mersen_00086_195_CAT.pdf

Data Sheet:

Mersen_00082_PF30_PF31_DATA.pdf

Characteristics:

Fast Acting, One Time

Terminal Type:

Ferrule

Interrupting Rating:

50 kA (AC), 20 kA (DC)

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

50/20 kA

TS PIK:

528110

Length:

5

Approval:

UL 248/248-9, CSA C22.2

Diameter:

0.81

Country of Origin:

Mexico

Eaton BR2100 Miniature Circuit Breakers (MCBs)

SKU:

C15-1215

Series:

BR

Type:

Thermal Magnetic

Type:

Common Trip

Approval:

UL 489

Approval:

CSA

Size:

1.9 Inch Length x 2 Inch Width x 2.4 Inch Height

Volts:

120/240 VAC

Amps:

32 A

Used On:

BR Series Load Center

Poles:

2

Mounting:

Plug-On

Interrupting Rating:

10 kA

Terminal Type:

Lug

Wire Size:

4 to 1/0 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 100 A, 10 kA, 2-Pole, Lug Screw Terminal, Plug-On Mount, Common Trip, Duplex, Thermal Magnetic

Catalog:

Eaton_36620_V1T1_56_V1T1_84_CAT.pdf

TS PIK:

21493865

Number of Poles:

2

Current Rating:

100 A

Voltage Rating:

120/240 VAC

Country of Origin:

Dominican Republic

Eaton C0200E2AFB Control Transformers EA

SKU:

T22-1147

Approval:

UL

Approval:

CSA

Approval:

CUL

Size:

4.488 Inch Width x 4.016 Inch Depth x 5.197 Inch Height

Mounting:

0.46 Inch Length x 0.2 Inch Width Slot

Terminal Type:

Screw Lug

Power Rating:

200 Volt Amp

Applicable Standard:

ANSI

Applicable Standard:

IEEE

Applicable Standard:

NEMA

Frequency Rating:

50/60 Hertz

Primary Voltage:

240 x 480 Volt AC

Primary Voltage:

230 x 460 Volt AC

Primary Voltage:

220 x 440 Volt AC

Secondary Voltage:

120/115/110 Volt AC

Temperature Rise:

55 Deg C

Insulation Class:

130

Short Description:

240 x 480 VAC, 230 x 460 VAC, 220 x 440 VAC Primary, 120/115/110 VAC Secondary, 50/60 Hz, 200 VA, Molded-In Terminal, Type MTE

Catalog:

Eaton_00010_V7T7_7_CAT.pdf

CAD Drawing:

Eaton_41153_1_CAD.pdf

TS PIK:

21518862

Eaton DH321FGK Heavy Duty Safety Switches 3P 30A 240V EA

SKU:

S21-1050

Short Description:

240 VAC, 250 VDC, 30 A, 7-1/2 HP, 3-Pole, 3-Wire, NEMA 1, Painted Steel, Class H Fusible, Heavy Duty

Type:

Heavy Duty

AC Voltage Rating:

240 V

DC Voltage Rating:

250 V

Current Rating:

30 A

Number of Poles:

3

Number of Wires:

3

Fuse Provision:

Fusible

Fuse Type:

Class H

Enclosure:

NEMA 1

Catalog:

Eaton_00003_V2T1_2_V2T1_4_V2T1_11_CAT.pdf,Eaton_00003_V2T1_2_V2T1_4_V2T1_11_CAT.pdf

Technical Specifications:

Eaton_38479_1_2_SPEC.pdf

Series:

DH

Size:

9.89 Inch Width x 7.75 Inch Depth x 16 Inch Height

Power Rating:

1-1/2 HP at 240 VAC 1-Phase, 3 HP at 240 VAC 3-Phase (Standard Fuse), 3 HP at 240 VAC 1-Phase, 7-1/2 HP at 240 VAC 3-Phase (Time Delay Fuse), 5 HP at 250 VDC

Enclosure Material:

Steel

Neutral Type:

None

Country of Origin:

United States

Approval:

UL 98

Finish:

Painted

Eaton DH361UGK Heavy Duty Safety Switches EA

SKU:

S21-1225

Short Description:

480 to 600 VAC, 250 VDC, 30 A, 30 HP, 3-Pole, 3-Wire, NEMA 1, Painted Steel, Non-Fusible, Heavy Duty, Single Throw Safety Switch

Type:

Heavy Duty

AC Voltage Rating:

600 V

DC Voltage Rating:

250 V

Current Rating:

30 A

Number of Poles:

3

Number of Wires:

3

Fuse Provision:

Non-Fusible

Enclosure:

NEMA 1

Catalog:

Eaton_00003_V2T1_2_V2T1_4_V2T1_11_CAT.pdf,Eaton_00003_V2T1_2_V2T1_4_V2T1_11_CAT.pdf

Technical Specifications:

Eaton_38535_1_2_SPEC.pdf

Power Rating:

3 HP at 240 VAC 1-Phase, 7-1/2 HP at 480 VAC 1-Phase, 10 HP at 600 VAC 1-Phase, 10 HP at 240 VAC 3-Phase, 20 HP at 480 VAC 3-Phase, 30 HP at 600 VAC 3-Phase, 5 HP at 250 VDC

Size:

9.12 Inch Width x 8.31 Inch Depth x 16.5 Inch Height

Neutral Type:

None

Series:

DH

Enclosure Material:

Steel

TS PIK:

111011442

Approval:

UL 98

Country of Origin:

United States

Finish:

Painted

Eaton DNPL154015 Miniature Circuit Breakers (MCBs) BRD 2P 15A/40A 240V 50/60Hz 3Ph

SKU:

C15-2964

Series:

DNPL

Type:

Quadplex

Type:

Independent Trip

Approval:

UL

Approval:

CSA

Volts:

Centre (120/240 VAC)

Volts:

Outer Left/Right (120 VAC)

Amps:

32 A

Used On:

Loadcenter

Poles:

1

Mounting:

Plug-On

Interrupting Rating:

10 kA

Wire Size:

14 to 4 AWG (Copper/Aluminum)

Short Description:

120/240 VAC Center, 120 VAC Outer Left/Right, 40/15 A, (2) 1-Pole, (1) 2-Pole, 10 kA, Plug-In Mount, Quadplex, Independent Trip

Catalog:

Eaton_00069_16_18_CAT.pdf

Number of Poles:

2

Current Rating:

40/15A

Voltage Rating:

120/240 VAC

Country of Origin:

United States

Eaton EHD2020 Molded Case Breakers (MCCBs) EHD 2P 20A 480V 50/60Hz 2Ph F Frame

SKU:

C15-1882

Series:

C, EHD

Type:

Duplex with LED Indicator Light

Approval:

UL

Size:

2.75 Inch W x 3.38 Inch D x 6 Inch H

Volts:

480 VAC at 50/60 Hz

Volts:

250 VDC

Amps:

32 A

Poles:

2

Interrupting Rating:

14 kA at 480 VAC

Interrupting Rating:

10 Kiloampere at 250 VDC

Terminal Type:

Standard Pressure Load Terminal

Frame Type:

F

Maximum AC Voltage Rating:

480

Maximum DC Voltage Rating:

250

Short Description:

480 VAC 50/60 Hz, 250 VDC, 20 A, 14/10 kA, 2-Pole, Standard Pressure Load Terminal, EHD Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_273_V4T2_274_CAT.pdf

Data Sheet:

LegrandNorthAmerica-Pass&Seymour_03871_1-4_DATA.pdf

Installation/Operator:

LegrandNorthAmerica-Pass&Seymour_00236_INST.pdf

Number of Poles:

2

Current Rating:

20 A

Voltage Rating:

480 VAC at 50/60 Hz, 250 VDC

Country of Origin:

Dominican Republic

Eaton GCWTK Circuit Breaker Accessories Control Wire Terminal Kit J-K Frame 12PK

SKU:

C15-2296

Type:

Control Wire Tab/Terminal

Used On:

PDG1X3TA125/PDG1X3T125 C Series J/K Frame Power Defense Molded Case Circuit Breaker

Specification/Technical:

Eaton_12459_1_2_SPEC.pdf

TS PIK:

117049645

Catalog:

Eaton_03771_V4T2_25_V4T2_128_V4T2_416_CAT.pdf

Short Description:

EATON MOLDED CASE CIRCUIT BREAKER ACCESSORY TERMINAL KIT, CONTROL WIRE TERMINAL

Country of Origin:

Dominican Republic

Eaton GDINBP10 DIN Rail and Accessories Din Rail Attachment

SKU:

C26-1182

Type:

DIN Rail Kit

Used On:

Circuit Breaker

Short Description:

2" x 0.5" x 2", 3-Pole

Country of Origin:

Dominican Republic

Ferraz Shawmut A70P400-4 Fuse Accessories 700V

SKU:

F16-3814

Short Description:

2" x 5.09", 700 VAC, 650 VDC, 400 A, 100 kA AC/DC Interrupt Rating, GMG Body, Tin Plated Copper Blade Terminal, Bolted Mount, Very Fast Acting, High Speed, Current Limiting, Semiconductor Protection Fuse

Type:

Round, Semiconductor

Characteristics:

Very Fast Acting, High Speed

Interrupting Rating:

50 kA (AC)

Current Rating:

400 A

Length:

5.09

Voltage Rating:

700 VAC, 650 VDC

Terminal Type:

Bolted

Data Sheet:

Mersen_00014_HS18_HS19_DATA.pdf

CAD Drawings:

Mersen_00132_1_CAD.pdf

Approval:

UL

Catalog:

Mersen_00697_34_35_CAT.pdf

Series:

A70P

Diameter:

2

Country of Origin:

Mexico

Ferraz Shawmut OT100 Fuses

SKU:

F16-3882

Short Description:

1.06" x 5.88", 250 VAC/VDC, 100 A, 50 kA AC/20 kA DC Interrupt, PolyTube Body, Tin Plated Copper Blade Terminal, Clip Mount, Class K5, Fast Acting, Low Vage UL Power Fuse (5 per Pack)

Current Rating:

100 A

Catalog:

Mersen_00086_195_CAT.pdf

Data Sheet:

Mersen_00082_PF30_PF31_DATA.pdf

Type:

Class K5

Interrupting Rating:

50 kA (AC), 20 kA (DC)

Characteristics:

Fast Acting

Series:

OT

Terminal Type:

Blade

CAD Drawings:

Mersen_00413_1_CAD.pdf

Voltage Rating:

250 VAC/DC

Interrupt Rating:

50 kA

TS PIK:

528086

Length:

5-7/8

Diameter:

1-1/16

Approval:

UL 248/248-9, CSA C22.2

Country of Origin:

Mexico

GENERAL ELECTRIC THQP240 Miniature Circuit Breakers (MCBs) 2P 40A 120V EA

SKU:

C15-2427

Type:

Thermal Magnetic

Approval:

UL

Size:

1/2 Inch Width

Volts:

120/240 VAC

Amps:

32 A

Poles:

2

Interrupting Rating:

10 kA at 120/240 VAC

Terminal Type:

Plug-On

Frame Type:

Q-Line

Maximum AC Voltage Rating:

240 V

Short Description:

120/240 VAC, 40 A, 10 kA Interrupt, 2-Pole, 8 to 4 AWG Aluminum/Copper Load Lug Terminal, 1/2" Plug-In Mount, Q-Line Frame, Non-Interchangeable/Internal Common Trip, Compact, Fixed Thermal Magnetic

Catalog:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00542_1_6_1_7_CAT.pdf

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00024_INST.pdf

CAD Drawing:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01810_1_CAD.pdf

TS PIK:

112127466

Current Rating:

40 A

Voltage Rating:

120/240 VAC

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01810_1_CAD.pdf

Number of Poles:

2

Mounting:

Plug-On

Series:

THQP

Country of Origin:

United States

Siemens QA115AFC Molded Case Breakers (MCCBs) QA 1P 15A 120V EA

SKU:

C15-4212

Type:

Combination Arc-Fault

Approval:

UL 1699

Size:

1 Inch Width x 6 Inch Depth x 3 Inch Height

Volts:

120 VAC

Amps:

32 A

Used On:

Load Center

Mounting:

Plug-On

Interrupting Rating:

10 kA

Application:

120 V Fluorescent Lighting

Wire Size:

14 to 8 AWG (Copper)

Wire Size:

12 to 8 AWG (Aluminum)

Poles:

1

Short Description:

120 VAC, 15 A, 10 kA, 1-Pole, Plug-In Mount, QAF2 Frame, Combination AFCI

Catalog:

SiemensAG_00562_1_40_CAT.pdf

Data Sheet:

SiemensAG_07079_1_DATA.pdf

TS PIK:

111034706

Voltage Rating:

120 VAC

Current Rating:

15 A

Country of Origin:

Philippines

Square D QOB115GFI Miniature Circuit Breakers (MCBs) 15A 120V

SKU:

C15-6384

TS PIK:

124023841

Size:

0.75 Inch W x 2.91 Inch D x 4.12 Inch H

Voltage Rating:

120 VAC at 50/60 Hz (UL/CSA)

Used On:

NQOD Panelboard/Interior

Terminal Type:

Pressure Plate

Installation/Operator:

SchneiderElectric-SquareD_00193_INST.pdf

Current Rating:

15 A

Series:

QOB-GFI

Short Description:

120 VAC 50/60 Hz, 15 A, 10 kA Interrupt, 1-Pole, Bolt-On Mount, 1-Panel Space, Pressure Plate Terminal, Pigtail, 6 mA Class A Ground Fault, Miniature Circuit Breaker

Interrupting Rating:

10 kA

Number of Poles:

1

Data Sheet:

SchneiderElectric-SquareD_15104_1_2_DATA.pdf

Type:

Thermal Magnetic, Equipment Protector

Catalog:

SchneiderElectric-SquareD_03283_9_14_CAT.pdf

Wire Size:

14 to 8 AWG (Aluminum/Copper)

Mounting:

Bolt-On

Prop 65 Warning:

Yes

Country of Origin:

United States

Approval:

UL, CSA

Trip Sensitivity:

6 MilliA

Square D QOU230VH Miniature Circuit Breakers (MCBs) EA

SKU:

C15-5292

Approval:

UL

Approval:

CSA

Amps:

30 A

Interrupting Rating:

22 kA

Mounting:

DIN Rail

Poles:

2

Size:

1.5 Inch Width x 2.95 Inch Depth x 4.05 Inch Height

Terminal Type:

Slotted Box Lug Line/Load

Type:

Miniature

Type:

Standard

Used On:

OEM

Volts:

120/240 VAC 50/60 Hertz

Gauge:

14 to 2 AWG (Copper/Aluminum)

Short Description:

120/240 VAC, 30 A, 22 kA Interrupt, 2-Pole, 14 to 2 AWG Copper/Aluminum, Unit Mount, Slotted Box Lug Line/Load, Standard, Miniature Circuit Breaker

Series:

QOU

Data Sheet:

SchneiderElectric_21578_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_02171_INST.pdf

CAD Drawing:

SchneiderElectric_30267_1_CAD.pdf

Catalog:

SchneiderElectric-SquareD_32357_7_19_7_21_CAT.pdf

CAD Drawings:

SchneiderElectric_30267_1_CAD.pdf

Number of Poles:

2

Voltage Rating:

120/240 VAC

Current Rating:

30 A

Wire Size:

14 to 2 AWG (Copper/Aluminum)

Country of Origin:

United States

Westinghouse 5155C62H01 Meter and Meter Socket Accessories PK

SKU:

L19-2850

Used On:

QUICKLAG/GB/GHB/GHBS Frame Pow-R-Line Xpert and Legacy PRL3X/PRL3a Series Panelboard

Catalog:

Eaton_07871_19_CAT.pdf

Short Description:

1-Pole, Blank Filler Plate for GB/GHB-Frame Panelboard Deadfront Cover

Bussmann GLR-10 Fuses

SKU:

F16-2998

TS PIK:

128115

Current Rating:

10 A

Series:

GLR

Characteristics:

Fast Acting, Non-Rejecting

Catalog:

Eaton-Bussmann_00349_2_11_CAT.pdf

Data Sheet:

Eaton-Bussmann_00310_1_2_DATA.pdf

Interrupting Rating:

10 kA

Short Description:

0.63" x 2.25", 300 VAC, 10 A, 10 kA Interrupt Rating, HLR Holder, Fast Acting, Non-Rejecting, Supplemental, In-Line Fuse

Country of Origin:

Mexico

Diameter:

0.63

Approval:

UL, CSA C22.2, CE

Fuse Holder Type:

HLR

Voltage Rating:

300 VAC

Length:

2.25

Eaton BAB2020H Miniature Circuit Breakers (MCBs) BAB 2P 20A 240V 50/60Hz 1Ph EA

SKU:

C15-1042

Series:

BAB

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA

Volts:

240 VAC

Amps:

32 A

Poles:

2

Mounting:

Bolt-On

Interrupting Rating:

10000 A at 120/240 VAC

Interrupting Rating:

5000 A at 24 to 48/62.5/80 VDC

Terminal Type:

Extended Tang Line Terminal

Terminal Type:

Box Lug Load Terminal

Wire Size:

14 to 4 AWG Aluminum/Copper (Load)

Short Description:

240 VAC, 20 A, 10 kA, 2-Pole, Extended Tang Line/Box Lug Load Terminal, Bolt-On Mount, Thermal Magnetic, Miniature

Catalog:

Eaton_03771_V4T1_3_V4T1_11_V4T1_12_CAT.pdf

TS PIK:

21508681

Current Rating:

20 A

Voltage Rating:

240 VAC

Number of Poles:

2

Country of Origin:

Dominican Republic

Eaton DH362FWK Safety Switches DH 3P 60A 600V 50/60Hz 3Ph Fusible w/o Neutral 3Wire EA NEMA 4X

SKU:

S21-1122

Short Description:

480 to 600 VAC, 250 VDC, 60 A, 50 HP, 3-Pole, 3-Wire, NEMA 4X, 304 Stainless Steel, Class H/Time Delay Fusible, Heavy Duty

Type:

Heavy Duty

AC Voltage Rating:

600 V

DC Voltage Rating:

250 V

Current Rating:

60 A

Number of Poles:

3

Number of Wires:

3

Fuse Provision:

Fusible

Fuse Type:

Class H

Enclosure:

NEMA 4X

Catalog:

Eaton_00003_V2T1_2_V2T1_7_V2T1_11_CAT.pdf,Eaton_00003_V2T1_2_V2T1_7_V2T1_11_CAT.pdf

Technical Specifications:

Eaton_38541_1_2_SPEC.pdf

Neutral Type:

None

Power Rating:

20 HP at 480 VAC 1-Phase, 25 HP at 600 VAC 1-Phase, 30 HP at 480 VAC 3-Phase, 50 HP at 600 VAC 3-Phase (Time Delay Fuse)

Enclosure Material:

Stainless Steel

Size:

10.22 Inch Width x 7.73 Inch Depth x 19.08 Inch Height

Series:

DH

Country of Origin:

United States

Approval:

UL 98

Eaton GBK1420 Meter and Meter Socket Accessories EA

SKU:

L19-1923

Used On:

CH/BR Load Center

Length:

6.74

Conductor Material:

Copper/Aluminum

Terminal Size:

14 Terminal (3) 14 to 10 AWG or (1) 14 to 4 AWG

Terminal Size:

(1) 6 to 2/0 AWG

Short Description:

6.74" L, 1-3/4" Mounting Hole, 1-2/0 Lug, 14-Terminal

Catalog:

Eaton_36620_V1T1_27_V1T1_72_V1T1_99_CAT.pdf

Installation/Operator:

Eaton_00482_INST.pdf

TS PIK:

111009855

Country of Origin:

United States

Eaton GHB3100 Molded Case Breakers (MCCBs) GHB 3P 100A 240V 50/60Hz 3Ph G Frame EA

SKU:

C15-3398

Series:

C

Type:

Molded Case

Type:

Thermal Magnetic

Approval:

UL 489

Approval:

CSA C22.2

Size:

3.8 Inch Width x 6.6 Inch Depth x 4 Inch Height

Volts:

277/480 VAC at 50/60 Hertz

Volts:

125/250 VDC

Amps:

32 A

Poles:

3

Interrupting Rating:

14 kA at 480 VAC Star/277 VAC/125/250 VDC

Terminal Type:

Aluminum Pressure Line and Load

Frame Type:

GHB

Maximum AC Voltage Rating:

480 V

Maximum DC Voltage Rating:

250 V

Short Description:

277/480 VAC 50/60 Hz, 125 VDC, 100 A, 14 kA, 3-Pole, Steel Pressure Screw Line and Load Terminal, GHB Frame, Thermal Magnetic, Molded Case

Catalog:

Eaton_27487_V4T2_254_V4T2_255_V4T2_259_V4T2_260_CAT.pdf

Installation/Operator:

Eaton_00166_INST.pdf

TS PIK:

21517410

Current Rating:

100 A

Number of Poles:

3

Voltage Rating:

277/480 VAC, 125/250 VDC

Country of Origin:

Dominican Republic

Eaton MHMVD Circuit Breaker Accessories Vari-Depth Mechanism M Frame

SKU:

C15-4787

Frame:

M

Short Description:

VARI-DEPTH ROTARY MECH 10 MM (MDL)

Country of Origin:

United States​

Eaton T5A3030U Disconnect Switches

SKU:

M01-2379

Amps:

30 A

Mounting:

Base/DIN Rail

Poles:

3

Operator Position:

External

Operator Type:

Handle

Type:

Disconnect Switch

Volts:

600 V

Short Description:

30 A, 3-Pole, Direct Handle, DIN/Base Mount, Non-Fusible, Toggle, Rotary Disconnect Switch

Specification/Technical:

Eaton_34766_1_2_SPEC.pdf

CAD Drawing:

Eaton_32680_1_CAD.pdf

Number of Poles:

3

CAD Drawings:

Eaton_32680_1_CAD.pdf

Current Rating:

30 A

Catalog:

Eaton_00002_V5T8_5_V5T8_6_CAT.pdf

Fuse Provision:

Non-Fusible

TS PIK:

123730050

Voltage Rating:

600 V

Country of Origin:

China

GENERAL ELECTRIC FBN36TE015RV Molded Case Breakers (MCCBs) 15A

SKU:

C15-6864

TS PIK:

115927047

Maximum AC Voltage Rating:

480 V

Installation/Operator:

ABBElectrificationProducts-ABBGEIndustrialSolutions_00018_INST.pdf

Interrupting Rating:

65 kA at 480 VAC, 150 kA at 240 VAC

Current Rating:

15 A

Terminal Type:

Line and Load Lug

CAD Drawings:

ABBElectrificationProducts-ABBGEIndustrialSolutions_01746_1_CAD.pdf

Number of Poles:

3

Type:

Thermal Magnetic

Frame Type:

FB100

Voltage Rating:

240/480 VAC

Short Description:

600 VAC Star/347 VAC, 15 A, 65 kA Interrupt, 3-Pole, 14 to 10 AWG Aluminum/Copper Load Lug Terminal, FB100-Frame, Fixed Thermal Magnetic, Molded Case Circuit Breaker with A-Series AD Plus Lighting Panel

Approval:

UL

Country of Origin:

United States

Mersen ATMR5 Fuses

SKU:

F16-3549

Short Description:

0.41" x 1.5", 600 VAC/VDC, 5 A, 200 kA AC/100 kA DC Interrupt, GMG Body, Tin Plated Copper Ferrule Terminal, Clip Mount, Class CC, Fast Acting, Power Fuse

Type:

Class CC Rejection

Series:

ATMR

Catalog:

Mersen_00086_194_CAT.pdf

Current Rating:

5 A

Data Sheet:

Mersen_00066_PF28_DATA.pdf

Interrupting Rating:

200 kA (AC), 100 kA (DC)

Characteristics:

Fast Acting

Terminal Type:

Ferrule

TS PIK:

110477189

Diameter:

0.41

Length:

1.5

Voltage Rating:

600 VAC/DC

Approval:

UL 248/248-4, CSA C22.2

Country of Origin:

Mexico

Mersen OT30 Fuses 30A 250V 10BOX

SKU:

F16-1470

Approval:

UL 248/248-9

Approval:

CSA C22.2

Characteristics:

Fast Acting

Characteristics:

One Time

Amps:

30 A

Diameter:

9/16

Interrupting Rating:

50 kA (AC)

Interrupting Rating:

20 Kiloamp (DC)

Length:

2

Terminal Type:

Ferrule

Type:

Class K5

Volts:

250 VAC/DC

Short Description:

0.56" x 2", 250 VAC/VDC, 30 A, 50 kA AC/20 kA DC Interrupt, Paper Body, Copper Ferrule Terminal, Clip Mount, Class K5, Fast Acting, Low Voltage UL Power Fuse (10 per Pack)

Series:

OT

Data Sheet:

Mersen_00082_PF30_PF31_DATA.pdf

CAD Drawing:

Mersen_00251_1_CAD.pdf

TS PIK:

528075

Current Rating:

30 A

CAD Drawings:

Mersen_00251_1_CAD.pdf

Catalog:

Mersen_00086_195_CAT.pdf

Voltage Rating:

250 VAC/DC

Interrupt Rating:

50/20 kA

Country of Origin:

United States

Square D QO1PA Circuit Breaker Accessories Padlock 1P

SKU:

C15-3806

Series:

QO

Type:

Padlockable

Used On:

QO Series Circuit Breaker

Poles:

1

Locking Provision:

On/Off

Short Description:

1-Pole, On/Off Locking

Catalog:

SchneiderElectric-SquareD_03264_1_8_CAT.pdf

Data Sheet:

SchneiderElectric-SquareD_14910_1_2_DATA.pdf

Installation/Operator:

SchneiderElectric-SquareD_00204_INST.pdf

Country of Origin:

Mexico

ABB AE30-30-11-81 Other Circuit Breakers

SKU:

C15-11371

Bussmann NOS45 Fuse Accessories

SKU:

F16-3200

Eaton 1MPLK1 Meter and Meter Socket Accessories

SKU:

L20-1040

Amps:

32 A

Used On:

1MP Series Meter Pack

Standard Package:

3

Wire Size:

(1) 6 AWG to 600 KCMIL/(2) 2/0 AWG to 250 KCMIL

Short Description:

6" x 4" x 0.1", 400/600 A, 6 AWG to 600 KCMIL/2/0 AWG to 250 KCMIL

Catalog:

Eaton_36620_V1T4_144_CAT.pdf

TS PIK:

21530977

Current Rating:

400/600 A

Country of Origin:

United States

Eaton AHL1630R Surge Protection Devices (SPDs) 3P 30A 480V
