Bussmann FRN-R-1-1/8 Class RK5 1-1/8A 250VAC, 125VDC Time Delay Fuse

SKU:

E30-6499

TS PIK:

126600

Terminal Type:

Ferrule

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 1-1/8 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Characteristics:

8 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Voltage Rating:

250 VAC, 125 VDC

Length:

2

Series:

FRN-R

Type:

Class RK5

Current Rating:

1-1/8 A

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Diameter:

0.56

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-110 Fuses EA

SKU:

F16-5020

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Short Description:

1.56" x 2", 250 VAC, 125 VDC, 110 A, 200 kA AC, 20 kA DC, Blade Terminal, Energy Efficient, Time Delay, Dual Element, Current Limiting, Non-Indicating, Class RK5, Low Vage Branch Circuit Fuse (1 per Carton)

Type:

Class RK5

Series:

FRN-R

Catalog:

EatonCorp-Bussmann_00026_1_29_CAT.pdf

Current Rating:

110 A

Characteristics:

Energy Efficient, Time Delay, Dual Element, Current Limiting, Non-Indicating

Data Sheet:

EatonCorp-Bussmann_00049_1-4_DATA.pdf

Terminal Type:

Blade

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126629

Diameter:

1.56

Length:

2

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-15 Class RK5 15A 250VAC, 125VDC Time Delay Fuse

SKU:

F16-2987

Terminal Type:

Ferrule

Type:

Class RK5

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 15 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Current Rating:

15 A

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Series:

FRN-R

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Characteristics:

8 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

TS PIK:

124395

Approval:

UL 248-12, CSA C22.2, CE

Length:

2

Diameter:

0.56

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-150 Fuses

SKU:

F16-2988

TS PIK:

124407

Current Rating:

150 A

Series:

FRN-R

Type:

Class RK5

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Short Description:

1.56" x 7.13", 250 VAC, 125 VDC, 150 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Terminal Type:

Blade

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

Diameter:

1.56

Length:

7.13

Approval:

UL 248-12, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-17-1/2 Class RK5 17.5A 250VAC, 125VDC Time Delay Fuse

SKU:

E30-6603

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Type:

Class RK5

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Series:

FRN-R

Current Rating:

17.5 A

Terminal Type:

Ferrule

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 17-1/2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Characteristics:

8 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126620

Diameter:

0.56

Length:

2

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRN-R-2-1/4 Class RK5 2-1/4A 250VAC, 125VDC Time Delay Fuse

SKU:

F16-5859

TS PIK:

126606

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Type:

Class RK5

Diameter:

0.56

Series:

FRN-R

Length:

2

Voltage Rating:

250 VAC, 125 VDC

Approval:

UL, CSA C22.2, CE

Characteristics:

8 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Current Rating:

2-1/4 A

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 2-1/4 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Terminal Type:

Ferrule

Country of Origin:

MEX

Class:

Class RK5

Bussmann FRN-R-20 Class RK5 20A 250V Power Fuse

SKU:

F16-2990

TS PIK:

124396

Series:

FRNR

Current Rating:

20 A

Interrupting Rating:

200 kA

Short Description:

250 V, 20 A, Class RK5, Power Fuse

Type:

Class RK5

Characteristics:

Time Delay

Voltage Rating:

250 V

Approval:

UL

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-200 Fuses

SKU:

F16-5519

TS PIK:

124408

Country of Origin:

Mexico

Type:

Class RK5

Terminal Type:

Blade

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Current Rating:

200 A

Short Description:

1.56" x 7.13", 250 VAC, 125 VDC, 200 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Diameter:

1.56

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Series:

FRN-R

Length:

7.13

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Voltage Rating:

250 VAC, 125 VDC

Approval:

UL 248-12, CSA C22.2, CE

Class:

Class RK5

Bussmann FRN-R-21/4 Class RK5 2.25A 250VAC

SKU:

F16-4998

Current Rating:

2.25 A

TS PIK:

126606

Country of Origin:

Mexico

Voltage Rating:

250 VAC

Short Description:

Class RK5 250 VAC 2.25 A fuse

Class:

Class RK5

Bussmann FRN-R-225 Fuses

SKU:

E30-6606

Terminal Type:

Blade

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Short Description:

2.38" x 8.63", 250 VAC/VDC, 225 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Current Rating:

225 A

Series:

FRN-R

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Type:

Class RK5

Voltage Rating:

250 VAC/DC

Interrupt Rating:

200/20 kA

Diameter:

2.38

Length:

8.63

Approval:

UL 248-12, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-250 Fuses 250V

SKU:

F16-4773

TS PIK:

126634

Terminal Type:

Blade

Short Description:

2.38" x 8.63", 250 VAC/VDC, 250 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Series:

FRN-R

Type:

Class RK5

Voltage Rating:

250 VAC/DC

Diameter:

2.38

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Length:

8.63

Current Rating:

250 A

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-30 Fuses

SKU:

F16-1224

Approval:

CE

Approval:

UL 248-12

Characteristics:

8 Second Time Delay (500 Percent Rated Load)

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Amps:

30 A

Diameter:

0.56

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

20 Kiloamp (DC)

Length:

2

Terminal Type:

Ferrule

Type:

Class RK5

Volts:

250 VAC

Volts:

125 VDC

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 30 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Series:

FRN-R

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

TS PIK:

124397

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Current Rating:

30 A

Voltage Rating:

250 VAC, 125 VDC

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-35 Fuses

SKU:

F16-1225

Series:

FRN-R

Type:

Class RK5

Approval:

UL 248-12

Approval:

CSA C22.2

Approval:

CE

Volts:

250 VAC

Volts:

125 VDC

Amps:

32 A

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Length:

3

Diameter:

0.81

Characteristics:

10 Second Time Delay (500 Percent Rated Current)

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Short Description:

0.81" x 3", 250 VAC, 125 VDC, 35 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

TS PIK:

124398

Current Rating:

35 A

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-40 Class RK5 40A 250VAC, 125VDC Time Delay Fuse

SKU:

F16-2991

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Type:

Class RK5

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Current Rating:

40 A

Series:

FRN-R

Short Description:

0.81" x 3", 250 VAC, 125 VDC, 40 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

TS PIK:

124399

Length:

3

Diameter:

0.81

Approval:

UL 248-12, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-400 Fuses EA

SKU:

F16-5516

Short Description:

8.63" x 2.06" x 2.06", 250 VAC/125VDC, 400 A, 200/20 kA Interrupt Rating, Class RK5, 10 Sec Time Delay, Blade Terminal, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Series:

FRN-R

Characteristics:

Time Delay, Current Limting

Catalog:

EatonCorp-Bussmann_00026_1_29_CAT.pdf

Current Rating:

400 A

Data Sheet:

EatonCorp-Bussmann_00049_1-4_DATA.pdf

Type:

Class RK5

Terminal Type:

Blade

Approval:

UL 248-12, CSA, CE

Voltage Rating:

250 VAC, 125 VDC

Length:

8.63

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-45 Fuse Accessories EA

SKU:

F16-2992

Short Description:

0.81" x 3", 250 VAC, 125 VDC, 45 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Current Rating:

45 A

Series:

FRN-R

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Terminal Type:

Ferrule

Type:

Class RK5

Length:

3

Voltage Rating:

250 VAC, 125 VDC

Approval:

UL 248-12, CSA C22.2, CE

Diameter:

0.81

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Characteristics:

10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-5 Fuses

SKU:

F16-2993

Series:

FRN-R

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 5 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Characteristics:

8 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Current Rating:

5 A

Type:

Class RK5

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126613

Length:

2

Diameter:

0.56

Country of Origin:

Mexico

Approval:

UL 248-12, CSA C22.2, CE

Class:

Class RK5

Bussmann FRN-R-500 Fuse Accessories

SKU:

F16-3035

Current Rating:

500 A

Type:

Class RK5

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Short Description:

2.88" x 10.38", 250 VAC/VDC, 500 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Series:

FRN-R

Terminal Type:

Blade

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Diameter:

2.88

Voltage Rating:

250 VAC/DC

Approval:

UL, CSA C22.2, CE

Length:

10.38

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-6/10 Fuse Accessories EA

SKU:

E30-6505

TS PIK:

126597

Series:

FRN-R

Type:

Class RK5

Current Rating:

6/10 A

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 6/10 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Terminal Type:

Ferrule

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Diameter:

0.56

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Approval:

UL, CSA C22.2, CE

Characteristics:

8 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Voltage Rating:

250 VAC, 125 VDC

Length:

2

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-60 Fuses

SKU:

F16-1175

Series:

FRN-R

Type:

Class RK5

Approval:

UL 248-12

Approval:

CSA C22.2

Approval:

CE

Volts:

250 VAC

Volts:

125 VDC

Amps:

32 A

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Ferrule

Length:

3

Diameter:

0.81

Characteristics:

10 Second Time Delay (500 Percent Rated Load)

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Short Description:

0.81" x 3", 250 VAC, 125 VDC, 60 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

TS PIK:

124402

Current Rating:

60 A

Voltage Rating:

250 VAC, 125 VDC

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-7 Fuses

SKU:

F16-2823

Data Sheet:

Eaton-Bussmann_00156_1-5_DATA.pdf

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Type:

Class RK5

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Terminal Type:

Ferrule

Short Description:

0.56" x 2", 250 VAC, 125 VDC, 7 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 8 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Characteristics:

8 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Current Rating:

7 A

Series:

FRN-R

Voltage Rating:

250 VAC, 125 VDC

Interrupt Rating:

200/20 kA

Length:

2

Diameter:

0.56

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-70 Fuses EA

SKU:

F16-2796

Series:

FRN-R

Type:

Class RK5

Approval:

UL 248

Approval:

CSA C22.2

Approval:

CE

Volts:

250 VAC

Amps:

32 A

Interrupting Rating:

200 kA (Symmetrical)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Blade

Length:

5.88

Diameter:

1.06

Characteristics:

10 Second Time Delay

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Characteristics:

Energy Efficient

Short Description:

1.06" x 5.88", 250 VAC, 70 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

TS PIK:

126625

Current Rating:

70 A

Voltage Rating:

250 VAC

Interrupt Rating:

200/20 kA

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRN-R-75 Class RK5 75A 250VAC, 125VDC Time Delay Fuse

SKU:

F16-5862

TS PIK:

110615735

Diameter:

1.06

Series:

FRN-R

Length:

5.88

Terminal Type:

Blade

Current Rating:

75 A

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Voltage Rating:

250 VAC, 125 VDC

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Short Description:

1.06" x 5.88", 250 VAC, 75 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (5 per Carton)

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element

Type:

Class RK5

Approval:

UL, CSA C22.2, CE

Data Sheet:

Eaton-Bussmann_00159_1-4_DATA.pdf

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS 50 Class RK5 50A 600VAC

SKU:

F16-7203

Country of Origin:

Mexico

Short Description:

50 Amp, 600 Volt AC, Class RK5, dual‑element, time‑delay fuse (non‑indicating)

Current Rating:

50 A

Voltage Rating:

600 VAC

Class:

Class RK5

Bussmann FRS-R-1 Fuses

SKU:

F16-1350

Series:

FRS-R

Type:

Class RK5

Approval:

UL

Approval:

CSA C22.2

Approval:

CE

Volts:

600 VAC

Volts:

300 VDC

Amps:

32 A

Interrupting Rating:

200 kA (Symmetrical)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Ferrule

Length:

5

Diameter:

0.81

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current)

Characteristics:

Dual Element

Characteristics:

Non-Indicating

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 1 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

TS PIK:

110615803

Current Rating:

1 A

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-1-1/8 Class RK5 1-1/8A 600VAC, 300VDC Time Delay Fuse

SKU:

E30-6700

TS PIK:

110615804

Length:

5

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 1-1/8 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Terminal Type:

Ferrule

Current Rating:

1-1/8 A

Type:

Class RK5

Approval:

UL, CSA C22.2, CE

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Series:

FRS-R

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Diameter:

0.81

Voltage Rating:

600 VAC, 300 VDC

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-1-6/10 Distribution Fuses

SKU:

E30-6703

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Current Rating:

1.6 A

Type:

Class RK5

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Terminal Type:

Ferrule

Series:

FRS-R

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 1-6/10 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

110615807

Length:

5

Diameter:

0.81

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRS-R-1/10 Distribution Fuses

SKU:

E30-6699

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 1/10 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Series:

FRS-R

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Current Rating:

0.1 A

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Type:

Class RK5

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

Diameter:

0.81

Length:

5

TS PIK:

110615795

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-15 Fuse Accessories Class RK5 15A 600V EA

SKU:

F16-1172

Approval:

CE

Approval:

UL 248-12

Characteristics:

10 Second Time Delay (500 Percent Rated Load)

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Amps:

15 A

Diameter:

0.81

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

20 Kiloamp (DC)

Length:

5

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Type:

Class RK5

Volts:

600 VAC

Volts:

300 VDC

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 15 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Series:

FRS-R

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

TS PIK:

126674

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Current Rating:

15 A

Voltage Rating:

600 VAC, 300 VDC

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-150 Fuse Accessories EA

SKU:

F16-3238

Short Description:

1.61" x 9.63", 600 VAC, 300 VDC, 150 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Type:

Class RK5

Terminal Type:

Blade

Series:

FRS-R

Current Rating:

150 A

Data Sheet:

Eaton-Bussmann_00309_1_2_DATA.pdf

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Voltage Rating:

600 VAC, 300 VDC

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Diameter:

1.61

Length:

9.63

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Approval:

UL 248-12, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-17-1/2 Class RK5 17.5A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-3239

Series:

FRS-R

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 17-1/2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Type:

Class RK5

Current Rating:

17.5 A

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Terminal Type:

Ferrule

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126675

Diameter:

0.81

Approval:

UL, CSA C22.2, CE

Length:

5

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-2 Fuses

SKU:

F16-3240

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Series:

FRS-R

Current Rating:

2 A

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Terminal Type:

Ferrule

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Type:

Class RK5

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126658

Diameter:

0.81

Length:

5

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-2-1/4 Fuse Accessories EA

SKU:

F16-3273

TS PIK:

110615810

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 2-1/4 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Terminal Type:

Ferrule

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Current Rating:

2-1/4 A

Type:

Class RK5

Series:

FRS-R

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Length:

5

Voltage Rating:

600 VAC, 300 VDC

Diameter:

0.81

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-20 20A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-1369

Series:

FRS-R

Type:

Class RK5

Approval:

UL 248-12

Approval:

CSA C22.2

Approval:

CE

Volts:

600 VAC

Volts:

300 VDC

Amps:

32 A

Interrupting Rating:

200 kA (AC)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Ferrule

Length:

5

Diameter:

0.81

Characteristics:

10 Second Time Delay (500 Percent Rated Load)

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Characteristics:

Dual Element

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 20 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

TS PIK:

126676

Current Rating:

20 A

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

Country of Origin:

Mexico

Bussmann FRS-R-25 Class RK5 25A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-3242

Series:

FRS-R

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 25 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Type:

Class RK5

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Characteristics:

10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element

Current Rating:

25 A

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126677

Length:

5

Diameter:

0.81

Country of Origin:

Mexico

Approval:

CE, UL 248-12

Class:

Class RK5

Bussmann FRS-R-3-1/2 Class RK5 3.5A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-3274

Series:

FRS-R

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 3-1/2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Current Rating:

3.5 A

Type:

Class RK5

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

110615814

Length:

5

Approval:

UL, CSA C22.2, CE

Diameter:

0.81

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-3-2/10 Class RK5 3.2A 600VAC, 300VDC Time Delay Fuse

SKU:

E30-6778

TS PIK:

126662

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Current Rating:

3.2 A

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 3-2/10 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Type:

Class RK5

Series:

FRS-R

Terminal Type:

Ferrule

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

Length:

5

Diameter:

0.81

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRS-R-3/10 Class RK5 0.3A 600VAC, 300VDC Time Delay Fuse

SKU:

E30-6706

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Current Rating:

0.3 A

Terminal Type:

Ferrule

Series:

FRS-R

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Type:

Class RK5

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 3/10 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

110615798

Diameter:

0.81

Length:

5

Country of Origin:

Mexico

Libra Liquidity Lot:

Libra Auction Lot

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRS-R-30 Fuses 30A 600V EA

SKU:

F16-1371

Series:

FRS-R

Type:

Class RK5

Approval:

UL 248-12

Approval:

CSA C22.2

Approval:

CE

Volts:

600 VAC

Volts:

300 VDC

Amps:

32 A

Interrupting Rating:

200 kA (Symmetrical AC)

Interrupting Rating:

20 kA (DC)

Terminal Type:

Ferrule

Length:

5

Diameter:

0.81

Characteristics:

10 Second Time Delay (500 Percent Rated Load)

Characteristics:

Dual Element

Characteristics:

Non-Indicating

Short Description:

0.81" x 5", 30 A, 600 VAC, 300 VDC, 200 kA Symmetrical AC, 20 kA DC, Class RK5

Catalog:

EatonCorp-Bussmann_00026_1_29_CAT.pdf

Data Sheet:

EatonCorp-Bussmann_00064_1-4_DATA.pdf

Current Rating:

30 A

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200 kA

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-4-1/2 Class RK5 4.5A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-3275

Series:

FRS-R

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 4-1/2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Type:

Class RK5

Current Rating:

4.5 A

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating

Terminal Type:

Ferrule

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

110615816

Diameter:

0.81

Length:

5

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRS-R-40 Time Delay Fuse

SKU:

F16-3244

TS PIK:

126680

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Short Description:

1.06" x 5.5", 600 VAC, 250 VDC, 40 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Current Rating:

40 A

Voltage Rating:

600 VAC, 250 VDC

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Type:

Class RK5

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Series:

FRS-R

Characteristics:

10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element

Interrupt Rating:

200/20 kA

Length:

5.5

Approval:

CE, UL 248-12

Diameter:

1.06

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-5 Fuse Accessories EA

SKU:

F16-3246

TS PIK:

126666

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 5 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Series:

FRS-R

Terminal Type:

Ferrule x Ferrule with Grooved Ring

Type:

Class RK5

Current Rating:

5 A

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Approval:

UL 248-12, CSA C22.2, CE

Length:

5

Diameter:

0.81

Voltage Rating:

600 VAC, 300 VDC

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-50 Fuses

SKU:

E30-6610

TS PIK:

126682

Type:

Class RK5

Short Description:

1.06" x 5.5", 600 VAC, 250 VDC, 50 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (10 per Carton)

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Current Rating:

50 A

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Terminal Type:

Ferrule

Series:

FRS-R

Characteristics:

10 Second Time Delay (500 Percent Rated Load), Current Limiting, Non-Indicating, Dual Element

Voltage Rating:

600 VAC, 250 VDC

Interrupt Rating:

200/20 kA

Length:

5.5

Diameter:

1.06

Country of Origin:

Mexico

Libra Liquidity Lot:

Libra Auction Lot

Approval:

UL

Class:

Class RK5

Bussmann FRS-R-500 Fuses EA

SKU:

E30-6780

Short Description:

2.88" x 13.38", 600 VAC, 300 VDC, 500 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Series:

FRS-R

Data Sheet:

Eaton-Bussmann_00309_1_2_DATA.pdf

Current Rating:

500 A

Type:

Class RK5

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Terminal Type:

Blade

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126699

Length:

13.38

Diameter:

2.88

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FRS-R-65 Class RK5 65A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-5868

TS PIK:

115442107

Data Sheet:

Eaton-Bussmann_00309_1_2_DATA.pdf

Short Description:

1.11" x 7.88", 600 VAC, 300 VDC, 65 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Current Rating:

65 A

Type:

Class RK5

Voltage Rating:

600 VAC, 300 VDC

Terminal Type:

Blade

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Series:

FRS-R

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Non-Indicating, Current Limiting

Approval:

UL, CSA C22.2, CE

Diameter:

1.11

Length:

7.88

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Country of Origin:

MEX

Class:

Class RK5

Bussmann FRS-R-7-1/2ID Class RK5 7-1/2A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-19075

TS PIK:

123371137

Type:

Class RK5

Series:

FRS-R

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element, Indicating

Voltage Rating:

600 VAC, 300 VDC

Data Sheet:

Eaton-Bussmann_00308_1-3_DATA.pdf

Terminal Type:

Ferrule

Length:

5

Diameter:

0.81

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Approval:

UL, CSA C22.2, CE

Current Rating:

7-1/2 A

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Short Description:

0.81" x 5", 600 VAC, 300 VDC, 7-1/2 A, 200/20 kA Interrupt Rating, Ferrule with Grooved Ring Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Indicating, Time Delay Fuse (10 per Carton)

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-70 Class RK5 70A 600VAC, 300VDC Time Delay Fuse

SKU:

F16-5538

Type:

Class RK5

Short Description:

1.11" x 7.88", 600 VAC, 300 VDC, 70 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Data Sheet:

Eaton-Bussmann_00309_1_2_DATA.pdf

Terminal Type:

Blade

Current Rating:

70 A

Characteristics:

10 Second Time Delay (500 Percent Rated Current), Current Limiting, Non-Indicating, Dual Element

Series:

FRS-R

Catalog:

Eaton-Bussmann_00350_45_CAT.pdf

Interrupting Rating:

200 kA (AC), 20 kA (DC)

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126684

Approval:

UL 248-12, CSA C22.2, CE

Length:

7.88

Diameter:

1.11

Country of Origin:

Mexico

Class:

Class RK5

Bussmann FRS-R-75 Fuses EA

SKU:

E30-6708

Current Rating:

75 A

Type:

Class RK5

Short Description:

1.11" x 7.88", 600 VAC, 300 VDC, 75 A, 200/20 kA Interrupt Rating, Blade Terminal, Class RK5, 10 Sec Time Delay, Dual Element, Current Limiting, Non-Indicating, Time Delay Fuse (1 per Carton)

Data Sheet:

Eaton-Bussmann_00309_1_2_DATA.pdf

Characteristics:

10 Second Time Delay (at 500 Percent Rated Current), Dual Element

Terminal Type:

Blade

Interrupting Rating:

200 kA (Symmetrical), 20 kA DC

Series:

FRS-R

Catalog:

Eaton-Bussmann_00349_1_2_1_29_1_30_CAT.pdf

Voltage Rating:

600 VAC, 300 VDC

Interrupt Rating:

200/20 kA

TS PIK:

126703

Length:

7.88

Diameter:

1.11

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Class:

Class RK5

Bussmann FWA-5A10F 5A 150VAC/DC (UL) High Speed Fuse

SKU:

F16-19190

TS PIK:

110617999

Short Description:

0.41" x 1-1/2", 150 VAC/VDC, 5 A, 200/50 kA Interrupt Rating, Ferrule Terminal, Class aR, Non-Indicating, High Speed Fuse (10 per Carton)

Country of Origin:

MEX

Characteristics:

High Speed

Voltage Rating:

150 VAC/DC (UL)

Current Rating:

5 A

Length:

1-1/2

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (Symmetrical), 50 kA DC at 150 VDC

Approval:

UL, CE

Catalog:

Eaton-Bussmann_00349_4_22_CAT.pdf

Data Sheet:

Eaton-Bussmann_00584_1-4_DATA.pdf

Series:

FWA

Diameter:

13/32

Type:

Class aR

Bussmann FWH-225A Semiconductor Class 225A 500VAC/DC North American Fuse

SKU:

F16-5878

TS PIK:

115442128

Voltage Rating:

500 VAC/DC

Interrupting Rating:

200 kA (Symmetrical), 50 kA at 500 VDC

Characteristics:

High Speed

Terminal Type:

Blade

Diameter:

1.5

Current Rating:

225 A

Length:

4.34

Type:

Round

Catalog:

Eaton-Bussmann_00349_4_8_CAT.pdf

Data Sheet:

Eaton-Bussmann_00611_1_DATA.pdf

Short Description:

1.5" x 4.34", 500 VAC/VDC, 225 A, 200/50 kA Interrupt Rating, Blade Terminal, High Speed, Bolted Tag, North American Fuse

Series:

FWH

Approval:

UL, CSA, CE

Class:

Semiconductor Class

Bussmann FWH-250A Class aR 250A 500VAC/DC North American Fuse

SKU:

F16-5879

TS PIK:

110614595

Type:

Round

Series:

FWH

Characteristics:

High Speed

Terminal Type:

Blade

Current Rating:

250 A

Short Description:

1.5" x 4.34", 500 VAC/VDC, 250 A, 200/50 kA Interrupt Rating, Blade Terminal, High Speed, Bolted Tag, North American Fuse

Catalog:

Eaton-Bussmann_00349_4_8_CAT.pdf

Interrupting Rating:

200 kA (AC), 50 kA (DC)

Data Sheet:

Eaton-Bussmann_00612_1_DATA.pdf

Length:

4.34

Diameter:

1.5

Approval:

UL, CSA, CE

Voltage Rating:

500 VAC/DC

Country of Origin:

Mexico

Class:

Class aR

Bussmann FWH-400 Semiconductor Class 400A 500VAC

SKU:

F16-5505

Current Rating:

400 A

Country of Origin:

Mexico

Short Description:

high-speed semiconductor fuse with an amp rating of 400 A and a voltage rating of 500 VAC/VDC or 750 VAC/VDC

Voltage Rating:

500 VAC

Class:

Semiconductor Class

Bussmann FWH-500A Semiconductor Class 500A 500VAC/DC North American Fuse

SKU:

E30-6510

TS PIK:

110614600

Series:

FWH

Characteristics:

High Speed

Short Description:

2" x 4.34", 500 VAC/VDC, 500 A, 200/50 kA Interrupt Rating, Blade Terminal, High Speed, Bolted Tag, North American Fuse

Approval:

UL, CSA, CE

Type:

Round

Current Rating:

500 A

Voltage Rating:

500 VAC/DC

Interrupting Rating:

200 kA (Symmetrical), 50 kA at 500 VDC

Data Sheet:

Eaton-Bussmann_00618_1_DATA.pdf

Catalog:

Eaton-Bussmann_00349_4_8_CAT.pdf

Terminal Type:

Blade

Diameter:

2

Length:

4.34

Country of Origin:

Mexico

Class:

Semiconductor Class

Bussmann FWH-90A 90A 500VAC/DC North American Fuse

SKU:

F16-19195

TS PIK:

124937964

Interrupting Rating:

200 kA (Symmetrical), 50 kA at 500 VDC

Short Description:

0.95" x 3.62", 500 VAC/VDC, 90 A, 200/50 kA Interrupt Rating, Blade Terminal, High Speed, Bolted Tag, North American Fuse

Voltage Rating:

500 VAC/DC

Current Rating:

90 A

Diameter:

0.947

Type:

Round

Characteristics:

High Speed

Approval:

UL, CSA, CE

Series:

FWH

Length:

3.625

Terminal Type:

Blade

Country of Origin:

MEX

Bussmann FWH300 Semiconductor Class 300A 500VAC

SKU:

E30-11109

Country of Origin:

Mexico

Short Description:

high-speed semiconductor fuse with a 300 amp rating and a voltage rating of 500V AC/DC

Voltage Rating:

500 VAC

Class:

Semiconductor Class

Current Rating:

300 A

Bussmann FWP-32A14FA Class aR 32A 700VAC

SKU:

F16-6549

Country of Origin:

Mexico

Short Description:

32 A 700 VAC Class aR Fuse

Voltage Rating:

700 VAC

Class:

Class aR

Current Rating:

32 A

Bussmann FWX-5A14F 5A 250VAC/DC (UL) Cylindrical Fuse

SKU:

F16-19189

TS PIK:

92

Country of Origin:

MEX

Current Rating:

5 A

Series:

FWX

Catalog:

Eaton-Bussmann_00941_4_23_CAT.pdf

Approval:

UL, CE, CSA 1422-30

Characteristics:

High Speed

Length:

2

Short Description:

14 MM x 51 MM, 250 VAC/VDC, 5 A, 200 kA Symmetrical/50 kA DC Interrupt, Ferrule Terminal, Class AR, High Speed, Cylindrical Fuse

Voltage Rating:

250 VAC/DC (UL)

Interrupting Rating:

200 kA (Symmetrical), 50 kA (DC)

Terminal Type:

Ferrule

Data Sheet:

Eaton-Bussmann_00671_1-4_DATA.pdf

Diameter:

0.563

Bussmann GLR-1 Miniature Cartridge Fuse 1A 300VAC In-Line Fuse

SKU:

F16-2997

TS PIK:

110617121

Diameter:

0.63

Interrupting Rating:

10 kA

Current Rating:

1 A

Characteristics:

Fast Acting

Voltage Rating:

300 VAC

Short Description:

0.63" x 2.25", 300 VAC, 1 A, 10 kA Interrupt Rating, HLR Holder, Fast Acting, Non-Rejecting, Supplemental, In-Line Fuse

Catalog:

Eaton-Bussmann_00349_2_11_CAT.pdf

Length:

2.25

Series:

GLR

Data Sheet:

Eaton-Bussmann_00310_1_2_DATA.pdf

Country of Origin:

Mexico

Approval:

UL, CSA C22.2, CE

Fuse Holder Type:

HLR

Class:

Miniature Cartridge Fuse

Bussmann GLR-3 Fuse Accessories 5BOX

SKU:

F16-2999

TS PIK:

128108

Short Description:

0.63" x 2.25", 300 VAC, 3 A, 10 kA Interrupt Rating, HLR Holder, Fast Acting, Non-Rejecting, Supplemental, In-Line Fuse

Catalog:

Eaton-Bussmann_00349_2_11_CAT.pdf

Current Rating:

3 A

Series:

GLR

Data Sheet:

Eaton-Bussmann_00310_1_2_DATA.pdf

Interrupting Rating:

10 kA

Length:

2.25

Diameter:

0.63

Voltage Rating:

300 VAC

Characteristics:

Fast Acting

Country of Origin:

Mexico

Fuse Holder Type:

HLR

Approval:

UL, CSA C22.2, CE

Class:

Miniature Glass Fuse

Bussmann GMA-15-R 15A 125VAC Electronic Fuse

SKU:

F16-19197

TS PIK:

121479544

Series:

GMA

Characteristics:

Fast Acting

Voltage Rating:

125 VAC

Terminal Type:

Ferrule

Interrupting Rating:

150 A at 125 VAC

Short Description:

5 MM x 20 MM, 125 VAC, 15 A, 150 A Interrupt Rating, Ferrule Terminal, Fast Acting, Glass Tube, Electronic Fuse

Diameter:

5 Millimeter

Approval:

UL 248-14, CSA, CE, PSE

Type:

Glass Tube

Length:

20 Millimeter

Current Rating:

15 A

Catalog:

Eaton-Bussmann_00350_39_42_CAT.pdf

Data Sheet:

Eaton-Bussmann_00034_1_2_DATA.pdf

Country of Origin:

MEX

Bussmann GMA-3A Fuses Fast Acting 3A 250V 5BOX

SKU:

F16-1207

UOM:

BOX

Volts:

250 V

Amps:

0.125 A

Type:

Fast Acting

Box Quantity:

5

Short Description:

5 MM x 20 MM, 250 VAC, 3 A, 10 kA Interrupt Rating, Ferrule Terminal, Fast Acting, Glass Tube, Electronic Fuse (5 per Pack)

Current Rating:

3 A

Terminal Type:

Ferrule

Characteristics:

Fast Acting

Series:

GMA

Interrupting Rating:

100 A at 250 VAC

Voltage Rating:

250 VAC, 32 VDC

Length:

20 Millimeter

Diameter:

5 Millimeter

Country of Origin:

China

Approval:

UL 248-14, CSA, CE, PSE

Class:

Miniature Glass Fuse

Bussmann GMA-4-R Small Dimension Fuses

SKU:

F16-5906

TS PIK:

121479566

Series:

GMA

Voltage Rating:

125 VAC

Terminal Type:

Ferrule

Short Description:

5 MM x 20 MM, 125 VAC, 4 A, 10 kA Interrupt Rating, Ferrule Terminal, Fast Acting, Glass Tube, Electronic Fuse (5 per Pack)

Characteristics:

Fast Acting

Current Rating:

4 A

Data Sheet:

Eaton-Bussmann_00034_1_2_DATA.pdf

Length:

20 Millimeter

Type:

Glass Tube

Interrupting Rating:

10000 A at 125 VAC

Diameter:

5 Millimeter

Catalog:

Eaton-Bussmann_00350_39_42_CAT.pdf

Approval:

UL 248-14, CSA, CE, PSE

Country of Origin:

Mexico

Class:

Miniature Glass Fuse

Bussmann GMA250R Miniature Glass Fuse 250VAC

SKU:

F16-7198

Country of Origin:

Mexico

Voltage Rating:

250 VAC

Class:

Miniature Glass Fuse

Short Description:

GMA250R - 250MA 250V Fa 5X20MM Glass Fuse

Bussmann GMC-10-R Small Dimension Fuses

SKU:

F16-5914

TS PIK:

121479272

Type:

Glass Tube

Short Description:

5 MM x 20 MM, 125 VAC, 10 A, 200 A Interrupt Rating, Ferrule Terminal, Fast Acting, Medium Time Delay, Glass Tube, Electronic Fuse (5 per Pack)

Series:

GMC

Terminal Type:

Ferrule

Diameter:

5 Millimeter

Catalog:

Eaton-Bussmann_00349_3_6_CAT.pdf

Interrupting Rating:

200 A at 125 VAC

Length:

20 Millimeter

Current Rating:

10 A

Characteristics:

Medium Time Delay

Data Sheet:

Eaton-Bussmann_00695_1_2_DATA.pdf

Voltage Rating:

125 VAC

Approval:

UL 248-14, CSA, MITI, CE, KC

Country of Origin:

Mexico

Class:

Miniature Glass Fuse

Bussmann GMC-100-R Small Dimension Fuses

SKU:

F16-5915

TS PIK:

121479274

Current Rating:

100 MilliA

Series:

GMC

Short Description:

5 MM x 20 MM, 250 VAC, 100 mA, 35 A at 250 VAC, 10000 A at 125 VAC, Ferrule Terminal, Medium Time Delay, Glass Tube, Electronic Fuse

Type:

Glass Tube

Diameter:

5 Millimeter

Voltage Rating:

250 VAC

Terminal Type:

Ferrule

Characteristics:

Medium Time Delay

Data Sheet:

Eaton-Bussmann_00912_1_2_DATA.pdf

Catalog:

Eaton-Bussmann_00831_3_6_8_3_CAT.pdf

Interrupting Rating:

35 A at 250 VAC, 10000 A at 125 VAC

Length:

20 Millimeter

Approval:

UL 248-14, CSA, MITI, CE, KC

Country of Origin:

Mexico

Class:

Miniature Glass Fuse

Bussmann GMT-1/2A Telecom Fuse 1/2A 120VAC, 60VDC Telecommunication Fuse

SKU:

F16-6951

TS PIK:

119102172

Series:

GMT

Current Rating:

1/2 A

Characteristics:

Fast Acting, Indicating

Length:

0.78

Interrupting Rating:

450 A at 60 VDC, 300 A at 125 VAC

Approval:

UL, CE

Short Description:

0.78" L, 120 VAC, 60 VDC, 1/2 A, Red, Tin Plated Beryllium Copper Terminal, Thermoplastic Body, Fast Acting, Non-Indicating, Telecommunication Fuse

Voltage Rating:

120 VAC, 60 VDC

Data Sheet:

Eaton-Bussmann_00913_1_2_DATA.pdf

Country of Origin:

Mexico

Class:

Telecom Fuse

Bussmann GMT-1/4A Telecommunication Fuse 1/4A 120VAC, 60VDC Telecommunication Fuse

SKU:

F16-6937

TS PIK:

115652869

Series:

GMT

Characteristics:

Fast Acting, Indicating

Length:

0.78

Short Description:

0.78" L, 125 VAC, 60 VDC, 1/4 A, Violet, Tin Plated Beryllium Copper Terminal, Thermoplastic Body, Fast Acting, Non-Indicating, Telecommunication Fuse

Data Sheet:

Eaton-Bussmann_00913_1_2_DATA.pdf

Current Rating:

1/4 A

Interrupting Rating:

450 A at 60 VDC, 300 A at 125 VAC

Approval:

UL, CE

Voltage Rating:

120 VAC, 60 VDC

Country of Origin:

Mexico

Class:

Telecommunication Fuse

Type:

Telecommunication Fuse

Bussmann GMT-5A Telecom Fuse 5A 125VAC, 60VDC Telecommunication Fuse

SKU:

F16-19060

TS PIK:

115652879

Country of Origin:

Mexico

Series:

GMT

Voltage Rating:

125 VAC, 60 VDC

Length:

0.688

Short Description:

0.78" L, 125 VAC, 60 VDC, 5 A, 450/300 A Interrupt Rating, Green, Fast Acting, Indicating, Telecommunication Fuse

Characteristics:

Fast Acting, Indicating

Data Sheet:

Eaton-Bussmann_00697_1_2_DATA.pdf

Approval:

UL, CE

Diameter:

0.118

Current Rating:

5 A

Catalog:

Eaton-Bussmann_00349_14_11_CAT.pdf

Interrupting Rating:

300 A at 125 VAC, 450 A at 60 VDC

Class:

Telecom Fuse

Bussmann HAC-R-15 Class R 15A 250VAC

SKU:

F16-5014

Country of Origin:

Mexico

Voltage Rating:

250 VAC

Short Description:

amp rating of 15 A, a voltage rating of 250 Vac,

Class:

Class R

Current Rating:

15 A

Bussmann HAC-R-60 Fuses

SKU:

F16-5017

Current Rating:

60 A

Country of Origin:

Mexico

Class:

Class H

Bussmann JJN-110 Fuses Class T

SKU:

F16-1945

Approval:

UL

Characteristics:

Fast Acting

Amps:

110 A

Diameter:

0.88

Interrupting Rating:

200 kA

Length:

2.44

Terminal Type:

Blade

Type:

Class T

Volts:

300 VAC

Short Description:

0.88" x 2.44", 300 VAC, 160 VDC, 110 A, 200/20 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (1 per Carton)

Series:

JJN

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00350_36_CAT.pdf

Current Rating:

110 A

Voltage Rating:

300 VAC, 160 VDC

Country of Origin:

Mexico

Bussmann JJN-150 Fuse Accessories

SKU:

F16-3048

Catalog:

Eaton-Bussmann_00350_36_CAT.pdf

Length:

2.44

Diameter:

0.88

Approval:

UL, CSA C22.2, CE

Short Description:

0.88" x 2.44", 300 VAC, 160 VDC, 150 A, 200/20 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (1 per Carton)

Series:

JJN

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Terminal Type:

Bolted Blade

Voltage Rating:

300 VAC, 160 VDC

Characteristics:

Fast Acting

Type:

Class T

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Current Rating:

150 A

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN-20 Class T 20A 300VAC, 160VDC Fast Acting Fuse

SKU:

F16-5934

TS PIK:

110616190

Current Rating:

20 A

Type:

Class T

Voltage Rating:

300 VAC, 160 VDC

Approval:

UL, CSA C22.2, CE

Series:

JJN

Interrupting Rating:

200 kA (Symmetrical), 20 kA (DC)

Diameter:

0.41

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Length:

0.88

Characteristics:

Fast Acting

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Short Description:

0.41" x 0.88", 300 VAC, 160 VDC, 20 A, 200/20 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN-40 Fuses EA

SKU:

F16-2847

Series:

JJN

Type:

Class T

Approval:

UL

Volts:

300 VAC

Amps:

32 A

Interrupting Rating:

200 kA

Terminal Type:

Blade

Length:

0.88

Diameter:

0.56

Characteristics:

Fast Acting

Short Description:

0.56" x 0.88", 300 VAC, 160 VDC, 40 A, 200/20 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Current Rating:

40 A

Voltage Rating:

300 VAC, 160 VDC

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN-6 Class T 6A 300VAC Fast Acting Fuse

SKU:

F16-5944

TS PIK:

110616176

Interrupting Rating:

200 kA (Symmetrical)

Series:

JJN

Characteristics:

Fast Acting

Type:

Class T

Diameter:

0.41

Length:

0.88

Terminal Type:

Ferrule

Short Description:

0.41" x 0.88", 300 VAC, 6 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Approval:

UL, CSA C22.2, CE

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Current Rating:

6 A

Voltage Rating:

300 VAC

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN-700 Class T 700A 300VAC, 170VDC Fast Acting Fuse

SKU:

F16-5946

TS PIK:

110616194

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Approval:

UL, CSA C22.2, CE

Short Description:

1.75" x 3.38", 300 VAC, 170 VDC, 700 A, 200/100 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (5 per Carton)

Current Rating:

700 A

Type:

Class T

Characteristics:

Fast Acting

Terminal Type:

Bolted Blade

Length:

3.38

Data Sheet:

Eaton-Bussmann_00313_1-4_DATA.pdf

Series:

JJN

Interrupting Rating:

200 kA (Symmetrical), 100 kA (DC)

Voltage Rating:

300 VAC, 170 VDC

Diameter:

1.75

Class:

Class T

Bussmann JJN10 Class T 10A 300VAC

SKU:

F16-5062

TS PIK:

110616180

Country of Origin:

Mexico

Short Description:

Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 10 A, Class T, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 300 V, Standard, 10, 300 V

Class:

Class T

Current Rating:

10 A

Voltage Rating:

300 VAC

Bussmann JJN20 Class T 20A 300VAC

SKU:

F16-5066

TS PIK:

110616190

Country of Origin:

Mexico

Voltage Rating:

300 VAC

Current Rating:

20 A

Class:

Class T

Short Description:

Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 20 A, Class T, Non-indicating, Ferrule end x ferrule end, 20 kAIC at 160 Vdc, 200 kAIC at 300 V, Standard, 10, 300 V, 160 Vdc

Bussmann JJN25 Class T 25A 300VAC

SKU:

F16-5065

TS PIK:

110616195

Country of Origin:

Mexico

Current Rating:

25 A

Class:

Class T

Short Description:

Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 25 A, Class T, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 300 V, 20 kAIC at 160 Vdc, Standard, 10, 300 V, 160 Vdc

Voltage Rating:

300 VAC

Bussmann JJN3 Class T 3A 300VAC

SKU:

F16-5063

Current Rating:

3 A

TS PIK:

110616177

Country of Origin:

Mexico

Voltage Rating:

300 VAC

Class:

Class T

Short Description:

Eaton Bussmann series JJN fuse, Current-limiting, Large apartment complexes, Multi-family meter stacks, VFD line protection, 3 A, Class T, Non-indicating, 200 kAIC at 300 Vac, Standard, 10, 300 V

Bussmann JJN350 Fuses

SKU:

F16-5074

Current Rating:

350 A

TS PIK:

110616183

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN500 Fuses

SKU:

F16-5073

Current Rating:

500 A

TS PIK:

110616201

Country of Origin:

Mexico

Class:

Class T

Bussmann JJN70 Class T 70A 300VAC

SKU:

F16-5068

TS PIK:

110616202

Country of Origin:

Mexico

Current Rating:

70 A

Short Description:

Eaton Bussmann series JJN fuse, Current-limiting, VFD line protection, 70 A, Class T, Non-indicating, Bolted blade end x bolted blade end, 20 kAIC at 160 Vdc, 200 kAIC at 300 V, Standard, 5, 300 V, 160 Vdc

Class:

Class T

Voltage Rating:

300 VAC

Bussmann JJS-100 Fuse Accessories 600V

SKU:

F16-3131

TS PIK:

110616207

Type:

Class T

Current Rating:

100 A

Series:

JJS

Interrupting Rating:

200 kA (Symmetrical)

Short Description:

0.75" x 2.95", 600 VAC, 100 A, 200 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (5 per Carton)

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Terminal Type:

Bolted Blade

Characteristics:

Fast Acting

Voltage Rating:

600 VAC

Length:

2.95

Diameter:

0.75

Approval:

UL, CSA C22.2, CE

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS-15 Fuses

SKU:

F16-2708

TS PIK:

110616220

Country of Origin:

Mexico

Series:

JJS

Short Description:

0.56" x 1.5", 600 VAC, 15 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Terminal Type:

Ferrule

Type:

Class T

Characteristics:

Fast Acting, Non-Indicating, Current Limiting

Diameter:

0.56

Current Rating:

15 A

Interrupting Rating:

200 kA (Symmetrical)

Approval:

UL, CSA C22.2, CE

Length:

1.5

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Voltage Rating:

600 VAC

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Class:

Class T

Bussmann JJS-2 Class T 2A 600VAC Fast Acting Fuse

SKU:

F16-5952

TS PIK:

110616219

Type:

Class T

Approval:

UL, CSA C22.2, CE

Characteristics:

Fast Acting

Voltage Rating:

600 VAC

Length:

1.5

Series:

JJS

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Short Description:

0.56" x 1.5", 600 VAC, 2 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Diameter:

0.56

Current Rating:

2 A

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Interrupting Rating:

200 kA (Symmetrical)

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS-25 Class T 25A 600VAC Fast Acting Fuse

SKU:

F16-5954

TS PIK:

110616227

Current Rating:

25 A

Series:

JJS

Short Description:

0.56" x 1.5", 600 VAC, 25 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Voltage Rating:

600 VAC

Diameter:

0.56

Type:

Class T

Terminal Type:

Ferrule

Interrupting Rating:

200 kA (Symmetrical)

Characteristics:

Fast Acting, Current Limiting, Non-Indicating

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Length:

1.5

Approval:

UL 248, CSA C22.2, CE

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS-30 Fuses EA

SKU:

F16-2738

Approval:

UL 248-15

Approval:

CSA C22.2

Approval:

CE

Characteristics:

Fast Acting

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Amps:

30 A

Diameter:

0.56

Interrupting Rating:

200 kA (AC)

Length:

1.5

Terminal Type:

Ferrule

Type:

Class T

Volts:

600 VAC

Short Description:

0.56" x 1.5", 600 VAC, 30 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Series:

JJS

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Current Rating:

30 A

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Voltage Rating:

600 VAC

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS-40 Fuses EA

SKU:

F16-2717

Approval:

UL 248-15

Approval:

CSA C22.2

Approval:

CE

Characteristics:

Fast Acting

Characteristics:

Current Limiting

Characteristics:

Non-Indicating

Amps:

40 A

Diameter:

0.81

Interrupting Rating:

200 kA (AC)

Length:

1.56

Terminal Type:

Ferrule

Type:

Class T

Volts:

600 VAC

Short Description:

0.81" x 1.56", 600 VAC, 40 A, 200 kA Interrupt Rating, Ferrule Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (10 per Carton)

Series:

JJS

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Current Rating:

40 A

Voltage Rating:

600 VAC

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS-400 Fuses EA

SKU:

F16-2104

Approval:

UL

Approval:

CSA C22.2

Approval:

CE

Characteristics:

Fast Acting

Amps:

400 A

Diameter:

1

Interrupting Rating:

200 kA (Symmetrical)

Length:

3.63

Terminal Type:

Bolted Blade

Type:

Class T

Volts:

600 VAC

Short Description:

1" x 3.63", 600 VAC, 400 A, 200 kA Interrupt Rating, Bolted Blade Terminal, Class T, Current Limiting, Non-Indicating, Very Fast Acting Fuse (1 per Carton)

Series:

JJS

Data Sheet:

Eaton-Bussmann_00116_1-4_DATA.pdf

Catalog:

Eaton-Bussmann_00349_1_31_CAT.pdf

Current Rating:

400 A

Voltage Rating:

600 VAC

Country of Origin:

Mexico

Class:

Class T

Bussmann JJS10 Class T 10A 600VAC

SKU:

E30-6639

TS PIK:

110616215

Country of Origin:

Mexico

Current Rating:

10 A

Voltage Rating:

600 VAC

Short Description:

Eaton Bussmann series JJS fuse, Current-limiting, Small footprint, VFD line protection, 10 A, Class T, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 600 V, Standard, 10, 600 V

Class:

Class T

Bussmann JJS25 Class T 25A 600VAC

SKU:

F16-5077

Current Rating:

25 A

TS PIK:

110616227

Country of Origin:

Mexico

Short Description:

Eaton Bussmann series JJS fuse, Current-limiting, Small footprint, VFD line protection, 25 A, Class T, Non-indicating, Ferrule end x ferrule end, 200 kAIC at 600 V, Standard, 10, 600 V

Voltage Rating:

600 VAC

Class:

Class T

Bussmann JJS30 Class T 30A 600V
